8-1. Specifications

■

Engine number

The engine number is stamped on the engine block as shown.



GS350



GS F



GS350



GS F

Engine

Model

3.5 L 6-cylinder (2GR-FKS)

Type

6-cylinder V type, 4-cycle, gasoline

Bore and stroke

3.70



3.27 in. (94.0



83.0 mm)

Displacement

210.9 cu.in. (3456 cm

)

Valve clearance

Automatic adjustment

Drive belt tension

Model

5.0 L 8-cylinder (2UR-GSE)

Type

8-cylinder V type, 4-cycle, gasoline

Bore and stroke

3.70



3.52 in. (94.0



89.5 mm)

Displacement

303.2 cu. in. (4969 cm

)

Valve clearance

(engine cold)

Intake: 0.006 in. (0.15 mm)

Exhaust: 0.009 in. (0.22 mm)

Drive belt tension

Automatic adjustment

519

8-1. Specifications

icl

e spe

cif

atio



GS350

: The engine oil capacity is a reference quantity to be used when changing the engine

oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.

■

Engine oil selection

Fuel

Fuel type

Unleaded gasoline only

Octane Rating

91 (Research Octane Number 96) or higher

Fuel tank capacity (Reference)

17.5 gal. (66.3 L, 14.6 Imp.gal.)

Lubrication system

GS350

2WD

AWD

Oil capacity

(Drain and refill



reference

)

With filter

Without filter

6.0 qt.

(5.7 L, 5.0 Imp.qt.)

5.8 qt.

(5.5 L, 4.8 Imp.qt.)

6.8 qt.

(6.4 L, 5.6 Imp.qt.)

6.3 qt.

(6.0 L, 5.3 Imp.qt.)

520

8-1. Specifications

Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.

Oil viscosity (0W-20 is explained here as an example):

• The 0W in 0W-20 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.

• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the

oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.

How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use.



GS F

: The engine oil capacity is a reference quantity to be used when changing the engine

oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.

Outside temperature

Oil capacity

(Drain and refill — reference

)

With filter

Without filter

9.3 qt. (8.8 L, 7.7 Imp.qt.)

8.3 qt. (7.9 L, 7.0 Imp.qt.)

521

8-1. Specifications

icl

e spe

cif

atio

■

Engine oil selection

“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 5W-30
SAE 5W-30 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 5W-30 is not available, SAE
10W-30 oil may be used. However,
it should be replaced with SAE 5W-
30 at the next oil change.

Oil viscosity (5W-30 is explained here as an example):

• The 5W in 5W-30 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.

• The 30 in 5W-30 indicates the viscosity characteristic of the oil when the

oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.

How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use.

Outside temperature

522

8-1. Specifications

Cooling system

Capacity

GS350

9.9 qt.(9.4 L, 8.3 Imp.qt.)

GS F

11.9 qt. (11.3 L, 9.9 Imp.qt.)

Coolant type

Use either of the following:

• “Toyota Super Long Life Coolant”

• Similar high-quality ethylene glycol-based non-

silicate, non-amine, non-nitrite, and non-borate

coolant with long-life hybrid organic acid tech-

nology

Do not use plain water alone.

Ignition system

GS350

GS F

Spark plug

Make

Gap

DENSO

FK20HBR8

0.031 in. (0.8 mm)

DENSO

FK20HBR-J8

0.031 in. (0.8 mm)

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

523

8-1. Specifications

ehic

eci

ficat
io

: The fluid capacity is the quantity of reference.

If replacement is necessary, contact your Lexus dealer.

Electrical system

Battery

Open voltage at 68



F (20



C):

12.3 V or higher

(Voltage is checked 20 minutes after the engine

and all lights are turned off.)

Charging rates

5 A

Automatic transmission

Fluid capacity

GS350 (2WD)

10.0 qt. (9.5 L, 8.4 Imp.qt.)

GS350 (AWD) 10.6 qt. (10.0 L, 8.8 Imp.qt.)

GS F

11.8 qt. (11.2 L, 9.9 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Automatic transmission fluid type

Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration

in shift quality, locking up of your transmission accompanied by vibration, and ulti-

mately damage the transmission of your vehicle.

Front differential (AWD models)

Oil capacity

0.74 qt. (0.70 L, 0.62 Imp.qt.)

Oil type and viscosity

Toyota Genuine Differential gear oil GL-5 or equivalent

Above 0



F (-18



C): SAE90

Below 0



F (-18



C): SAE80W or SAE80W-90

524

8-1. Specifications



GS350



GS F

: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory.

Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of
matching quality to satisfy the above specification. Please contact your Lexus dealer
for further details.

: Torque transfer modules are located on the right and left sides of the rear differential

unit.

: Using torque transfer module fluid other than “Toyota Genuine ATF WS” may cause

deterioration of performance, vibration, or ultimately damage the TVD system of your
vehicle.

: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N, 51.0 kgf)

while the engine is running.

Rear differential

Oil capacity

1.43 qt. (1.35 L, 1.19 Imp.qt.)

Oil type and viscosity

Vehicles without LSD (Limited Slip Differential):

Toyota Genuine Differential gear oil LT

75W-85 GL-5 or equivalent

Vehicles with LSD (Limited Slip Differential):

Toyota Genuine Differential gear oil LX 75W-85 GL-5

or equivalent

Differential

Torque transfer module

Oil capacity

1.43 qt. (1.35 L, 1.19 Imp. qt.)

Left-hand side:

0.74 qt. (0.70 L, 0.62 Imp. qt.)

Right-hand side:

0.74 qt. (0.70 L, 0.62 Imp. qt.)

Oil type and

viscosity

Toyota Genuine Differential gear

oil LT

75W-85 GL-5 or equivalent

Toyota Genuine ATF WS

Brakes

Pedal clearance

GS350

4.0 in. (102 mm) Min.

GS F

4.4 in. (112 mm) Min.

Pedal free play

0.04 — 0.24 in. (1.0 — 6.0 mm)

Brake pad wear limit

0.04 in. (1.0 mm)

Parking brake lining wear limit

0.04 in. (1.0 mm)

Fluid type

SAE J1703 or FMVSS No. 116 DOT 3

525

8-1. Specifications

icl

e spe

cif

atio



GS350 (Type A)



GS350 (Type B)

Steering

Free play

Less than 1.2 in. (30 mm)

Tires and wheels

Tire size

235/45R18 94Y

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 137 mph

(220 km/h)

45 (310, 3.1)

137 mph (220 km/h)

or less

35 (240, 2.4)

Wheel size



Wheel nut torque

76 ft

•

lbf (103 N

•

m, 10.5 kgf

•

Tire size

P235/45R18 94V

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 99 mph

(160 km/h)

45 (310, 3.1)

99 mph (160 km/h)

or less

35 (240, 2.4)

Wheel size



Wheel nut torque

76 ft

•

lbf (103 N

•

m, 10.5 kgf

•

526

8-1. Specifications



GS350 (Type C)



GS350 (Type D)

Tire size

235/40R19 96Y XL (front), 265/35R19 94Y (rear)

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 137 mph

(220 km/h)

45 (310, 3.1)

137 mph (220 km/h)

or less

35 (240, 2.4)

36 (250, 2.5)

Wheel size



8J (235/40R19), 19



9J (265/35R19)

Wheel nut torque

76 ft

•

lbf (103 N

•

m, 10.5 kgf

•

Tire size

235/40R19 96Y XL

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 137 mph

(220 km/h)

45 (310, 3.1)

137 mph (220 km/h)

or less

35 (240, 2.4)

36 (250, 2.5)

Wheel size



Wheel nut torque

76 ft

•

lbf (103 N

•

m, 10.5 kgf

•

527

8-1. Specifications

icl

e spe

cif

atio



GS350 (Type E)



GS350 (Compact spare tire)

Tire size

235/40R19 96V XL

Tire inflation

pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 99 mph

(160 km/h)

45 (310, 3.1)

99 mph (160 km/h)

or less

35 (240, 2.4)

36 (250, 2.5)

Wheel size



Wheel nut torque

76 ft

•

lbf (103 N

•

m, 10.5 kgf

•

Tire size

T155/70D17 110M, T145/70D18 107M

Tire inflation pressure

(Recommended cold tire

inflation pressure)

60 psi (420kPa, 4.2kgf/cm

or bar)

Wheel size



4T (T155/70D17), 18



4T (T145/70D18)

Wheel nut torque

76 ft

•

lbf (103 N

•

m, 10.5 kgf

•

528

8-1. Specifications



GS F

: If equipped

Tire size

255/35ZR19 (92Y) (front), 275/35ZR19 (96Y) (rear),
225/40ZR19 (93Y) XL (spare)

Tire inflation pressure

(Recommended

cold tire inflation

pressure)

Vehicle speed

Front tire

psi (kPa, kgf/cm

or bar)

Rear tire

psi (kPa, kgf/cm

or bar)

More than 137 mph

(220 km/h)

44 (300, 3.0)

137 mph (220 km/h)

or less

36 (250, 2.5)

Tire inflation pressure

(spare)

(Recommended

cold tire inflation

pressure)

42 psi (290kPa, 2.9kgf/cm

or bar)

Wheel size



9J (255/35ZR19), 19



10J (275/35ZR19),



8 1/2J (225/40ZR19)

Wheel nut torque

76 ft

•

lbf (103 N

•

m, 10.5 kgf

•

Light bulbs

Bulb No.

Type

Exterior

Front turn signal lights

7444NA

Outer foot lights

W5W

Interior

Vanity lights



Trunk light



3.8

A: Wedge base bulbs (amber)

B: Wedge base bulbs (clear)

: Vehicles with single-beam headlights

529

8-1. Specifications

icl

e spe

cif

atio

Fuel information

■

Gasoline quality

In very few cases, driveability problems may be caused by the brand of gasoline you are

using. If driveability problems persist, try changing the brand of gasoline. If this does not

correct the problem, consult your Lexus dealer.

■

Recommendation of the use of gasoline containing detergent additives

●

Lexus recommends the use of gasoline that contains detergent additives to avoid the

build-up of engine deposits.

●

All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or

keep clean intake systems, per EPA’s lowest additives concentration program.

●

Lexus strongly recommends the use of Top Tier Detergent Gasoline. For more informa-

tion on Top Tier Detergent Gasoline and a list of marketers, please go to the official

website www.toptiergas.com.

You must only use unleaded gasoline.
Select premium unleaded gasoline with an octane rating of 91 (Research
Octane Number 96) or higher required for optimum engine performance
and fuel economy.
If the octane rating is less than 91, damage to the engine may occur and may
void the vehicle warranty.

At minimum, the gasoline you use should meet the specifications of ASTM
D4814 in the U.S.A..

530

8-1. Specifications

■

Recommendation of the use of low emissions gasoline

Gasolines containing oxygenates such as ethers and ethanol, as well as reformulated

gasolines, are available in some cities. These fuels are typically acceptable for use, pro-

viding they meet other fuel requirements.
Lexus recommends these fuels, since the formulations allow for reduced vehicle emis-

sions.

■

Non-recommendation of the use of blended gasoline

●

If you use gasohol in your vehicle, be sure that it has an octane rating no lower than 91.

●

Lexus does not recommend the use of gasoline containing methanol.

■

Non-recommendation of the use of gasoline containing MMT

Some gasoline contains an octane enhancing additive called MMT (Methylcyclopenta-

dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasoline that contains MMT. If fuel containing

MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instrument cluster may come on. If this happens,

contact your Lexus dealer for service.

■

If your engine knocks

●

Consult your Lexus dealer.

●

You may occasionally notice light knocking for a short time while accelerating or driv-

ing uphill. This is normal and there is no need for concern.

●

Use only gasoline containing up to 15% etha-

nol.

DO NOT use any flex-fuel or gasoline that

could contain more than 15% ethanol, includ-

ing from any pump labeled E30, E50, E85

(which are only some examples of fuel con-

taining more than 15% ethanol).

DO NOT use gasoline con-
taining more than 15% ethanol.

(30% ethanol)

(50% ethanol)

(85% ethanol)

531

8-1. Specifications

ehic

eci

ficat
io

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If improper fuels are used, the engine will be damaged.

●

Do not use leaded gasoline.

Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters

causing the emission control system to malfunction.

●

Do not use gasohol other than the type previously stated.

Other gasohol may cause fuel system damage or vehicle performance problems.

●

Using unleaded gasoline with an octane number or rating lower than the level previ-

ously stated may cause persistent heavy knocking.

At worst, this may lead to engine damage and will void the vehicle warranty.

■

Fuel-related poor driveability

If poor driveability (poor hot starting, vaporization, engine knocking, etc.) is encoun-

tered after using a different type of fuel, discontinue the use of that type of fuel.

■

When refueling with gasohol

Take care not to spill gasohol. It can damage your vehicle’s paint.

533

8-1. Specifications

icl

e spe

cif

atio

Tire size

(



P. 534)

DOT and Tire Identification Number (TIN)

(



P. 534)

Location of treadwear indicators

(



P. 394)

Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands which form the

plies in a tire.

Radial tires or bias-ply tires

A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply

tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire

has a tube inside the tire and the tube maintains the air pressure.

Load limit at maximum cold tire inflation pressure

(



P. 537)

Maximum cold tire inflation pressure

(



P. 537)

This means the pressure to which a tire may be inflated.

Uniform tire quality grading

For details, see “Uniform Tire Quality Grading” that follows.

Summer tires or all season tires

(



P. 398)

An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer

tire.

“TEMPORARY USE ONLY”

A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded

on its sidewall. This tire is designed for temporary emergency use only.

2
3
4

Lexus GS350 (2020 year). Manual in english - page 32
