Lexus LC500 (2022 year). Manual in english - page 7

130

3-3. Adjusting the seats

3-3.Adjusting the seats

Seat position adjustment

Seatback angle adjustment

Head restraint height adjustment (if
equipped) (



P.136)

Seat cushion (front) angle adjust-
ment

Vertical height adjustment

Lumbar support adjustment

When adjusting the seat

Make sure that any surrounding passen-

gers or objects are not contact the seat.

Take care when adjusting the seat so that

the head restraint does not touch the ceil-

ing.

Vehicles with power head restraint:

Depending on the position of the front

seat, the front head restraint may not be

able to be adjusted upward if it is close to

the ceiling.

Seat-linked function

This function operates when the seat is

moved forward, backward or in the

reclining direction a certain distance or

more.

Vehicles with power head restraint:

When the seat is adjusted forward a cer-

tain distance or more, the head restraint

moves down.

Vehicles with power head restraint:

When the seat is raised a certain distance

or more, the seat stops and the head

restraint moves down.

Power easy access system

The driver’s seat and steering wheel move

in accordance with engine switch <power

switch> mode and the driver’s seat belt con-

dition. (



P.132)

Front seats

The seats can be adjusted (longitu-
dinally, vertically, etc.). Adjust the
seat to ensure the correct driving
posture.

Adjustment procedure

A
B
C

E
F

WARNING

When adjusting the seat position

Take care when adjusting the seat

position to ensure that other passen-

gers are not injured by the moving

seat.

Do not put your hands under the seat

or near the moving parts to avoid

injury.

Fingers or hands may become

jammed in the seat mechanism.

Make sure to leave enough space

around the feet so they do not get

stuck.

131

3-3. Adjusting the seats

Before drivi

Before entering/exiting the rear
seats



Remove the seat belt from the seat
belt guide. (



P.37)



Stow the sun visor.

Entering/exiting the rear seat

Pull the lever.

The front seat will lower automatically.

Fold the seatback completely for-
ward.

The front seat will move forward and the

head restraint will move downward

auto-

matically.

: Power type only

Returning the front seat to its origi-
nal position

Move the seatback backward until it
locks. The front seat will return to its
original position automatically.

Lever-operated “Front, Fold & Return”

seat

After the front seat is moved forward by

operating the “Front, Fold & Return” seat

lever, if a power seat adjusting switch or a

driving position memory switch is

pressed, the front seat will not return to its

original position even if the front seat-

back is moved backward until it locks.

The lever-operated “Front, Fold &

Return” seat will not operate in the fol-

lowing situations:

• The seat belt of the seat to be operated is

fastened.

• The engine switch <power switch> is in

IGNITION ON mode <ON mode> and

the shift position is in a position other than

Operation of the lever-operated “Front,

Fold & Return” seat will stop in the follow-

ing situations:

• A power seat adjusting switch or a driv-

ing position memory switch is pressed.

• The seat belt of the seat which is operat-

ing is fastened.

• The engine switch <power switch> is in

IGNITION ON mode <ON mode> and

WARNING

Seat adjustment

To reduce the risk of sliding under the lap

belt during a collision, do not recline the

seat more than necessary.

If the seat is too reclined, the lap belt may

slide past the hips and apply restraint

forces directly to the abdomen, or your

neck may contact the shoulder belt,

increasing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made while

driving as the seat may unexpectedly

move and cause the driver to lose con-

trol of the vehicle.

Entering/exiting the rear seats
(lever-operated “Front, Fold &
Return” seat)

132

3-3. Adjusting the seats

the shift position is changed to a position

other than P.

If the front seat is close to the sun visor or

other surrounding parts, frontwards and

upwards movement may be restricted.

Jam protection function

While the driving position is recalling or the

power easy access system is operating, if an

object is stuck behind the front seat, the

front seat will stop and then move slightly

forward.
While the lever-operated “Front, Fold &

Return” seat is operating, if an object is

stuck either in front of or behind the front

seat, the front seat will stop and then move

in the opposite direction slightly.
When the jam protection function operates,

the seat stops at a position other than the

set seat position. Check the seat position.

The seat and steering wheel are auto-
matically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the seat and steering wheel
are automatically adjusted to a position
that allows the driver to enter and exit
the vehicle easily.



The shift position has been shifted to
P.



The engine switch <power switch>
has been turned off.



The driver’s seat belt has been
unfastened.

WARNING

Lever-operated “Front, Fold &

Return” seat

Before operating the lever-operated

“Front, Fold & Return” seat, ensure

that any surrounding passengers or

objects will not contact the seat.

Make sure the seatback is locked

securely before driving.

Never operate the lever-operated

“Front, Fold & Return” seat while the

vehicle is moving.

Jam protection function

Do not use a hand, foot, or any other part

of your body to intentionally activate the

jam protection function.

Driving position memory

This feature automatically adjusts
the positions of the driver’s seat,
steering wheel, outside rear view
mirrors and head-up display (if
equipped) to make entering and
exiting the vehicle easier or to suit
your preferences.
Up to 3 different driving positions
can be recorded.
Each electronic key (including a
card key) can be registered to
recall your preferred driving posi-
tion.

Power easy access system

133

3-3. Adjusting the seats

Before drivi

When any of the following has been
performed, the driver’s seat and steer-
ing wheel automatically return to their
original positions.



The engine switch <power switch>
has been turned to ACCESSORY
mode or IGNITION ON mode
<ON mode>.



The driver’s seat belt has been fas-
tened.

Operation of the power easy access

system

When exiting the vehicle, the power easy

access system may not operate if the seat

is already close to the rearmost position,

etc.

If the seat or power head restraint (if

equipped) position is adjusted during the

power easy access system operation, the

automatic operating will stop. (The seat

will change to manual operation.)

If the seat or power head restraint (if

equipped) position is adjusted during or

after the power easy access system oper-

ation when the driver is exiting the vehi-

cle, the power easy access system will not

operate when entering the vehicle.

Vehicles with power head restraint: If the

head restraint is close to the ceiling when

the driver is exiting the vehicle, the head

restraint may move down during the

power easy access system operation.

Also, the head restraint may be restricted

from being adjusted upward after the

power easy access system operates.

When the driver is entering the vehicle,

the head restraint returns to its original

position.

Customization

The seat movement amount settings of the

power easy access system can be custom-

ized.

(Customizable features:



P.425)

Turn the engine switch <power
switch> to IGNITION ON mode
<ON mode>.

Check that the shift position is in P.

Adjust the driver’s seat, steering
wheel, outside rear view mirrors
and head-up display to the desired
positions.

While pressing the “SET” button, or
within 3 seconds after the “SET”
button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

will be overwritten.

Seat positions that can be memorized

(



P.130)

The adjusted positions other than the posi-

Recording a driving position into
memory

134

3-3. Adjusting the seats

tion adjusted by lumbar support switch can

be recorded.

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

Turn the engine switch <power
switch> to IGNITION ON mode
<ON mode>.

Check that the shift position is in P.

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

To stop the position recall operation

part-way through

Perform any of the following:

Press the “SET” button.

Press button “1”, “2” or “3”.

Operate any of the seat adjustment

switches (only cancels seat position

recall).

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

Operate the head-up display position

adjustment switch (if equipped) (only

cancels head-up display position recall).

Operating the driving position memory

after turning the engine switch <power

switch> off

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.

When the recorded seat position can-

not be recalled

The seat position may not be recalled in

some situations when the seat position is

recorded in a certain range. For details,

contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

Registering procedure

Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key you want to regis-
ter, and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be recorded
properly.

Turn the engine switch <power
switch> to IGNITION ON mode
<ON mode>.

Check that the shift position is in P.

WARNING

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

Registering/canceling/recall-
ing a driving position to an elec-
tronic key (including a card key)
(memory recall function)

135

3-3. Adjusting the seats

Before drivi

Recall the driving position that you
want to record.

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

If the button could not be registered, the

buzzer sounds continuously for approxi-

mately 3 seconds.

Cancelation procedure

Carry only the key you want to can-
cel and then close the driver’s door.

If 2 or more keys are in the vehicle, the

driving position cannot be canceled prop-

erly.

Turn the engine switch <power
switch> to IGNITION ON mode
<ON mode>.

Check that the shift position is in P.

While pressing the “SET” button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds twice.

If the button could not be canceled, the

buzzer sounds continuously for approxi-

mately 3 seconds.

Recall procedure

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key

that has been registered to the driv-
ing position, and then unlock and
open the driver’s door using the
smart entry & start system or wire-
less remote control.

The driving position will move to the

recorded position (not including the steer-

ing wheel and head-up display).
If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

Turn the engine switch <power
switch> to ACCESSORY mode or
IGNITION ON mode <ON
mode>, or fasten a seat belt.

The steering wheel and head-up display

will move to the recorded position.

Recalling the driving position using the

memory recall function

Different driving positions can be regis-

tered for each electronic key. Therefore,

the driving position that is recalled may

be different depending on the key being

carried.

If the passenger’s door is unlocked with

the smart entry & start system, the driving

position cannot be recalled. In this case,

press the driving position button which

has been set.

Customization

The unlock door settings of the memory

recall function can be changed.

(Customizable features:



P.425)

136

3-3. Adjusting the seats



Manual type

Pull the head restraints up.

Down

Push the head restraint down while press-
ing the lock release button



Power type

Down

About the head restraints (power type)

Depending on the position of the front seat,

the front head restraint may not be able to

be adjusted upward if it is close to the ceil-

ing.

Adjusting the height of the head

restraints

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

Pull the head restraint up while press-
ing the lock release button

If the head restraint touches the ceiling,
making the removal difficult, change
the seat height or angle. (



P.130)

Head restraints

Head restraints are provided for
front seats.

WARNING

Head restraint precautions

Observe the following precautions

regarding the head restraints. Failure to

do so may result in death or serious

injury.

Adjust the head restraints to the cor-

rect position at all times.

Manual type: After adjusting the head

restraints, push down on them and

make sure they are locked in position.

Manual type: Do not drive with the

head restraints removed.

Vertical adjustment

Removing the head restraints
(manual type only)

137

3-3. Adjusting the seats

Before drivi

Removing the head restraints (power

type only)

For removing and installation of the head

restraint, contact any authorized Lexus

retailer or Lexus authorized repairer, or any

reliable repairer.

Align the head restraint with the instal-
lation holes and push it down to the
lock position.
Press and hold the lock release button

when lowering the head restraint.

Installing the head restraints
(manual type only)

138

3-4. Adjusting the steering wheel and mirrors

3-4.Adjusting the steering wheel and mirrors

Operating the switch moves the steer-
ing wheel in the following directions:

Down

Toward the driver

Away from the driver

The steering wheel can be adjusted

when

The engine switch <power switch> is in

ACCESSORY or IGNITION ON mode

<ON mode>.

Automatic adjustment of the steering

position

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.132)

Power easy access system

The driver’s seat and steering wheel move

in accordance with engine switch <power

switch> mode and the driver’s seat belt con-

dition. (



P.132)

Press on or close to the

mark.

Steering wheel

Adjustment procedure

WARNING

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

Sounding the horn

139

3-4. Adjusting the steering wheel and mirrors

Before drivi

The height of the rear view mirror can
be adjusted to suit your driving pos-
ture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness
of the headlights of vehicles behind, the
reflected light is automatically
reduced.
Turn the automatic anti-glare function

mode on/off

When the automatic anti-glare function is
in ON mode, the indicator

illuminates.

The function will set to ON mode each
time the engine switch <power switch> is
turned to IGNITION ON mode <ON
mode>.
Pressing the button turns the function to
OFF mode. (The indicator

also turns

off.)

To prevent sensor error

To ensure that the sensors operate prop-

erly, do not touch or cover them.

Inside rear view mirror

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

Adjusting the height of rear view
mirror

WARNING

Caution while driving

Do not adjust the position of the mirror

while driving.

Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

Anti-glare function

140

3-4. Adjusting the steering wheel and mirrors

To select a mirror to adjust, press
the switch.

The indicator comes on.

Left

Right

Pressing the same switch again will put the
switch in neutral.

To adjust the mirror, press the
switch.

Right

Down

Left

Mirror angle can be adjusted when

The engine switch <power switch> is in

ACCESSORY or IGNITION ON mode

<ON mode>.

Defogging the mirrors

The outside rear view mirrors can be

cleared using the mirror defoggers. Turn on

the rear window defogger to turn on the

outside rear view mirror defoggers.

(



P.281)

Auto anti-glare function

When the anti-glare inside rear view mirror

is set to automatic mode, the outside rear

view mirrors will activate in conjunction

with the anti-glare inside rear view mirror to

reduce reflected light. (



P.139)

Automatic adjustment of the mirror

angle

A desired mirror face angle can be entered

to memory and recalled automatically by

the driving position memory. (



P.132)

Outside rear view mirrors

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

WARNING

Important points while driving

Observe the following precautions while

driving.

Failure to do so may result in loss of con-

trol of the vehicle and cause an accident,

resulting in death or serious injury.

Do not adjust the mirrors while driving.

Do not drive with the mirrors folded.

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

Adjustment procedure

A
B

A
B
C
D

141

3-4. Adjusting the steering wheel and mirrors

Before drivi

Using the switch

Press the switch to fold the mirrors.

Press it again to extend them to the original
position.

Setting automatic mode

Automatic mode allows the folding or
extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode.

The indicator

will come on.

Pressing the switch once more will return
to manual mode.

When disconnecting and reconnecting

12-volt battery terminals

The automatic folding/extending mirror

function will return to off as default. To turn

the function on, press the switch again to

select on.

Using automatic mode in cold weather

When automatic mode is used in cold

weather, the door mirror could freeze up

and automatic stowing and return may not

be possible. In this case, remove any ice and

snow from the door mirror, then either

operate the mirror using manual mode or

move the mirror by hand.

Customization

The automatic mirror folding and extending

operation can be changed.

(Customizable features:



P.425)

When either “L” or “R” of the mirror
select switch is selected, the outside
rear view mirrors will automatically
angle downwards when the vehicle is
reversing in order to give a better view

WARNING

When the outside rear view mirror

defoggers are operating

Do not touch the outside rear view mir-

ror surfaces, as they can become very

hot and burn you.

Folding and extending the mir-
rors

WARNING

When a mirror is moving

To avoid personal injury and mirror mal-

function, be careful not to get your hand

caught by the moving mirror.

Linked mirror function when
reversing

142

3-4. Adjusting the steering wheel and mirrors

of the ground.
To disable this function, select neither
“L” nor “R”.

Adjusting the mirror angle when
the vehicle is reversing

With the shift position in R, adjust the
mirror angle at a desired position.
The adjusted angle will be memorized
and the mirror will automatically tilt to
the memorized angle whenever the
shift position is shifted to R from next
time.

The memorized downward tilt position of
the mirror is linked to the normal position
(angle adjusted with the shift position in
other than R). Therefore, if the normal
position is changed after adjustment, the
tilt position will also change.
When the normal position is changed,
readjust the angle in reversing.

143

3-5. Opening, closing the windows

Before drivi

3-5.Opening, closing the windows

The power windows can be opened
and closed by one-touch operation of
the switches.

Closing

One-touch closing

Opening

One-touch opening

: To stop the window partway, operate

the switch in the opposite direction.

The power windows can be operated

when

The engine switch <power switch> is in

IGNITION ON mode <ON mode>.

Operating the power windows after

turning the engine <hybrid system> off

The power windows can be operated for

approximately 45 seconds after the engine

switch <power switch> is turned to ACCES-

SORY mode or turned off. They cannot,

however, be operated once either door is

opened.

Jam protection function

If an object becomes jammed between the

window and the window frame while the

window is closing, window movement is

stopped and the window is opened slightly.

Catch protection function

If an object becomes caught between the

door and window while the window is open-

ing, window movement is stopped.

When the window cannot be opened or

closed

When the jam protection function or catch

protection function operates unusually and

the door window cannot be opened or

closed, perform the following operations

with the power window switch of that door.

Stop the vehicle. With the engine switch

<power switch> in IGNITION ON mode

<ON mode>, within 4 seconds of the jam

protection function or catch protection

function activating, continuously operate

the power window switch in the one-

touch closing direction or one-touch

opening direction so that the door win-

dow can be opened and closed.

If the door window cannot be opened

and closed even when performing the

above operations, perform the following

procedure for function initialization.

Close both side doors.

Turn the engine switch <power switch>

to IGNITION ON mode <ON mode>.

Pull and hold the power window switch

in the one-touch closing direction and

completely close the door window.

Release the power window switch for a

moment, resume pulling the switch in

the one-touch closing direction, and

hold it there for approximately 6 sec-

onds or more.

Press and hold the power window

switch in the one-touch opening direc-

tion. After the door window is com-

pletely opened, continue holding the

switch for an additional 1 second or

more.

Release the power window switch for a

moment, resume pushing the switch in

the one-touch opening direction, and

hold it there for approximately 4 sec-

onds or more.

Pull and hold the power window switch

in the one-touch closing direction

Power windows

Opening and closing the power
windows

144

3-5. Opening, closing the windows

again. After the door window is com-

pletely closed, continue holding the

switch for a further 1 second or more.

If you release the switch while the window is

moving, start again from the beginning.

If the window reverses and cannot be fully

closed or opened, have the vehicle

inspected by any authorized Lexus retailer

or Lexus authorized repairer, or any reli-

able repairer.

Door lock linked window operation

The power windows can be opened and
closed using the mechanical key.

(



P.392)

The power windows can be opened and

closed using the wireless remote con-
trol.

(



P.118)

: These settings must be customized at any

authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.

Power windows open warning buzzer

The buzzer sounds and “Window Open” is

shown on the multi-information display in

the instrument cluster when the engine

switch <power switch> is turned off and the

driver’s door is opened with the power win-

dows open.

Customization

Settings (e.g. linked door lock operation)

can be changed.

(Customizable features:



P.425)

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

Closing the windows

The driver is responsible for all the

power window operations, including

the operation for the passengers. In

order to prevent accidental operation,

especially by a child, do not let a child

operate the power windows. It is possi-

ble for children and other passengers

to have body parts caught in the power

window. Also, when riding with a child,

it is recommended to use the window

lock switch. (



P.145)

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when a window is being operated.

When using the wireless remote con-

trol or mechanical key and operating

the power windows, operate the

power window after checking to make

sure that there is no possibility of any

passenger having any of their body

parts caught in the window. Also do

not let a child operate window by the

wireless remote control or mechanical

key. It is possible for children and other

passengers to get caught in the power

window.

When exiting the vehicle, turn the

engine switch <power switch> off,

carry the key and exit the vehicle along

with the child. There may be accidental

operation, due to mischief, etc., that

may possibly lead to an accident.

Jam protection function

Never use any part of your body to

intentionally activate the jam protec-

tion function.

The jam protection function may not

work if something gets jammed just

before the window is fully closed. Be

careful not to get any part of your body

jammed in the window.

145

3-5. Opening, closing the windows

Before drivi

This function can be used to prevent
children from accidentally opening or
closing a passenger window.
Press the switch.

The indicator

will come on and the

passenger window will be locked.

The power windows can be operated

when

The engine switch <power switch> is in

IGNITION ON mode <ON mode>.

When the 12-volt battery is discon-

nected

The window lock switch is disabled. If nec-

essary, press the window lock switch after

reconnecting the 12-volt battery.

WARNING

Catch protection function

Never use any part of your body or

clothing to intentionally activate the

catch protection function.

The catch protection function may not

work if something gets caught just

before the window is fully opened. Be

careful not to get any part of your body

or clothing caught in the window.

Preventing accidental opera-
tion (window lock switch)

Content .. 5 6 7 8 ..
