Lexus LC Cabriolet (2021 year). Manual in english - page 13

288

4-5. Using the driving support systems

Example:

The RCTA function is operational when

The RCTA function operates when all of the

following conditions are met:

The RCTA function is on.

The shift position is in R.

The vehicle speed is less than approxi-

mately 8 km/h (5 mph).

The approaching vehicle speed is

between approximately 8 km/h (5 mph)

and 28 km/h (18 mph).

Conditions under which the RCTA

function will not detect a vehicle

The RCTA function is not designed to

detect the following types of vehicles

and/or objects:

Vehicles approaching from directly

behind

Vehicles backing up in a parking space

next to your vehicle

Vehicles that the sensors cannot detect

due to obstructions

Guardrails, walls, signs, parked vehicles
and similar stationary objects

Small motorcycles, bicycles, pedestrians,
etc.

Vehicles moving away from your vehicle

Vehicles approaching from the parking
spaces next to your vehicle

: Depending on the conditions, detection

of a vehicle and/or object may occur.

Conditions under which the RCTA

function may not function correctly

The RCTA function may not detect vehi-

cles correctly in the following situations:

• When the sensor is misaligned due to a

strong impact to the sensor or its sur-

rounding area

• When mud, snow, ice, a sticker, etc. is

covering the sensor or surrounding area

on the rear bumper

• When driving on a road surface that is

wet with standing water during bad

weather, such as heavy rain, snow, or fog

• When multiple vehicles are approaching

with only a small gap between each vehi-

cle

• When a vehicle is approaching at high

speed

• When a towing eyelet is installed to the

rear of the vehicle.

• When backing up on a slope with a sharp

change in grade

• When backing out of a shallow angle

parking spot

Approaching vehi-

cle speed

Approximate

alert distance

28 km/h (18 mph)

(fast)

20 m (65 ft.)

8 km/h (5 mph)

(slow)

5.5 m (18 ft.)

289

4-5. Using the driving support systems

ivin
g

• Immediately after the RCTA function is

turned on

• Immediately after the engine is started

with the RCTA function on

• When the sensors cannot detect a vehi-

cle due to obstructions

Instances of the RCTA function unneces-

sarily detecting a vehicle and/or object

may increase in the following situations:

• When a vehicle passes by the side of your

vehicle

• When the parking space faces a street

and vehicles are being driven on the

street

• When the distance between your vehicle

and metal objects, such as a guardrail,

wall, sign, or parked vehicle, which may

reflect electrical waves toward the rear of

the vehicle, is short

• When a towing eyelet is installed to the

rear of the vehicle.

WARNING

Cautions regarding the use of the

function

The driver is solely responsible for safe

driving. Always drive safely, taking care

to observe your surroundings.
The RCTA function is only a supplemen-

tary function which alerts the driver that a

vehicle is approaching from the right or

left at the rear of the vehicle. As the

RCTA function may not function cor-

rectly under certain conditions, the

driver’s own visual confirmation of safety

is necessary. Over reliance on this func-

tion may lead to an accident resulting

death or serious injury.

290

4-5. Using the driving support systems

: If equipped

ECB (Electronically Controlled
Brake System)

The electronically controlled system
generates braking force correspond-
ing to the brake operation

ABS (Anti-lock Brake System)

Helps to prevent wheel lock when the
brakes are applied suddenly, or if the
brakes are applied while driving on a
slippery road surface

Brake assist

Generates an increased level of brak-
ing force after the brake pedal is
depressed when the system detects a
panic stop situation

VSC (Vehicle Stability Control)

Helps the driver to control skidding
when swerving suddenly or turning on
slippery road surfaces

TRC (Traction Control)

Helps to maintain drive power and
prevent the drive wheels from spinning

Exhaust Gas Filter system

The Exhaust Gas Filter system is
designed to collect particulate mat-
ter in the exhaust gases using an
exhaust gas filter installed to the
exhaust pipes.

NOTICE

To prevent the Exhaust Gas Filter

system from failing

Do not use fuel other that the specified

type

Do not modify the exhaust pipes

Driving assist systems

To keep driving safety and perfor-
mance, the following systems oper-
ate automatically in response to
various driving situations. Be
aware, however, that these systems
are supplementary and should not
be relied upon too heavily when
operating the vehicle.

Summary of the driving assist
systems

291

4-5. Using the driving support systems

ivin
g

when starting the vehicle or accelerat-
ing on slippery roads

Active Cornering Assist (ACA) (if
equipped)

Helps to prevent the vehicle from drift-
ing to the outer side by performing
inner wheel brake control when
attempting to accelerate while turning

Hill-start assist control

Helps to reduce the backward move-
ment of the vehicle when starting on an
uphill

EPS (Electric Power Steering)

Employs an electric motor to reduce
the amount of effort needed to turn the
steering wheel

AVS (Adaptive Variable Suspen-
sion System)

By independently controlling the
damping force of the shock absorbers
for each of the 4 wheels according to
the road and driving conditions, this
system helps riding comfort with supe-
rior vehicle stability, and helps good
vehicle posture
Also, the damping force changes
depending on the selected driving
mode. (



P.262)

VDIM (Vehicle Dynamics Inte-
grated Management)

Provides integrated control of the
ABS, brake assist, TRC, VSC, hill-start
assist control and EPS systems
Helps to maintain vehicle stability
when swerving on slippery road sur-

faces by controlling the brakes, engine
output, steering assist (if equipped),
and steering ratio (if equipped)

Emergency brake signal

When the brakes are applied suddenly,
the stop lights automatically flash to
alert the vehicle behind

Secondary Collision Brake

When the SRS airbag sensor detects a
collision and the system operates, the
brakes and brake lights are automati-
cally controlled to reduce the vehicle
speed and help reduce the possibility
of further damage due to a secondary
collision.

When the TRC/VSC/ABS systems are

operating

The slip indicator light will flash while the

TRC/VSC/ABS systems are operating.

Disabling the TRC system

If the vehicle gets stuck in mud, dirt or snow,

the TRC system may reduce power from

the engine to the wheels. Pressing the

switch to turn the system off may

make it easier for you to rock the vehicle in

order to free it.
To turn the TRC system off, quickly press

and release the

switch.

The “Traction Control Turned Off” will be
shown on the multi-information display.

292

4-5. Using the driving support systems

Press the

switch again to turn the

system back on.

Turning off both TRC and VSC systems

To turn the TRC and VSC systems off,

press and hold the

switch for more

than 3 seconds while the vehicle is stopped.
The VSC OFF indicator light will come on

and the “Traction Control Turned Off” will
be shown on the multi-information display.

Press the

switch again to turn the

systems back on.

: PCS (Pre-Collision System) will also be

disabled (only Pre-Collision warning is
available). The PCS warning light will
come on and a message will be displayed
on the multi-information display.
(



P.239)

When the message is displayed on the

multi-information display showing that

TRC has been disabled even if the

switch has not been pressed

TRC is temporary deactivated. If the infor-

mation continues to show, contact any

authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer.

Operating conditions of hill-start assist

control

When the following four conditions are met,

the hill-start assist control will operate:

The shift position is in a position other

than P or N (when starting off for-

ward/backward on an upward incline).

The vehicle is stopped.

The accelerator pedal is not depressed.

The parking brake is not engaged.

Automatic system cancelation of hill-

start assist control

The hill-start assist control will turn off in any

of the following situations:

The shift position is shifted to P or N.

The accelerator pedal is depressed.

The parking brake is engaged.

2 seconds at maximum elapsed after the

brake pedal is released

Sounds and vibrations caused by the

ABS, brake assist, VSC, TRC and hill-

start assist control systems

A sound may be heard from the engine

compartment when the brake pedal is

depressed repeatedly, when the engine is

started or just after the vehicle begins to

move. This sound does not indicate that a

malfunction has occurred in any of these

systems.

Any of the following conditions may

occur when the above systems are oper-

ating. None of these indicates that a mal-

function has occurred.

• Vibrations may be felt through the vehi-

cle body and steering.

• A motor sound may be heard also after

the vehicle comes to a stop.

Active Cornering Assist operation

sounds and vibrations

When the Active Cornering Assist is oper-

ated, operation sounds and vibrations may

be generated from the brake system, but

this is not a malfunction.

ECB operating sound

ECB operating sound may be heard in the

following cases, but it does not indicate that

a malfunction has occurred.

Operating sound heard from the engine

compartment when the brake pedal is

operated.

Motor sound of the brake system heard

293

4-5. Using the driving support systems

ivin
g

from the front part of the vehicle when

the driver’s door is opened.

Operating sound heard from the engine

compartment when one or two minutes

passed after the stop of the engine.

EPS operation sound

When the steering wheel is operated, a

motor sound (whirring sound) may be

heard. This does not indicate a malfunction.

Automatic reactivation of TRC and

VSC systems

After turning the TRC and VSC systems off,

the systems will be automatically re-

enabled in the following situations:

When the engine switch is turned off

If only the TRC system is turned off, the

TRC will turn on when vehicle speed

increases

If both the TRC and VSC systems are

turned off, automatic re-enabling will not

occur when vehicle speed increases.

Operating conditions of Active Corner-

ing Assist

The system operates when the following

occurs.

TRC/VSC can operate

The driver is attempting to accelerate

while turning

The system detects that the vehicle is

drifting to the outer side

The brake pedal is released

Operating conditions of emergency

brake signal

When the following conditions are met, the

emergency brake signal will operates:

The emergency flashers are off.

Actual vehicle speed is over 55 km/h

(35 mph).

The system judges from the vehicle

deceleration that it is a sudden braking

operation

Automatic system cancelation of emer-

gency brake signal

The emergency brake signal will be can-

celed in any of the following situations:

The emergency flashers are turned on.

The system judges from the vehicle

deceleration that is not a sudden braking

operation.

Secondary Collision Brake operating

conditions

The system operates when the SRS airbag

sensor detects a collision while the vehicle

is in motion.
However, the system does not operate in

any of the following situations.

The vehicle speed is below 10 km/h (6

mph)

Components are damaged

Secondary Collision Brake automatic

cancellation

The system is automatically canceled in any

of the following situations:

The vehicle speed drops below approxi-

mately 10 km/h (6 mph)

A certain amount of time elapses during

operation

The accelerator pedal is depressed a

large amount

Reduced effectiveness of the EPS sys-

tem

The effectiveness of the EPS system is

reduced to prevent the system from over-

heating when there is frequent steering

input over an extended period of time. The

steering wheel may feel heavy as a result.

Should this occur, refrain from excessive

steering input or stop the vehicle and turn

the engine off. The EPS system should

return to normal within 10 minutes.

WARNING

The ABS does not operate effectively

when

The limits of tire gripping performance

have been exceeded (such as exces-

sively worn tires on a snow covered

road).

294

4-5. Using the driving support systems

WARNING

The vehicle hydroplanes while driving

at high speed on wet or slick roads.

Stopping distance when the ABS is

operating may exceed that of normal

conditions

The ABS is not designed to shorten the

vehicle’s stopping distance. Always

maintain a safe distance from the vehicle

in front of you, especially in the following

situations:

When driving on dirt, gravel or snow-

covered roads

When driving with tire chains

When driving over bumps in the road

When driving over roads with pot-

holes or uneven surfaces

TRC/VSC may not operate effec-

tively when

Directional control and power may not

be achievable while driving on slippery

road surfaces, even if the TRC/VSC sys-

tem is operating.
Drive the vehicle carefully in conditions

where stability and power may be lost.

Active Cornering Assist does not

operate effectively when

Do not overly rely on Active Corner-

ing Assist. Active Cornering Assist

may not operate effectively when

accelerating down slopes or driving on

slippery road surfaces.

When Active Cornering Assist fre-

quently operates, Active Cornering

Assist may temporarily stop operating

to ensure proper operation of the

brakes, TRC and VSC.

Hill- start assist control does not

operate effectively when

Do not overly rely on hill-start assist

control. Hill-start assist control may

not operate effectively on steep

inclines and roads covered with ice.

Unlike the parking brake, hill-start

assist control is not intended to hold

the vehicle stationary for an extended

period of time. Do not attempt to use

hill-start assist control to hold the vehi-

cle on an incline, as doing so may lead

to an accident.

When the TRC/ABS/VSC is acti-

vated

The slip indicator light flashes. Always

drive carefully. Reckless driving may

cause an accident. Exercise particular

care when the indicator light flashes.

When the TRC/VSC systems are

turned off

Be especially careful and drive at a

speed appropriate to the road condi-

tions. As these are the systems to help

ensure vehicle stability and driving force,

do not turn the TRC/VSC systems off

unless necessary.

Replacing tires

Make sure that all tires are of the speci-

fied size, brand, tread pattern and total

load capacity. In addition, make sure that

the tires are inflated to the recom-

mended tire inflation pressure level.
The ABS, TRC and VSC systems will not

function correctly if different tires are

installed on the vehicle.
Contact any authorized Lexus retailer or

Lexus authorized repairer, or any reli-

able repairer for further information

when replacing tires or wheels.

Handling of tires and the suspension

Using tires with any kind of problem or

modifying the suspension will affect the

driving assist systems, and may cause a

system to malfunction.

295

4-5. Using the driving support systems

ivin
g

WARNING

Secondary Collision Brake

Do not rely solely upon the Secondary

Collision Brake. This system is designed

to help reduce the possibility of further

damage due to a secondary collision,

however, that effect changes according

to various conditions. Overly relying on

the system may result in death or serious

injury.

296

4-6. Driving tips

4-6.Driving tips



Use fluids that are appropriate to
the prevailing outside temperatures.

• Engine  oil
• Engine  coolant
• Washer  fluid



Have a service technician inspect
the condition of the battery.



Have the vehicle fitted with four
snow tires.

Ensure that all tires are the specified size
and the same brand.



Tire chains can only be installed on
the rear tires. However, tire chains
cannot be installed on 275/35RF21
or 275/40RF20 rear tires.

Before installing tire chains, change all four
tires and wheels to those of the specified
size for use with tire chains (front tires:
245/45RF20, rear tires: 245/45RF20,
wheels: 20 x 8 1/2 J 25 inset). Use the
specified type of tire chains and install
them on the rear tires only.
For details, contact any authorized Lexus
retailer or Lexus authorized repairer, or
any reliable repairer.

Winter driving tips

Carry out the necessary prepara-
tions and inspections before driving
the vehicle in winter. Always drive
the vehicle in a manner appropriate
to the prevailing weather condi-
tions.

Preparation for winter

WARNING

Driving with snow tires

Observe the following precautions to

reduce the risk of accidents.
Failure to do so may result in a loss of

vehicle control and cause death or seri-

ous injury.

Use tires of the specified size.

Maintain the recommended level of air

pressure.

Do not drive at speeds in excess of the

speed limit or the speed limit specified

for the snow tires being used.

Use snow tires on all, not just some

wheels.

Driving with tire chains

Observe the following precautions to

reduce the risk of accidents.
Failure to do so may result in the vehicle

being unable to be driven safely, and may

cause death or serious injury.

Do not drive in excess of the speed

limit specified for the tire chains being

used, or 50 km/h (30 mph), which-

ever is lower.

Avoid driving on bumpy road surfaces

or over potholes.

Avoid sudden acceleration, abrupt

steering, sudden braking and shifting

operations that cause sudden engine

braking.

Slow down sufficiently before entering

a curve to ensure that vehicle control

is maintained.

Do not use LKA (Lane-Keeping

Assist) system.

297

4-6. Driving tips

ivin
g

Perform the following according to the
driving conditions:



Do not try to forcibly open a door or
a side window, or move wipers that
are frozen. Pour warm water over
the frozen area to melt the ice, and
then wipe away the water immedi-
ately to prevent it from freezing.



When the outside door handle is
frozen, unlock the doors using the
wireless remote control. If the out-
side door handles remain retracted
and do not move even if the doors
are unlocked using the wireless
remote control, pour warm water
over the frozen area to melt the ice
and wipe away the water immedi-
ately to prevent it from freezing. The
outside door handle may not retract
due to ice, however, the outside
door handle will return to the nor-
mal position after the ice melts.



To ensure proper operation of the
climate control system fan, remove
any snow that has accumulated on
the air inlet vents in front of the

windshield.



Check for and remove any excess
ice or snow that may have accumu-
lated on the exterior lights, soft top
roof, chassis, around the tires or on
the brakes.



Remove any snow or mud from the
bottom of your shoes before getting
in the vehicle.

To protect windshield wipers



P.216

Accelerate the vehicle slowly, keep a
safe distance between you and the
vehicle ahead, and drive at a reduced
speed suitable to road conditions.

Park the vehicle and shift the shift posi-
tion to P without setting the parking
brake. The parking brake may freeze
up, preventing it from being released. If
the vehicle is parked without setting
the parking brake, make sure to block
the wheels.
Failure to do so may be dangerous

NOTICE

Repairing or replacing snow tires

Request repairs or replacement of snow

tires from any authorized Lexus retailer

or Lexus authorized repairer, or any reli-

able repairer.
This is because the removal and attach-

ment of snow tires affects the operation

of the tire pressure warning valves and

transmitters.

Before driving the vehicle

NOTICE

When the side windows or rear quar-

ter windows are frozen



P.182

When removing ice that accumulates

on the windshield glass and windows

Do not strike the ice. The windshield

glass and windows may be cracked.

When driving the vehicle

When parking the vehicle

298

4-6. Driving tips

because it may cause the vehicle to
move unexpectedly, possibly leading
to an accident.



Vehicles with front and rear tires of
the same size

Use the correct tire chain size when
mounting the tire chains.
Chain size is regulated for each tire
size.

Side chain (3 mm [0.12 in.] in diam-
eter)

Cross chain (4 mm [0.16 in.] in
diameter)



Vehicles with front and rear tires of
differing sizes

Tire chains cannot be mounted.
Snow tires should be used instead.

Regulations regarding the use of tire
chains vary depending on location and
type of road. Always check local regu-
lations before installing chains.

Tire chain installation

Observe the following precautions when

installing and removing chains:

Install and remove tire chains in a safe

location.

Install tire chains on the rear tires. Do not

install tire chains on the front tires.

Install tire chains on rear tires as tightly as

possible. Retighten chains after driving

0.5 - 1.0 km (1/4 - 1/2 mile).

Install tire chains following the instruc-

tions provided with the tire chains.

To enable the windshield wipers to be
lifted when heavy snow or icy condi-
tions are expected, change the rest
position of the windshield wipers from
the retracted position below the hood
to the service position using the wiper
lever. (



P.217)

Selecting tire chains

Regulations on the use of tire
chains

NOTICE

Fitting tire chains

The tire pressure warning valves and

transmitters may not function correctly

when tire chains are fitted.

Windshield wipers

299

rior f
eat
ur

Interior features

5-1. Remote Touch

Remote Touch............................

300

5-2. Lexus Climate Concierge

Lexus Climate Concierge.....

304

5-3. Using the air conditioning system

Automatic air conditioning system

........................................................

306

Heated steering wheel/seat heat-

ers/seat ventilators/neck heat-
ers..................................................

314

5-4. Using the interior lights

Interior lights list..........................

318

5-5. Using the storage features

List of storage features ...........

320

Trunk features.............................

322

5-6. Using the other interior features

Other interior features ...........

323

300

5-1. Remote Touch

5-1.Remote Touch

Switches

“MAP” button/ “HOME” button

“MAP” button: Press to display the current
location.

“HOME” button: Press to display the home
screen.

“MENU” button

Press to display the menu screen.

Back button

Press to display the previous screen.

Touchpad

Slide your finger on the touchpad and
move the pointer to select a function, letter
and screen button.
Press the touchpad to enter the selected
function, letter or screen button. Certain
finger movements on the touchpad can
perform functions, such as changing map

scalings and scrolling list screens.

Sub function button

When

is displayed on the screen, a

function screen assigned to the screen can
be displayed.

: Refer to the “NAVIGATION SYSTEM

OWNER’S MANUAL”.

Using the touchpad

Select: Touch the touchpad to
select the desired button on the
screen.

Enter: The buttons on the screen
can be selected by either depress-
ing or double tapping on the
touchpad. Once a button has been
selected, the screen will change.

Touch operation

Operations are performed by touch-
ing the touchpad with your finger.



Trace

Trace the pad surface while maintaining
contact with the touchpad. Moving the
cursor and the pointer.

Remote Touch

The Remote Touch can be used to
operate Center Display.
For details on the Remote Touch,
refer to the “NAVIGATION SYS-
TEM OWNER’S MANUAL”.

Remote Touch operation

301

5-1. Remote Touch

rior f
eat
ur



Double tap

Tap the touchpad twice, quickly. Select the
button on the screen.



Flick

Quick and long movement along the
touchpad with your finger. Move the list
screen.



Pinch in/Pinch out

Slide fingers toward each other or apart on
the touchpad. Change the scale of the
map.

Menu screen

Press the “MENU” button on the
Remote Touch to display the menu
screen.
The display may differ depending on
the type of the system.

NOTICE

To prevent damage to the Remote

Touch

Observe the following precautions. Fail-

ure to do so may cause damage to the

Remote Touch.

Do not allow the Remote Touch to

come into contact with food, liquid,

stickers or lit cigarettes.

Do not subject the Remote Touch to

excessive pressure or strong impact.

Do not push the touchpad with a

strong force or use a sharp pointed

object to operate the pad.

Center Display overview

302

5-1. Remote Touch

: Refer to the “NAVIGATION SYSTEM

OWNER’S MANUAL”.

: If equipped

: This function is not made available in

some countries or areas.

Split-screen display

Different information can be displayed on the left and right of the screen. For
example, air conditioning system screen can be displayed and operated while the
fuel consumption information screen is being displayed. The large screen on the
left of the display is called the main display, and the small screen to the right is
called the side display.

Switch

Function

Select to display the destination
screen.

*1, 2

Select to operate the audio con-
trol screen.

Select to display the hands-free
control screen.

Select to display application
screen.

*1, 3

When an Apple
CarPlay/Android Auto connec-
tion is established and this but-
ton displays “Apple
CarPlay”/“Android Auto”,
select to display the home
screen of Apple
CarPlay/Android Auto.

*1, 3

Select to display the information
screen.

(



P.103)

Select to display the general set-
tings screen.

Select to display the air condi-
tioning control screen.
(



P.309)

Switch

Function

303

5-1. Remote Touch

rior f
eat
ur

Main display

For details about the functions and
operation of the main display, refer to
the respective section and “NAVIGA-
TION SYSTEM OWNER’S MAN-
UAL”.

Side display

The following functions can be dis-
played and operated on the side dis-
play.

Select

to display the desired

screen.

Navigation system

Audio

Vehicle information (



P.104)

Air conditioning system (



P.310)

Show/hide the side display

: Refer to the “NAVIGATION SYSTEM

OWNER’S MANUAL”.

Screen display during low temperatures

When the ambient temperature is

extremely low, screen response may be

delayed even if the Remote Touch is oper-

ated.

A
B
C

Content .. 11 12 13 14 ..
