LEXUS UX 200 (2019 year). Instruction - part 22

348

6-3. Do-it-yourself maintenance

WARNING

●

Fully install light bulb and any parts

used to secure it. Failure to do so may

result in heat damage, fire, or water

entering the light unit. This may dam-

age the light or cause condensation to

build up on the lens.

■

To prevent damage or fire

●

Make sure bulb is fully seated and

locked.

●

Check the wattage of the bulb before

installing to prevent heat damage.

349

When trouble

ari

ses

When trouble arises

7-1. Essential information

Emergency flashers..................

350

If your vehicle has to be stopped in

an emergency..........................

350

If the vehicle is trapped in rising

water.............................................

351

7-2. Steps to take in an emergency

If your vehicle needs to be towed

........................................................

353

If you think something is wrong

........................................................

356

Fuel pump shut off system .....

357

If a warning light turns on or a

warning buzzer sounds .......

358

If a warning message is displayed

........................................................

367

If you have a flat tire (vehicles with

spare tire) ..................................

370

If you have a flat tire (vehicles

without spare tire)..................

377

If the engine will not start .......

378

If you lose your keys.................

379

If the fuel filler door cannot be

opened........................................

380

If the electronic key does not

operate properly ....................

380

If the vehicle battery is discharged

........................................................

382

If your vehicle overheats ........

386

If the vehicle becomes stuck

388

350

7-1. Essential information

7-1.Essential information

Press the switch.

All the turn signal lights will flash. To turn
them off, press the switch once again.

■

Emergency flashers

●

If the emergency flashers are used for a

long time while the engine is not running,

the battery may discharge.

●

If any of the SRS airbags deploy (inflate)

or in the event of a strong rear impact, the

emergency flashers will turn on automati-

cally. The emergency flashers will turn off

automatically after operating for approxi-

mately 20 minutes. To manually turn the

emergency flashers off, press the switch

twice. (The emergency flashers may not

turn on automatically depending on the

force of the impact and conditions of the

collision.)

Steadily step on the brake pedal
with both feet and firmly depress it.

Do not pump the brake pedal repeatedly

as this will increase the effort required to

slow the vehicle.

Shift the shift lever to N.



If the shift lever is shifted to N

After slowing down, stop the vehi-
cle in a safe place by the road.

Stop the engine.



If the shift lever cannot be shifted to
N

Keep depressing the brake pedal
with both feet to reduce vehicle
speed as much as possible.

To stop the engine, press and hold
the engine switch for 2 consecutive

Emergency flashers

The emergency flashers are used to
warn other drivers when the vehicle
has to be stopped in the road due to
a breakdown, etc.

Operating instructions

If your vehicle has to be
stopped in an emergency

Only in an emergency, such as if it
becomes impossible to stop the
vehicle in the normal way, stop the
vehicle using the following proce-
dure:

Stopping the vehicle

351

7-1. Essential information

n t

ris

seconds or more, or press it briefly
3 times or more in succession.

Stop the vehicle in a safe place by
the road.

 Remove the seat belt first.
 If the door can be opened, open the

door and exit the vehicle.

 If the door can not be opened, open

the window using the power window
switch and exit the vehicle through
the window.

 If the window can not be opened

using the power window switch,
remain calm, wait until the water
level inside the vehicle rises to the
point that the water pressure inside
of the vehicle equals the water pres-
sure outside of the vehicle, and then
open the door and exit the vehicle.

WARNING

■

If the engine has to be turned off while

driving

Power assist for the brakes and steering

wheel will be lost, making the brake

pedal harder to depress and the steering

wheel heavier to turn. Decelerate as

much as possible before turning off the

engine.

If the vehicle is trapped in
rising water

In the event the vehicle is sub-
merged in water, remain calm and
perform the following.

WARNING

■

Using an emergency hammer

for

emergency escape

The rear side windows and rear window

of this vehicle can be shattered by an
emergency hammer

used for emer-

gency escape, however, since the wind-
shield and front side windows

are

laminated glass they can not be shattered
by an emergency hammer

: Contact your Lexus dealer or after-

market accessory manufacturer for
further information about an emer-
gency hammer.

: Vehicles with laminated glass

352

7-1. Essential information

■

How to distinguish laminated glass

When looking from the cross-sectional

view point, laminated glass is two sheets of

glass pasted together.

Laminated glass

Tempered glass

WARNING

■

Escaping the vehicle from the window

There are cases where escaping the

vehicle from the window is not possible

due to seating position, passenger body

type, etc.
When using an emergency hammer,

consider your seat location and the size

of the window opening to ensure that the

opening is accessible and large enough

to escape.

353

7-2. Steps to take in an emergency

n t

ris

7-2.Steps to take in an emergency

The following may indicate a problem
with your transmission. Contact your
Lexus dealer or commercial towing
service before towing.
 The engine is running but the vehi-

cle does not move.

 The vehicle makes an abnormal

sound.

If your vehicle needs to be
towed

If towing is necessary, we recom-
mend having your vehicle towed by
your Lexus dealer or commercial
towing service, using a wheel-lift
type truck or flatbed truck.
Use a safety chain system for all
towing, and abide by all state/pro-
vincial and local laws.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

When towing the vehicle

Be sure to transport the vehicle with the

front wheels raised or with all four wheels

raised off the ground. If the vehicle is

towed with the front wheels contacting

the ground, the drivetrain and related

parts may be damaged.

■

While towing

●

When towing using cables or chains,

avoid sudden starts, etc. which place

excessive stress on the towing eyelets,

cables or chains. The towing eyelets,

cables or chains may become dam-

aged, broken debris may hit people,

and cause serious damage.

●

Do not turn the engine switch off.

There is a possibility that the steering

wheel is locked and cannot be oper-

ated.

■

Installing towing eyelets to the vehi-

cle

Make sure that towing eyelets are

installed securely.

If not securely installed, towing eyelets

may come loose during towing.

NOTICE

■

To prevent damage to the vehicle

when towing using a wheel-lift type

truck

●

Do not tow the vehicle from the rear

when the engine switch is OFF.

The steering lock mechanism is not

strong enough to hold the front wheels

straight.

●

When raising the vehicle, ensure ade-

quate ground clearance for towing at

the opposite end of the raised vehicle.

Without adequate clearance, the vehi-

cle could be damaged while being

towed.

■

To prevent damage to the vehicle

when towing with a sling-type truck

Do not tow with a sling-type truck, either

from the front or rear.

■

To prevent damage to the vehicle

during emergency towing

Do not secure cables or chains to the

suspension components.

Situations when it is necessary to
contact dealers before towing

354

7-2. Steps to take in an emergency

Do not tow with a sling-type truck to
prevent body damage.



From the front

Release the parking brake.



From the rear

Use a towing dolly under the front
wheels.

If your vehicle is transported by a flat-
bed truck, it should be tied down at the
locations shown in the illustration.

If you use chains or cables to tie down
your vehicle, the angles shaded in
black must be 45°.
Do not overly tighten the tie downs or
the vehicle may be damaged.

If a tow truck is not available in an
emergency, your vehicle may be tem-
porarily towed using cables or chains
secured to the emergency towing eye-
lets. This should only be attempted on
hard surfaced roads for at most 50
miles (80 km) at under 18 mph (30
km/h).
A driver must be in the vehicle to steer

Towing with a sling-type truck

Towing with a wheel-lift type
truck

Using a flatbed truck

Emergency towing

355

7-2. Steps to take in an emergency

When trouble

ari

ses

and operate the brakes. The vehicle’s
wheels, drivetrain, axles, steering and
brakes must be in good condition.

To have your vehicle towed by another
vehicle, the towing eyelet must be
installed to your vehicle. Install the tow-
ing eyelet by following the specified
procedure.

Take out the towing eyelet.
(

P.280)

Remove the eyelet cover using a
flathead screwdriver.

To protect the bodywork, place a rag

between the screwdriver and the vehicle

body as shown in the illustration.

Insert the towing eyelet into the
hole and tighten partially by hand.

Tighten down the towing eyelet
securely using a wheel nut wrench

or hard metal bar.

: If a wheel nut wrench is not equipped, a

wheel nut wrench can be purchased at
your Lexus dealer.

Securely attach cables or chains to
the towing eyelet.

Take care not to damage the vehicle body.

Enter the vehicle being towed and
start the engine.

If the engine does not start, turn the engine

switch to ON.

Shift the shift lever to N and release
the parking brake.

When the shift lever cannot be shifted:

P.157

■

While towing

If the engine is not running, the power assist

for the brakes and steering will not function,

marking steering and braking more difficult.

■

Wheel nut wrench

Vehicles with wheel nut wrench: Wheel nut

wrench is installed in luggage compart-

ment. (

P.280)

Vehicles without wheel nut wrench: Wheel

nut wrench can be purchased at your Lexus

dealer.

Emergency towing procedure

356

7-2. Steps to take in an emergency

 Fluid leaks under the vehicle

(Water dripping from the air condi-
tioning after use is normal.)

 Flat-looking tires or uneven tire

wear

 Engine coolant temperature gauge

needle continually points higher
than normal

 Changes in exhaust sound
 Excessive tire squeal when corner-

ing

 Strange noises related to the sus-

pension system

 Pinging or other noises related to

the engine

 Engine missing, stumbling or run-

ning roughly

 Appreciable loss of power
 Vehicle pulls heavily to one side

when braking

 Vehicle pulls heavily to one side

when driving on a level road

 Loss of brake effectiveness, spongy

feeling, pedal almost touches the
floor

If you think something is
wrong

If you notice any of the following
symptoms, your vehicle probably
needs adjustment or repair. Con-
tact your Lexus dealer as soon as
possible.

Visible symptoms

Audible symptoms

Operational symptoms

357

7-2. Steps to take in an emergency

n t

ris

Follow the procedure below to restart
the engine after the system is activated.

Turn the engine switch to ACC or
turn it off.

Restart the engine.

Fuel pump shut off system

To minimize the risk of fuel leakage
when the engine stalls or when an
airbag inflates upon collision, the
fuel pump shut off system stops the
supply of fuel to the engine.

Restarting the engine

NOTICE

■

Before starting the engine

Inspect the ground under the vehicle.

If you find that fuel has leaked onto the

ground, the fuel system has been dam-

aged and is in need of repair. Do not

restart the engine.

358

7-2. Steps to take in an emergency

■

Brake system warning light (warning buzzer)

■

Charging system warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Low engine oil pressure warning light

(warning buzzer)

: This light illuminates on the multi-information display.

If a warning light turns on or a warning buzzer sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by your Lexus dealer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(U.S.A.)

(red)

(Canada)

Indicates that:
The brake fluid level is low; or
The brake system is malfunctioning
 Immediately stop the vehicle in a safe place and contact your Lexus

dealer. Continuing to drive the vehicle may be dangerous.

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system
 Immediately stop the vehicle in a safe place and contact your Lexus

dealer.

Warning light

Details/Actions

Indicates that the engine oil pressure is too low
 Immediately stop the vehicle in a safe place and contact your Lexus

dealer.

359

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Malfunction indicator lamp (warning buzzer)

■

High coolant temperature warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Tire pressure warning light

■

Brake system warning light (warning buzzer)

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:
The electronic engine control system;
The electronic throttle control system; or
The electronic automatic transmission control system
 Immediately stop the vehicle in a safe place and contact your Lexus

dealer.

Warning light

Details/Actions

Indicates that the engine coolant temperature is too high
 Immediately stop the vehicle in a safe place.

Handling method (

P.386)

Warning light

Details/Actions

When the light comes on after blinking for approximately 1 minute:
Malfunction in the tire pressure warning system
 Have the system checked by your Lexus dealer.
When the light comes on:
Low tire inflation pressure such as
Natural causes
Flat tire
Vehicles without run-flat tires
 Immediately stop the vehicle in a safe place. (P.365)
Vehicles with run-flat tires
 P.365

Warning light

Details/Actions

(yellow)

Indicates a malfunction in:
The electronically controlled brake system (if equipped); or
The parking brake system
 Have the vehicle inspected by your Lexus dealer immediately.

360

7-2. Steps to take in an emergency

■

SRS warning light (warning buzzer)

■

ABS warning light (warning buzzer)

■

Electric power steering system warning light (warning buzzer)

■

Slip indicator

Warning light

Details/Actions

Indicates a malfunction in:
The SRS airbag system;
The front passenger occupant classification system; or
The seat belt pretensioner system
 Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:
The ABS; or
The brake assist system
 Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

(red)

(yellow)

Indicates a malfunction in the EPS (Electric Power Steering) system
 Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

Indicates a malfunction in:
The VSC system;
The TRAC system; or
The hill-start assist control system
 Have the vehicle inspected by your Lexus dealer immediately.

361

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Parking brake indicator

■

Brake hold operated indicator (warning buzzer)

■

Intuitive parking assist OFF indicator (warning buzzer)

■

RCTA OFF indicator (warning buzzer)

Warning light

Details/Actions

(flashes)

(U.S.A.)

(flashes)

(Canada)

Indicates a malfunction in the parking brake system
 Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

(flashes)

Indicates a malfunction in the brake hold system
 Have the vehicle inspected by your Lexus dealer immediately.

Warning light

Details/Actions

(flashes)

(if equipped)

When a buzzer sounds:
Indicates a malfunction in the intuitive parking assist function
 Have the vehicle inspected by your Lexus dealer immediately.
When a buzzer does not sound:
Indicates that the system is temporarily unavailable, possibly due to a
sensor being dirty or covered with ice, etc.
 Follow the instructions displayed on the multi-information display.

(

P.222)

Warning light

Details/Actions

(flashes)

(if equipped)

Indicates a malfunction in the RCTA (Rear Cross Traffic Alert) function
 Have the vehicle inspected by your Lexus dealer immediately.

362

7-2. Steps to take in an emergency

■

PKSB OFF indicator (warning buzzer)

■

Low fuel level warning light

■

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat belt is not
fastened. Once the engine switch is turned to ON the buzzer sounds for 6 seconds. If the
vehicle reaches a speed of 12 mph (20 km/h), the buzzer sounds once. If the seat belt is still
unfastened after 24 seconds, the buzzer will sound intermittently for 6 seconds. Then, if the
seat belt is still unfastened, the buzzer will sound in a different tone for 90 more seconds.
Front passenger’s seat belt warning buzzer:
The front passenger’s seat belt warning buzzer sounds to alert the front passenger that his
or her seat belt is not fastened. The buzzer sounds once if the vehicle reaches a speed of 12
mph (20 km/h). If the seat belt is still unfastened after 24 seconds, the buzzer will sound
intermittently for 6 seconds. Then, if the seat belt is still unfastened, the buzzer will sound in
a different tone for 90 more seconds.

Warning light

Details/Actions

(flashes)

(if equipped)

When a buzzer sounds:
Indicates a malfunction in the PKSB (Parking Support Brake) system
 Have the vehicle inspected by your Lexus dealer immediately.
When a buzzer does not sound:
Indicates that the system is temporarily unavailable, possibly due to a
sensor being dirty or covered with ice, etc.
 Follow the instructions displayed on the multi-information display.

(

P.367)

Warning light

Details/Actions

Indicates that remaining fuel is approximately 1.9 gal. (7.1 L, 1.6 Imp.gal.)
or less
 Refuel the vehicle.

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their seat belts
 Fasten the seat belt.

If the front passenger’s seat is occupied, the front passenger’s seat
belt also needs to be fastened to make the warning light (warning
buzzer) turn off.

363

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Rear passengers’ seat belt reminder lights

(warning buzzer)

: This light illuminates on the multi-information display.

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear passengers that his
or her seat belt is not fastened. The buzzer sounds once if the vehicle reaches a speed of 12
mph (20 km/h). If the seat belt is still unfastened after 24 seconds, the buzzer will sound
intermittently for 6 seconds. Then, if the seat belt is still unfastened, the buzzer will sound in
a different tone for 30 more seconds.

■

Brake Override System warning light/Drive-Start Control warning
light/PKSB warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

LTA indicator

(warning buzzer)

: This light illuminates on the multi-information display.

Warning light

Details/Actions

Warns the rear passengers to fasten their seat belts
 Fasten the seat belt.

Warning light

Details/Actions

When a buzzer sounds:
Brake Override System is malfunctioning;
Drive-Start Control is operating;
Drive-Start Control is malfunctioning; or
Parking Support Brake function (for static objects) (if equipped) is

operating

 Follow the instructions displayed on the multi-information display

and head-up display (if equipped).

When a buzzer does not sound:
Brake Override System is operating
 Release the accelerator pedal and depress the brake pedal.

Warning light

Details/Actions

(orange)

Indicates a malfunction in the LTA (Lane Tracing Assist)
 Follow the instructions displayed on the multi-information display.

(

P.201)

Content .. 20 21 22 23 ..
