LEXUS RX 450HL (2019 year). Instruction

128

2. Instrument cluster

RX450h_RX450hL_U

Average fuel consumption for the past 15 minutes is divided by color into past
averages and averages attained since the power switch was last turned to ON
mode. Use the displayed average fuel consumption as a reference.
The image is an example only.

■

Past record



Lexus Display Audio screen

Press the “MENU” button on the Lexus Display Audio controller, then select
“Info” on the “Menu” screen, and then select “Fuel Consumption”.

If the “Past Record” screen does not appear, move the controller to the right and

select “Past Record”.

Previous fuel consumption record
Current fuel consumption
Best recorded fuel consumption



Navigation system screen

Press the “MENU” button on the Remote Touch, then select

on the

“Menu” screen, and then select “Fuel Consumption”.

If the “Energy Monitor” or “Trip Information” screen is displayed, select “Past

Record”.

Resetting the past record data
Best recorded fuel consumption
Average fuel consumption
Previous fuel consumption record
Updating the average fuel con-
sumption data

The average fuel consumption history is divided by color into past averages
and the average fuel consumption since the last updated. Use the displayed
average fuel consumption as a reference.
The image is an example only.

2
3

2
3
4
5

129

2. Instrument cluster

Instrument cl

uste
r

RX450h_RX450hL_U

■

Updating the past record data



Vehicles with a Lexus Display Audio system
Update the average fuel consumption by moving the controller to the left and select

“Update” to measure the current fuel consumption again.



Vehicles with a navigation system
Update the average fuel consumption by selecting “Update” to measure the current

fuel consumption again.

■

Resetting the data



Vehicles with a Lexus Display Audio system
The fuel consumption data can be deleted by moving the controller to the left and

select “Clear”.



Vehicles with a navigation system
The fuel consumption data can be deleted by selecting “Clear”.

■

Cruising range
Displays the estimated maximum distance that can be driven with the quantity of fuel

remaining.
This distance is computed based on your average fuel consumption.

As a result, the actual distance that can be driven may differ from that displayed.

Vehicle information can be displayed on the side display (

P. 505), then select

“<” or “>” to select the desired screen.



Fuel consumption

Displays the average fuel consumption
and regenerated energy for the past 10
minutes in 1 minute intervals, as well as
the cruising range.

Using the side display (vehicles with 12.3-inch display)

130

2. Instrument cluster

RX450h_RX450hL_U



Past record

Displays the average fuel consumption
and highest fuel consumption.



Trip information

Displays the cruising range, average
fuel consumption and the amount of
time elapsed since the hybrid system
was started.



Energy monitor

Displays the hybrid system operation
and energy recovery states.

The image is an example only, and may vary slightly from actual conditions.

132

RX450h_RX450hL_U

3-1. Key information

The following keys are provided with the vehicle.

Electronic keys

• Operating the smart access sys-

tem with push-button start
(

P. 158)

• Operating the wireless remote

control function

Mechanical keys
Key number plate

Locks all the doors (

P. 136)

Unlocks all the doors (

P. 136)

Opens the windows

and the

moon roof

1, 2

or panoramic moon

roof

1, 2

(

P. 136)

Opens and closes the power back
door (

P. 142)

Sounds the alarm (

P. 133)

: If equipped

: This setting must be customized at your Lexus dealer.

Keys

The keys

2
3

Wireless remote control

2
3

133

3-1. Key information

Op
era
tio

n of
ea

RX450h_RX450hL_U

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be

inserted in one direction, as the key only

has grooves on one side. If the key can-

not be inserted in a lock cylinder, turn it

over and re-attempt to insert it.
After using the mechanical key, store it

in the electronic key. Carry the mechan-

ical key together with the electronic key.

If the electronic key battery is depleted

or the entry function does not operate

properly, you will need the mechanical

key. (

P. 692)

■

Panic mode

■

When required to leave the vehicle’s key with a parking attendant
Lock the glove box as circumstances demand. (

P. 534)

Remove the mechanical key for your own use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys
New genuine mechanical keys can be made by your Lexus dealer using another

mechanical key and the key number stamped on your key number plate. Keep the plate

in a safe place such as your wallet, not in the vehicle.

■

When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press any but-

tons on the electronic key while inside the aircraft cabin. If you are carrying an electronic

key in your bag, etc., ensure that the buttons are not likely to be pressed accidentally.

Pressing a button may cause the electronic key to emit radio waves that could interfere

with the operation of the aircraft.

Using the mechanical key

When

is pressed for longer than about

one second, an alarm will sound intermittently

and the vehicle lights will flash to deter any per-

son from trying to break into or damage your

vehicle.
To stop the alarm, press any button on the elec-

tronic key.

134

3-1. Key information

RX450h_RX450hL_U

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years.

●

If the battery becomes low, an alarm will sound in the cabin when the hybrid system is

stopped. (

P. 630)

●

As the electronic key always receives radio waves, the battery will become depleted

even if the electronic key is not used. The following symptoms indicate that the elec-

tronic key battery may be depleted. Replace the battery when necessary. (

P. 630)

• The smart access system with push-button start or the wireless remote control does

not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface does not turn on.

●

To reduce key battery depletion when the electronic key is to not be used for long peri-

ods of time, set the electronic key to the battery-saving mode. (

P. 160)

●

To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of the

following electrical appliances that produce a magnetic field:
• TVs

• Personal computers

• Cellular phones, cordless phones and battery chargers

• Recharging cellular phones or cordless phones

• Induction cookers

• Table lamps

■

Replacing the battery
P. 630

■

Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask your Lexus

dealer for details.

■

If a wrong key is used
The key cylinder rotates freely, isolated from the internal mechanism.

135

3-1. Key information

Op
era
tio

n of
ea

RX450h_RX450hL_U

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to strong shocks or bend them.

●

Do not expose the keys to high temperatures for long periods of time.

●

Do not get the keys wet or wash them in an ultrasonic washer, etc.

●

Do not attach metallic or magnetic materials to the keys or place the keys close to

such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else to the surface of the electronic key.

●

Do not place the keys near objects that produce magnetic fields, such as TVs, audio

systems and induction cookers, or medical electrical equipment, such as low-fre-

quency therapy equipment.

■

Carrying the electronic key on your person
Carry the electronic key 3.9 in. (10 cm) or more away from electric appliances that are

turned on. Radio waves emitted from electric appliances within 3.9 in. (10 cm) of the

electronic key may interfere with the key, causing the key to not function properly.

■

In case of a smart access system with push-button start malfunction or other key-

related problems
Take your vehicle with all the electronic keys provided with your vehicle to your Lexus

dealer.

■

When an electronic key is lost
If the electronic key remains lost, the risk of vehicle theft increases significantly. Visit

your Lexus dealer immediately with all remaining electronic keys that were provided

with your vehicle.

136

RX450h_RX450hL_U

3-2. Opening, closing and locking the doors

◆

Smart access system with push-button start

Carry the electronic key to enable this function.

Grip the driver’s door handle to
unlock the door. Grip any passen-
ger door handle to unlock all the
doors.

Make sure to touch the sensor on the

back of the handle.
The doors cannot be unlocked for

3 seconds after the doors are locked.

: The door unlock settings can be

changed. (

P. 140,740)

Touch the lock sensor (indentation on the surface of the door handle) to
lock all the doors.

Check that the door is securely locked.

◆

Wireless remote control

Locks all the doors

Check that the door is securely

locked.

Unlocks all the doors

Pressing the button unlocks the

driver’s door. Pressing the button

again within 3 seconds unlocks the

other doors.
Press and hold to open the win-
dows

and the moon roof

1, 2

panoramic moon roof

1, 2

: If equipped

: This setting must be customized at your Lexus dealer.

Side doors

The vehicle can be locked and unlocked using the entry function, wireless
remote control or door lock switches.

Locking and unlocking the doors from the outside

137

3-2. Opening, closing and locking the doors

Op
era
tio

n of
ea

RX450h_RX450hL_U

■

Operation signals
Doors:

A buzzer sounds and the emergency flashers flash to indicate that the doors have been

locked/unlocked. (Locked: Once; Unlocked: Twice)
Windows and moon roof or panoramic moon roof:

A buzzer sounds.

■

Security feature
If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the

security feature automatically locks the vehicle again.

■

When the door cannot be locked by the lock sensor on the surface of the door handle

■

Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds

continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehicle

once more.

■

Setting the alarm
Locking the doors will set the alarm system. (

P. 86)

■

If the smart access system with push-button start or the wireless remote control does

not operate properly

●

Use the mechanical key to lock and unlock the doors. (

P. 692)

●

Replace the key battery with a new one if it is depleted. (

P. 630)

When the door cannot be locked even if the

lock sensor on the surface of the door handle is

touched by a finger, touch the lock sensor with

the palm.
When gloves are being worn, remove the

gloves.

138

3-2. Opening, closing and locking the doors

RX450h_RX450hL_U

◆

Door lock switches (to lock/unlock)

Locks all the doors
Unlocks all the doors

◆

Inside lock buttons (to lock)

Push down the inside lock button to
lock the door.

◆

Inside door handles (to unlock)



For the front doors

Pull the handle to unlock and open
the door.

When the door is unlocked, the
inside lock button will pop up.



For the rear doors

Pull the handle to unlock the door.
Pull the handle a second time to
open the door.

When the door is unlocked, the
inside lock button will pop up.

Locking and unlocking the doors from the inside

139

3-2. Opening, closing and locking the doors

Op
era
tio

n of
ea

RX450h_RX450hL_U

Push down the inside lock button.
Close the door.

The door cannot be locked if the power switch is in ACCESSORY or ON mode, or

the electronic key is left inside the vehicle. However, the key may not be detected cor-

rectly and the door may be locked.

The door cannot be opened from inside
the vehicle when the lock is set.

Unlock
Lock

These locks can be set to prevent chil-

dren from opening the rear doors. Push

down on each rear door switch to lock

both rear doors.

The following functions can be set or canceled:

For instructions on customizing, refer to P. 738.

Locking the doors from the outside without a key

Rear door child-protector lock

Automatic door locking and unlocking systems

Function

Operation

Speed linked door locking function

All doors are automatically locked when

vehicle speed is approximately 12 mph

(20 km/h) or higher.

Shift position linked door locking

function

All doors are automatically locked when

shifting the shift lever out of P.

Shift position linked door unlocking

function

All doors are automatically unlocked

when shifting the shift lever to P.

Driver’s door linked door unlocking

function

All doors are automatically unlocked

when driver’s door is opened.

140

3-2. Opening, closing and locking the doors

RX450h_RX450hL_U

■

Switching the door unlock function
It is possible to set which doors the entry function unlocks using the wireless remote con-

trol.

Turn the power switch off.
When the indicator light on the key surface is not on, press and hold

for approximately 5 seconds while pressing and holding

The setting changes each time an operation is performed, as shown below. (When

changing the setting continuously, release the buttons, wait for at least 5 seconds, and

repeat step .)

To prevent unintended triggering of the alarm, unlock the doors using the wireless

remote control and open and close a door once after the settings have been changed. (If
a door is not opened within 60 seconds after

is pressed, the doors will be locked

again and the alarm will automatically be set.)

In a case that the alarm is triggered, immediately stop the alarm. (

P. 86)

■

Impact detection door lock release system
In the event that the vehicle is subject to a strong impact, all the doors are unlocked.

Depending on the force of the impact or the type of accident, however, the system may

not operate.

■

Using the mechanical key
The doors can also be locked and unlocked with the mechanical key. (

P. 692)

■

Open door warning buzzer
If the vehicle speed reaches 3 mph (5 km/h), the master warning light flashes and a

buzzer sounds to indicate that door(s) or the hood in not fully closed.

The open door(s) or hood is displayed on the multi-information display.

Multi-information

display

Unlocking function

Beep

Holding the driver’s door handle

unlocks only the driver’s door.

Exterior: Beeps 3 times

Interior: Pings once

Holding any of the passenger

door handles unlocks all the

doors.

Holding a door handle unlocks

all the doors.

Exterior: Beeps twice

Interior: Pings once

141

3-2. Opening, closing and locking the doors

Op
era
tio

n of
ea

RX450h_RX450hL_U

■

Conditions affecting the operation of the smart access system with push-button start

or wireless remote control
P. 160

■

Customization
Some functions can be customized. (

P. 736)

WARNING

■

To prevent an accident
Observe the following precautions while driving the vehicle.

Failure to do so may result in a door opening and an occupant falling out, resulting in

death or serious injury.

●

Ensure that all doors are properly closed and locked.

●

Do not pull the inside handle of the doors while driving.
Be especially careful for the front doors, as the doors may be opened even if the

inside lock buttons are in locked position.

●

Set the rear door child-protector locks when children are seated in the rear seats.

■

When opening or closing a door
Check the surroundings of the vehicle such as whether the vehicle is on an incline,

whether there is enough space for a door to open and whether a strong wind is blow-

ing. When opening or closing the door, hold the door handle tightly to prepare for any

unpredictable movement.

142

3-2. Opening, closing and locking the doors

RX450h_RX450hL_U

◆

Smart access system with push-button start

Carry the electronic key to enable
this function.

Locks all the doors

Check that the door is securely

locked.

Unlocks all the doors

The doors cannot be unlocked for 3

seconds after the doors are locked.

◆

Wireless remote control

P. 136

◆

Door lock switch

P. 138

Press and hold the switch for approxi-
mately 1 second.

The power back door can be operated

whether it is locked

or unlocked.

Pressing the switch while the power

back door is opening/closing will stop

the operation.
Pressing and holding the switch again

for approximately 1 second will operate

the power back door in the opposite

direction.

: Opening of the power back door when it is locked can be disabled by a customized

setting. (

P. 741)

Power back door

The power back door can be locked/unlocked and opened/closed by the fol-
lowing procedures.

Locking and unlocking the power back door from the outside

Locking and unlocking the power back door from the inside

Opening/closing the power back door using the wireless remote con-
trol

143

3-2. Opening, closing and locking the doors

Op
era
tio

n of
ea

RX450h_RX450hL_U

Press and hold the switch for approxi-
mately 1 second.

A buzzer will sound and the power back

door will automatically open or close.

However, if the power back door is

locked, it will not open.
Pressing the switch while the power

back door is opening/closing will stop

the operation.
Pressing and holding the switch again

for approximately 1 second will operate

the power back door in the opposite

direction.

■

Back door opener switch
When the power back door is
unlocked: Press the back door
opener switch.
When the power back door is
locked: While carrying an elec-
tronic key, press and hold the back
door opener switch.

A buzzer will sound and the power

back door will automatically open.
Pressing the switch while the power back door is opening/closing will stop the

operation.

■

Wireless remote control
P. 142

Opening/closing the power back door from the inside

Opening the power back door from the outside

LEXUS RX 450HL (2019 year). Instruction - part 8
