LEXUS RC F (2019 year). Instruction

542

8-1. Specifications

RC F_U

■

Engine oil selection (RC300)
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.

Oil viscosity (0W-20 is explained here as an example):

• The 0W in 0W-20 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.

• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the

oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.

How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use.

Outside temperature

543

8-1. Specifications

icl

e spe

cif

atio

RC F_U

■

Engine oil selection (RC F)
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 5W-30
SAE 5W-30 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 5W-30 is not available, SAE
10W-30 oil may be used. However,
it should be replaced with SAE 5W-
30 at the next oil change.

Oil viscosity (5W-30 is explained here as an example):

• The 5W in 5W-30 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.

• The 30 in 5W-30 indicates the viscosity characteristic of the oil when the

oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.

How to read oil container label:
The International Lubricant Specifi-
cation Advisory Committee
(ILSAC) Certification Mark is added
to some oil containers to help you
select the oil you should use.

Outside temperature

544

8-1. Specifications

RC F_U

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

■

Spark plug

Cooling system

Capacity

RC350/

RC300

AWD

10.0 qt. (9.5 L, 8.4 Imp. qt.)

RC300



Gasoline engine

8.5 qt. (8.0 L, 7.0 Imp. qt.)



Intercooler

3.3 qt. (3.1 L, 2.7 Imp. qt.)

RC F

12.2 qt. (11.5 L, 10.1 Imp. qt.)

Coolant type

Use either of the following:

• “Toyota Super Long Life Coolant”

• Similar high-quality ethylene glycol-based non-sili-

cate, non-amine, non-nitrite, and non-borate coolant

with long-life hybrid organic acid technology

Do not use plain water alone.

Ignition system

RC350/RC300

AWD

RC300

RC F

Make

DENSO

FK20HBR8

NGK

DILFR7K9G

DENSO

FK20HBR-J8

Gap

0.031 in. (0.8 mm)

0.035 in. (0.9 mm)

0.031 in. (0.8 mm)

NOTICE

■

Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

545

8-1. Specifications

icl

e spe

cif

atio

RC F_U

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

Electrical system

Battery

Open voltage at 68

F

(20

C):

12.3 V or higher

If the voltage is lower than the standard value, charge

the battery.

(Voltage is checked 20 minutes after the engine and all

lights are turned off.)

Charging rates

5 A max.

Automatic transmission

Fluid capacity

RC350

10.0 qt. (9.5 L, 8.4 Imp. qt.)

RC350AWD/RC300

AWD

10.6 qt. (10.0 L, 8.8 Imp. qt.)

RC300

9.2 qt. (8.7 L, 7.7 Imp. qt.)

RC F

11.8 qt. (11.2 L, 9.9 Imp. qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Automatic transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration

in shift quality, locking up of your transmission accompanied by vibration, and ulti-

mately damage the transmission of your vehicle.

Front differential (AWD models)

Oil capacity

0.74 qt. (0.70 L, 0.61 Imp. qt.)

Oil type and viscosity

Hypoid gear oil API GL-5

Above 0

F (-18C): SAE90

Below 0

F (-18C): SAE80W or SAE80W-90

546

8-1. Specifications

RC F_U



RC350/RC300 (vehicles without LSD [Limited Slip Differential])



RC350/RC300/RC F (vehicles with LSD [Limited Slip Differential])



RC F (vehicles with TVD [Torque Vectoring Differential])

: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory.

Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of
matching quality to satisfy the above specification. Please contact your Lexus dealer
for further details.

: Torque transfer modules are located on the right and left sides of the rear differential

unit.

: Using torque transfer module fluid other than “Toyota Genuine ATF WS” may cause

deterioration of performance, vibration, or ultimately damage the TVD system of your
vehicle.

Rear differential

Oil capacity

1.42 qt. (1.35 L, 1.19 Imp. qt.)

Oil type and viscosity

Toyota Genuine Differential Gear Oil LT
75W-85 GL-5 or equivalent

Oil capacity

1.42 qt. (1.35 L, 1.19 Imp. qt.)

Oil type and viscosity

Toyota Genuine Differential Gear Oil LX
75W-85 GL-5 or equivalent

Differential

Torque transfer module

Oil capacity

1.42 qt. (1.35 L, 1.19 Imp. qt.)

Left-hand side:

0.74 qt. (0.70 L, 0.62 Imp. qt.)

Right-hand side:

0.74 qt. (0.70 L, 0.62 Imp. qt.)

Oil type and viscos-

ity

Toyota Genuine Differential

Gear Oil LT

75W-85 GL-5 or equiva-
lent

Toyota Genuine ATF WS

547

8-1. Specifications

icl

e spe

cif

atio

RC F_U

: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N, 51.0 kgf)

while the engine is running.

: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N, 30.6 kgf)

Brakes

Pedal clear-

ance

RC350

4.3 in. (108 mm) Min.

RC350AWD/RC300

AWD

4.5 in. (115 mm) Min.

RC300

4.1 in. (104 mm) Min.

RC F

4.4 in. (112 mm) Min.

Pedal free play

0.04 — 0.24 in. (1.0 — 6.0 mm)

Brake pad wear limit

0.04 in. (1.0 mm)

Parking brake lining wear limit

0.04 in. (1.0 mm)

Parking brake pedal travel

8 - 11 clicks

Fluid type

SAE J1703 or FMVSS No.116 DOT 3,

or SAE J1704 or FMVSS No.116 DOT 4

brake fluid

Steering

Free play

Less than 1.2 in. (30 mm)

548

8-1. Specifications

RC F_U



RC350/RC300 (type A)



RC350/RC300 (type B)

Tires and wheels

Tire size

235/45R18 94Y, T155/70D17 110M (spare)

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in

countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front

tires, 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the rear

tires. Never exceed the maximum cold tire inflation

pressure indicated on the tire sidewall.

Wheel size

 8J, 17  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

235/45R18 94Y, T145/70D18 107M (spare)

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in

countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front

tires, 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the rear

tires. Never exceed the maximum cold tire inflation

pressure indicated on the tire sidewall.

Wheel size

 8J, 18  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

549

8-1. Specifications

icl

e spe

cif

atio

RC F_U



RC350/RC300 (type C)



RC350/RC300 (type D)

Tire size

P235/45R18 94V, T155/70D17 110M (spare)

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in

countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front

tires, 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the rear

tires. Never exceed the maximum cold tire inflation

pressure indicated on the tire sidewall.

Wheel size

 8J, 17  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

P235/45R18 94V, T145/70D18 107M (spare)

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in

countries where such speeds are permitted by law)

Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the front

tires, 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the rear

tires. Never exceed the maximum cold tire inflation

pressure indicated on the tire sidewall.

Wheel size

 8J, 18  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

550

8-1. Specifications

RC F_U



RC350/RC300 (type E)



RC350/RC300 (type F)

Tire size

235/40R19 96V, T155/70D17 110M (spare)

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in

countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front

tires, 8 psi (50 kPa, 0.5 kgf/cm

or bar) to the rear

tires. Never exceed the maximum cold tire inflation

pressure indicated on the tire sidewall.

Wheel size

 8J, 17  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

235/40R19 96V, T145/70D18 107M (spare)

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in

countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front

tires, 8 psi (50 kPa, 0.5 kgf/cm

or bar) to the rear

tires. Never exceed the maximum cold tire inflation

pressure indicated on the tire sidewall.

Wheel size

 8J, 18  4T (spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

551

8-1. Specifications

icl

e spe

cif

atio

RC F_U



RC350/RC300 (type G)



RC350/RC300 (type H)

Tire size

Front tires: 235/40R19 96Y XL

Rear tires: 265/35R19 94Y

Spare tire: T155/70D17 110M

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in

countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front

tires. Never exceed the maximum cold tire inflation

pressure indicated on the tire sidewall.

Wheel size

Front wheels: 19

 8J

Rear wheels: 19

 9J

Spare wheel: 17

 4T

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

Front tires: 235/40R19 96Y XL

Rear tires: 265/35R19 94Y

Spare tire: T145/70D18 107M

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 35 psi (240 kPa, 2.4 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 60 psi (420 kPa, 4.2 kgf/cm

or bar)

Driving at high speeds (above 100 mph [160 km/h]) (in

countries where such speeds are permitted by law)

Add 6 psi (40 kPa, 0.4 kgf/cm

or bar) to the front

tires. Never exceed the maximum cold tire inflation

pressure indicated on the tire sidewall.

Wheel size

Front wheels: 19

 8J

Rear wheels: 19

 9J

Spare wheel: 18

 4T

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

552

8-1. Specifications

RC F_U



RC F (type A)



RC F (type B)

Tire size

Front tires: 255/35ZR19 (92Y)

Rear tires: 275/35ZR19 (96Y)

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Driving at high speeds (above 137 mph [220 km/h]) (in

countries where such speeds are permitted by law)

Add 8 psi (50 kPa, 0.5 kgf/cm

or bar) to the front

tires and rear tires. Never exceed the maximum cold

tire inflation pressure indicated on the tire sidewall.

Wheel size

Front wheels: 19

 9J

Rear wheels: 19

 10J

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

Front tires: 255/35ZR19 (92Y)

Rear tires: 275/35ZR19 (96Y)

Spare tire: 225/40ZR19 (93Y)

Tire inflation pressure

(Recommended cold tire

inflation pressure)

Driving under normal conditions

Front: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Rear: 36 psi (250 kPa, 2.5 kgf/cm

or bar)

Spare: 42 psi (290 kPa, 2.9 kgf/cm

or bar)

Driving at high speeds (above 137 mph [220 km/h]) (in

countries where such speeds are permitted by law)

Add 8 psi (50 kPa, 0.5 kgf/cm

or bar) to the front

tires and rear tires. Never exceed the maximum cold

tire inflation pressure indicated on the tire sidewall.

Wheel size

Front wheels: 19

 9J

Rear wheels: 19

 10J

Spare wheel: 19

 8 1/2J

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

553

8-1. Specifications

icl

e spe

cif

atio

RC F_U

Light bulbs

Bulb No.

Type

Exterior

Front turn signal lights (bulb type)

7444NA

28/8

Rear turn signal lights



Back-up lights

921

Interior

Vanity lights



Footwell lights

194

3.8

Trunk light



A: Wedge base bulbs (amber)

B: Wedge base bulbs (clear)

554

8-1. Specifications

RC F_U

■

Gasoline quality
In very few cases, driveability problems may be caused by the brand of gasoline you are

using. If driveability problems persist, try changing the brand of gasoline. If this does not

correct the problem, consult your Lexus dealer.

Fuel information

You must only use unleaded gasoline.
Select premium unleaded gasoline with an octane rating of 91 (Research
Octane Number 96) or higher required for optimum engine performance
and fuel economy.
If the octane rating is less than 91, damage to the engine may occur and may
void the vehicle warranty.

At minimum, the gasoline you use should meet the specifications of ASTM
D4814 in the U.S.A..

555

8-1. Specifications

icl

e spe

cif

atio

RC F_U

■

Recommendation of the use of gasoline containing detergent additives

●

Lexus recommends the use of gasoline that contains detergent additives to avoid the

build-up of engine deposits.

●

All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or

keep clean intake systems, per EPA’s lowest additives concentration program.

●

Lexus strongly recommends the use of Top Tier Detergent Gasoline. For more informa-

tion on Top Tier Detergent Gasoline and a list of marketers, please go to the official

website www.toptiergas.com.

■

Recommendation of the use of low emissions gasoline
Gasolines containing oxygenates such as ethers and ethanol, as well as reformulated

gasolines, are available in some cities. These fuels are typically acceptable for use, pro-

viding they meet other fuel requirements.
Lexus recommends these fuels, since the formulations allow for reduced vehicle emis-

sions.

■

Non-recommendation of the use of blended gasoline

●

If you use gasohol in your vehicle, be sure that it has an octane rating no lower than 91.

●

Lexus does not recommend the use of gasoline containing methanol.

■

Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcyclopenta-

dienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasoline that contains MMT. If fuel containing

MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the instrument cluster may come on. If this happens,

contact your Lexus dealer for service.

■

If your engine knocks

●

Consult your Lexus dealer.

●

You may occasionally notice light knocking for a short time while accelerating or driv-

ing uphill. This is normal and there is no need for concern.

●

Use only gasoline containing up to 15% etha-

nol.

DO NOT use any flex-fuel or gasoline that

could contain more than 15% ethanol, includ-

ing from any pump labeled E30, E50, E85

(which are only some examples of fuel con-

taining more than 15% ethanol).

DO NOT use gasoline con-
taining more than 15% ethanol.

(30% ethanol)

(50% ethanol)

(85% ethanol)

556

8-1. Specifications

RC F_U

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If improper fuels are used, the engine will be damaged.

●

Do not use leaded gasoline.

Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters

causing the emission control system to malfunction.

●

Do not use gasohol other than the type previously stated.

Other gasohol may cause fuel system damage or vehicle performance problems.

●

Using unleaded gasoline with an octane number or rating lower than the level previ-

ously stated may cause persistent heavy knocking.

At worst, this may lead to engine damage and will void the vehicle warranty.

■

Fuel-related poor driveability
If poor driveability (poor hot starting, vaporization, engine knocking, etc.) is encoun-

tered after using a different type of fuel, discontinue the use of that type of fuel.

■

When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle’s paint.

LEXUS RC F (2019 year). Instruction - part 34
