434

7-1. Essential information



Remove the seat belt first.



If the door can be opened, open the
door and exit the vehicle.



If the door can not be opened, open
the window using the power window
switch and exit the vehicle through
the window.



If the window can not be opened
using the power window switch,
remain calm, wait until the water
level inside the vehicle rises to the
point that the water pressure inside
of the vehicle equals the water pres-
sure outside of the vehicle, and then
open the door and exit the vehicle.

If the vehicle is trapped in
rising water

In the event the vehicle is sub-
merged in water, remain calm and
perform the following.

WARNING

Q

Using an emergency hammer

*

 for

emergency escape

The front side windows and rear side

windows, as well as the rear window can
be shattered by an emergency hammer

*



used for emergency escape.
However, an emergency hammer can

not shatter the windshield as it is lami-

nated glass.

*

: Contact any authorized Lexus retailer

or Lexus authorized repairer, or any
reliable repairer, or aftermarket acces-
sory manufacturer for further informa-
tion about an emergency hammer.

Q

Escaping the vehicle from the window

There are cases where escaping the

vehicle from the window is not possible

due to seating position, passenger body

type, etc.
When using an emergency hammer,

consider your seat location and the size

of the window opening to ensure that the

opening is accessible and large enough

to escape.

435

7

7-2. Steps to take in an emergency

Wh
en

 troubl
e ar
ises

7-2.Steps to take in an emergency

If your vehicle needs to be
towed

If towing is necessary, we recom-
mend having your vehicle towed by
any authorized Lexus retailer or
Lexus authorized repairer, or any
reliable repairer or commercial
towing service, using a wheel-lift
type truck or flatbed truck.
Use a safety chain system for all
towing, and abide by all state/pro-
vincial and local laws.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

Q

When towing the vehicle

LC500: Be sure to transport the vehicle

with all four wheels raised off the ground.

If the vehicle is towed with the tires con-

tacting the ground, the drivetrain and

related parts may be damaged or an

accident may occur due to a change in

direction of the vehicle.

LC500h: Be sure to transport the vehi-

cle with all four wheels raised off the

ground. If the vehicle is towed with the

tires contacting the ground, the drive-

train and related parts may be damaged,

an accident may occur due to a change

in direction of the vehicle or electricity

generated by the operation of the motor

may cause a fire to occur depending on

the nature of the damage or malfunction.

Q

While towing

O

When towing using cables or chains,

avoid sudden starts, etc. which place

excessive stress on the towing eyelets,

cables or chains. The towing eyelets,

cables or chains may become dam-

aged, broken debris may hit people,

and cause serious damage.

O

Do not turn the engine switch <power

switch> off.

This may lead to an accident as the

rear wheels will be locked by the park-

ing lock. Also, there is a possibility that

the steering wheel is locked and can-

not be operated.

Q

Installing towing eyelets to the vehi-

cle

Make sure that towing eyelets are

installed securely.

If not securely installed, towing eyelets

may come loose during towing.

436

7-2. Steps to take in an emergency

In the following situations, it is not pos-
sible to be towed by another vehicle
using cables or chains, as the rear
wheels may be locked due to the park-
ing lock. Contact any authorized Lexus
retailer or Lexus authorized repairer,
or any reliable repairer or commercial
towing service.



There is a malfunction in the shift
control system. (



P.208, 213,

454)



There is a malfunction in the engine
immobilizer system <immobilizer
system>. (



P.77)



There is a malfunction in the smart
entry & start system. (



P.462)



The 12-volt battery is discharged.
(



P.465)

The following may indicate a problem
with your transmission. Contact any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer or commercial towing service
before towing.



LC500: The engine is running but
the vehicle does not move.



LC500h: The hybrid system warn-
ing message is shown on the multi-
information display and the vehicle
does not move.



The vehicle makes an abnormal
sound.



From the front

Use a towing dolly under the rear
wheels.

NOTICE

Q

To prevent damage to the vehicle

when towing using a wheel-lift type

truck

O

Do not tow the vehicle from the rear

when the engine switch <power

switch> is off. The steering lock mecha-

nism is not strong enough to hold the

front wheels straight.

O

When raising the vehicle, ensure ade-

quate ground clearance for towing at

the opposite end of the raised vehicle.

Without adequate clearance, the vehi-

cle could be damaged while being

towed.

Q

To prevent damage to the vehicle

when towing with a sling-type truck

Do not tow with a sling-type truck, either

from the front or rear.

Q

To prevent damage to the vehicle

during emergency towing

Do not secure cables or chains to the

suspension components.

Situations when it is not possible
to be towed by another vehicle

Situations when it is necessary to
contact dealers before towing

Towing with a wheel-lift type
truck

437

7

7-2. Steps to take in an emergency

Wh
en

 troubl
e ar
ises



From the rear

Use a towing dolly under the front
wheels.

When using a flat-bed truck to trans-
port the vehicle, use tire strapping
belts. Refer to the owner’s manual of
the flat-bed truck for the tire strapping
method.
In order to suppress vehicle movement
during transportation, set the parking
brake and turn the engine switch
<power switch> off.

If a tow truck is not available in an

emergency, your vehicle may be tem-
porarily towed using cables or chains
secured to the emergency towing eye-
lets. This should only be attempted on
hard surfaced roads for short distances
at under 30 km/h (18 mph).
A driver must be in the vehicle to steer
and operate the brakes. The vehicle’s
wheels, drive train, axles, steering and
brakes must be in good condition.

To have your vehicle towed by another
vehicle, the towing eyelet must be
installed to your vehicle. Install the tow-
ing eyelet using the following proce-
dure.

1

Take out the screwdriver and the
towing eyelet. (



P.412)

2

Remove the eyelet cover using a
flathead screwdriver.

To protect the bodywork, place a rag

between the screwdriver and the vehicle

body as shown in the illustration.

NOTICE

Q

Towing with a sling-type truck

Do not tow with a sling-type truck to pre-

vent body damage.

Using a flatbed truck

Emergency towing

Emergency towing procedure

438

7-2. Steps to take in an emergency

3

Insert the towing eyelet into the
hole and tighten partially by hand.

4

Tighten down the towing eyelet
securely using the screwdriver or
hard metal bar.

5

Securely attach cables or chains to
the towing eyelet.

Take care not to damage the vehicle body.

6

Enter the vehicle being towed and
start the engine <hybrid system>.

If the engine <hybrid system> does not

start, turn the engine switch <power

switch> to IGNITION ON mode <ON

mode>.

7

Shift the shift position to N and
release the parking brake.

Turn automatic mode off. (



P.232)

Q

While towing

If the engine is not running <hybrid system is

off>, the power assist for the brakes and

steering will not function, making steering

and braking more difficult.

Q

Wheel nut wrench

Wheel nut wrench can be purchased at any

authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer.

439

7

7-2. Steps to take in an emergency

Wh
en

 troubl
e ar
ises



Fluid leaks under the vehicle.
(Water dripping from the air condi-
tioning after use is normal.)



Flat-looking tires or uneven tire
wear



Engine coolant temperature gauge
continually points higher than nor-
mal.



Changes in exhaust sound



Excessive tire squeal when corner-
ing



Strange noises related to the sus-
pension system



Pinging or other noises related to
the engine <hybrid system>



Engine missing, stumbling or run-
ning roughly



Appreciable loss of power



Vehicle pulls heavily to one side
when braking



Vehicle pulls heavily to one side
when driving on a level road



Loss of brake effectiveness, spongy
feeling, pedal almost touches the
floor

If you think something is
wrong

If you notice any of the following
symptoms, your vehicle probably
needs adjustment or repair. Con-
tact any authorized Lexus retailer
or Lexus authorized repairer, or any
reliable repairer as soon as possi-
ble.

Visible symptoms

Audible symptoms

Operational symptoms

440

7-2. Steps to take in an emergency

Follow the procedure below to restart
the engine after the system is activated.

1

Turn the engine switch to ACCES-
SORY mode or turn it off.

2

Restart the engine.

Fuel pump shut off system
(LC500)

To minimize the risk of fuel leakage
when the engine stalls or when an
airbag inflates upon collision, the
fuel pump shut off system stops the
supply of fuel to the engine.

Restarting the engine

NOTICE

Q

Before starting the engine

Inspect the ground under the vehicle.

If you find that fuel has leaked onto the

ground, the fuel system has been dam-

aged and is in need of repair. Do not

restart the engine.

441

7

7-2. Steps to take in an emergency

Wh
en

 troubl
e ar
ises

Q

Brake system warning light (warning buzzer)

Q

Charging system warning light

*

*

: This light illuminates on the multi-information display.

If a warning light turns on or a warning buzzer sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by any authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.

Actions to the warning lights or warning buzzers

Warning

light

Details/Actions

(red)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning

This light also comes on when the parking brake is not released. If the light
turns off after the parking brake is fully released the system is operating nor-
mally.



Immediately stop the vehicle in a safe place and contact any authorized
Lexus retailer or Lexus authorized repairer, or any reliable repairer.
Continuing to drive the vehicle may be dangerous.



Indicates that the brake pads are worn out (only the right-side pads can be
detected)



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer.

Warning

light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and contact any authorized
Lexus retailer or Lexus authorized repairer, or any reliable repairer.

442

7-2. Steps to take in an emergency

Q

Low engine oil pressure warning light (warning buzzer)

*

*

: This light illuminates on the multi-information display.

Q

Malfunction indicator lamp (warning buzzer)

*

: If equipped

Q

SRS warning light

Warning

light

Details/Actions

Indicates that the engine oil pressure is too low



Immediately stop the vehicle in a safe place and contact any authorized
Lexus retailer or Lexus authorized repairer, or any reliable repairer.

Warning

light

Details/Actions

Indicates a malfunction in:



The electronic engine control system;



The hybrid system (LC500h);



The electronic throttle control system;



The electronic automatic transmission control system (LC500);



The electronic hybrid transmission control system (LC500h); or



The Exhaust Gas Filter system

*



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

Indicates a malfunction in:



The SRS airbag system; or



The seat belt pretensioner system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

443

7

7-2. Steps to take in an emergency

Wh
en

 troubl
e ar
ises

Q

ABS warning light (warning buzzer)

Q

Electric power steering system warning light (warning buzzer)

Q

PCS warning light (warning buzzer)

Warning

light

Details/Actions

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

(red)

or

(yellow)

Indicates a malfunction in the EPS (Electric Power Steering) system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

(Flashes or

illuminates)

(if equipped)

When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-Collision System).



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily unavailable, cor-
rective action may be necessary.



Follow the instructions displayed on the multi-information display.
(



P.257, 451)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability Control) system
is disabled, the PCS warning light will illuminate.



P.266

444

7-2. Steps to take in an emergency

Q

LKA indicator

*

*

: This light illuminates on the multi-information display.

Q

Slip indicator

*

: Only when controlled by the VDIM system.

Warning

light

Details/Actions

(orange)

(if equipped)

Indicates a malfunction in the LKA (Lane-Keeping Assist)



When “Lane Keeping Assist Unavailable” is displayed on the multi-
information display, turn the LKA (Lane-Keeping Assist) system off,
drive the vehicle for a short time, and then turn the LKA (Lane-Keeping
Assist) system back on. (



P.270)

When a message other than above is displayed, follow the instructions
displayed in the message.

Warning

light

Details/Actions

Indicates a malfunction in:



The VSC (Vehicle Stability Control) system;



The TRC (Traction Control) system; or



The hill-start assist control system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

The light will flash when the VSC, TRC, ABS, VGRS

*

 or DRS

*

 system is

operating.

445

7

7-2. Steps to take in an emergency

Wh
en

 troubl
e ar
ises

Q

Brake Override System warning light/Drive-Start Control warning light
(warning buzzer)

*

*

: This light illuminates on the multi-information display.

Q

Brake hold operated indicator

Q

Parking brake indicator

Warning

light

Details/Actions

When the warning light flashes (and a buzzer sounds):
Indicates a malfunction in the Brake Override System or Drive-Start Control



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Indicates that the shift position was changed while depressing the accelera-
tor pedal and Drive-Start Control was operated



Momentarily release the accelerator pedal.

When the warning light flashes (and a buzzer does not sound):
Indicates that the accelerator and brake pedals are being depressed simulta-
neously



Release the accelerator pedal and depress the brake pedal.

Warning

light

Details/Actions

(flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

(flashes)

Indicates a malfunction in the parking brake system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

446

7-2. Steps to take in an emergency

Q

Brake system warning light

Q

Low fuel level warning light

Q

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

*

*

: Driver’s and front passenger’s seat belt warning buzzer:

The driver’s and front passenger’s seat belt warning buzzer sounds to alert the driver and
front passenger that his or her seat belt is not fastened. If the seat belt is unfastened, the
buzzer sounds intermittently for a certain period of time after the vehicle reaches a certain
speed.

Q

Rear passengers’ seat belt reminder lights (warning buzzer

*1

)

*2

*1

: Rear passengers’ seat belt warning buzzer:

Warning

light

Details/Actions

(yellow)

Indicates a malfunction in:



The electronically controlled brake system



The regenerated braking system (LC500h)



The parking brake system



Have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

Warning

light

Details/Actions

Indicates that remaining fuel is approximately 12.1L [3.2 gal., 2.7 Imp.gal.] or
less



Refuel the vehicle.

Warning

light

Details/Actions

Warns the driver and/or front passenger to fasten their seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front passenger’s seat belt
also needs to be fastened to make the warning light (warning buzzer)
turn off.

Warning

light

Details/Actions

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

447

7

7-2. Steps to take in an emergency

Wh
en

 troubl
e ar
ises

The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger that his or
her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds intermittently
for a certain period of time, after the seat belt is fastened and unfastened and the vehicle
reaches a certain speed.

*2

: This light illuminates on the center panel.

Q

Master warning light (warning buzzer)

Q

Tire pressure warning light

Q

High coolant temperature warning light (warning buzzer)

*

*

: This light illuminates on the multi-information display.

Warning

light

Details/Actions

A buzzer sounds and the warning light comes on and flashes to indicate that
the master warning system has detected a malfunction.



P.451

Warning

light

Details/Actions

When the light comes on:
Low tire inflation pressure such as



Natural causes (



P.449)



Flat tire (



P.457)



Adjust the tire inflation pressure to the specified level.
The light will turn off after a few minutes. In case the light does not turn
off even if the tire inflation pressure is adjusted, have the system
checked by any authorized Lexus retailer or Lexus authorized repairer,
or any reliable repairer.

When the light comes on after blinking for 1 minute:
Malfunction in the tire pressure warning system



Have the system checked by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer.

Warning

light

Details/Actions

Indicates that the engine coolant temperature increases



Immediately stop the vehicle in a safe place.
Handling method (



P.474, 476)

448

7-2. Steps to take in an emergency

Q

Hybrid system overheat warning light (warning buzzer)

*

 (LC500h)

*

: This light illuminates on the multi-information display.

Q

Front passenger detection sensor, seat belt reminder and warning buzzer

O

If luggage is placed on a front passenger seat, the front passenger detection sensor may

cause the warning light to flash and the warning buzzer to sound even if a passenger is not

sitting in the seat.

O

If a cushion is placed on the seat, the sensor may not detect a passenger, and the warning

light may not operate properly.

Q

If the malfunction indicator lamp comes on while driving

The malfunction indicator lamp will come on if the fuel tank becomes completely empty. If

the fuel tank is empty, refuel the vehicle immediately. The malfunction indicator lamp will go

off after several trips.
If the malfunction indicator lamp does not go off, contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable repairer as soon as possible.

Q

Electric power steering system warning light (warning buzzer)

When the 12-volt battery charge becomes insufficient or the voltage temporarily drops, the

electric power steering system warning light may come on and the warning buzzer may

sound.

Q

Tire pressure warning light

When a malfunction occurs in the tire pressure warning system, the tire pressure warning

light blinks to warn the driver. However, if the warning light blinks for 1 minute, and then

remains illuminated, making it difficult to determine whether the warning light is blinking,

turn the engine switch <power switch> from off to IGNITION ON mode <ON mode> and

check if the warning light blinks.

Q

When the tire pressure warning light comes on

Carry out the following procedure after the tire temperature has lowered sufficiently.

O

Check the tire inflation pressure and adjust to the appropriate level.

O

If the warning light does not go out even after several minutes, check that the tire inflation

pressure is at the specified level and carry out initialization. (



P.409)

The warning light may come on again if the above operations are conducted without first

allowing the tire temperature to lower sufficiently.

Warning

light

Details/Actions

Indicates that the hybrid system has overheated
This light may be displayed when driving under severe operating conditions.
(For example, when driving up a long steep hill.)



Stop the vehicle in a safe place.
Handling method (



P.478)

449

7

7-2. Steps to take in an emergency

Wh
en

 troubl
e ar
ises

Q

The tire pressure warning light may come on due to natural causes

The tire pressure warning light may come on due to natural causes such as natural air leaks

and tire inflation pressure changes caused by temperature. In this case, adjusting the tire

inflation pressure will turn off the warning light (after a few minutes).

Q

Situations in which the tire pressure warning system may not function properly



P.399

Q

If the tire pressure warning light frequently comes on after blinking for 1 minute

If the tire pressure warning light frequently comes on after blinking for 1 minute when the

engine switch <power switch> is turned to IGNITION ON mode <ON mode>, have it

checked by any authorized Lexus retailer or Lexus authorized repairer, or any reliable

repairer.

Q

Warning buzzer

In some cases, the buzzer may not be heard due to being in a noisy location or audio sound.

WARNING

Q

If both the ABS and the brake system warning lights remain on

Stop your vehicle in a safe place immediately and contact any authorized Lexus retailer

or Lexus authorized repairer, or any reliable repairer. The vehicle will become extremely

unstable during braking, and the ABS system may fail, which could cause an accident

resulting in death or serious injury.

Q

When the electric power steering system warning light comes on

When the light comes on yellow, the assist to the power steering is restricted. When the

light comes on red, the assist to the power steering is lost and handling operations of the

steering wheel become extremely heavy. When steering wheel operations are heavier

than usual, grip the steering wheel firmly and operate it using more force than usual.

Q

If the tire pressure warning light comes on

Be sure to observe the following precautions. Failure to do so could cause a loss of vehi-

cle control and result in death or serious injury.

O

Decelerate to the lowest appropriate speed as soon as possible. Do not drive over 80

km/h (50 mph).

O

Check and adjust the tire inflation pressure immediately.

O

If the tire pressure warning light comes on even after tire inflation pressure adjustment,

it is probable that you have a flat tire. Have the flat tire replaced by nearest authorized

Lexus retailer or Lexus authorized repairer, or any reliable repairer.

O

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose

control of the steering wheel or the brakes.

Q

If a blowout or sudden air leakage should occur

The tire pressure warning system may not activate immediately.
