LEXUS RX 450HL (2019 year). Instruction

193

3-4. Adjusting the steering wheel and mirrors

Op
era
tio

n of
ea

RX450h_RX450hL_U

To select a mirror to adjust, press the
switch.

Left
Right

Pressing the same switch again will

put the switch in neutral.

To adjust the mirror, press the switch.

Up
Right
Down
Left

Push the mirror back in the direction of
the vehicle’s rear.

Outside rear view mirrors

Adjustment procedure

2
3
4

Folding the mirrors (manual type)

194

3-4. Adjusting the steering wheel and mirrors

RX450h_RX450hL_U

■

Using the switch
Press the switch to fold the mirrors.

Press it again to extend them to the

original position.

■

Setting automatic mode
Automatic mode allows the folding or extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode.

The indicator will come on.
Pressing the switch once more will

return to manual mode.

When the mirror select switch is in the “L” or “R” position, the outside rear view
mirrors will automatically angle downwards when the vehicle is reversing in
order to give a better view of the ground.
To disable this function, select neither “L” nor “R” of the mirror select switch.

■

Adjusting the mirror angle when the vehicle is reversing
With the shift lever in R, adjust the mirror angle at a desired position.
The adjusted angle will be memorized and the mirror will automatically tilt to
the memorized angle whenever the shift lever is shifted to R from next time.

The memorized downward tilt position of the mirror is linked to the normal position

(angle adjusted with the shift lever in other than R). Therefore, if the normal posi-

tion is changed after adjustment, the tilt position will also change.

When the normal position is changed, readjust the angle in reversing.

Folding and extending the mirrors (power type)

Indicator

Linked mirror function when reversing

195

3-4. Adjusting the steering wheel and mirrors

Op
era
tio

n of
ea

RX450h_RX450hL_U

■

Mirror angle can be adjusted when
The power switch is in ACCESSORY or ON mode.

■

When disconnecting and reconnecting 12-volt battery terminals (power type)
The automatic folding/extending mirror function will return to off as default. To turn the

function on, press the switch again to select on.

■

When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the

rear window defogger to turn on the outside rear view mirror defoggers. (

P. 516)

■

Automatic adjustment of the mirror angle (if equipped)
A desired mirror face angle can be entered to memory and recalled automatically by the

driving position memory. (

P. 181)

■

Auto anti-glare function (if equipped)
When the anti-glare inside rear view mirror is set to automatic mode, the outside rear

view mirrors will activate in conjunction with the anti-glare inside rear view mirror to

reduce reflected light. (

P. 191)

■

Using automatic mode in cold weather (if equipped)
When automatic mode is used in cold weather, the door mirror could freeze up and

automatic stowing and return may not be possible. In this case, remove any ice and snow

from the door mirror, then either operate the mirror using manual mode or move the mir-

ror by hand.

■

Customization
Some functions can be customized. (

P. 736)

WARNING

■

Important points while driving
Observe the following precautions while driving.

Failing to do so may result in loss of control of the vehicle and cause an accident, result-

ing in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly adjusted

before driving.

■

When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your hand caught

by the moving mirror.

■

When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot and burn you.

196

RX450h_RX450hL_U

3-5. Opening, closing the windows and moon roof

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing
One-touch closing

Opening
One-touch opening

: To stop the window partway, operate the

switch in the opposite direction.

Press the switch down to lock the pas-
senger windows. The indicator light will
come on when the passenger windows
are locked.

Use this switch to prevent children from

accidentally opening or closing a pas-

senger window.
The passenger windows can still be

opened and closed using the driver’s

switch even if the lock switch is on.

Power windows

Opening and closing procedures

2
3
4

Window lock switch

Indicator

197

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RX450h_RX450hL_U

■

The power windows can be operated when
The power switch is in ON mode.

■

Operating the power windows after turning the hybrid system off
The power windows can be operated for approximately 45 seconds even after the

power switch is turned to ACCESSORY mode or turned off. They cannot, however, be

operated once either front door is opened.

■

Jam protection function
If an object becomes jammed between the window and the window frame while the win-

dow is closing, window movement is stopped and the window is opened slightly.

■

Catch protection function
If an object becomes caught between the door and window while the window is opening,

window movement is stopped.

■

When the window cannot be opened or closed
When the jam protection function or catch protection function operates unusually and

the door window cannot be opened or closed, perform the following operations with the

power window switch of that door.

●

Stop the vehicle. With the power switch in ON mode, within 4 seconds of the jam pro-

tection function or catch protection function activating, continuously operate the

power window switch in the one-touch closing direction or one-touch opening direc-

tion so that the door window can be opened and closed.

●

If the door window cannot be opened and closed even when performing the above

operations, perform the following procedure for function initialization.

Turn the power switch to ON mode.
Pull and hold the power window switch in the one-touch closing direction and com-

pletely close the door window.
Release the power window switch for a moment, resume pulling the switch in the

one-touch closing direction, and hold it there for approximately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direction. After

the door window is completely opened, continue holding the switch for an additional

1 second or more.
Release the power window switch for a moment, resume pushing the switch in the

one-touch opening direction, and hold it there for approximately 4 seconds or

more.
Pull and hold the power window switch in the one-touch closing direction again.

After the door window is completely closed, continue holding the switch for a fur-

ther 1 second or more.

If you release the switch while the window is moving, start again from the beginning.

If the window reverses and cannot be fully closed or opened, have the vehicle inspected

by your Lexus dealer.

198

3-5. Opening, closing the windows and moon roof

RX450h_RX450hL_U

■

Door lock linked window operation

●

The power windows can be opened and closed using the mechanical key.

(

P. 693)

●

The power windows can be opened using the wireless remote control.

(



P. 136)

: These settings must be customized at your Lexus dealer.

■

Alarm
The alarm may be triggered if the alarm is set and a power window is closed using the

door lock linked power window operation function. (

P. 87)

■

When the 12-volt battery is disconnected
The window lock switch is disabled. If necessary, press the window lock switch after

reconnecting the 12-volt battery.

■

Power windows open warning buzzer
A buzzer sounds and a message is shown on the multi-information display in the instru-

ment cluster when the power switch is turned off and the driver’s door is opened with the

power windows open.

■

Customization
Some functions can be customized. (

P. 736)

199

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RX450h_RX450hL_U

WARNING

Observe the following precautions.

Failing to do so may result in death or serious injury.

■

Opening and closing the windows

●

The driver is responsible for all the power window operations, including the operation

for the passengers. In order to prevent accidental operation, especially by a child, do

not let a child operate the power windows. It is possible for children and other passen-

gers to have body parts caught in the power window. Also, when riding with a child, it

is recommended to use the window lock switch. (

P. 196)

●

When using the wireless remote control or mechanical key and operating the power

windows, operate the power window after checking to make sure that there is no pos-

sibility of any passenger having any of their body parts caught in the window. Also do

not let a child operate power window by the wireless remote control or mechanical

key. It is possible for children and other passengers to get caught in the power win-

dow.

●

When exiting the vehicle, turn the power switch off, carry the key and exit the vehicle

along with the child. There may be accidental operation, due to mischief, etc., that

may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection function.

●

The jam protection function may not work if something gets jammed just before the

window is fully closed. Be careful not to get any part of your body jammed in the win-

dow.

■

Catch protection function

●

Never use any part of your body or clothing to intentionally activate the catch protec-

tion function.

●

The catch protection function may not work if something gets caught just before the

window is fully opened. Be careful not to get any part of your body or clothing caught

in the window.

●

Check to make sure that all passengers do

not have any part of their body in a position

where it could be caught when a window is

being operated.

200

3-5. Opening, closing the windows and moon roof

RX450h_RX450hL_U

Opens the moon roof

The moon roof stops slightly before the

fully open position to reduce wind noise.
Press the switch again to fully open the

moon roof.

Closes the moon roof

: Lightly press either side of the moon

roof switch to stop the moon roof part-
way.

Tilts the moon roof up

Tilts the moon roof down

: Lightly press either side of the moon

roof switch to stop the moon roof part-
way.

Moon roof



: If equipped

Use the overhead switches to open and close the moon roof and tilt it up and
down.

Opening and closing

Tilting up and down

201

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RX450h_RX450hL_U

■

The moon roof can be operated when
The power switch is in ON mode.

■

Operating the moon roof after turning the hybrid system off
The moon roof can be operated for approximately 45 seconds after the power switch is

turned to ACCESSORY mode or turned off. It cannot, however, be operated once the

driver’s door is opened.

■

Jam protection function
If an object is detected between the moon roof and the frame while the moon roof is clos-

ing or tilting down, travel is stopped and the moon roof opens slightly.

■

Sunshade
The sunshade can be opened and closed manually. However, the sunshade will open

automatically when the moon roof is opened.

■

Door lock linked moon roof operation

●

The moon roof can be opened and closed using the mechanical key.

(

P. 693)

●

The moon roof can be opened using the wireless remote control.

(

P. 136)

: These settings must be customized at your Lexus dealer.

202

3-5. Opening, closing the windows and moon roof

RX450h_RX450hL_U

■

When the moon roof does not close normally
Perform the following procedure:

●

If the moon roof closes but then re-opens slightly

Stop the vehicle.
Press and hold the “CLOSE” switch.

The moon roof will close, reopen and pause for approximately 10 seconds.

Then it

will close again, tilt up and pause for approximately 1 second. Finally, it will tilt down,

open and close.
Check to make sure that the moon roof is completely closed and then release the

switch.

●

If the moon roof tilts down but then tilts back up

Stop the vehicle.
Press and hold the “UP” switch

until the moon roof moves into the tilt up position

and stops.
Release the “UP” switch once and then press and hold the “UP” switch again.

The moon roof will pause for approximately 10 seconds in the tilt up position.

Then it will adjust slightly and pause for approximately 1 second. Finally, it will tilt

down, open and close.
Check to make sure that the moon roof is completely closed and then release the

switch.

: If the switch is released at the incorrect time, the procedure will have to be per-

formed again from the beginning.

: If the switch is released after the above mentioned 10 second pause, automatic

operation will be disabled. In that case, press and hold the “CLOSE” or “UP” switch,
and the moon roof will tilt up and pause for approximately 1 second. Then it will tilt
down, open and close. Check to make sure that the moon roof is completely closed
and then release the switch.

If the moon roof does not fully close even after performing the above procedure cor-

rectly, have the vehicle inspected by your Lexus dealer.

■

Alarm
The alarm may be triggered if the alarm is set and the moon roof is closed using the door

lock linked moon roof operation function. (

P. 87)

■

Moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in the instru-

ment cluster when the power switch is turned off and the driver’s door is opened with the

moon roof open.

■

Customization
Some functions can be customized. (

P. 736)

203

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RX450h_RX450hL_U

WARNING

Observe the following precautions.

Failing to do so may cause death or serious injury.

■

Opening the moon roof

●

Do not allow any passengers to put their hands or heads outside the vehicle while it is

moving.

●

Do not sit on top of the moon roof.

■

Opening and closing the moon roof

●

The driver is responsible for moon roof opening and closing operations.

In order to prevent accidental operation, especially by a child, do not let a child oper-

ate the moon roof. It is possible for children and other passengers to have body parts

caught in the moon roof.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection function.

●

The jam protection function may not work if something gets caught just before the

moon roof is fully closed. Also, the jam protection function is not designed to operate

while the switch is being pressed. Take care so that your fingers, etc. do not get

caught.

●

Check to make sure that all passengers do

not have any part of their body in a position

where it could be caught when the moon roof

is being operated.

●

When using the wireless remote control or

mechanical key and operating the moon roof,

operate the moon roof after checking to

make sure that there is no possibility of any

passenger having any of their body parts

caught in the moon roof. Also, do not let a

child operate moon roof by the wireless

remote control or mechanical key. It is possi-

ble for children and other passengers to get

caught in the moon roof.

●

When exiting the vehicle, turn the power

switch off, carry the key and exit the vehicle

along with the child. There may be accidental

operation, due to mischief, etc., that may pos-

sibly lead to an accident.

204

3-5. Opening, closing the windows and moon roof

RX450h_RX450hL_U

Opens the electronic sunshade

Slide and hold the

switch back-

ward. The electronic sunshade will fully
open automatically.

Closes the electronic sunshade

Slide and hold the

switch for-

ward. The electronic sunshade will fully
close automatically.

: Quickly slide and release the

switch in either direction to stop the electronic

sunshade partway.

Tilts the panoramic moon roof up
(press)

When the panoramic moon roof is tilted

up, the electronic sunshade will open to

the half-open position of the roof.

: Lightly press the

switch again to

stop the panoramic moon roof partway.

Tilts the panoramic moon roof down
(press and hold)

The panoramic moon roof can be tilted down only when it is in the tilt-up position.

Panoramic moon roof



: If equipped

Use the overhead switches to operate the panoramic moon roof and elec-
tronic sunshade.

Opening and closing the electronic sunshade

Tilting the panoramic moon roof up and down

205

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RX450h_RX450hL_U

Opens the panoramic moon roof*
Slide and hold the

switch back-

ward. The panoramic moon roof and
electronic sunshade will open automat-
ically.

The panoramic moon roof can be

opened from the tilt-up position.

: Quickly slide and release the

switch in either direction to stop the
panoramic moon roof partway.

Closes the panoramic moon roof
Slide and hold the

switch for-

ward. The panoramic moon roof will
fully close automatically.

■

The panoramic moon roof can be operated when
The power switch is in ON mode.

■

Operating the panoramic moon roof after turning the hybrid system off
The panoramic moon roof and electronic sunshade can be operated for approximately

45 seconds after the power switch is turned to ACCESSORY mode or turned off. They

cannot, however, be operated once the driver’s door is opened.

■

Jam protection function
If an object is detected between the panoramic moon roof and the frame in the following

situations, travel is stopped and the panoramic moon roof opens slightly:

●

The panoramic moon roof is closing or tilting down.

●

The electronic sunshade is closing.

■

Door lock linked panoramic moon roof operation

●

The panoramic moon roof can be opened and closed using the mechanical key.

(

P. 693)

●

The panoramic moon roof can be opened using the wireless remote control.

(

P. 136)

: These settings must be customized at your Lexus dealer.

Opening and closing the panoramic moon roof

206

3-5. Opening, closing the windows and moon roof

RX450h_RX450hL_U

■

Closing both the panoramic moon roof and electronic sunshade
Slide the

switch forward.

The electronic sunshade will close to the half-open position and pause. The panoramic

moon roof will then fully close. Then the electronic sunshade will fully close.

■

When the panoramic moon roof or electronic sunshade does not close normally
Perform the following procedure:

Stop the vehicle.
Turn the power switch to ON mode.
Slide and hold the

switch or

switch forward. Continue pressing the

switch for approximately 10 seconds after the panoramic moon roof or electronic

sunshade closes and reopens. The panoramic moon roof and electronic sunshade
will start to close.

Check that the panoramic moon roof and electronic sunshade are fully closed and

release the switch.

: If the switch is released at the incorrect time, the procedure will have to be per-

formed again from the beginning.

If the panoramic moon roof or electronic sunshade does not fully close even after per-

forming the above procedure correctly, have the vehicle inspected by your Lexus dealer.

■

Alarm
A alarm may be triggered if the alarm is set and the panoramic moon roof is closed using

the door lock linked panoramic moon roof operation function. (

P. 87)

■

Panoramic moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in the instru-

ment cluster when the power switch is turned off and the driver’s door is opened with the

panoramic moon roof open.

■

Customization
Some functions can be customized. (

P. 736)

207

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RX450h_RX450hL_U

WARNING

Observe the following precautions.

Failing to do so may cause death or serious injury.

■

Opening and closing the electronic sunshade

■

Opening and closing the panoramic moon roof

●

The driver is responsible for panoramic moon roof opening and closing operations.

In order to prevent accidental operation, especially by a child, do not let a child oper-

ate the panoramic moon roof. It is possible for children and other passengers to have

body parts caught in the panoramic moon roof.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection function.

●

The jam protection function may not work if something gets caught just before the

panoramic moon roof or electronic sunshade is fully closed. Also, the jam protection

function is not designed to operate while the switch is being pressed. Take care so that

your fingers, etc. do not get caught.

●

Check to make sure that all passengers do

not have any part of their body in a position

where it could be caught when the electronic

sunshade is being operated.

●

Do not let a child operate the electronic sun-

shade. Closing the electronic sunshade on

someone can cause death or serious injury.

●

Check to make sure that all passengers do

not have any part of their body in a position

where it could be caught when the panoramic

moon roof is being operated.

●

When using the wireless remote control or

mechanical key and operating the panoramic

moon roof, operate the panoramic moon roof

after checking to make sure that there is no

possibility of any passenger having any of

their body parts caught in the panoramic

moon roof. Also, do not let a child operate

panoramic moon roof by the wireless remote

control or mechanical key. It is possible for

children and other passengers to get caught

in the panoramic moon roof.

●

When exiting the vehicle, turn the power

switch off, carry the key and exit the vehicle

along with the child. There may be accidental

operation, due to mischief, etc., that may pos-

sibly lead to an accident.

LEXUS RX 450HL (2019 year). Instruction - part 12
