Lexus LS (2022 year). Manual in english

1-2. Child safety

■

ISOFIX lower anchorages
(ISOFIX child restraint system)

Lower anchorages are provided for the
outboard rear seats. (Tags displaying
the location of the anchorages are
attached to the seats.)

■

Installation with ISOFIX lower
anchorage (ISOFIX child restraint
system)

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.
If the child restraint system on hand is
not within the “universal” category (or
the necessary information is not in the
table), refer to the “Vehicle List” pro-
vided by the child restraint system
maker for various possible installation
positions, or check the compatibility
after asking the retailer of the child
seat. (



P.49, 50)

Vehicles with power rear seat:
Adjust the seat

If there is a gap between the child seat and

the seatback, adjust the seatback angle

until good contact is achieved. (



P.46)

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not allow children to play with the

seat belt. If the seat belt becomes

twisted around a child’s neck, it may

lead to choking or other serious inju-

ries that could result in death. If this

occurs and the buckle cannot be

unfastened, scissors should be used to

cut the belt.

●

Ensure that the belt and plate are

securely locked and the seat belt is not

twisted.

●

Shake the child restraint system left

and right, and forward and backward

to ensure that it has been securely

installed.

●

After securing a child restraint system,

never adjust the seat.

●

When a junior seat is installed, always

ensure that the shoulder belt is posi-

tioned across the center of the child’s

shoulder. The belt should be kept away

from the child’s neck, but not so that it

could fall off the child’s shoulder.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

Child restraint system fixed with
an ISOFIX lower anchorage

1-2. Child safety

For safety and security

Open the cover.

Insert the tab into the slit of
the cover.

The cover will be held open.

Check the positions of the exclu-
sive fixing bars, and install the child
restraint system to the seat.

The bars are installed in the clearance

between the seat cushion and seatback.

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.56)

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

After securing a child restraint system,

never adjust the seat.

●

When using the lower anchorages, be

sure that there are no foreign objects

around the anchorages and that the

seat belt is not caught behind the child

restraint system.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

1-2. Child safety

■

Top tether anchorages

Top tether anchorages are provided
for the outboard rear seats.
Use top tether anchorages when fixing
the top strap.

Top tether anchorages
Top strap

■

Fixing the top strap to the top
tether anchorages

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.
Open the top tether anchorages cover,
latch the hook onto the top tether
anchorage and tighten the top strap.

Make sure the top strap is securely latched.
(



P.56)

Hook
Top strap

Using a top tether anchorage

A
B

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Firmly attach the top strap and make

sure that the belt is not twisted.

●

Do not attach the top strap to anything

other than the top tether anchorages.

●

After securing a child restraint system,

never adjust the seat.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

NOTICE

■

Top tether anchorages

When not in use, make certain to close

the lid. If it remains open, the lid may be

damaged.

A
B

1-3. Emergency assistance

For safety and security

1-3.Emergency assistance

: If equipped

: Operates within regions offering emer-

gency notification services. Ask any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer for details.

: The system name differs depending on

the country.

Microphone

“SOS” button

Indicator lights

: This button is intended for communica-

tion with the ERA-GLONASS/EVAK
system operator.
Other SOS buttons available in other
systems of a motor vehicle do not relate
to the device and are not intended for
communication with the
ERA-GLONASS/EVAK system opera-
tor.

■

Automatic Emergency Calls

If any airbag deploys, the system is
designed to automatically call the
ERA-GLONASS/EVAK control
center.

The answering operator

receives the vehicle’s location, the time
of the incident and the vehicle VIN,
and attempts to speak with the vehicle

ERA-GLONASS/EVAK

*1, 2, 3

The Emergency Call system is a
device installed on a vehicle to
determine its location and move-
ment direction (using GLONASS
[Global Navigation Satellite Sys-
tem] and GPS [Global Positioning
System] signals), and ensure the
generation and transmission of
vehicle information (in a nonadjust-
able form) in case of traffic acci-
dents or other incidents on motor
roads in the countries offering
emergency notification services. In
addition, it ensures two-way voice
communication between the vehi-
cle and an ERA-GLONASS/EVAK
system operator through cellular
networks (GSM).

Automatic Emergency Calls (via
Automatic Collision Notification)
and manual Emergency Calls (by
pressing the “SOS” button) can be
made to the
ERA-GLONASS/EVAK control
center.

This service is mandatory accord-
ing to the technical regulations of
the Customs Union.

System components

Emergency Notification Ser-
vices

A
B
C

1-3. Emergency assistance

occupants to assess the situation. If the
occupants are unable to communicate,
the operator automatically treats the
call as an emergency and contacts the
nearest emergency services provider
(112 system etc.) to describe the situa-
tion and request that assistance be sent
to the location.

: In some cases, the call cannot be made.

(



P.61)

■

Manual Emergency Calls

In the event of an emergency, press the
“SOS” button to call the
ERA-GLONASS/EVAK control
center.

The answering operator will

determine your vehicle’s location,
assess the situation, and dispatch the
necessary assistance required.

If you accidentally press the “SOS” button,
tell the operator that you are not experi-
encing an emergency.

: In some cases, the call cannot be made.

(



P.61)

When the engine switch is turned to
IGNITION ON mode, the red indica-
tor light will illuminate for 10 seconds
and then the green indicator light will
illuminate, indicating that the system is
enabled. The indicator lights indicate
the following:



If the green indicator light illumi-
nates and stays on, the system is
enabled.



If the green indicator light flashes
twice per second, an automatic or

manual Emergency Call is being
made.



If no indicator lights illuminate, the
system is not enabled.



If the red indicator light illuminates
at any time other than immediately
after the engine switch is turned to
IGNITION ON mode, the system
may be malfunctioning or the
backup battery may be depleted.
The backup battery has lifespan of
at least 3 years. Contact any author-
ized Lexus retailer or Lexus author-
ized repairer, or any reliable
repairer.



If the red indicator light blinks for
approximately 30 seconds during
an Emergency Call, the call has
been disconnected or the cellular
network signal is weak.

A test mode is provided for to check
the performance of the Emergency
Call system. To test the device, contact
any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

■

Free/Open Source Software Informa-

tion

This product contains Free/Open Source

Software (FOSS). The license information

and/or the source code of such FOSS can

be found at the following URL.
http://www.opensourceautomotive.com/

dcm/lexus/

Indicator lights

Device test mode

1-3. Emergency assistance

For safety and security

WARNING

■

When the Emergency Call may not

be made

●

It may not be possible to make Emer-

gency Calls in any of the following situ-

ations. In such cases, report to

emergency services provider (112 sys-

tem etc.) by other means such as

nearby public phones.

• Even when the vehicle is in the cellular

phone service area, it may be difficult

to connect to the

ERA-GLONASS/EVAK control

center if the reception is poor or the

line is busy. In such cases, even though

the system attempts to connect to the

ERA-GLONASS/EVAK control

center, you may not be able to connect

to the ERA-GLONASS/EVAK con-

trol center to make Emergency Calls

and contact emergency services.

• When the vehicle is out of the cellular

phone service area, the Emergency

Calls cannot be made.

• When any related equipment (such as

the “SOS” button panel, indicator

lights, microphone, speaker, DCM,

antenna, or any wires connecting the

equipment) is malfunctioning, dam-

aged or broken, the Emergency Call

cannot be made.

• During an Emergency Call, the system

makes repeated attempts to connect

to the ERA-GLONASS/EVAK con-

trol center. However, if it cannot con-

nect to the ERA-GLONASS/EVAK

control center due to poor radio wave

reception, the system may not be able

to connect to the cellular network and

the call may finish without connecting.

The red indicator light will blink for

approximately 30 seconds to indicate

this disconnection.

• This device may not function if a shock

is applied to it.

●

If the battery’s voltage decreases or

there is a disconnection, the system

may not be able to connect to the

ERA-GLONASS/EVAK control

center.

■

When the Emergency Call system is

replaced with a new one

The Emergency Call system should be

registered. Contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

■

For your safety

●

Please drive safely.

The function of this system is to assist

you in making the Emergency Call in

case of accidents such as traffic acci-

dents or sudden medical emergencies,

and it does not protect the driver or

passengers in any way. Please drive

safely and fasten your seatbelts at all

times for your safety.

●

In case of an emergency, make lives

the top priority.

●

If you smell anything burning or other

unusual smells, leave the vehicle and

evacuate to a safe area immediately.

●

Since the system detects shocks, the

automatic reporting may not always

occur synchronized with the operation

of the airbag system. (If the vehicle is

struck from behind, etc.)

●

For safety, do not make the Emergency

Call while driving.

Making calls during driving may cause

mishandling of the steering wheel,

which may lead to unexpected acci-

dents.

Stop the vehicle and confirm the safety

of your surroundings before making

the Emergency Call.

●

When changing fuses, please use the

specified fuses. Using other fuses may

cause ignition or smoke in the circuit

and lead to a fire.

1-3. Emergency assistance

WARNING

●

Using the system while there is smoke

or an unusual smell may cause a fire.

Stop using the system immediately and

consult any authorized Lexus retailer

or Lexus authorized repairer, or any

reliable repairer.

NOTICE

■

To prevent damage

Do not pour any liquids onto the “SOS”

button panel, etc. and do not impact it.

■

If the “SOS” button panel, speaker or

microphone malfunctions during an

Emergency Call or manual mainte-

nance check

It may not be possible to make Emer-

gency Calls, confirm the system status, or

communicate with the

ERA-GLONASS/EVAK control center

operator. If any of the above equipment is

damaged, please consult any authorized

Lexus retailer, Lexus authorized repairer,

or any reliable repairer.

1-4. Theft deterrent system

For safety and security

1-4.Theft deterrent system

The indicator light flashes after the
engine switch has been turned off to
indicate that the system is operating.
The indicator light stops flashing after
the engine switch has been turned to
ACCESSORY or IGNITION ON
mode to indicate that the system has
been canceled.

■

System maintenance

The vehicle has a maintenance-free type

engine immobilizer system.

■

Conditions that may cause the system to

malfunction

●

If the grip portion of the key is in contact

with a metallic object

●

If the key is in close proximity to or touch-

ing a key to the security system (key with

a built-in transponder chip) of another

vehicle

Engine immobilizer system

The vehicle’s keys have built-in
transponder chips that prevent the
engine from starting if a key has not
been previously registered in the
vehicle’s on-board computer.

Never leave the keys inside the
vehicle when you leave the vehicle.

This system is designed to help pre-
vent vehicle theft but does not
guarantee absolute security
against all vehicle thefts.

Operating the system

NOTICE

■

To ensure the system operates cor-

rectly

Do not modify or remove the system. If

modified or removed, the proper opera-

tion of the system cannot be guaranteed.

1-4. Theft deterrent system

■

Setting

Turn the engine switch off, have all the
passengers exit the vehicle and ensure
that all the doors are closed.
Using the entry function: Touch the
sensor area on the outside door handle
twice within 5 seconds.
Using the wireless remote control:
Press

twice within 5 seconds.

■

Canceling

Using the entry function: Hold the out-
side door handle, press the power
trunk lid switch or move your foot
under the center of the rear bumper
(vehicles with a Hands Free Power

Trunk Lid).
Using the wireless remote control:
Press .

Double locking system

Unauthorized access to the vehicle
is prevented by disabling the door
unlocking function from both the
interior and exterior of the vehicle.

Vehicles employing this system
have labels on the window glass of
both front doors.

Setting/canceling the double
locking system

WARNING

■

Double locking system precaution

Never activate the double locking sys-

tem when there are people in the vehicle

because all the doors cannot be opened

from inside the vehicle.

1-4. Theft deterrent system

For safety and security

■

Items to check before locking the
vehicle

To prevent unexpected triggering of
the alarm and vehicle theft, make sure
of the following:



Nobody is in the vehicle.



The windows and moon roof are
closed before the alarm is set.



No valuables or other personal
items are left in the vehicle.

■

Setting

Close the doors, trunk and hood, and
lock all the doors using the entry func-
tion or wireless remote control. The
system will be set automatically after
30 seconds.

The indicator light changes from being on
to flashing when the system is set.

■

Deactivating or stopping

Do one of the following to deactivate
or stop the alarms:



Unlock the doors or open the trunk
using the entry function or wireless
remote control.



Starting the engine. (The alarm will
be deactivated or stopped after a
few seconds.)

■

System maintenance

The vehicle has a maintenance-free type

alarm system.

■

Triggering of the alarm

The alarm may be triggered in the following

situations:

(Stopping the alarm deactivates the alarm

system.)

●

The doors are unlocked using the

mechanical key.

Alarm

The alarm uses light and sound to
give an alert when an intrusion is
detected.
The alarm is triggered in the follow-
ing situations when the alarm is set:



A locked door or trunk is
unlocked or opened in any way
other than using the entry func-
tion or wireless remote control.
(The doors will lock again auto-
matically.)



The hood is opened.



The intrusion sensor detects
something moving inside the
vehicle. (Example: an intruder
breaks a window and gets into the
vehicle.)



The tilt sensor detects a change of
vehicle inclination.

Setting/deactivating/stopping
the alarm system

1-4. Theft deterrent system

●

The trunk is opened using the mechanical

key.

●

A person inside the vehicle opens a door,

the trunk or hood, or unlocks the vehicle.

●

The battery is recharged or replaced

when the vehicle is locked. (



P.456)

■

Alarm-operated door lock

In the following cases, depending on the sit-

uation, the door may automatically lock to

prevent improper entry into the vehicle:

●

When a person remaining in the vehicle

unlocks the door and the alarm is acti-

vated.

●

While the alarm is activated, a person

remaining in the vehicle unlocks the door.

■

The intrusion sensor and tilt sensor
detection



The intrusion sensor detects intrud-
ers or movement in the vehicle.



The tilt sensor detects changes in
vehicle inclination, such as when the
vehicle is towed away.

This system is designed to deter and
prevent vehicle theft but does not
guarantee absolute security against all
intrusions.

■

Setting the intrusion sensor and tilt
sensor

The intrusion sensor and tilt sensor will
be set automatically when the alarm is
set. (



P.65)

■

Canceling the intrusion sensor and
tilt sensor

If you are leaving pets or other moving
things inside the vehicle, make sure to
disable the intrusion sensor and tilt
sensor before setting the alarm, as they
will respond to movement inside the
vehicle.

Turn the engine switch off.

NOTICE

■

To ensure the system operates cor-

rectly

Do not modify or remove the system. If

modified or removed, the proper opera-

tion of the system cannot be guaranteed.

The intrusion sensor and tilt sen-
sor detection

1-4. Theft deterrent system

For safety and security

Press the intrusion sensor and tilt
sensor cancel switch.

Press the switch again to re-enable the

intrusion sensor and tilt sensor.
Each time the intrusion sensor and tilt sen-

sor are canceled/set, a message will be

shown on the multi-information display.

■

Canceling and automatic re-enabling of

the intrusion sensor and tilt sensor

●

The alarm will still be set even when the

intrusion sensor and tilt sensor are

canceled.

●

After the intrusion sensor and tilt sensor

are canceled, pressing the engine switch

or unlocking the doors using the entry

function or wireless remote control will

re-enable the intrusion sensor and tilt

sensor.

●

The intrusion sensor and tilt sensor will

automatically be re-enabled when the

alarm system is deactivated.

■

Intrusion sensor detection considera-

tions

The sensor may trigger the alarm in the fol-

lowing situations:

●

People or pets are in the vehicle.

●

A window or moon roof is open.

In this case, the sensor may detect the fol-
lowing:
• Wind or the movement of objects such as

leaves and insects inside the vehicle

• Ultrasonic waves emitted from devices

such as the intrusion sensors of other

vehicles

• The movement of people outside the

vehicle

●

Small insects such as moths or flies are in

the vehicle.

●

Unstable items, such as dangling acces-

sories or clothes hanging on the coat

hooks, are in the vehicle.

●

The vehicle is parked in a place where

extreme vibrations or noises occur, such

as in a parking garage.

●

Ice or snow is removed from the vehicle,

causing the vehicle to receive repeated

impacts or vibrations.

1-4. Theft deterrent system

●

The vehicle is inside an automatic or

high-pressure car wash.

●

The vehicle experiences impacts, such as

hail, lightning strikes, and other kinds of

repeated impacts or vibrations.

■

Tilt sensor detection considerations

The sensor may trigger the alarm in the fol-

lowing situations:

●

The vehicle is transported by a ferry,

trailer, train, etc.

●

The vehicle is parked in a parking garage.

●

The vehicle is inside a car wash that

moves the vehicle.

●

Any of the tires loses air pressure.

●

The vehicle is jacked up.

●

An earthquake occurs or the road caves

in.

●

Cargo is loaded onto or unloaded from

the roof luggage carrier.

NOTICE

■

To ensure the intrusion sensor func-

tion correctly

●

To ensure that the sensors operate

properly, do not touch or cover them.

●

Do not spray air fresheners or other

products directly into the sensor holes.

●

Installing accessories other than genu-

ine Lexus parts or leaving objects

between the driver’s seat and front

passenger’s seat may reduce the

detection performance.

Vehi

e s

tus

info
rm

ation a

indi
cators

Vehicle status information

and indicators

2-1. Instrument cluster

Warning lights and indicators

...........................................................

Gauges and meters (except F

SPORT models) .........................

Gauges and meters (F SPORT

models)...........................................

Multi-information display...........

Head-up display ...........................

Fuel consumption information

...........................................................

2-1. Instrument cluster

Vehi

e s

tus

info
rm

ation a

indi
cators

Warning lights inform the driver of mal-
functions in the indicated vehicle’s sys-
tems.

: These lights come on when the engine

switch is turned to IGNITION ON
mode to indicate that a system check is
being performed. They will turn off after
the engine is started, or after a few sec-
onds. There may be a malfunction in a
system if the lights do not come on, or
turn off. Have the vehicle inspected by
any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

: This light illuminates on the multi-infor-

Warning lights

(red)

Brake system warning light

(



P.435)

(yellow)

Brake system warning light

(



P.435)

High coolant temperature
warning light

(



P.435)

Charging system warning
light

(



P.436)

Low engine oil pressure warn-
ing light

(



P.436)

Malfunction indicator lamp

(



P.436)

SRS warning light

(



P.436)

Pop Up Hood warning light

(



P.437)

ABS warning light

(



P.437)

Inappropriate pedal operation
warning light

(



P.437)

(red)

Electric power steering system
warning light

(



P.438)

(yellow)

Electric power steering system
warning light

(



P.438)

Low fuel level warning light
(



P.438)

Driver’s and front passenger’s
seat belt reminder light
(



P.438)

Rear passengers’ seat
belt reminder lights
(except F SPORT mod-
els) (



P.439)

Rear passengers’ seat belt
reminder lights (F SPORT mod-
els) (



P.439)

Tire pressure warning light

(



P.439)

(orange)

LTA indicator (if equipped)
(



P.439)

(flashes)

Stop & Start cancel indicator

(



P.440)

(flashes)

RCD OFF indicator (if
equipped) (



P.440)

(flashes or

illuminates)

PCS warning light

(if

equipped) (



P.440)

Slip indicator

(



P.441)

(flashes)

Parking brake indicator
(



P.441)

(flashes)

Brake hold operated indicator

(



P.441)

Lexus LS (2022 year). Manual in english - page 3
