Lexus RX L (2022 year). Manual in english - page 11

268

4-2. Driving procedures

Right turn

Lane change to the right (move the
lever partway and release it)

The right hand signals will flash 3 times.

Lane change to the left (move the
lever partway and release it)

The left hand signals will flash 3 times.

Left turn

■

Turn signals can be operated when

The engine switch is in IGNITION ON

mode.

■

If the indicator flashes faster than usual

Check that a light bulb in the front or rear

turn signal lights has not burned out.

■

If the turn signals stop flashing before a

lane change has been performed

Operate the lever again.

■

Customization

Some functions can be customized.

(



P.592)

Turn signal lever

Operating instructions

269

4-2. Driving procedures

Driving

■

Using the manual mode

The parking brake can be set and
released manually.

Parking brake light

Pull the parking brake switch to set
the parking brake

The parking brake indicator light and park-
ing brake light will turn on.

Pull and hold the parking brake switch if an
emergency occurs and it is necessary to
operate the parking brake while driving.

Push the parking brake switch to
release the parking brake

Operate the switch while depressing the
brake pedal or slowly depressing the
accelerator pedal.
Make sure that the parking brake indicator
light and parking brake light turn off.

If the parking brake indicator light and
parking brake light flashes, operate the
switch again. (



P.533)

■

Turns automatic mode on

While the vehicle is stopped, pull and
hold the parking brake switch until
“Automatic Mode On” will be dis-
played on the multi-information dis-
play.

When the automatic mode is turned
on, the parking brake operates as fol-
lows.



When the shift lever is moved out of
P, the parking brake will be released,
and the parking brake indicator light
and parking brake light turn off.



When the shift lever is moved into P,
the parking brake will be set, and the
parking brake indicator light and

Parking brake

The parking brake can be set or
released automatically or manually.

In automatic mode, the parking
brake can be set or released auto-
matically according to the shift
lever operation. Also, even in auto-
matic mode, the parking brake can
be set or released manually.

Operating instructions

270

4-2. Driving procedures

parking brake light turn on.

Operate the shift lever with the brake
pedal depressed.

■

Turns automatic mode off

While the vehicle is stopped, press and
hold the parking brake switch until
“Automatic Mode Off” will be dis-
played on the multi-information dis-
play.

■

Parking brake operation

●

When the engine switch is not in IGNI-

TION ON mode, the parking brake can-

not be released using the parking brake

switch.

●

When the engine switch is not in IGNI-

TION ON mode, automatic mode (auto-

matic brake setting and releasing) is not

available.

■

Parking brake automatic release func-

tion

The parking brake is automatically released

when slowly depress the accelerator pedal.
The parking brake will be released auto-

matically under the following conditions:
• The driver’s door is closed.
• The driver’s seatbelt is fastened.
• Shift the shift lever is in a forward or

reverse position.

• The malfunction indicator lamp or brake

system warning light is not illuminated.

If the automatic release function does not

operate, manually release the parking

brake.

■

If “Parking Brake Overheated Parking

Brake Unavailable” is displayed on the

multi-information display

If the parking brake is operated repeatedly

over a short period of time, the system may

restrict operation to prevent overheating. If

this happens, refrain from operating the

parking brake. Normal operation will return

after about 1 minute.

■

If “EPB Activation Stopped Incom-

pletely” or “Parking Brake Unavailable”

is displayed on the multi-information

display

Operate the parking brake switch. If the

message does not disappear after operat-

ing the switch several times, the system may

be malfunctioning. Have the vehicle

inspected by any authorized Lexus retailer

or Lexus authorized repairer, or any reliable

repairer immediately.

■

Parking brake operation sound

When the parking brake operates, a motor

sound (whirring sound) may be heard. This

does not indicate a malfunction.

■

Parking brake indicator light and park-

ing brake light

●

Depending on the engine switch mode,

the parking brake indicator light and

parking brake light will turn on and stay

on as described below:

IGNITION ON mode: Comes on until

the parking brake is released.

Not in IGNITION ON mode: Stays on

for approximately 15 seconds.

●

When the engine switch is turned off with

the parking brake set, the parking brake

indicator light and parking brake light will

stay on for about 15 seconds. This does

not indicate a malfunction.

■

Changing the mode

When changing the automatic mode on/off,

the message will be shown on the

multi-information display and the buzzer

sounds.

271

4-2. Driving procedures

Driving

■

Parking the vehicle



P.244

■

Parking brake engaged warning buzzer

A buzzer will sound if the vehicle is driven

with the parking brake engaged. “Release

Parking Brake” is displayed on the

multi-information display.

■

Warning messages and buzzers

Warning messages and buzzers are used to

indicate a system malfunction or to inform

the driver of the need for caution. If a warn-

ing message is shown on the multi-informa-

tion display, read the message and follow

the instructions.

■

If the brake system warning light comes



P.527

■

Usage in winter time



P.404

WARNING

■

When parking the vehicle

Do not leave a child in the vehicle alone.

The parking brake may be released unin-

tentionally and there is the danger of the

vehicle moving that may lead to an acci-

dent resulting in death or serious injury.

■

Parking brake switch

Do not set any objects near the parking

brake switch. Objects may interfere with

the switch and may lead the parking

brake to unexpectedly operate.

NOTICE

■

When parking the vehicle

Before you leave the vehicle, shift the

shift lever to P, set the parking brake and

make sure that the vehicle does not

move.

■

When the system malfunctions

Stop the vehicle in a safe place and

check the warning messages.

■

When the parking brake cannot be

released due to a malfunction

Driving the vehicle with the parking

brake set will lead to brake components

overheating, which may affect braking

performance and increase brake wear.
Have the vehicle inspected by contact

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer immediately if this occurs.

272

4-2. Driving procedures

Turns the brake hold system on

The brake hold standby indicator (green)

comes on. While the system is holding

the brake, the brake hold operated indica-
tor (yellow)

comes on.

■

Brake hold system operating conditions

The brake hold system cannot be turned on

in the following conditions:

●

The driver’s door is not closed.

●

The driver is not wearing the seat belt.

If any of the conditions above are detected

when the brake hold system is enabled, the

system will turn off and the brake hold

standby indicator light will go off. In addi-

tion, if any of the conditions are detected

while the system is holding the brake, a

warning buzzer will sound and a message

will be shown on the multi-information dis-

play. The parking brake will then be set

automatically.

■

Brake hold function

●

If the brake pedal is left released for a

period of about 3 minutes after the sys-

tem has started holding the brake, the

parking brake will be set automatically. In

this case, a warning buzzer sounds and a

message is shown on the multi-informa-

tion display.

●

To turn the system off while the system is

holding the brake, firmly depress the

brake pedal and press the button again.

●

The brake hold function may not hold the

vehicle when the vehicle is on a steep

incline. In this situation, it may be neces-

sary for the driver to apply the brakes. A

warning buzzer will sound and the

multi-information display will inform the

driver of this situation. If a warning mes-

sage is shown on the multi-information

display, read the message and follow the

instructions.

■

When the parking brake is set automati-

cally while the system is holding the

brakes

Perform any of the following operations to

release the parking brake.

●

Depress the accelerator pedal. (The

parking brake will not be released auto-

matically if the seat belt is not fastened.)

●

Operate the parking brake switch with

the brake pedal depressed.

Make sure that the parking brake indicator

light goes off. (



P.269)

■

When an inspection at any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer is nec-

essary

When the brake hold standby indicator

(green) does not illuminate even when the

brake hold switch is pressed with the brake

hold system operating conditions met, the

system may be malfunctioning. Have the

vehicle inspected at any authorized Lexus

retailer or Lexus authorized repairer, or any

Brake Hold

The brake hold system keeps the
brake applied when the shift lever is
in D, M or N with the system on and
the brake pedal has been
depressed to stop the vehicle. The
system releases the brake when the
accelerator pedal is depressed with
the shift lever in D or M to allow
smooth start off.

Enabling the system

273

4-2. Driving procedures

Driving

reliable repairer.

■

If “Brake Hold Fault Depress Brake to

Deactivate Visit Your Dealer” or “Brake

Hold Malfunction Visit Your Dealer” is

displayed on the multi-information dis-

play

The system may be malfunctioning. Have

the vehicle inspected by any authorized

Lexus retailer or Lexus authorized repairer,

or any reliable repairer.

■

Warning messages and buzzers

Warning messages and buzzers are used to

indicate a system malfunction or to inform

the driver of the need for caution. If a warn-

ing message is shown on the multi-informa-

tion display, read the message and follow

the instructions.

■

If the brake hold operated indicator

flashes



P.534

WARNING

■

When the vehicle is on a steep incline

When using the brake hold system on a

steep incline exercise caution. The brake

hold function may not hold the vehicle in

such a situation.

■

When stopped on a slippery road

The system cannot stop the vehicle when

the gripping ability of the tires has been

exceeded. Do not use the system when

stopped on a slippery road.

NOTICE

■

When parking the vehicle

The brake hold system is not designed

for use when parking the vehicle for a

long period of time. Turning the engine

switch off while the system is holding the

brake may release the brake, which

would cause the vehicle to move. When

operating the engine switch, depress the

brake pedal, shift the shift lever to P and

set the parking brake.

274

4-3. Operating the lights and wipers

4-3.Operating the lights and wipers

Operating the

switch turns on

the lights as follows:

The front position, tail, rear

side marker, license plate and
instrument panel lights turn on.

The headlights and all the

lights listed above turn on.

The headlights, daytime run-

ning lights (



P.274) and all the

lights listed above turn on and off
automatically.
(When the engine switch is in

IGNITION ON mode.)

■

Daytime running light system

To make your vehicle more visible to other

drivers during daytime driving, the daytime

running lights turn on automatically when-

ever the engine is started and the parking

brake is released with the headlight switch
in

position. (Illuminate brighter than

the front position lights.) Daytime running

lights are not designed for use at night.

■

Headlight control sensor

The sensor may not function properly if an

object is placed on the sensor, or anything

that blocks the sensor is affixed to the wind-

shield.

Doing so interferes with the sensor detect-

ing the level of ambient light and may cause

the automatic headlight system to malfunc-

tion.

■

Automatic light off system

●

When the light switch is in the

position: The headlights and front

fog lights (if equipped) turn off automati-

cally if the engine switch is turned to

ACCESSORY mode or off.

●

When the light switch is in the

posi-

tion: The headlights and all lights turn off

automatically if the engine switch is

turned to ACCESSORY mode or off.

To turn the lights on again, turn the engine

switch to IGNITION ON mode, or turn the
light switch to the

position once and

then back to

Headlight switch

The headlights can be operated
manually or automatically.

Operating instructions

275

4-3. Operating the lights and wipers

Driving

■

Automatic headlight leveling system

The level of the headlights is automatically

adjusted according to the number of pas-

sengers and the loading condition of the

vehicle to ensure that the headlights do not

interfere with other road users.

■

Light reminder buzzer

A buzzer sounds when the engine switch is

turned off or turned to ACCESSORY

mode and the driver’s door is opened while

the lights are turned on.

■

Welcome lighting

If the headlight switch is turned to

and

the surrounding area is dark, unlocking the

doors using the smart entry & start system

or wireless remote control will turn the front

position lights and tail lights on automati-

cally.

■

Battery-saving function

In order to prevent the battery of the vehicle

from discharging, if the light switch is in the

position when the engine

switch is turned off the battery saving func-

tion will operate and automatically turn off

all the lights after approximately 20 min-

utes. When the engine switch is turned to

IGNITION ON mode, the battery-saving

function will be disabled.

When any of the following are performed,

the battery-saving function is canceled

once and then reactivated. All the lights will

turn off automatically 20 minutes after the

battery- saving function has been reacti-

vated:

●

When the headlight switch is operated

●

When a door is opened or closed

■

Customization

Some functions can be customized.

(



P.592)

With the headlights on, push the
lever away from you to turn on the
high beams.

Pull the lever toward you to the center
position to turn the high beams off.

Pull the lever toward you and
release it to flash the high beams
once.

You can flash the high beams with the
headlights on or off.
On vehicles with AHS (Adaptive
High-beam System), the high beams can-
not be illuminated by pulling the lever
toward you when the engine switch is off.

This system allows the headlights to be
turned on for 30 seconds when the
engine switch is off.
Pull the lever toward you and release it

with the light switch in

after turn-

ing the engine switch off.

Pull the lever toward you and release it
again to turn off the lights.

NOTICE

■

To prevent battery discharge

Do not leave the lights on longer than

necessary when the engine is off.

Turning on the high beam head-
lights

Follow me home system

276

4-3. Operating the lights and wipers



When the steering wheel or turn
signal lever is operated while the
headlights are on (low beam), a cor-
nering light will turn on and light up
the direction of movement of the
vehicle. The cornering lights are
designed to ensure excellent visibil-
ity when making a turn at an inter-
section.

However, when vehicle speed is approxi-
mately 35 km/h (22 mph) or higher, the
cornering lights will not turn on.



When the shift lever is in R while the
headlights are on (low beam), both
cornering lights will turn on. This is
designed to enhance visibility when
parking.

■

Cornering lights (if equipped)

When the cornering lights are on for more

than 30 minutes, they will turn off automati-

cally.

: If equipped



Adjusts the brightness and illumi-
nated area of the high beams
according to the vehicle speed.



Adjusts the intensity of the high
beams, while driving on a curve, so
that the area in the direction that the
vehicle is turning will be illuminated
more brightly than other areas.



Operates the shaded high beams so
that the area around vehicles ahead
is partially not illuminated while all
other areas continue to be illumi-

Cornering lights (if equipped)

AHS (Adaptive High-beam
System)

The Adaptive High-beam System
uses a camera sensor located
behind the upper portion of the
windshield to assess the brightness
of the lights of vehicles ahead,
streetlights, etc., and automatically
controls the headlight light distribu-
tion as necessary.

WARNING

■

Limitations of the Adaptive

High-beam System

Do not overly rely on the Adaptive

High-beam System. Always drive safely,

taking care to observe your surroundings

and turning the high beams on or off

manually if necessary.

■

To prevent incorrect operation of the

Adaptive High-beam System

Do not overload the vehicle.

System functions

277

4-3. Operating the lights and wipers

Driving

nated with the high beams.

The shaded high beams help optimize for-
ward visibility while reducing the dazzling
effect on the drivers of vehicles ahead.



Adjusts the distance that the low
beams are projected according to
the distance to a preceding vehicle.

Press the Adaptive High-beam Sys-
tem switch.

Turn the headlight switch to the

position.

The Adaptive High-beam System indicator

will come on when the system is operating.

■

Conditions in which the light distribu-

tion control of the headlights changes

automatically

●

When all of the following conditions are

met, the high beams will be turned on

automatically and the system will operate:

• The vehicle speed is approximately 60

km/h (38 mph) or more.

• The area ahead of the vehicle is dark.

●

When all of the following conditions are

met, the shaded high beams will turn on

and the distance that the low beams are

projected will be adjusted automatically,

depending on the location of vehicles

ahead:

• The vehicle speed is approximately 60

km/h (38 mph) or more.

• The area ahead of the vehicle is dark.

• There are vehicles ahead with headlights

or tail lights turned on.

●

If any of the following conditions is met,

the high beams or shaded high beams will

be changed to the low beams automati-

cally:

• The vehicle speed is below approxi-

mately 40 km/h (25 mph).

• The area ahead of the vehicle is not dark.

• There are many vehicles ahead.

• Vehicles ahead are moving quickly and

the high beams may blind the drivers of

the other vehicles.

■

Camera sensor detection information

●

The high beams may not be automatically

changed to the shaded high beams in the

following situations:

• When vehicles ahead suddenly appear

from a curve

Activating the Adaptive
High-beam System

278

4-3. Operating the lights and wipers

• When the vehicle is cut in front of by

another vehicle

• When vehicles ahead are hidden from

sight due to repeated curves, road divid-

ers or roadside trees

• When vehicles ahead appear from the

faraway lane on wide road

• When vehicles ahead have no lights

●

The high beams may be changed to the

shaded high beams if a vehicle ahead that

is using fog lights without its headlights

turned on is detected.

●

House lights, street lights, traffic signals,

and illuminated billboards or signs and

other reflective objects may cause the

high beams to change to the shaded high

beams, cause the high beams not to

change to the shaded high beams, or

change the area that is not illuminated.

●

The following factors may affect the

amount of time taken to turn the high

beam on or off, or the speed by which the

areas not illuminated change:

• The brightness of headlights, fog lights,

and tail lights of vehicles ahead

• The movement and direction of vehicles

ahead

• When a vehicle ahead only has opera-

tional lights on one side

• When a vehicle ahead is a two-wheeled

vehicle

• The condition of the road (gradient,

curve, condition of the road surface etc.)

• The number of passengers and amount of

luggage

●

The light distribution control of the head-

lights may change unexpectedly.

●

Bicycles or similar objects may not be

detected.

●

In the following situations the system may

not be able to correctly detect the sur-

rounding brightness level. This may cause

the low beams to remain on or the high

beams to flash or dazzle pedestrians or

vehicles ahead. In such a case, it is neces-

sary to manually switch between the high

and low beams.

• When driving in inclement weather

(heavy rain, snow, fog, sandstorms, etc.)

• When the windshield is obscured by fog,

mist, ice, dirt, etc.

• When the windshield is cracked or dam-

aged

• When the camera sensor is deformed or

dirty

• When the temperature of the camera

sensor is extremely high

• When the surrounding brightness level is

equal to that of headlights, tail lights or

fog lights

• When headlights or tail lights of vehicles

ahead are turned off, dirty, changing

color, or not aimed properly

• When the vehicle is hit by water, snow,

dust, etc. from a preceding vehicle

• When driving through an area of inter-

mittently changing brightness and dark-

ness

• When frequently and repeatedly driving

ascending/descending roads, or roads

with rough, bumpy or uneven surfaces

(such as stone-paved roads, gravel roads,

etc.)

• When frequently and repeatedly taking

curves or driving on a winding road

• When there is a highly reflective object

ahead of the vehicle, such as a sign or

mirror

• When the back of a preceding vehicle is

highly reflective, such as a container on a

truck

• When the vehicle’s headlights are dam-

aged or dirty, or are not aimed properly

• When the vehicle is listing or tilting due to

a flat tire, a trailer being towed, etc.

• When the headlights are changed

between the high beams and low beams

repeatedly in an abnormal manner

• When the driver believes that the high

beams may be flashing or dazzling

pedestrians or other drivers

• When the vehicle is used in an area in

which vehicles travel on the opposite side

of the road of the country for which the

vehicle was designed, for example using

a vehicle designed for right-hand traffic in

a left-hand traffic area, or vice versa

■

Customization

Some functions can be customized.

(



P.592)

279

4-3. Operating the lights and wipers

Driving

■

Switching to the low beams

Press the Adaptive High-beam System
switch.

The Adaptive High-beam System indicator
will turn off.
Press the switch to activate the Adaptive
High-beam System again.

■

Switching to the high beams

Push the lever away from you.

The Adaptive High-beam System indicator
will turn off and the high beam indicator
will turn on.
Pull the lever to its original position to acti-
vate the Adaptive High-beam System
again.

■

Temporarily switching to the low
beams

Pull the lever toward you and then
return it to its original position.

The high beams are on while the lever is
pulled toward you, however, after the lever
is returned to its original position, the low
beams remain on for a certain amount of
time. Afterwards, the Adaptive High-beam
System will be activated again.

■

Temporarily switching to the low beams

It is recommended to switch to the low

beams when the high beam may cause

problems or distress to other drivers or

pedestrians nearby.

Turning the high beams on/off
manually

280

4-3. Operating the lights and wipers

: If equipped

Press the Automatic High Beam
switch.

Turn the headlight switch to the

position.

The Automatic High Beam indicator will

come on when the system is operating.

■

Conditions to turn the high beams on/off

automatically

●

When all of the following conditions are

met, the high beams will be turned on

automatically (after approximately 1 sec-

ond):

• The vehicle speed is approximately 40

km/h (25 mph) or more.

• The area ahead of the vehicle is dark.

• There are no vehicles ahead with head-

lights or tail lights turned on.

• There are few streetlights on the road

ahead.

●

If any of the following conditions is met,

the high beams will turn off automatically:

• The vehicle speed is below approxi-

mately 30 km/h (19 mph).

• The area ahead of the vehicle is not dark.

• Vehicles ahead have their headlights or

tail lights turned on.

• There are many streetlights on the road

ahead.

■

Camera sensor detection information

●

The high beams may not be automatically

turned off in the following situations:

• When a vehicle suddenly appears from

around a curve

• When the vehicle is cut in front of by

another vehicle

• When vehicles ahead cannot be

detected due to repeated curves, road

dividers or roadside trees

AHB (Automatic High
Beam)

The Automatic High Beam uses a
camera sensor located behind the
upper portion of the windshield to
assess the brightness of the lights of
vehicles ahead, streetlights, etc.,
and automatically turns the high
beams on or off as necessary.

WARNING

■

Limitations of the Automatic High

Beam

Do not overly rely on the Automatic High

Beam. Always drive safely, taking care to

observe your surroundings and turning

the high beams on or off manually if nec-

essary.

■

To prevent incorrect operation of the

Automatic High Beam system

Do not overload the vehicle.

Activating the Automatic High
Beam

281

4-3. Operating the lights and wipers

Driving

• When vehicles ahead appear in a fara-

way lane on a wide road

• When the lights of vehicles ahead are not

●

The high beams may be turned off if a

vehicle ahead that is using fog lights with-

out its headlights turned on is detected.

●

House lights, street lights, traffic signals,

and illuminated billboards or signs and

other reflective objects may cause the

high beams to change to the low beams,

or the low beams to remain on.

●

The following factors may affect the

amount of time taken for the high beams

to turn on or off:

• The brightness of the headlights, fog

lights, and tail lights of vehicles ahead

• The movement and direction of vehicles

ahead

• When a vehicle ahead only has opera-

tional lights on one side

• When a vehicle ahead is a two-wheeled

vehicle

• The condition of the road (gradient,

curve, condition of the road surface, etc.)

• The number of passengers and amount of

luggage in the vehicle

●

The high beams may turn on or off unex-

pectedly.

●

Bicycles or similar vehicles may not be

detected.

●

In the following situations the system may

not be able to correctly detect the sur-

rounding brightness level. This may cause

the low beams to remain on or the high

beams to flash or dazzle pedestrians or

vehicles ahead. In such a case, it is neces-

sary to manually switch between the high

and low beams.

• When driving in inclement weather

(heavy rain, snow, fog, sandstorms, etc.)

• When the windshield is obscured by fog,

mist, ice, dirt, etc.

• When the windshield is cracked or dam-

aged

• When the camera sensor is deformed or

dirty

• When the temperature of the camera

sensor is extremely high

• When the surrounding brightness level is

equal to that of headlights, tail lights or

fog lights

• When headlights or tail lights of vehicles

ahead are turned off, dirty, changing

color, or not aimed properly

• When the vehicle is hit by water, snow,

dust, etc. from a preceding vehicle

• When driving through an area of inter-

mittently changing brightness and dark-

ness

• When frequently and repeatedly driving

ascending/descending roads, or roads

with rough, bumpy or uneven surfaces

(such as stone-paved roads, gravel roads,

etc.)

• When frequently and repeatedly taking

curves or driving on a winding road

• When there is a highly reflective object

ahead of the vehicle, such as a sign or

mirror

• When the back of a preceding vehicle is

highly reflective, such as a container on a

truck

• When the vehicle’s headlights are dam-

aged or dirty, or are not aimed properly

• When the vehicle is listing or titling due to

a flat tire, a trailer being towed, etc.

• When the headlights are changed

between the high beams and low beams

repeatedly in an abnormal manner

• When the driver believes that the high

beams may be flashing or dazzling

pedestrians or other drivers

• When the vehicle is used in an area in

which vehicles travel on the opposite side

of the road of the country for which the

vehicle was designed, for example using

a vehicle designed for right-hand traffic in

a left-hand traffic area, or vice versa

■

Switching to the high beams

Push the lever away from you.

The Automatic High Beam indicator will
turn off and the high beam indicator will
turn on.
Pull the lever to its original position to acti-

Turning the high beams on/off
manually

282

4-3. Operating the lights and wipers

vate the Automatic High Beam system
again.

■

Switching to the low beams

Press the Automatic High Beam
switch.

The Automatic High Beam indicator will
turn off.
Press the switch to activate the Automatic
High Beam system again.

■

Temporarily switching to the low
beams

Pull the lever toward you and then
return it to its original position.

■

Temporarily switching to the low beams

It is recommended to switch to the low

beams when the high beam may cause

problems or distress to other drivers or

pedestrians nearby.

283

4-3. Operating the lights and wipers

Driving

: If equipped



Rear fog light switch

Turns the rear fog light off

Turns the rear fog light on

Releasing the switch ring returns it to

Operating the switch ring again turns only
the rear fog lights off.



Front and rear fog light switch

Turns the front and rear fog

lights off

Turns the front fog lights on

Turns both front and rear fog

lights on

Releasing the switch ring returns it to

Operating the switch ring again turns only
the rear fog lights off.

■

Fog lights can be used when



Vehicles with rear fog lights only

The headlights are turned on.



Vehicles with front and rear fog lights

Front fog lights: The headlights or front

position lights are turned on.
Rear fog lights: The front fog lights are

turned on.

Fog light switch

The fog lights secure excellent visi-
bility in difficult driving conditions,
such as in rain and fog.

Operating instructions

Content .. 9 10 11 12 ..
