Lexus NX300 (2021 year). Manual in english - page 14

235

4-5. Using the driving support systems

Driving

: If equipped

■

Types of sensors

Front corner sensors

Front center sensors

Rear corner sensors

Rear center sensors

■

Display

When the sensors detect an obstacle,
the following displays inform the driver
of the position and distance to the
obstacle.



Multi-information display

Front corner sensor operation

Front center sensor operation

Rear corner sensor operation

Rear center sensor operation



Navigation or multimedia system



Lexus parking assist monitor



Panoramic view monitor

Intuitive parking assist can be

Intuitive parking assist

The distance from your vehicle to
nearby obstacles when parallel
parking or maneuvering into a
garage is measured by the sensors
and communicated via the displays
and a buzzer. Always check the sur-
rounding area when using this sys-
tem.

System components

A
B
C
D

Turning intuitive parking assist
on/off

A
B
C
D

236

4-5. Using the driving support systems

enabled/disabled on the multi-informa-
tion display as following:

Press

of meter control

switches and select

Press

of meter control

switches and select “PKSA”.

Press

of meter control

switches, select

, and then press

to select the desired setting

(on/off).

When ON (enable) is selected, the
intuitive parking assist indicator comes
on.
When switched to OFF (disable) and
the intuitive parking assist is deacti-
vated, the system will not reactivate if it
is not switched to ON again from the

screen of the multi-information dis-

play (Will not reactivate via engine
switch operations).

■

The intuitive parking assist can be oper-

ated when

●

The engine switch is in IGNITION ON

mode.

●

Intuitive parking assist function is on.

●

The vehicle speed is less than about 6

mph (10 km/h).

●

A shift position other than P is selected.

■

Setting the buzzer volume

The buzzer volume can be adjusted on the

multi-information display. (



P.234)

■

Muting the buzzer sound

●

To mute the buzzer sound
The buzzer can be temporarily muted by
pressing

of the meter control

switches while an obstacle detection dis-
play is shown on the multi-information
display.

●

To cancel the mute

Mute will be automatically canceled in

the following situations.

• When the shift position is changed

• When the vehicle speed has reached or

exceeded approximately 6 mph (10

km/h) with the shift lever in D

• When the intuitive parking assist is turned

off once and turned on again

• When the engine switch is turned off

once and turned to IGNITION ON

mode again

• When a sensor is malfunctioning

■

Intuitive parking assist display

When an obstacle is detected while the

intuitive parking assist monitor is in use, the

warning indicator will appear in the upper

corner of the screen even if the display set-

ting has been set to off.

■

If “Parking Assist Unavailable” or “Park-

ing Assist Unavailable Clean Parking

Assist Sensor” is displayed on the multi-

information display

A sensor may be dirty or covered with snow

or ice. In such cases, if it is removed from

the sensor, the system should return to nor-

mal.

Also, due to the sensor being frozen at low

temperatures, a malfunction display may

appear or an obstacle may not be detected.

If the sensor thaws out, the system should

return to normal.

237

4-5. Using the driving support systems

Driving

■

If “Parking Assist Malfunction Visit Your

Dealer” is displayed on the multi-infor-

mation display

Depending on the malfunction of the sen-

sor, the device may not be working nor-

mally. Have the vehicle inspected by your

Lexus dealer.

■

Sensor detection information

●

The sensor’s detection areas are limited

to the areas around the vehicle’s bumper.

●

Certain vehicle conditions and the sur-

rounding environment may affect the

ability of a sensor to correctly detect an

obstacle. Particular instances where this

may occur are listed below.

• There is dirt, snow or ice on the sensor.

(Wiping the sensors will resolve this

problem.)

• The sensor is frozen. (Thawing the area

will resolve this problem.)

In especially cold weather, if a sensor is

frozen the screen may show an abnormal

display, or obstacles may not be

detected.

• The sensor is covered in any way.

• The vehicle is leaning considerably to one

side.

• On an extremely bumpy road, on an

incline, on gravel, or on grass.

• The vicinity of the vehicle is noisy due to

vehicle horns, motorcycle engines, air

brakes of large vehicles, or other loud

noises producing ultrasonic waves.

• There is another vehicle equipped with

parking assist sensors in the vicinity.

• The sensor is coated with a sheet of spray

or heavy rain.

• The vehicle is equipped with a fender

pole or wireless antenna.

• Towing eyelets are installed.

• The bumper or sensor receives a strong

impact.

• A backlit license plate, license plate

holder, etc., are installed.

• The vehicle is approaching a tall or

curved curb.

• In harsh sunlight or intense cold weather.

• The area directly under the bumpers is

not detected.

• If obstacles draw too close to the sensor.

• A non-genuine Lexus suspension (low-

ered suspension, etc.) is installed.

• People may not be detected if they are

wearing certain types of clothing.

In addition to the examples above, there are
instances in which, because of their shape,
signs and other objects may be judged by a
sensor to be closer than they are.

●

The shape of the obstacle may prevent a

sensor from detecting it. Pay particular

attention to the following obstacles:

• Wires, fences, ropes, etc.

• Cotton, snow and other materials that

absorb sound waves

• Sharply-angled objects

• Low obstacles

• Tall obstacles with upper sections pro-

jecting outwards in the direction of your

vehicle

●

The following situations may occur

during use.

• Depending on the shape of the obstacle

and other factors, the detection distance

may shorten, or detection may be impos-

sible.

• Obstacles may not be detected if they

are too close to the sensor.

• There will be a short delay between

obstacle detection and display. Even at

slow speeds, there is a possibility that the

obstacle will come within the sensor’s

detection areas before the display is

shown and the buzzer sounds.

• Thin posts or objects lower than the sen-

sor may not be detected when

approached, even if they have been

detected once.

• It might be difficult to hear beeps due to

the volume of audio system or air flow

noise of the air conditioning system.

■

Customization

Some functions can be customized.

(Customizable features:



P.425)

238

4-5. Using the driving support systems

■

Detection range of the sensors

Approximately 3.3 ft. (100 cm)

Approximately 4.9 ft. (150 cm)

Approximately 1.9 ft. (65 cm)

The diagram shows the detection range of
the sensors. Note that the sensors cannot
detect obstacles that are extremely close
to the vehicle.
The range of the sensors may change
depending on the shape of the object, etc.

■

Distance display

Sensors that detect an obstacle will illu-
minate continuously or blink.

WARNING

■

When using the intuitive parking

assist

Observe the following precautions.
Failure to do so may result in the vehicle

being unable to be driven safely and pos-

sibly cause an accident.

●

Do not use the sensor at speeds in

excess of 6 mph (10 km/h).

●

The sensors’ detection areas and reac-

tion times are limited. When moving

forward or reversing, check the areas

surrounding the vehicle (especially the

sides of the vehicle) for safety, and

drive slowly, using the brake to control

the vehicle’s speed.

●

Do not install accessories within the

sensors’ detection areas.

NOTICE

■

When using intuitive parking assist

In the following situations, the system

may not function correctly due to a sen-

sor malfunction, etc. Have the vehicle

checked by your Lexus dealer.

●

The intuitive parking assist operation

display flashes, and a buzzer sounds

when no obstacles are detected.

●

If the area around a sensor collides

with something, or is subjected to

strong impact.

●

If the bumper collides with something.

●

If the display shows continuously with-

out beeping, except when the buzzer

mute switch has been turned on.

●

If a display error occurs, first check the

sensor.

If the error occurs even if there is no

ice, snow or mud on the sensor, it is

likely that the sensor is malfunctioning.

■

Notes when washing the vehicle

Do not apply intensive bursts of water or

steam to the sensor area.

Doing so may result in the sensor mal-

functioning.

Sensor detection display, obsta-
cle distance

A
B
C

239

4-5. Using the driving support systems

Driving

: The images may differ from that shown

in the illustrations. (



P.235)

: Automatic buzzer mute function is

enabled. (



P.239)

: The distance segments will blink slowly.

■

Buzzer operation and distance to
an obstacle

A buzzer sounds when the sensors are
operating.



The buzzer sounds faster as the
vehicle approaches an obstacle.
When the vehicle comes within the

approximately 1.2 ft. (35 cm) of the
obstacle, the buzzer sounds contin-
uously.



When 2 or more obstacles are
detected simultaneously, the buzzer
system responds to the nearest
obstacle. If one or both come within
the above distances, the beep will
repeat a long tone, followed by fast
beeps.



Automatic buzzer mute function:
After a buzzer begins sounding, if
the distance between the vehicle
and the detected object does not
become shorter, the buzzer will be
muted automatically. (However, if
the distance between the vehicle
and object is 1.0 ft. (30 cm) or less,
this function will not operate.)

Approximate distance to

obstacle

Display

Rear center sensor: 4.9 ft.

(150 cm) to 1.9 ft. (65

cm)

Front center sensor: 3.3
ft. (100 cm) to 1.9 ft. (65

cm)

1.9 ft. (65 cm) to 1.5 ft. (45

cm)

1.5 ft. (45 cm) to 1.0 ft.

(30 cm)

1.0 ft. (30 cm) to 0.5 ft.

(15 cm)

Less than 0.5 ft. (15 cm)

240

4-5. Using the driving support systems

: If equipped

The system operates in the following
situations when a static object is
detected in the traveling direction of
the vehicle.

■

The vehicle is driven at low speeds
and the brake pedal is not
depressed, or is depressed too late

■

The accelerator pedal is depressed
too far

Parking Support Brake func-
tion (for static objects)

When a collision may occur with a
static object while parking or trav-
eling at low speeds, when the vehi-
cle suddenly moves forward due to
mistaken accelerator pedal opera-
tion, or when the vehicle moves due
to the shift lever being in the wrong
position, the sensors detect static
objects to the front or rear in the
traveling direction of the vehicle,
and the system operates to lessen
impact with static objects such as
walls, and reduce resulting dam-
age.

Examples of system operation

241

4-5. Using the driving support systems

Driving

■

When the shift lever is mistakenly
in D and the vehicle moves forward

■

Sensor positions and types

Front corner sensors

Front center sensors

Rear corner sensors

Rear center sensors

This system can be enabled/disabled
on the multi-information display.

WARNING

■

For safe use

Do not rely solely upon the system. Rely-

ing solely upon the system may lead to an

unexpected accident.

●

Driving safely is the sole responsibility

of the driver. Pay careful attention to

the surrounding conditions in order to

ensure safe driving. The Parking Sup-

port Brake function (for static objects)

can provide support to lessen the

severity of collisions. However, it may

not operate depending on the situa-

tion.

●

The Parking Support Brake function

(for static objects) is not a system

designed to completely stop the vehi-

cle. Furthermore, even if the Parking

Support Brake function (for static

objects) is able to stop the vehicle,

brake control is canceled after

approximately 2 seconds, so depress

the brake pedal immediately.

Sensor positions and types

NOTICE

■

Preventing sensor malfunctions

●

If the area around a sensor is subjected

to an impact, equipment may not oper-

ate properly due to a sensor malfunc-

tion. Have the vehicle inspected by

your Lexus dealer.

●

When using a high-pressure washer to

wash the vehicle, do not spray water

directly on the sensors. The sensors

may not function properly if subjected

to an impact from strong water pres-

sure.

●

When using steam to wash the vehicle,

do not direct steam too close to the

sensors. The sensors may not function

properly if subjected to steam.

Changing settings of the Park-
ing Support Brake function (for
static objects)

A
B
C
D

242

4-5. Using the driving support systems

Press “

” or “

” of the meter

control switches and select

Press “

” or “

” of the meter

control switches and select

Press

on the meter control

switches to enable/disable the sys-
tem.
The PKSB OFF indicator comes on
when the Parking Support Brake
function is OFF (not operating).

When the Parking Support Brake func-

tion is switched OFF, system operation
does not resume until the function is
switched back ON through the set-
tings screen on the multi-information
display. (System operation does not
resume by operating the engine
switch.)

■

Engine output restraint control

When there is a static object, where a potential collision may occur, is detected, the
increase of the vehicle speed is restrained due to engine output being controlled.

Accelerator pedal

Operation

243

4-5. Using the driving support systems

Driving

Brake pedal

Engine output

Braking force

OFF

Control starts

Collision is likely

DOWN

“BRAKE!” is displayed in the multi-information display

“Switch to Brake” is displayed in the multi-information display

■

Brake Control

If the accelerator is continuously depressed even after the engine output is being
controlled, the brakes are engaged and the vehicle decelerates.

Accelerator pedal

Brake pedal

Engine output

Braking force

B
C
D

E
F

A
B
C
D

244

4-5. Using the driving support systems

OFF

Control starts

Collision is likely

DOWN

Collision possibility is very high

“BRAKE!” is displayed in the multi-information display

“Switch to Brake” is displayed in the multi-information display

■

Operation starting conditions

When the PKSB OFF indicator is not illumi-

nated or flashing (



P.241, 376) and all of

the following conditions are met, the system

operates.

●

Engine output restriction control

• The Parking Support Brake function (for

static objects) is on.

• The vehicle speed is 10 mph (15 km/h) or

less.

• There is a static object in the traveling

direction of the vehicle (6 to 13 ft. [2 to 4

m] ahead).

• The system determined that a stronger

than-normal brake operation was neces-

sary to avoid a collision.

●

Brake control

• Engine output restriction control is being

performed.

• The system determined that an emer-

gency brake operation was necessary to

avoid a collision.

■

Operation ending conditions

In any of the following situations, the system

stops operating.

●

Engine output restriction control

• The Parking Support Brake function (for

static objects) has been turned off

(stopped).

• The collision became avoidable with nor-

mal brake operation.

• The static object is no longer in the travel-

ing direction of the vehicle (6 to 13 ft. [2

to 4 m] ahead).

●

Brake control

• The Parking Support Brake function (for

static objects) has been turned off

(stopped).

• Approximately 2 seconds elapsed after

the vehicle was stopped by brake control.

• The brake pedal was depressed after the

vehicle was stopped by brake control.

• The static object is no longer in the travel-

ing direction of the vehicle (6 to 13 ft. [2

to 4 m] ahead).

■

Sensor detection range

The detection range of the Parking Support

Brake function (for static objects) differs

from the detection range of the clearance

sonar (



P.238).

Therefore, even if the clearance sonar

detects a static object and provides a warn-

ing, the Parking Support Brake function (for

static objects) may not start operating.

■

Static objects not detected by the sen-

sors

The following static objects may not be

detected by the sensors.

●

Objects such as people, cloth and snow,

that are difficult for sonic waves to reflect

off of. (In particular, people may also not

be detected depending on the type of

clothing they are wearing.)

●

Objects not perpendicular with the

ground, objects not at a right angle to the

traveling direction of the vehicle, uneven

E
F

245

4-5. Using the driving support systems

Driving

objects or waving objects

●

Low objects

●

Thin objects such as wires, fences, ropes

and signposts

●

Objects that are extremely close to the

bumper

●

Sharply-angled objects

●

Tall objects with upper sections project-

ing outwards in the direction of your vehi-

cle

■

Situations in which the Parking Support

Brake function (for static objects) may

not operate

When driving with the shift lever in N

■

Situations when the system may operate

even though there is no possibility of a

collision

In the following situations, the system may

operate even though there is no possibility

of a collision.

●

Environmental influence

• The vehicle is driven on a narrow road

• The vehicle is driven on a gravel road or

in an area with tall grass

• The vehicle is driven toward a banner or

flag, a low-hanging branch or a boom

barrier (such as those used at railroad

crossings, toll gates and parking lots).

• There is a static object on the shoulder of

the road (when the vehicle is driven in a

narrow tunnel, on a narrow bridge or on a

narrow road)

• The vehicle is being parallel parked

• There is a rut or hole in the surface of the

road

• When the vehicle is driven on a metal

cover (grating), such as those used for

drainage ditches

• The vehicle is driven on a steep slope

• The sensor is covered by water on a

flooded road

●

Influence from the weather

• Ice, snow, dirt, etc., has adhered to the

sensor (if removed, the system returns to

normal)

• Heavy rain or water strikes the vehicle

• In severe weather such as fog, snow or a

sand storm

●

Influence from other sonic waves

• An ultrasonic wave source is nearby, such

as the horn or clearance sonar of another

vehicle, a vehicle detector, a motorcycle

engine or the air brake of a large vehicle

• Electronic components (such as a backlit

license plate (especially fluorescent

types), fog lights, a fender pole or a wire-

less antenna) are installed near the sen-

sors

●

Changes in the vehicle

• The vehicle is tilted a large amount

• The height of the vehicle has drastically

changed due to the carried load (the

nose tilts up or down)

• The direction of the sensor has deviated

due to a collision or other impact

■

Situations in which the system may not

operate normally

In the following situations, the system may

not operate normally.

●

Environmental influence

• There is a static object that cannot be

detected between the vehicle and

another static object that can be

detected

• A static object such as another vehicle, a

motorcycle, a bicycle or a pedestrian cuts

in front of the vehicle or jumps out from

the side.

●

Influence from the weather

• The area around the sensor is extremely

hot or cold

246

4-5. Using the driving support systems

• The vehicle is driven on a gravel road or

in an area with tall grass

• Ice, snow, dirt, etc., has adhered to the

sensor (if removed, the system returns to

normal)

• Heavy rain or water strikes the vehicle

• In severe weather such as fog, snow or a

sand storm

●

Influence from other sonic waves

• An ultrasonic wave source is nearby, such

as the horn or clearance sonar of another

vehicle, a vehicle detector, a motorcycle

engine or the air brake of a large vehicle

• Electronic components (such as a backlit

license plate (especially fluorescent

types), fog lights, a fender pole or a wire-

less antenna) are installed near the sen-

sors

●

Changes in the vehicle

• The vehicle is tilted a large amount

• The height of the vehicle has drastically

changed due to the carried load (the

nose tilts up or down)

• The direction of the sensor has deviated

due to a collision or other impact

■

When “Parking Support Brake Unavail-

able” is displayed on the multi-informa-

tion display and the PKSB OFF indicator

flashes

●

Ice, snow, dirt, etc., may have adhered to

the sensor. If this occurs, remove the ice,

snow, dirt, etc., from the sensor to return

the system to normal.

Also, a warning message may be dis-

played at low temperatures due to ice

forming on the sensor, and the sensor

may not detect static objects. Once the

ice melts, the system will return to normal.

●

If this message is shown even after

removing dirt from the sensor, or shown

when the sensor was not dirty to begin

with, have the vehicle inspected by your

Lexus dealer.

●

System initialization may not have been

performed after removal and installation

of the battery. Perform system initializa-

tion.

■

When removing and installing the bat-

tery

The system needs to be initialized.
The system can be initialized by driving the

vehicle straight ahead for 5 seconds or

more at a speed of approximately 22 mph

(35 km/h) or higher.

■

When “Parking Support Brake Mal-

function Visit Your Dealer” is displayed

on the multi-information display, the

PKSB OFF indicator flashes and the

buzzer sounds

The system may not be operating properly.

Have the vehicle inspected by your Lexus

dealer.

WARNING

■

In order for the system to operate

properly

Make sure to observe the following pre-

cautions regarding the sensors

(



P.238). Failure to observe these pre-

cautions may cause the sensors not to

operate properly, and may result in an

unexpected accident.

●

Do not perform work such as modifi-

cation, disassembly or painting

●

Only perform replacements using

genuine parts

●

Do not subject the area around the

sensors to any impacts

247

4-5. Using the driving support systems

Driving

When the engine output restriction
control or brake control operates, the
buzzer sounds and a message is dis-
played on the multi-information dis-

play, head-up display and
navigation/multimedia system screen
to alert the driver.

Depending on the situation, output restric-
tion control operates to either limit accel-
eration or restrict output as much as
possible.

■

Engine output restriction control is
operating (acceleration limitation
control)

■

Engine output restriction control is
operating (control to restrict out-
put as much as possible)

WARNING

●

Do not damage the sensors, and

always keep them clean

■

Handling the suspension

Do not modify the suspension, as

changes to the height or incline of the

vehicle may prevent the sensors from

correctly detecting static objects, may

cause the system not operate, or may

cause the system to operate unnecessar-

ily.

NOTICE

■

Preventing unnecessary operation

In the following situations, turn the Park-

ing Support Brake function (for static

objects) OFF. The system may operate

even though there is no possibility of a

collision.

●

A chassis roller, chassis dynamo, free

roller or similar equipment is being

used for an inspection, etc.

●

The vehicle is being loaded onto a ship,

truck or other transport vessel

●

The suspension has been lowered or

tires that have a different size than the

genuine tires are equipped

●

The height of the vehicle has drastically

changed due to the carried load (the

nose tilts up or down).

●

A towing hook is installed

●

When using an automatic car wash

Display and buzzer for engine
output restriction control and
brake control

Situation

Acceleration at a certain

speed or higher is not

possible.

Multi-informa-

tion dis-

play/Head-up

display

“Object Detected Accel-

eration Reduced”

Naviga-

tion/multime-

dia system

screen



PKSB OFF

Indicator

Not illuminated

Buzzer



Situation

A stronger than normal

brake operation is neces-

sary

Multi-informa-

tion dis-

play/Head-up

display

“BRAKE!”

Naviga-

tion/multime-

dia system

screen

248

4-5. Using the driving support systems

■

Brake control is operating

■

The vehicle is stopped by system
operation

: If the accelerator pedal is not depressed,

“Press Brake Pedal” will be displayed.

■

If the Parking Support Brake has oper-

ated

If the vehicle is stopped due to operation of

the Parking Support Brake, the Parking

Support Brake will be disabled and the

PKSB OFF indicator will illuminate. If the

Parking Support Brake operates unneces-

sarily, brake control can be canceled by

depressing the brake pedal or waiting for

approximately 2 seconds for it to automati-

cally be canceled. Then, the vehicle can be

operated by depressing the accelerator

pedal.

■

Re-enabling the Parking Support Brake

To re-enable the Parking Support Brake

when it has been disabled due to system

operation, perform any of the following

operations. At this time, the PKSB OFF indi-

cator will turn off (



P.74)

●

Turn the PKSB system on (



P.241)

●

Turn the engine switch off, and then back

to IGNITION ON mode

●

Shift the shift lever to P

●

Drive with no operation targets in the

traveling direction of the vehicle

●

Change the traveling direction of the

vehicle

■

Lexus parking assist-sensor buzzer

Regardless of whether the Lexus parking

assist-sensor buzzer is enabled or not

(



P.235), if the Parking Support Brake

function (static objects) is enabled

(



P.241), the front or rear sensors detect

an object and brake control is performed,

the Lexus parking assist-sensor buzzer will

sound to notify the driver of the approxi-

mate distance to the object.

■

In the unlikely event that the Parking

Support Brake function (for static

objects) mistakenly operates at a cross-

ing or elsewhere

Even in the unlikely event that the Parking

Support Brake function (for static objects)

mistakenly operates at a crossing or else-

where, brake control is canceled after

approximately 2 seconds, allowing you to

proceed forward and leave the area. Fur-

thermore, brake control is also canceled

PKSB OFF

Indicator

Not illuminated

Buzzer

Short beep

Situation

Emergency braking is

necessary

Multi-informa-

tion dis-

play/Head-up

display

“BRAKE!”

Naviga-

tion/multime-

dia system

screen

PKSB OFF

Indicator

Not illuminated

Buzzer

Short beep

Situation

The vehicle is stopped

after brake control oper-

ation

Multi-informa-

tion dis-

play/Head-up

display

“Switch to Brake”

Naviga-

tion/multime-

dia system

screen

“Press Brake Pedal”

PKSB OFF

Indicator

Illuminated

Buzzer

Short beep

249

4-5. Using the driving support systems

Driving

when the brake pedal is depressed.

Depressing the accelerator pedal again

allows you to proceed forward and leave

the area.

: If equipped

BSM main switch

Pressing the switch turns the system on or

BSM (Blind Spot Monitor)

The Blind Spot Monitor uses the
sensors installed behind the rear
bumper. The system is intended to
assist the driver check areas that
are not easily visible. The system
has the following two functions:



The Blind Spot Monitor function

Assists the driver in making the decision
when changing lanes



The Rear Cross Traffic Alert func-
tion

Assists the driver when backing up

These functions use the same sen-
sors.

System components

250

4-5. Using the driving support systems

off. When the switch is set to on, the
switch’s indicator illuminates and the
buzzer sounds. This switch is for both Blind
Spot Monitor function and Rear Cross
Traffic Alert function.

BSM outside rear view mirror indi-
cators

Blind Spot Monitor function:
When a vehicle is detected in a blind spot
of the outside rear view mirrors or
approaching rapidly from behind into a
blind spot, the outside rear view mirror
indicator on the detected side will illumi-
nate. If the turn signal lever is operated
toward the detected side, the outside rear
view mirror indicator will flash.
Rear Cross Traffic Alert function:
When a vehicle approaching from the right
or left at the rear of the vehicle is detected,
both outside rear view mirror indicators
will flash.

Rear Cross Traffic Alert buzzer
(Rear Cross Traffic Alert function
only)

When a vehicle approaching from the right
or left rear of the vehicle is detected, a
buzzer sounds from behind the right-hand
rear seat.

Navigation/multimedia system
screen (Rear Cross Traffic Alert
function only)

If a vehicle approaching from the right or
left at the rear of the vehicle is detected,
the Rear Cross Traffic Alert icon
(



P.254) for the detected side will be dis-

played.

■

The BSM outside rear view mirror indi-

cators visibility

When under strong sunlight, the BSM out-

side rear view mirror indicator may be diffi-

cult to see.

■

Rear Cross Traffic Alert buzzer hearing

Rear Cross Traffic Alert function may be

difficult to hear over loud noises such as

high audio volume.

■

When “Blind Spot Monitor Unavailable”

is shown on the multi-information dis-

play

Water, snow mud, etc., may be built up in

the vicinity of the sensor area of bumper.

(



P.252) Removing the water, snow, mud,

etc., from the vicinity of the sensor area

bumper should return it to normal. Also, the

sensor may not function normally when

used in extremely hot or cold weather.

■

When “Blind Spot Monitor System Mal-

function Visit Your Dealer” is shown on

the multi-information display

There may be a sensor malfunction or volt-

age abnormality. Have the vehicle

inspected at a Lexus dealer.

Content .. 12 13 14 15 ..
