1-1. For safe use

●

If the vehicle speed is not detected cor-

rectly, such as if the vehicle is sliding side-

ways, the system may not operate

properly.

■

Conditions under which the Pop Up

Hood will not operate

The Pop Up Hood will not operate in the

following situations:

●

Colliding with a lying person

●

A frontal impact applied to the front

bumper while driving at speeds outside

of the operational speed range

●

A side impact or rear impact

●

A vehicle rollover (In some accident situ-

ations, the Pop Up Hood may operate.)

WARNING

■

When the Pop Up Hood is operated

●

Do not pull the hood lock release lever.

Doing so after the Pop Up Hood has

operated will further raise the hood

and may cause an injury. Do not drive

with the hood raised, as doing so may

block the driver’s vision, possibly caus-

ing an accident.

●

Do not forcibly push down the hood.

As the popped up hood cannot be

lowered by hand, doing so may deform

the hood or cause an injury.

●

If the Pop Up Hood has operated, have

it replaced by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer. If the Pop Up

Hood has operated, stop the vehicle in

a safe place and contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

●

Do not touch the lifters immediately

after the Pop Up Hood has operated,

as the lifters may be hot and burn you.

NOTICE

■

Pop Up Hood precautions

●

Make sure to close the hood before

driving, as the system may not operate

properly if the hood is not fully closed.

●

Make sure that all 4 tires are of the

specified size and inflated to the speci-

fied tire pressure. If tires of a different

size are used, the system may not

operate properly.

●

If something has hit the area around

the front bumper, the sensors may be

damaged even if the Pop Up Hood has

not operated. Have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer.

●

Do not remove or repair the parts or

wiring of the Pop Up Hood, as doing

so may cause accidental operation or

prevent the system from operating

properly. If repair or replacement is

necessary, contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

●

Do not remove such components as

the front bumper, hood or suspension,

or replace them with non-genuine

parts, as doing so may prevent the sys-

tem from operating properly.

●

Do not install anything to the front

bumper or hood, as doing so may pre-

vent the sensors from detecting an

impact correctly and prevent the sys-

tem from operating properly.

●

Do not close the hood with force or

apply load to the lifters, as doing so

may damage the lifters and prevent the

system from operating properly.

●

Do not modify the suspension, as

changes made to the vehicle height

may prevent the system from operat-

ing properly.

1-1. For safe use

For safety and security

Exhaust gas precautions

Harmful substance to the human
body is included in exhaust gases if
inhaled.

WARNING

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.

Failure to do so may cause exhaust gases

enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

■

Important points while driving

●

Keep the trunk lid closed.

●

If you smell exhaust gases in the vehi-

cle even when the trunk lid is closed,

open the windows and have the vehi-

cle inspected at any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer as soon as pos-

sible.

■

When parking

●

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the engine.

●

Do not leave the vehicle with the

engine on for a long time.

If such a situation cannot be avoided,

park the vehicle in an open space and

ensure that exhaust fumes do not enter

the vehicle interior.

●

Do not leave the engine running in an

area with snow build-up, or where it is

snowing. If snowbanks build up around

the vehicle while the engine is running,

exhaust gases may collect and enter

the vehicle.

■

Exhaust pipe

The exhaust system needs to be checked

periodically. If there is a hole or crack

caused by corrosion, damage to a joint

or abnormal exhaust noise, be sure to

have the vehicle inspected and repaired

by any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

1-2. Child safety

1-2.Child safety

“PASSENGER AIR BAG” indica-
tor

“PASSENGER AIR BAG” and “ON” indi-
cator light turns on when the airbag system
is on, and about after 60 seconds they go
off. (only when the engine switch is in
IGNITION ON mode)

Airbag manual on-off switch

Insert the mechanical key into the cyl-
inder and rotate to the “OFF” position.

The “OFF” indicator light turns on (only
when the engine switch is in IGNITION
ON mode).

■

“PASSENGER AIR BAG” indicator

information

If any of the following problems occur, it is

possible that there is a malfunction in the

system. Have the vehicle inspected by any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer.

●

The “OFF” indicator does not illuminate

when the airbag manual on-off switch is

set to “OFF”.

●

The indicator light does not change when

the airbag manual on-off switch is

switched to “ON” or “OFF”.

Airbag manual on-off system

This system deactivates the front
passenger airbag and front passen-
ger knee airbag.
Only deactivate the airbags when
using a child restraint system on the
front passenger seat.

System components

Deactivating the front seat pas-
senger airbag and front passen-
ger knee airbag

1-2. Child safety

For safety and security

WARNING

■

When installing a child restraint sys-

tem

For safety reasons, always install a child

restraint system in a rear seat. In the

event that the rear seat cannot be used,

the front seat can be used as long as the

airbag manual on-off system is set to

“OFF”.

If the airbag manual on-off system is left

on, the strong impact of the airbag

deployment (inflation) may cause serious

injury or even death.

■

When a child restraint system is not

installed on the front passenger seat

Ensure that the airbag manual on-off sys-

tem is set to “ON”.

If it is left off, the airbag may not deploy in

the event of an accident, which may

result in serious injury or even death.

Riding with children

Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.



It is recommended that children
sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch etc.



Use the rear door child-protector
lock or the window lock switch to
avoid children opening the door
while driving or operating the
power window accidentally.
(



P.106, 154)



Do not let small children operate
equipment which may catch or
pinch body parts, such as the
power window, hood, trunk, seats
etc.

WARNING

■

When children are in the vehicle

Never leave children unattended in the

vehicle, and never allow children to have

or use the key.
Children may be able to start the vehicle

or shift the vehicle into neutral. There is

also a danger that children may injure

themselves by playing with the windows,

the moon roof, or other features of the

vehicle. In addition, heat build-up or

extremely cold temperatures inside the

vehicle can be fatal to children.

1-2. Child safety

Points to remember: P.44
When using a child restraint system:
P.45
Child restraint system compatibility for
each seating position: P.49
Child restraint system installation
method: P.54
• Fixed with a seat belt: P.54
• Fixed with an ISOFIX lower anchor-

age: P.56

• Using a top tether anchorage: P.58



Prioritize and observe the warn-
ings, as well as the laws and regula-
tions for child restraint systems.



Use a child restraint system until the
child becomes large enough to
properly wear the vehicle’s seat belt.



Choose a child restraint system
appropriate to the age and size of
the child.



Note that not all child restraint sys-
tems can fit in all vehicles.
Before using or purchasing a child
restraint system, check the compati-
bility of the child restraint system
with seat positions. (



P.49)

Child restraint systems

Before installing a child restraint
system in the vehicle, there are pre-
cautions that need to be observed,
different types of child restraint sys-
tems, as well as installation meth-
ods, etc., written in this manual.



Use a child restraint system when
riding with a small child that can-
not properly use a seat belt. For
the child’s safety, install the child
restraint system to a rear seat. Be
sure to follow the installation
method that is in the operation
manual enclosed with the
restraint system.



The use of a Lexus genuine child
restraint system is recom-
mended, as it is safer to use in this
vehicle. Lexus genuine child
restraint systems are made specif-
ically for Lexus vehicles. They can
be purchased at a Lexus dealer.

Table of contents

Points to remember

WARNING

■

When a child is riding

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

For effective protection in automobile

accidents and sudden stops, a child

must be properly restrained, using a

seat belt or child restraint system

which is correctly installed. For installa-

tion details, refer to the operation man-

ual enclosed with the child restraint

system. General installation instruction

is provided in this manual.

●

Lexus strongly urges the use of a

proper child restraint system that con-

forms to the weight and size of the

child, installed on the rear seat.

According to accident statistics, the

child is safer when properly restrained

in the rear seat than in the front seat.

1-2. Child safety

For safety and security

■

When installing a child restraint
system to a front passenger seat

For the safety of a child, install child
restraint systems to a rear seats. When
installing child restraint system to a
front passenger seat is unavoidable,
adjust the seat as follows and install the
child restraint system:



Move the front seat fully rearward.



Adjust the seatback angle to the
most upright position.

When installing a forward-facing child
seat, if there is a gap between the child seat
and the seatback, adjust the seatback
angle until good contact is achieved.



Adjust the front of the seat cushion
to the lowest position.



Adjust the seat height to the upper-
most position.



Adjust the lumbar support to the
lowest position.



Adjust the shoulder bolster to the
lowest position (if equipped).



Adjust the pelvic support to the low-
est position.



Adjust the seatback side bolster to
the widest position (if equipped).



Adjust the seat cushion side bolster
to the lowest position (if equipped).



Adjust the hip support to the lowest
position (if equipped).



If the head restraint interferes with

WARNING

●

Holding a child in your or someone

else’s arms is not a substitute for a child

restraint system. In an accident, the

child can be crushed against the wind-

shield or between the holder and the

interior of the vehicle.

■

Handling the child restraint system

If the child restraint system is not prop-

erly fixed in place, the child or other pas-

sengers may be seriously injured or even

killed in the event of sudden braking, sud-

den swerving, or an accident.

●

If the vehicle were to receive a strong

impact from an accident, etc., it is pos-

sible that the child restraint system has

damage that is not readily visible. In

such cases, do not reuse the restraint

system.

●

Depending on the child restraint sys-

tem, installation may be difficult or

impossible. In those cases, check

whether the child restraint system is

suitable for installment in the vehicle.

(



P.49) Be sure to install and

observe the usage rules after carefully

reading the child restraint system fixing

method in this manual, as well as the

operation manual enclosed with the

child restraint system.

●

Keep the child restraint system prop-

erly secured on the seat even if it is not

in use. Do not store the child restraint

system unsecured in the passenger

compartment.

●

If it is necessary to detach the child

restraint system, remove it from the

vehicle or store it securely in the trunk.

When using a child restraint sys-
tem

1-2. Child safety

the child restraint system installa-
tion and the head restraint can be
removed, remove the head restraint.
Otherwise, put the head restraint in
the upper most position.

■

When installing a child restraint
system to a power rear seat (if
equipped)

When using a child restraint system in
an outer rear seat, adjust the seat as
follows and install the child restraint
system:



Adjust the seat cushion to the fully
rearward position.



Adjust the upper seatback to the
rearmost position.



Adjust the front of the seat cushion
to the lowest position.



Adjust the head restraint to the low-
est and rearmost position.



Adjust the shoulder bolster to the
lowest position.



Adjust the lumbar support to the
lowest position.



Adjust the pelvic support to the low-
est position.



Disable the automatic rear seat

operation. (



P.129)



For the rear seat with an ottoman (if
equipped): Adjust the seatback to
the most upright position and otto-
man (footrest) to the stowed posi-
tion.

WARNING

■

When using a child restraint system

Observe the following precautions.

Failure to do so may result in death or

serious injury.

1-2. Child safety

For safety and security

WARNING

●

Never use a rear-facing child restraint

system on the front passenger seat

when the airbag manual on-off switch

is on. (



P.42)

The force of the rapid inflation of the

front passenger airbag can cause

death or serious injury to children in

the event of an accident.

●

There is a label(s) on the passenger

side sun visor, indicating it is forbidden

to attach a rear-facing child restraint

system to the front passenger seat.

Details of the label(s) are shown in the

illustration below.

1-2. Child safety

WARNING

●

Only put a forward-facing child

restraint system on the front seat when

unavoidable. When installing a for-

ward-facing child restraint on the front

passenger seat, move the seat as far

back as possible. Failing to do so may

result in death or serious injury if the

airbags deploy (inflate).

●

Do not allow the child to lean his/her

head or any part of his/her body

against the door or the area of the seat,

front or rear pillars, or roof side rails

from which the SRS side airbags or

SRS curtain shield airbags deploy even

if the child is seated in the child

restraint system. It is dangerous if the

SRS side and curtain shield airbags

inflate, and the impact could cause

death or serious injury to the child.

●

When a junior seat is installed, always

ensure that the shoulder belt is posi-

tioned across the center of the child’s

shoulder. The belt should be kept away

from the child’s neck, but not so that it

could fall off the child’s shoulder.

●

Use child restraint system suitable to

the age and size of the child and install

it to the rear seat.

1-2. Child safety

For safety and security

■

Child restraint system compatibil-
ity for each seating position

Compatibility of each seating position
with child restraint systems (



P.50)

displays the type of child restraint sys-
tems that can be used and possible
seating positions for installation using
symbols. Also, the recommended child
restraint system that is suitable for your
child can be selected.
Otherwise, check [Recommended
child restraint systems and Compatibil-
ity table] for recommended child
restraint systems. (



P.52)

Check the selected child restraint sys-
tem together with the following
[Before confirming the compatibility of
each seating position with child
restraint systems].

■

Before confirming the compatibil-
ity of each seating position with
child restraint systems

Checking the child restraint system
standards.
Use a child restraint system that
conforms to UN(ECE) R44

UN(ECE) R129

*1, 2

The following approval mark is dis-
played on child restraint systems
which are conformed.
Check for an approval mark
attached to the child restraint sys-
tem.

Example of the displayed regulation Num-
ber

UN(ECE) R44 approval mark

The weight range of the child who is
applicable for an UN(ECE) R44
approval mark is indicated.

UN(ECE) R129 approval mark

The height range of the child who is
applicable as well as available
weights for an UN(ECE) R129
approval mark is indicated.

WARNING

●

If the driver’s seat interferes with the

child restraint system and prevents it

from being attached correctly, attach

the child restraint system to the

right-hand rear seat. (



P.52)

Child restraint system compati-
bility for each seating position

1-2. Child safety

Checking the category of the child
restraint system.
Check the approval mark of the
child restraint system for which of
the following categories the child
restraint system is suitable.
Also, if there are any uncertainties,
check the user’s guide included
with the child restraint system or
contact the retailer of the child
restraint system.

• “universal”
• “semi-universal”
• “restricted”
• “vehicle specific”

: UN(ECE) R44 and UN(ECE) R129

are U.N. regulations for child restraint
systems.

: The child restraint systems mentioned in

the table may not be available outside of
the EU area.

: The displayed mark may differ depend-

ing on the product.

■

Compatibility of each seating posi-
tion with child restraint systems

*1, 2, 3

*2, 3

Suitable for “universal” category
child restraint system fixed with
the seat belt.
Suitable for child restraint systems
given on recommended child
restraint systems and compatibility
table (



P.52)

Suitable for i-Size and ISOFIX
child restraint system.

Includes a top tether anchorage
point.

1-2. Child safety

For safety and security

: Move the front seat fully rearward. If the

passenger seat height can be adjusted,
move it to the upper most position.

: Adjust the seatback angle to the most

upright position. When installing a for-
ward-facing child seat, if there is a gap
between the child seat and the
seatback, adjust the seatback angle
until good contact is achieved.

: If the head restraint interferes with your

child restraint system, and the head
restraint can be removed, remove the
head restraint.
Otherwise, put the head restraint in the
upper most position.

: Use only a front-facing child restraint

system when the airbag manual on-off
switch is on.

■

Detail information for CRS installation

Not suitable for child restraint sys-
tem.
Never use a rear-facing child
restraint system on the front pas-
senger seat when the airbag man-
ual on-off switch is on.

Seating position

Seat position number

Airbag manual on-off

switch

OFF

Seating position suitable for uni-

versal belted (yes/no)

yes

Forward

facing only

yes

i-Size seating position (yes/no)

yes

Seating position suitable for lateral

fixture (L1/L2/no)

Suitable rearward facing fixture

(R1/R2X/R2/R3/no)

R1, R2X, R2,

Suitable forward facing fixture

(F2X/F2/F3/no)

F2X, F2, F3 F2X, F2, F3

Suitable junior seat fixture

(B2/B3/no)

B2, B3

1-2. Child safety

ISOFIX child restraint systems are divided into different “fixture”. The child
restraint system can be used in the seating positions for “fixture” mentioned in the
table above. For kind of “fixture” relation, confirm the following table.
If your child restraint system has no kind of “fixture” (or if you cannot find informa-
tion in the table below), please refer to the child restraint system “vehicle list” for
compatibility information or ask the retailer of your child seat.

■

Recommended child restraint systems and Compatibility table



Vehicles without power rear seat

Fixture

Description

Full-height, forward-facing child restraint systems

Reduced-height forward-facing child restraint systems

F2X

Reduced-height forward-facing child restraint systems

Full-size, rearward-facing child restraint systems

Reduced-size, rearward-facing child restraint systems

R2X

Reduced-size, rearward-facing child restraint systems

Rearward-facing infant seat

Left lateral-facing (carrycot) infant seat

Right lateral-facing (carrycot) infant seat

Junior seat

Mass groups

Recommended Child

Restraint System

Seating position

Airbag manual

on-off switch

OFF

0, 0+
Up to 13 kg (28 lb.)

LEXUS G0+, BABY SAFE
PLUS (yes/no)

yes

I
9 to 18 kg (20 to
39 lb.)

LEXUS DUO PLUS
(yes/no)

yes

Belt fix

only

yes

Belt fix

only

yes

1-2. Child safety

For safety and security



Vehicles with power rear seat

The child restraint systems mentioned in the table may not be available outside the
EU countries and United Kingdom.
When securing some types of child
restraint systems in rear seat, it may not
be possible to properly use the seat
belts in positions next to the child
restraint without interfering with it or
affecting seat belt effectiveness. Be
sure your seat belt fits snugly across
your shoulder and low on your hips. If it
does not, or if it interferes with the child
restraint, move to a different position.
Failure to do so may result in death or
serious injury.



When installing a child restraint in
the rear seats, adjust the front seat
so that it does not interfere with the
child or child restraint system.



When installing a child seat with
support base, if the child seat inter-
feres with the seatback when latch-
ing it into the support base, adjust
the seatback rearward until there is
no interference.



If the seat belt shoulder anchor is
ahead of the child seat belt guide,
move the seat cushion forward.



When installing a junior seat, if the
child in your child restraint system is
in a very upright position, adjust the
seatback angle to the most comfort-
able position. And if the seat belt
shoulder anchor is ahead of the
child seat belt guide, move the seat
cushion forward.

Mass groups

Recommended Child

Restraint System

Seating position

Airbag manual

on-off switch

OFF

0, 0+
Up to 13 kg (28 lb.)

LEXUS G0+, BABY SAFE
PLUS (yes/no)

yes

I
9 to 18 kg (20 to
39 lb.)

LEXUS DUO PLUS
(yes/no)

yes

Belt fix

only

yes

Belt fix

only

yes

1-2. Child safety

Confirm with the operation manual enclosed with the child restraint system about
the installation of the child restraint system.

■

Installing child restraint system
using a seat belt

Install the child restraint system in

accordance to the operation manual
enclosed with the child restraint sys-
tem.
If the child restraint system on hand is
not within the “universal” category (or
the necessary information is not in the

Child restraint system installation method

Installation method

Page

Seat belt attachment

P.54

ISOFIX lower anchorage

attachment

P.56

Top tether anchorage

attachment

P.58

Child restraint system fixed with
a seat belt

1-2. Child safety

For safety and security

table), refer to the “Vehicle List” pro-
vided by the child restraint system
maker for various possible installation
positions, or check the compatibility
after asking the retailer of the child
seat. (



P.49, 50)

Adjust the seat



When using the front passenger
seat

If installing the child restraint system to the
front passenger seat is unavoidable, refer
to P.45for the front passenger seat adjust-
ment.



When using the power rear seat (if
equipped)

If there is a gap between the child seat and
the seatback, adjust the seatback angle
until good contact is achieved. (



P.46)

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted. Securely fix the
seat belt to the child restraint sys-
tem in accordance to the directions
enclosed with the child restraint
system.

If your child restraint system is not
equipped with a lock-off (a seat belt

locking feature), secure the child
restraint system using a locking clip.

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.56)

■

Removing a child restraint system
installed with a seat belt

Press the buckle release button and
fully retract the seat belt.

When releasing the buckle, the child
restraint system may spring up due to the
rebound of the seat cushion. Release the
buckle while holding down the child
restraint system.
Since the seat belt automatically reels itself,
slowly return it to the stowing position.

■

When installing a child restraint system

You may need a locking clip to install the

child restraint system. Follow the instruc-

tions provided by the manufacturer of the

system. If your child restraint system does

not provide a locking clip, you can purchase

the following item from any authorized

Lexus retailer or Lexus authorized repairer,

or any reliable repairer: Locking clip for

child restraint system

(Part No. 73119-22010)

Content .. 1 2 3 ..
