Lexus GS350 (2020 year). Manual in english - page 30

486

7-2. Steps to take in an emergency

: Use of the jack (



P. 479)

Location of the emergency tire puncture repair kit, jack and tools

Jack handle
Emergency tire puncture repair kit
Parking brake release tool
Screwdriver

Towing eyelet
Wheel nut wrench
Jack

2
3
4

5
6
7

487

7-2. Steps to take in an emergency

When trouble

ari

ses

Emergency tire puncture repair kit components

Bottle
Hose
Air pressure gauge
Compressor switch

Compressor
Stickers
Power plug
Air release cap

2
3
4

5
6
7
8

488

7-2. Steps to take in an emergency

Remove the center luggage mat. (



P. 345)

Take out the emergency tire punc-
ture repair kit.

Remove the center luggage mat. (



P. 345)

Remove the center auxiliary box.

Take out the jack.

For tightening
For loosening

Taking out the emergency tire puncture repair kit

Taking out the jack

489

7-2. Steps to take in an emergency

When trouble

ari

ses

Remove the valve cap from the valve
of the punctured tire.

Remove the air release cap from the
hose.

You will use the air release cap again.

Therefore keep it in a safe place.

Emergency repair method

490

7-2. Steps to take in an emergency

Connect the hose to the valve.

Screw the end of the hose clockwise as

far as possible.

Make sure that the compressor
switch is off.

Remove the rubber stopper from the
compressor.

Connect the power plug to the power outlet socket.



Inside of console box



Backside of console box

491

7-2. Steps to take in an emergency

When trouble

ari

ses

Connect the bottle to the compres-
sor.

Connect by inserting the bottle straight

into the compressor, and make sure that

the protruding part of the bottle is prop-

erly aligned with the groove in the case.

Attach the 2 stickers as shown.

Remove any dirt and moisture from the

wheel before attaching the sticker.
If you are unable to apply the stickers,

inform the nearest your Lexus dealer

that sealant has been applied to the

puncture when having the tire repaired

or replaced.

492

7-2. Steps to take in an emergency

Check the specified tire inflation
pressure.

Tire inflation pressure is specified on the

label as shown. (



P. 525)

Start the engine. (



P. 203)

To inject the sealant and inflate the
tire, turn the compressor switch on.

Inflate the tire until the recom-
mended pressure is reached.

The sealant will be injected and
the pressure will spike to 44 psi
(300 kPa, 3.0 kgf/cm

or bar) or

58 psi (400 kPa, 4.0 kgf/cm

bar), and then gradually
decrease.
The air pressure gauge will dis-
play the actual tire inflation pres-
sure about 1 minute (15 minutes at
low temperature) after the switch
is turned on.
Inject to recommended pressure.

• Turn the compressor switch off

and then check the tire inflation

pressure. Being careful not to

over inflate, check and repeat the

inflation procedure until the spec-

ified tire inflation pressure is

reached.

493

7-2. Steps to take in an emergency

When trouble

ari

ses

• If the tire inflation pressure is still lower than the specified point after inflation for

10 minutes (35 minutes at low temperature) with the switch on, the tire is too

damaged to be repaired. Turn the compressor switch off and contact your

Lexus dealer.

• If the tire inflation pressure exceeds the recommended level, let out some air to

adjust the tire inflation pressure. (



P. 495, 525)

With the compressor switch off, disconnect the hose from the valve on the tire
and then pull out the power plug from the power outlet socket.

Some sealant may leak when the hose is removed.

Install the valve cap onto the valve of the emergency repaired tire.
Attach the air release cap to the end
of the hose.

If the air release cap is not attached, the

sealant may leak and the vehicle may

get dirty.

Temporarily store the bottle in the trunk while it is connected to the compres-
sor.
To spread the liquid sealant evenly within the tire, immediately drive safely for
about 3 miles (5 km) below 50 mph (80 km/h).
After driving for about 3 miles
(5 km), stop your vehicle in a safe
place on a hard, flat surface and
remove the air release cap from the
hose before reconnecting the repair
kit.

494

7-2. Steps to take in an emergency

Turn the compressor switch on and
wait for several seconds, and then
turn it off. Check the tire inflation
pressure.

If the tire inflation pressure is under
19 psi (130 kPa, 1.3 kgf/cm

bar): The puncture cannot be
repaired. Contact your Lexus
dealer.
If the tire inflation pressure is 19 psi (130 kPa, 1.3 kgf/cm

or bar) or higher,

but less than the recommended level: Proceed to step .
If the tire inflation pressure is the recommended level: Proceed to step .

Turn the compressor switch on to inflate the tire until the recommended tire
inflation pressure is reached. Drive for about 3 miles (5 km) and then perform
step .
Attach the air release cap to the end
of the hose.

If the air release cap is not attached, the

sealant may leak and the vehicle may

get dirty.

Store the bottle in the trunk while it is connected to the compressor.
Taking precautions to avoid sudden braking, sudden acceleration and sharp
turns, drive carefully at under 50 mph (80 km/h) to your Lexus dealer that is
less than 62 miles (100 km) away for tire repair or replacement.

22
23

495

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Emergency tire puncture repair kit

●

The sealant has a limited lifespan. The expiry date is shown on the bottle. The sealant

should be replaced before the expiry date. Contact your Lexus dealer for replacement.

●

The sealant stored in the emergency tire puncture repair kit can be used only once to

temporarily repair a single tire. If the sealant has been used and need to be purchased,

contact your Lexus dealer.

●

The sealant can be used when the outside temperature is from -40



F (-40



C) to

140



F (60



C).

●

The repair kit is exclusively designed for size and type of tires originally installed on your

vehicle. Do not use it for tires that a different size than the original ones, or for any other

purposes.

●

If the sealant gets on your clothes, it may stain.

●

If the sealant adheres to a wheel or the surface of the vehicle body, the stain may not be

removable if it is not cleaned at once. Immediately wipe away the sealant with a wet

cloth.

●

During operation of the repair kit, a loud operation noise is produced. This does not

indicate a malfunction.

●

Do not use the emergency tire puncture repair kit to check or to adjust the tire pres-

sure.

■

If the tire is inflated to more than the recommended level

Disconnect the hose from the valve.

Disconnect the hose from the valve, remove the air release cap from the hose and then

reconnect the hose.
Turn the compressor switch on and wait for several seconds, and then turn it off. Check

that the air pressure indicator shows the recommended level. (



P. 525)

If the air pressure is lower than the recommended level, turn the compressor switch on

again and repeat the inflation procedure until the recommended pressure is reached.

■

The valve of a tire that has been repaired

●

After a tire is repaired with the emergency tire puncture repair kit, the valve should be

replaced.

●

After a tire is repaired with the emergency tire puncture repair kit, even if the tire infla-

tion pressure is at the recommended level, the tire pressure warning light may come

on/flash.

■

Note for checking the emergency tire puncture repair kit

Check the sealant expiry date occasionally.

The expiry date is shown on the bottle.

Do not use sealant whose expiry date has already passed. Otherwise, repairs conducted

using the emergency tire puncture repair kit may not be performed properly.

Install the air release cap to the end of the

hose and push the protrusion on the air

release cap into the tire valve to let some air

out.

496

7-2. Steps to take in an emergency

WARNING

■

Caution while driving

Observe the following precautions.

Failure to do so may cause an accident.

●

The emergency tire puncture repair kit is made exclusively for your vehicle. Do not

use it on other vehicles.

●

Do not use the emergency tire puncture repair kit for tires that are a different size

than the specified ones or for any other purpose. Doing so may cause the tires to not

be repaired properly.

■

Precautions for use of the sealant

●

Ingesting the sealant is hazardous to your health. If you ingest sealant, consume as

much water as possible, and then immediately consult a doctor.

●

If sealant gets in eyes or adheres to skin, immediately wash it off with water. If discom-

fort persists, consult a doctor.

■

When fixing the flat tire

●

Stop your vehicle in a safe and flat area.

●

Do not touch the wheels or the area around the brakes immediately after the vehicle

has been driven.

After the vehicle has been driven, the wheels and the area around the brakes may be

extremely hot. Touching these areas with hands, feet or other body parts may result in

burns.

●

Connect the valve and hose securely with the tire installed on the vehicle.

●

If the hose is not properly connected to the valve, air leakage may occur or sealant

may be sprayed out.

●

If the hose comes off the valve while inflating the tire, there is a risk that the hose will

move abruptly due to air pressure.

●

After inflation of the tire has completed, the sealant may splatter when the hose is dis-

connected or some air is let out of the tire.

●

Follow the operation procedure to repair the tire. If the procedures not followed, the

sealant may spray out.

●

Keep back from the tire while it is being repaired, as there is a chance of it bursting

while the repair operation is being performed. If you notice any cracks or deforma-

tion of the tire, turn off the compressor switch and stop the repair operation immedi-

ately.

●

The repair kit may overheat if operated for a long period of time. Do not operate the

repair kit continuously for more than 35 minutes.

●

Parts of the repair kit become hot during operation. Be careful handling the repair kit

during and after operation. Do not touch the metal part connecting the bottle and the

compressor. It will be extremely hot.

●

Do not attach the vehicle speed warning sticker to an area other than the one indi-

cated. If the sticker is attached to an area where an SRS airbag is located, such as the

pad of the steering wheel, it may prevent the SRS air bag from operating properly.

497

7-2. Steps to take in an emergency

When trouble

ari

ses

WARNING

■

Driving to spread the liquid sealant evenly

●

Drive the vehicle carefully at a low speed. Be especially careful when turning and cor-

nering.

●

If the vehicle does not drive straight or you feel a pull through the steering wheel, stop

the vehicle and check the following:
• Tire condition. The tire may have separated from the wheel.

• Tire inflation pressure. If tire inflation pressure is 19 psi (130 kPa, 1.3 kgf/cm

bar) or less, the tire may be severely damaged.

NOTICE

■

When performing an emergency repair

●

Perform the emergency repair without removing the nail or screw that has punctured

the tread of the tire. If the object that has punctured the tire is removed, repair by the

emergency tire puncture repair kit may not be possible.

●

The repair kit is not waterproof. Make sure that the repair kit is not exposed to water,

such as when it is being used in the rain.

●

Do not put the repair kit directly onto dusty ground such as sand at the side of the

road. If the repair kit vacuums up dust etc., a malfunction may occur.

■

Handling the emergency tire puncture repair kit

●

The repair kit power source should be 12 V DC suitable for vehicle use. Do not con-

nect the repair kit to any other source.

●

If gasoline splatters on the repair kit, the repair kit may deteriorate. Take care not to

allow gasoline to contact it.

●

Store the emergency tire puncture repair kit in the trunk.

The kit may be thrown around during sudden braking and so forth, damaging the kit.

●

Store the repair kit in the trunk out of reach of children.

●

Do not disassemble or modify the repair kit. Do not subject parts such as the air pres-

sure indicator to impacts. This may cause a malfunction.

■

To avoid damage to the tire pressure warning valves and transmitters

When a tire is repaired with liquid sealants, the tire pressure warning valve and trans-

mitter may not operate properly. If a liquid sealant is used, contact your Lexus dealer or

other qualified service shop as soon as possible. Make sure to replace the tire pressure

warning valve and transmitter when replacing the tire. (



P. 395)

498

7-2. Steps to take in an emergency

If the engine will not start

One of the following may be the cause of the problem:

●

There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.

●

The engine may be flooded.
Try to restart the engine again following correct starting procedures.
(



P. 203)

●

There may be a malfunction in the engine immobilizer system. (



P. 77)

One of the following may be the cause of the problem:

●

The battery may be discharged. (



P. 505)

●

The battery terminal connections may be loose or corroded.

The engine starting system may be malfunctioning due to an electrical problem
such as electronic key battery depletion or a blown fuse. However, an interim
measure is available to start the engine. (



P. 499)

One of the following may be the cause of the problem:

●

One or both of the battery terminals may be disconnected.

●

The battery may be discharged. (



P. 505)

●

There may be a malfunction in the steering lock system.

Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures

are unknown.

If the engine will not start even though correct starting procedures are being
followed (



P. 203), consider each of the following points:

The engine will not start even though the starter motor operates nor-
mally.

The starter motor turns over slowly, the interior lights and headlights
are dim, or the horn does not sound or sounds at a low volume.

The starter motor does not turn over

The starter motor does not turn over, the interior lights and headlights
do not turn on, or the horn does not sound.

499

7-2. Steps to take in an emergency

When trouble

ari

ses

When the engine does not start, the following steps can be used as an interim
measure to start the engine if the engine switch is functioning normally.

Press the parking brake switch to check that the parking brake is set.
(



P. 217)

Parking brake indicator will come on.

Shift the shift lever to P.
Turn the engine switch to ACCESSORY mode.
Press and hold the engine switch for about 15 seconds while depressing the
brake pedal firmly.

Even if the engine can be started using the above steps, the system may be mal-
functioning. Have the vehicle inspected by your Lexus dealer.

Emergency start function

2
3
4

500

7-2. Steps to take in an emergency

If the parking brake cannot be released

●

Shift the shift lever to P.

●

Turn the engine switch off.

●

Check that the parking brake indicator is off.

●

Chock the tires.

Take out the parking brake release
tool and the screwdriver from the
trunk. (



P. 474, 486)

Fit the parking brake release tool into

the screwdriver handle.

Vehicles with spare tire: Take out the spare tire. (



P. 477)

Vehicles without spare tire: Remove the center auxiliary box. (



P. 488)

In the event that the battery is discharged or switch operation does not
release the parking brake, the parking brake can be released manually using
the procedure below. This procedure should be performed only if necessary,
such as in an emergency.
If the switch cannot be operated even when the battery is normal, the parking
brake system may be malfunctioning. Have the vehicle inspected by your
Lexus dealer immediately.

Before releasing the parking brake manually

Releasing the parking brake manually

501

7-2. Steps to take in an emergency

When trouble

ari

ses

Remove the plug.

Insert the tool and press it down
firmly while turning it counterclock-
wise until it stops.

■

Manual operation of the parking brake

The parking brake cannot be set manually.

WARNING

■

When releasing the parking brake manually

●

Shift the shift lever to P, turn the engine switch off and chock the tires. Failure to do so

may cause the vehicle to move, resulting in an accident.

●

Turn the engine switch off and check that the parking brake indicator is off. Failure to

do so may cause the system to operate and turn the inserted parking brake release

tool, resulting in an injury.

Content .. 28 29 30 31 ..
