1-1. For safe use

A frontal impact applied to the front

bumper while driving at speeds outside

of the operational speed range

A side impact or rear impact

A vehicle rollover (In some accident situ-

ations, the Pop Up Hood may operate.)

WARNING

When the Pop Up Hood is operated

Do not pull the hood lock release lever.

Doing so after the Pop Up Hood has

operated will further raise the hood

and may cause an injury. Do not drive

with the hood raised, as doing so may

block the driver’s vision, possibly caus-

ing an accident.

Do not forcibly push down the hood.

As the popped up hood cannot be

lowered by hand, doing so may deform

the hood or cause an injury.

If the Pop Up Hood has operated, have

it replaced by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer. If the Pop Up

Hood has operated, stop the vehicle in

a safe place and contact authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

Do not touch the lifters immediately

after the Pop Up Hood has operated,

as the lifters may be hot and burn you.

NOTICE

Pop Up Hood precautions

Make sure to close the hood before

driving, as the system may not operate

properly if the hood is not fully closed.

Make sure that all 4 tires are of the

specified size and inflated to the speci-

fied tire pressure. If tires of a different

size are used, the system may not

operate properly.

If something has hit the area around

the front bumper, the sensors may be

damaged even if the Pop Up Hood has

not operated. Have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer.

Do not remove or repair the parts or

wiring of the Pop Up Hood, as doing

so may cause accidental operation or

prevent the system from operating

properly. If repair or replacement is

necessary, contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

Do not remove such components as

the front bumper, hood or suspension,

or replace them with non-genuine

parts, as doing so may prevent the sys-

tem from operating properly.

Do not install anything to the front

bumper or hood, as doing so may pre-

vent the sensors from detecting an

impact correctly and prevent the sys-

tem from operating properly.

Do not close the hood with force or

apply load to the lifters, as doing so

may damage the lifters and prevent the

system from operating properly.

Do not modify the suspension, as

changes made to the vehicle height

may prevent the system from operat-

ing properly.

1-1. For safe use

For
sa

d s

uri

Exhaust gas precautions

Harmful substance to the human
body is included in exhaust gases if
inhaled.

WARNING

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.

Failure to do so may cause exhaust gases

enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

Important points while driving

Keep the trunk lid closed.

If you smell exhaust gases in the vehi-

cle even when the trunk lid is closed,

open the windows and have the vehi-

cle inspected at any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer as soon as pos-

sible.

When parking

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the engine <hybrid sys-

tem>.

Do not leave the vehicle with the

engine running <hybrid system operat-

ing> for a long time.

If such a situation cannot be avoided,

park the vehicle in an open space and

ensure that exhaust fumes do not enter

the vehicle interior.

Do not leave the engine running

<hybrid system operating> in an area

with snow build-up, or where it is

snowing. If snowbanks build up around

the vehicle while the engine is running

<hybrid system is operating>, exhaust

gases may collect and enter the vehi-

cle.

Exhaust pipe

The exhaust system needs to be checked

periodically. If there is a hole or crack

caused by corrosion, damage to a joint

or abnormal exhaust noise, be sure to

have the vehicle inspected and repaired

by any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

1-2. Child safety

1-2.Child safety

“PASSENGER AIR BAG” indica-
tor

“PASSENGER AIR BAG” and “ON” indi-
cator light turns on when the airbag system
is on, and about after 60 seconds they go
off. (only when the engine switch <power
switch> is in IGNITION ON mode <ON
mode>).

Airbag manual on-off switch

“PASSENGER AIR BAG” indicator

information

If any of the following problems occur, it is

possible that there is a malfunction in the

system. Have the vehicle inspected by any

authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer.

The “OFF” indicator does not illuminate

when the airbag manual on-off switch is

set to “OFF”.

The indicator light does not change when

the airbag manual on-off switch is

switched to “ON” or “OFF”.

Insert the mechanical key into the cyl-
inder and turn to the “OFF” position.

The “OFF” indicator light turns on (only
when the engine switch <power switch> is
in IGNITION ON mode <ON mode>).

Airbag manual on-off system

This system deactivates the front
passenger airbag and front passen-
ger knee airbag.
Only deactivate the airbags when
using a child restraint system on the
front passenger seat.

System components

Deactivating the airbags for the
front passenger

1-2. Child safety

For
sa

d s

uri

WARNING

When installing a child restraint sys-

tem

For safety reasons, always install a child

restraint system in a rear seat. In the

event that the rear seat cannot be used,

the front seat can be used as long as the

airbag manual on-off system is set to

“OFF”.

If the airbag manual on-off system is left

on, the strong impact of the airbag

deployment (inflation) may cause serious

injury or even death.

When a child restraint system is not

installed on the front passenger seat

Ensure that the airbag manual on-off sys-

tem is set to “ON”.

If it is left off, the airbag may not deploy in

the event of an accident, which may

result in serious injury or even death.

Riding with children

Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.



It is recommended that children
sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch, etc.



Use the window lock switch to
avoid children operating the
power window accidentally.
(



P.193)



Do not let small children operate
equipment which may catch or
pinch body parts, such as the
power window, hood, trunk, seats
etc.

WARNING

When children are in the vehicle

Never leave children unattended in the

vehicle, and never allow children to have

or use the key.
Children may be able to start the vehicle

or shift the vehicle into neutral. There is

also a danger that children may injure

themselves by playing with the windows

or other features of the vehicle. In addi-

tion, heat build-up or extremely cold

temperatures inside the vehicle can be

fatal to children.

1-2. Child safety

Points to remember: P.52
When using a child restraint system:
P.53
Child restraint system compatibility for
each seating position: P.57
Child restraint system installation
method: P.59
• Fixed with a seat belt:



P.60

• Fixed with an ISOFIX lower anchor-

age:



P.62

• Using a top tether anchor-

age:



P.63



Prioritize and observe the warn-
ings, as well as the laws and regula-
tions for child restraint systems.



Use a child restraint system until the
child becomes large enough to
properly wear the vehicle’s seat belt.



Choose a child restraint system
appropriate to the age and size of
the child.



Note that not all child restraint sys-
tems can fit in all vehicles. Before
using or purchasing a child restraint
system, check the compatibility of
the child restraint system with seat
positions. (



P.57)

Child restraint systems

Before installing a child restraint
system in the vehicle, there are pre-
cautions that need to be observed,
different types of child restraint sys-
tems, as well as installation meth-
ods, etc., written in this manual.



Use a child restraint system when
riding with a small child that can-
not properly use a seat belt. For
the child’s safety, install the child
restraint system to a rear seat. Be
sure to follow the installation
method that is in the operation
manual enclosed with the
restraint system.



The use of a Lexus genuine child
restraint system is recom-
mended, as it is safer to use in this
vehicle. Lexus genuine child
restraint systems are made specif-
ically for Lexus vehicles. They can
be purchased at a Lexus dealer.

Table of contents

Points to remember

WARNING

When a child is riding

Observe the following precautions.

Failure to do so may result in death or

serious injury.

For effective protection in automobile

accidents and sudden stops, a child

must be properly restrained, using a

seat belt or child restraint system

which is correctly installed. For installa-

tion details, refer to the operation man-

ual enclosed with the child restraint

system. General installation instruction

is provided in this manual.

1-2. Child safety

For
sa

d s

uri

When installing a child restraint
system to a front passenger seat

For the safety of a child, install child
restraint system to the rear seats.
When installing child restraint system
to a front passenger seat is unavoid-
able, adjust the seat as follows and
install the child restraint system.



Raise the seatback as much as pos-
sible



Move the seat to the rearmost posi-
tion



Raise the seat to the highest position



If the head restraint interferes with
the child restraint system installa-
tion and the head restraint can be
removed, remove the head restraint.
Otherwise, put the head restraint in
the upper most position.

WARNING

Lexus strongly urges the use of a

proper child restraint system that con-

forms to the weight and size of the

child, installed on the rear seat.

According to accident statistics, the

child is safer when properly restrained

in the rear seat than in the front seat.

Holding a child in your or someone

else’s arms is not a substitute for a child

restraint system. In an accident, the

child can be crushed against the wind-

shield or between the holder and the

interior of the vehicle.

Handling the child restraint system

If the child restraint system is not prop-

erly fixed in place, the child or other pas-

sengers may be seriously injured or even

killed in the event of sudden braking, sud-

den swerving, or an accident.

If the vehicle were to receive a strong

impact from an accident, etc., it is pos-

sible that the child restraint system has

damage that is not readily visible. In

such cases, do not reuse the restraint

system.

Depending on the child restraint sys-

tem, installation may be difficult or

impossible. In those cases, check

whether the child restraint system is

suitable for installment in the vehicle.

(



P.57) Be sure to install and observe

the usage rules after carefully reading

the child restraint system fixing

method in this manual, as well as the

operation manual enclosed with the

child restraint system.

Keep the child restraint system prop-

erly secured on the seat even if it is not

in use. Do not store the child restraint

system unsecured in the passenger

compartment.

If it is necessary to detach the child

restraint system, remove it from the

vehicle or store it securely in the trunk.

When using a child restraint sys-
tem

WARNING

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

1-2. Child safety

WARNING

Never use a rear-facing child restraint

system on the front passenger seat

when the airbag manual on-off switch

is on. (



P.50)

The force of the rapid inflation of the

front passenger airbag can cause

death or serious injury to children in

the event of an accident.

There is a label(s) on the passenger

side sun visor, indicating it is forbidden

to attach a rear-facing child restraint

system to the front passenger seat.

Details of the label(s) are shown in the

illustration below.

1-2. Child safety

For
sa

d s

uri

WARNING

Only put a forward-facing child

restraint system on the front seat when

unavoidable. When installing a for-

ward-facing child restraint on the front

passenger seat, move the seat as far

back as possible. Failing to do so may

result in death or serious injury if the

airbags deploy (inflate).

Do not allow the child to lean his/her

head or any part of his/her body

against the door or the area of the seat,

front or rear pillars or roof side rails

from which the SRS side airbags or

SRS curtain shield airbags deploy even

if the child is seated in the child

restraint system. It is dangerous if the

SRS side and curtain shield airbags

inflate, and the impact could cause

death or serious injury to the child.

When a junior seat is installed, always

ensure that the shoulder belt is posi-

tioned across the center of the child’s

shoulder. The belt should be kept away

from the child’s neck, but not so that it

could fall off the child’s shoulder.

Use a child restraint system suitable to

the age and size of the child and install

it to the rear seat.

1-2. Child safety

Child restraint system compatibil-
ity for each seating position

Compatibility of each seating position
with child restraint systems (



P.57)

displays the type of child restraint sys-
tems that can be used and possible
seating positions for installation using
symbols. Also, the recommended child
restraint system that is suitable for your
child can be selected.
Check the selected child restraint sys-
tem together with the following
“Before confirming the compatibility of
each seating position with child
restraint systems”.

Before confirming the compatibil-
ity of each seating position with
child restraint systems

Checking the child restraint system
standards.

Use a child restraint system that
conforms to UN(ECE) R44

The following approval mark is dis-
played on child restraint systems
which are conformed.
Check for an approval mark
attached to the child restraint sys-
tem.

Example of the displayed regulation Num-
ber
UN(ECE) R44 approval mark

The weight range of the child who is appli-
cable for an UN(ECE) R44 approval mark
is indicated.

Checking the category of the child
restraint system.
Check the approval mark of the
child restraint system for which of
the following categories the child
restraint system is suitable.
Also, if there are any uncertainties,
check the user’s guide included
with the child restraint system or
contact the retailer of the child
restraint system.

• “universal”

WARNING

If the driver’s seat interferes with the

child restraint system and prevents it

from being attached correctly, attach

the child restraint system to the right-

hand rear seat (left-hand drive vehi-

cles) or the left-hand rear seat (right-

hand drive vehicles). (



P.59)

Child restraint system compati-
bility for each seating position

1-2. Child safety

For
sa

d s

uri

• “semi-universal”
• “restricted”
• “vehicle specific”

: UN(ECE) R44 is U.N. regulations for

child restraint systems.

: The displayed mark may differ depend-

ing on the product.

Compatibility of each seating posi-
tion with child restraint systems



Left-hand drive vehicles



Right-hand drive vehicles

: Move the front seat fully rearward. If the

passenger seat height can be adjusted,
move it to the upper most position.

: Adjust the seatback angle to the most

upright position. When installing a for-
ward-facing child seat, if there is a gap
between the child seat and the seat-
back, adjust the seatback angle until
good contact is achieved.

*1, 2, 3

Suitable for “universal” category
child restraint system fixed with
the seat belt.
Suitable for ISOFIX child restraint
system.

Includes a top tether anchorage
point.
Never use a rear-facing child
restraint system on the front pas-
senger seat when the airbag man-
ual on-off switch is on.

1-2. Child safety

: If the head restraint interferes with your

child restraint system, and the head
restraint can be removed, remove the
head restraint.
Otherwise, put the head restraint in the
upper most position.

: Use only a front-facing child restraint

system when the airbag manual on-off
switch is on.

Detail information for CRS installation

ISOFIX child restraint systems are divided into different “fixture”. The child
restraint system can be used in the seating positions for “fixture” mentioned in the
table above. For kind of “fixture” relation, confirm the following table.
If your child restraint system has no kind of “fixture” (or if you cannot find informa-
tion in the table below), please refer to the child restraint system “vehicle list” for
compatibility information or ask the retailer of your child seat.

Seating position

Seat position number

Airbag manual on-

off switch

OFF

Seating position suitable for universal

belted (Yes/No)

Yes

Forward-

facing

only

Yes

i-Size seating position (Yes/No)

Seating position suitable for lateral fixture

(L1/L2/No)

Suitable rearward facing fixture

(R1/R2X/R2/R3/No)

Suitable forward facing fixture

(F2X/F2/F3/No)

F2X

Suitable junior seat fixture (B2/B3/No)

1-2. Child safety

For
sa

d s

uri



When installing a child restraint in
the rear seats, adjust the front seat
so that it does not interfere with the
child or child restraint system.



When installing a child seat with
support base, if the child seat inter-
feres with the seatback when latch-
ing it into the support base, adjust
the seatback rearward until there is
no interference.



If the seat belt shoulder anchor is
ahead of the child seat belt guide,
move the seat cushion forward.



When installing a junior seat, if the
child in your child restraint system is
in a very upright position, adjust the
seatback angle to the most comfort-
able position. And if the seat belt
shoulder anchor is ahead of the
child seat belt guide, move the seat
cushion forward.

Confirm with the operation manual enclosed with the child restraint system about
the installation of the child restraint system.

Fixture

Description

Full-height, forward-facing child restraint systems

Reduced-height forward-facing child restraint systems

F2X

Reduced-height forward-facing child restraint systems

Full-size, rearward-facing child restraint systems

Reduced-size, rearward-facing child restraint systems

R2X

Reduced-size, rearward-facing child restraint systems

Rearward-facing infant seat

Left lateral-facing (carrycot) infant seat

Right lateral-facing (carrycot) infant seat

Junior seat

Child restraint system installation method

1-2. Child safety

Installing child restraint system
using a seat belt

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.
If the child restraint system on hand is

not within the “universal” category (or
the necessary information is not in the
table), refer to the “Vehicle List” pro-
vided by the child restraint system
maker for various possible installation
positions, or check the compatibility
after asking the retailer of the child
seat. (



P.56, 57)

If installing the child restraint sys-
tem to the front passenger seat is

Installation method

Page

Seat belt attachment

P.60

ISOFIX lower anchorage

attachment

P.62

Top tether anchorage

attachment

P.63

Child restraint system fixed with
a seat belt

1-2. Child safety

For
sa

d s

uri

unavoidable, refer to P.53 for front
passenger seat adjustment.

If the head restraint interferes with
the child restraint system installa-
tion and the head restraint can be
removed, remove the head
restraint. Otherwise, put the head
restraint in the upper most position.
(



P.184)

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted. Securely fix the
seat belt to the child restraint sys-
tem in accordance to the directions
enclosed with the child restraint
system.

If your child restraint system is not
equipped with a lock-off (a seat belt
locking feature), secure the child
restraint system using a locking clip.

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.62)

Removing a child restraint system
installed with a seat belt

Press the buckle release button and
fully retract the seat belt.

When releasing the buckle, the child
restraint system may spring up due to the
rebound of the seat cushion. Release the
buckle while holding down the child
restraint system.
Since the seat belt automatically reels itself,
slowly return it to the stowing position.

When installing a child restraint system

You may need a locking clip to install the

child restraint system. Follow the instruc-

tions provided by the manufacturer of the

system. If your child restraint system does

not provide a locking clip, you can purchase

the following item from any authorized

Lexus retailer or Lexus authorized repairer,

or any reliable repairer:

Locking clip for child restraint system (Part

No. 73119-22010)

WARNING

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

Do not allow children to play with the

seat belt. If the seat belt becomes

twisted around a child’s neck, it may

lead to choking or other serious inju-

ries that could result in death. If this

occurs and the buckle cannot be

unfastened, scissors should be used to

cut the belt.

1-2. Child safety

ISOFIX lower anchorages (ISO-
FIX child restraint system)

Lower anchorages are provided for the
each rear seat. (Buttons displaying the
location of the anchorages are
attached to the seats.)

Installation with ISOFIX lower
anchorage (ISOFIX child restraint
system)

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.
If the child restraint system on hand is
not within the “universal” category (or
the necessary information is not in the
table), refer to the “Vehicle List” pro-
vided by the child restraint system
maker for various possible installation
positions, or check the compatibility
after asking the retailer of the child
seat. (



P.56, 57)

Check the positions of the exclu-
sive fixing bars, and install the child
restraint system to the seat.

The bars are installed in the clearance

between the seat cushion and seatback.

WARNING

Ensure that the belt and plate are

securely locked and the seat belt is not

twisted.

Shake the child restraint system left

and right, and forward and backward

to ensure that it has been securely

installed.

After securing a child restraint system,

never adjust the seat.

When a junior seat is installed, always

ensure that the shoulder belt is posi-

tioned across the center of the child’s

shoulder. The belt should be kept away

from the child’s neck, but not so that it

could fall off the child’s shoulder.

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

Child restraint system fixed with
an ISOFIX lower anchorage

1-2. Child safety

For
sa

d s

uri

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.62)

Top tether anchorages

Top tether anchorages are provided
for each rear seat.
Use top tether anchorages when fixing
the top strap.

Top strap

Top tether anchorages

Fixing the top strap to the top
tether anchorage

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.
Open the top tether anchorage cover,
latch the hook onto the top tether
anchorage and tighten the top strap.

Make sure the top strap is securely latched.
(



P.62)

Top strap

Hook

WARNING

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

After securing a child restraint system,

never adjust the seat.

When using the lower anchorages, be

sure that there are no foreign objects

around the anchorages and that the

seat belt is not caught behind the child

restraint system.

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

Using a top tether anchorage

A
B

WARNING

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

Firmly attach the top strap and make

sure that the belt is not twisted.

Do not attach the top strap to anything

other than the top tether anchorage.

After securing a child restraint system,

never adjust the seat.

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

A
B

Content .. 1 2 3 ..
