P.68)

Doing so may cause the hybrid battery,

electrical components, etc. to mal-

function or catch fire.

●

Do not get any of the SRS components

or wiring in the vehicle interior wet.

(



P.28)

An electrical malfunction may cause

the airbags to deploy or not function

properly, resulting in death or serious

injury.

■

Cleaning the interior (especially

instrument panel)

Do not use polish wax or polish cleaner.

The instrument panel may reflect off the

windshield, obstructing the driver’s view

and leading to an accident, resulting in

death or serious injury.

NOTICE

■

Cleaning detergents

●

Do not use the following types of

detergent, as they may discolor the

vehicle interior or cause streaks or

damage to painted surfaces:

• Non-seat portions: Organic sub-

stances such as benzene or gasoline,

alkaline or acidic solutions, dye, and

bleach

• Seats: Alkaline or acidic solutions,

such as thinner, benzene, and alcohol

●

Do not use polish wax or polish

cleaner. The instrument panel’s or

other interior part’s painted surface

may be damaged.

■

Preventing damage to leather sur-

faces

Observe the following precautions to

avoid damage to and deterioration of

leather surfaces:

●

Remove any dust or dirt from leather

surfaces immediately.

●

Do not expose the vehicle to direct

sunlight for extended periods of time.

Park the vehicle in the shade, espe-

cially during summer.

●

Do not place items made of vinyl, plas-

tic, or containing wax on the uphol-

stery, as they may stick to the leather

surface if the vehicle interior heats up

significantly.

■

Water on the floor

Do not wash the vehicle floor with water.

Vehicle systems such as the audio system

may be damaged if water comes into

contact with electrical components such

as the audio system above or under the

floor of the vehicle. Water may also

cause the body to rust.

291

6-1. Maintenance and care

Mai
nte

e a

are

To prevent the hybrid battery (traction
battery) air intake vents from becom-
ing clogged, clean them periodically.

■

Cleaning the air intake vents

Remove the dust from the air intake
vents with a vacuum cleaner etc.
Make sure to only use a vacuum to
suck out dust and clogs. Attempting to
blow out dust and clogs using a com-

pressed air blow gun, etc. may push it
into the air intake vents. (

P.293)

If dust and clogs cannot be completely
removed with the air intake vent covers
installed, remove the covers and clean the
filters.

■

Cleaning the filters

If dust and clogs cannot be completely
removed with the air intake vent covers
installed, remove the air intake vent
covers and clean the filters.

Remove the grille.

Remove the filter.

NOTICE

■

When cleaning the inside of the wind-

shield

Do not allow glass cleaner to contact the

lens. Also, do not touch the lens.

(



P.194)

■

Cleaning the inside of the rear win-

dow

●

Do not use glass cleaner to clean the

rear window, as this may cause dam-

age to the rear window defogger

heater wires or antenna. Use a cloth

dampened with lukewarm water to

gently wipe the window clean. Wipe

the window in strokes running parallel

to the heater wires or antenna.

●

Be careful not to scratch or damage

the heater wires or antenna.

Cleaning the hybrid battery
(traction battery) air intake vents
(LC500h)

292

6-1. Maintenance and care

Remove dust using a vacuum
cleaner etc. to clean the filter.

Also, remove dust on the grille as well as on

the filter using a vacuum cleaner.

Install the filter in its original posi-
tion, and then install the grille.

If a warning message was displayed
on the multi-information display
before cleaning the filters, start the
hybrid system and check that the
message disappears.

It may take several minutes before the

warning message disappears.

■

Scheduled maintenance of the air

intake filters is necessary when

In some situations such as when the vehicle

is used frequently or in heavy traffic or dusty

areas, the air intake filters may need to be

cleaned more regularly.

For details, refer to “Owner’s Manual Sup-

plement” or “Scheduled Maintenance”.

■

Air intake vents maintenance

●

If the vehicle is driven with the air intake

vents clogged, charging/discharging of

the hybrid battery (traction battery) may

become limited and the fuel consumption

may increase.

●

Depending on the conditions under

which the vehicle is used, the air intake

vents may need to be cleaned more reg-

ularly.

■

Cleaning the air intake vents

●

Dust in the air intake vents may interfere

with the cooling of the hybrid battery

(traction battery). If charging/discharging

of the hybrid battery (traction battery)

becomes limited, the distance that the

vehicle can be driven using the electric

motor (traction motor) may be reduced

and the fuel economy may be reduced.

Inspect and clean the air intake vents

periodically.

●

Improper handling may result in damage

to the air intake vent covers or filters. If

you have any concerns about cleaning

the filters, contact your Lexus dealer.

●

The necessary cleaning interval of the air

intake vents will differ according to the

vehicle usage environment.

■

If “Maintenance Required for Traction

battery Cooling Parts See owner’s man-

ual” is displayed on the multi-informa-

tion display

●

If this warning message is displayed on

the multi-information display, remove the

air intake vent covers and clean the filters.

(



P.291)

●

After cleaning the air intake vents, start

the hybrid system and check that the

warning message is no longer displayed.

After the hybrid system is started, it may

be necessary to drive the vehicle up to

approximately 20 minutes before the

warning message disappears. If the warn-

ing message does not disappear after

driving for appropriately 20 minutes,

have the vehicle inspected by your Lexus

dealer.

WARNING

■

When cleaning the hybrid battery

(traction battery) air intake vents/fil-

ters

●

Do not use water or other liquids to

clean the air intake vents/filters. If

water is applied to the hybrid battery

(traction battery) or other compo-

nents, a malfunction or fire may occur.

●

When the air intake vent covers (under

the both sides of the rear seat) are to

be removed, make sure to turn the

power switch off to stop the hybrid sys-

tem.

293

6-1. Maintenance and care

Mai
nte

e a

are



Remove dirt using a water-damp-
ened soft cloth or synthetic chamois.



Wipe the surface with a dry soft
cloth to remove any remaining
moisture.

■

Cleaning the areas with satin-finish

metal accents

The metal areas use a layer of real metal for

the surface. It is necessary to clean them

regularly. If dirty areas are left uncleaned for

long periods of time, they may be difficult to

clean.



Remove dirt and dust using a vac-
uum cleaner.



Wipe off any excess dirt and dust
with a soft cloth dampened with
diluted detergent.

Use a diluted water solution of approxi-
mately 5% neutral wool detergent.



Wring out any excess water from
the cloth and thoroughly wipe off all
remaining traces of detergent.



Wipe the surface with a dry soft

NOTICE

■

When cleaning the air intake vents

When cleaning the air intake vents, make

sure to only use a vacuum to suck out

dust and clogs. If a compressed air blow

gun, etc. is used to blow out dust and

clogs, the dust or clogs may be pushed

into the air intake vents, which may affect

the performance of the hybrid battery

(traction battery) and cause a malfunc-

tion.

■

To prevent damage to the vehicle

●

Do not allow water or foreign matter to

enter the air intake vents when the

cover is removed.

●

Carefully handle the removed filters so

that it will not be damaged.

If the filters are damaged, have them

replaced with new filters by your Lexus

dealer.

●

Make sure to reinstall the filters and

cover to their original positions after

cleaning.

●

Do not install anything to the air intake

vents other than the exclusive filters for

this vehicle or use the vehicle without

the filters installed.

■

If “Maintenance Required for Trac-

tion battery Cooling Parts See

owner’s manual” is displayed on the

multi-information display

If the vehicle is continuously driven with

the warning message (indicating that

charging/discharging of the hybrid bat-

tery [traction battery] may become lim-

ited) displayed, the hybrid battery

(traction battery) may malfunction. If the

warning message is displayed, clean the

air intake vents immediately.

Cleaning the areas with satin-fin-
ish metal accents

Cleaning the leather areas

294

6-1. Maintenance and care

cloth to remove any remaining
moisture. Allow the leather to dry in
a shaded and ventilated area.

■

Caring for leather areas

Lexus recommends cleaning the interior of

the vehicle at least twice a year to maintain

the quality of the vehicle’s interior.



Remove dirt and dust using a vac-
uum cleaner.



Wipe it off with a soft cloth damp-
ened with neutral detergent diluted
to approximately 1%.



Wring out any excess water from
the cloth and thoroughly wipe off
remaining traces of detergent and
water.



Brush the surfaces using a soft
brush.

Do not brush hard as doing so may cause
damage.



Wipe the surfaces clean with a soft
cloth that has been dampened in
cold or lukewarm water and
squeezed out.



Allow the artificial leather (Alcan-
tara

®*

) to dry in a shaded and venti-

lated area.

: “Alcantara

” is a registered trademark

of Alcantara S.p.A.

Cleaning the synthetic leather
areas

Cleaning the artificial leather
(Alcantara

®*

) areas

295

6-2. Maintenance

Mai
nte

e a

are

6-2.Maintenance

■

Repair and replacement

It is recommended that genuine Lexus parts

be used for repairs to ensure performance

of each system. If non-Lexus parts are used

in replacement or if a repair shop other than

a Lexus dealer performs repairs, confirm

the warranty coverage.

■

Allow inspection and repairs to be per-

formed by a Lexus dealer

●

Lexus technicians are well-trained spe-

cialists and are kept up to date with the

latest service information. They are well

informed about the operations of all sys-

tems on your vehicle.

●

Keep a copy of the repair order. It proves

that the maintenance that has been per-

formed is under warranty coverage. If any

problem should arise while your vehicle is

under warranty, your Lexus dealer will

promptly take care of it.

General maintenance should be per-
formed on a daily basis. This can be
done by yourself or by a Lexus dealer.

Scheduled maintenance should be
performed at specified intervals
according to the maintenance sched-
ule.

For details about maintenance items and
schedules, refer to the “Warranty and Ser-
vice Guide”, “Owner’s Manual Supple-
ment” or “Scheduled Maintenance”.

■

Resetting the message indicating main-

tenance is required

After the required maintenance is per-

formed according to the maintenance

schedule, please reset the message.

To reset the message, follow the procedure

described below:

Press

of the meter control

switches and select

Press

of the meter control

switches and select “Vehicle Settings”.

Then press “OK”.

Maintenance requirements

To ensure safe and economical driv-
ing, day-to-day care and regular
maintenance are essential. It is the
owner’s responsibility to perform
regular checks. Lexus recommends
the following maintenance:

WARNING

■

If your vehicle is not properly main-

tained

Improper maintenance could result in

serious damage to the vehicle and possi-

ble death or serious injury.

■

Handling of the 12-volt battery

●

Engine exhaust, some of its constitu-

ents, and a wide variety of automobile

components contain or emit chemicals

known to the State of California to

cause cancer and birth defects and

other reproductive harm. Work in a

well ventilated area.

●

Oils, fuels and fluids contained in vehi-

cles as well as waste produced by

component wear contain or emit

chemicals known to the State of Cali-

fornia to cause cancer and birth

defects or other reproductive harm.

Avoid exposure and wash any affected

area immediately.

●

12-volt battery posts, terminals and

related accessories contain lead and

lead compounds which are known to

cause brain damage. Wash your hands

after handling. (



P.311)

General maintenance

Scheduled maintenance

296

6-2. Maintenance

Press

of the meter control

switches and select “Scheduled Mainte-

nance”. Then press “OK”.

Select “Yes” and press “OK”.

A message will be displayed when the reset

procedure has been completed.

You can perform some maintenance
procedures by yourself.
Please be aware that do-it-yourself
maintenance may affect warranty cov-
erage.

The use of Lexus repair manuals is recom-
mended.
For details about warranty coverage, refer
to the separate “Owner’s Guide”, “War-
ranty and Service Guide”, “Owner’s Man-
ual Supplement” or “Warranty Booklet”.

Do-it-yourself maintenance

General maintenance

Listed below are the general main-
tenance items that should be per-
formed at the intervals specified in
the “Warranty and Service Guide”
or “Owner’s Manual Supplement”.
It is recommended that any prob-
lem you notice should be brought to
the attention of your Lexus dealer
or qualified service shop for advice.

WARNING

■

If the engine is running <hybrid sys-

tem is operating>

Turn the engine <hybrid system> off and

ensure that there is adequate ventilation

before performing maintenance checks.

Engine compartment

Items

Check points

Brake fluid

Is the brake fluid at the
correct level?
(



Engine coolant
(LC500)

Is the engine coolant at
the correct level?
(



Engine/power
control unit cool-
ant (LC500h)

Is the engine/power
control unit coolant at
the correct level?
(



Engine oil

Is the engine oil at the
correct level?
(



P.305)

Exhaust system

There should not be
any fumes or strange
sounds.

297

6-2. Maintenance

Mai
nte

e a

are

Radiator/con-
denser

The radiator and con-
denser should be free
from foreign objects.
(



Washer fluid

Is there sufficient
washer fluid?
(



P.310)

Trunk

Items

Check points

12-volt battery

Check the battery fluid
level and connections.
(



P.311)

Vehicle interior

Items

Check points

Accelerator
pedal

• The accelerator

pedal should move
smoothly (without
uneven pedal effort
or catching).

Automatic trans-
mission “Park”
mechanism
(LC500)/Hybrid
transmission
“Park” mecha-
nism (LC500h)

• When parked on a

slope and the shift
position is in P, is the
vehicle securely
stopped?

Items

Check points

Brake pedal

• Does the brake

pedal move
smoothly?

• Does the brake

pedal have appro-
priate clearance
from the floor?

• Does the brake

pedal have the cor-
rect amount of free
play?

Brakes

• The vehicle should

not pull to one side
when the brakes are
applied.

• The brakes should

work effectively.

• The brake pedal

should not feel
spongy.

• The brake pedal

should not get too
close to the floor
when the brakes are
applied.

Head restraints

• Do the head

restraints move
smoothly and lock
securely?

Indicators/buzz-
ers

• Do the indicators

and buzzers function
properly?

Lights

• Do all the lights

come on?

• Are the headlights

aimed correctly?

Items

Check points

298

6-2. Maintenance

Parking brake

• Move smoothly?
• When parked on a

slope and the park-
ing brake is on, is the
vehicle securely
stopped?

Seat belts

• Do the seat belts

operate smoothly?

• The seat belts should

not be damaged.

Seats

• Do the seat controls

operate properly?

Steering wheel

• Does the steering

wheel rotate
smoothly?

• Does the steering

wheel have the cor-
rect amount of free
play?

• There should not be

any strange sounds
coming from the
steering wheel.

Vehicle exterior

Items

Check points

Doors/trunk

• Do the doors/trunk

operate smoothly?

Engine hood

• Does the engine

hood lock system
work properly?

Fluid leaks

• There should not be

any signs of fluid
leakage after the
vehicle has been
parked.

Items

Check points

Tires

• Is the tire inflation

pressure correct?

• The tires should not

be damaged or
excessively worn.

• Have the tires been

rotated according to
the maintenance
schedule?

• The wheel nuts

should not be loose.

Windshield wip-
ers

• The wiper blades

should not show any
signs of cracking,
splitting, wear, con-
tamination or defor-
mation.

• The wiper blades

should clear the
windshield without
streaking or skip-
ping.

Items

Check points

299

6-2. Maintenance

Mai
nte

e a

are

The OBD system determines that a
problem exists somewhere in the emis-
sion control system. Your vehicle may
not pass the I/M test and may need to
be repaired. Contact your Lexus
dealer to service the vehicle.



When the 12-volt battery is discon-
nected or discharged
Readiness codes that are set during
ordinary driving are erased.
Also, depending on your driving
habits, the readiness codes may not
be completely set.



When the fuel tank cap is loose
The malfunction indicator lamp
comes on indicating a temporary
malfunction and your vehicle may
not pass the I/M test.

The error code in the OBD system will
not be cleared unless the vehicle is
driven 40 or more times.

Contact your Lexus dealer to prepare
the vehicle for re-testing.

Emission inspection and
maintenance (I/M) pro-
grams

Some states have vehicle emission
inspection programs which include
OBD (On Board Diagnostics)
checks. The OBD system monitors
the operation of the emission con-
trol system.

If the malfunction indicator lamp
comes on

Your vehicle may not pass the
I/M test in the following situa-
tions:

When the malfunction indicator
lamp still remains on after sev-
eral driving trips

If your vehicle does not pass the
I/M test

300

6-3. Do-it-yourself maintenance

6-3.Do-it-yourself maintenance

Do-it-yourself service pre-
cautions

If you perform maintenance by
yourself, be sure to follow the cor-
rect procedure as given in these
sections.

Maintenance

Items

Parts and tools

12-volt battery
condition
(



P.311)

• Grease
• Conventional wrench

(for terminal clamp
bolts)

Brake fluid
level
(



• SAE J1703 or FMVSS

No.116 DOT 3 brake
fluid

• Rag or paper towel
• Funnel (used only for

adding brake fluid)

Engine coolant
level (LC500)
(

• “Toyota Super Long Life

Coolant” or a similar
high quality ethylene
glycol-based non-sili-
cate, non-amine, non-
nitrite and non-borate
coolant with long-life
hybrid organic acid
technology
For the U.S.A.:
“Toyota Super Long Life
Coolant” is pre-mixed
with 50% coolant and
50% deionized water.
For Canada:
“Toyota Super Long Life
Coolant” is pre-mixed
with 55% coolant and
45% deionized water.

• Funnel (used only for

adding coolant)

Engine/power
control unit
coolant level
(LC500h)
(

• “Toyota Super Long Life

• Funnel (used only for

adding coolant)

Items

Parts and tools

301

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Engine oil level
(



P.305)

• “Toyota Genuine Motor

Oil” or equivalent

• Rag or paper towel
• Funnel (used only for

adding engine oil)

Fuses
(



P.331)

• Fuse with same amper-

age rating as original

Headlight aim

• Phillips-head screw-

driver

Light bulbs
(



P.336)



Radiator and
condenser
(





Tire inflation
pressure
(



P.325)

• Tire pressure gauge
• Compressed air source

Washer fluid
(



P.310)

• Water or washer fluid

containing antifreeze
(for winter use)

• Funnel (used only for

adding water or washer
fluid)

WARNING

The engine compartment contains many

mechanisms and fluids that may move

suddenly, become hot, or become elec-

trically energized. To avoid death or seri-

ous injury, observe the following

precautions.

■

When working on the engine com-

partment

●

LC500h: Make sure that the “IGNI-

TION ON” on the multi-information

display and the “READY” indicator are

both off.

●

Keep hands, clothing and tools away

from the moving fan and engine drive

belt.

Items

Parts and tools

●

LC500: Be careful not to touch the

engine, radiator, exhaust manifold, etc.

right after driving as they may be hot.

Oil and other fluids may also be hot.

LC500h: Be careful not to touch the

engine, power control unit, radiator,

exhaust manifold, etc. right after driv-

ing as they may be hot. Oil and other

fluids may also be hot.

●

Do not leave anything that may burn

easily, such as paper and rags, in the

engine compartment.

●

Do not smoke, cause sparks or expose

an open flame to fuel. Fuel fumes are

flammable.

■

When working near the electric cool-

ing fan or radiator grille

Be sure the engine switch <power

switch> is off.

With the engine switch <power switch> in

IGNITION ON mode <ON mode>, the

electric cooling fan may automatically

start to run if the air conditioning is on

and/or the coolant temperature is high.

(
