350

RC F_U

5-3. Using the storage features

List of storage features

Glove box

 (

P. 351)

Cup holders (if equipped)

(

P. 352)

Console box

 (

P. 351)

WARNING

●

Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause

the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact with other

stored items.

• Lighters or spray cans may explode. If they come into contact with other stored

items, the lighter may catch fire or the spray can may release gas, causing a fire

hazard.

●

When driving or when the storage compartments are not in use, keep the lids closed.

In the event of sudden braking or sudden swerving, an accident may occur due to an

occupant being struck by an open lid or the items stored inside.

1

2

3

351

5-3. Using the storage features

RC F_U

5

Inte
rior fe

ature

s

Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key

●

The glove box light turns on when the engine switch is in ACCESSORY or IGNITION

ON mode.

●

The trunk opener main switch is located in the glove box. (

P. 152)

Push the knob.

Lift  by  hand  to  fully  open  the  console

box.

Glove box

1

2
3

●

The insert inside the glove box can be

removed.

Console box

352

5-3. Using the storage features

RC F_U

●

The rubber mats at the bottom of the front cup holders can be removed.

Cup holders



Front



Rear (RC F)

●

Rear cup holder insert can be removed.

WARNING

■

Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.

Other items may be thrown out of the holders in the event of an accident or sudden

braking, causing injury. If possible, cover hot drinks to prevent burns.

■

When not in use (rear)
Keep the cup holders closed. In the event of sudden braking, an accident may occur

due to an occupant being struck by the items stored inside.

353

5-3. Using the storage features

RC F_U

5

Inte
rior fe

ature

s

Raise the hooks when needed.

The cargo hooks are provided for

securing loose items.

Loosen the belt
Tighten the belt

Trunk features

Cargo hooks

WARNING

To avoid injury, always return the cargo hooks to their stowed positions when not in use.

First-aid kit storage belt

1

2

354

RC F_U

5-4. Using the other interior features

To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.

Slide the cover to open.

The light turns on when the cover is

opened.

If the vanity lights remain on when the engine switch is turned off, the lights will go off

automatically after 20 minutes.

Other interior features

Sun visors

1

2

3

Vanity mirrors

NOTICE

To prevent battery discharge, do not leave the lights on longer than necessary when the

engine is off.

355

5-4. Using the other interior features

RC F_U

5

Inte
rior fe

ature

s

The clock can be adjusted.

Pressing and holding will move the
clock hands backward.
Pressing and holding will move the
clock hands forward.

Please use as a power supply for electronic goods that use less than 12 VDC/10
A (power consumption of 120 W).
Open the lid.

Clock

1

2

Power outlet

356

5-4. Using the other interior features

RC F_U

●

The power outlet can be used when the engine switch is in ACCESSORY or IGNI-

TION ON mode.

Fold down the armrest for use.

●

The shape of the console box rim allows power

cables to be passed through when the console

box lid is closed.

NOTICE

●

To avoid damaging the power outlet, close the power outlet lid when the power outlet

is not in use. Foreign objects or liquids that enter the power outlet may cause a short

circuit.

●

To prevent battery discharge, do not use the power outlet longer than necessary

when the engine is off.

Armrest (RC F)

NOTICE

To prevent damage to the armrest, do not apply too much load on the armrest.

357

5-4. Using the other interior features

RC F_U

5

Inte
rior fe

ature

s

Long objects can be loaded in the vehicle by utilizing the trunk space and rear
seat area.

Pull down the armrest.

Separate the fastener and turn back
the trunk door cover.

Open the inside trunk door from the
trunk and load baggage or other
items.

Trunk storage extension (RC F)

1

2

3

WARNING

■

When not in use
Ensure that the inside trunk door is closed.

In the event of sudden braking, items stored in the trunk may be thrown forward into

the cabin, resulting in injury.

358

5-4. Using the other interior features

RC F_U

An assist grip installed on the ceiling
can be used to support your body while
sitting on the seat.

To use the coat hook, push it in.

Assist grips

WARNING

Do not use the assist grip when getting in or out of the vehicle or rising from your seat.

NOTICE

To prevent damage to the assist grip, do not put a heavy load on the assist grip.

Coat hooks

WARNING

Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS cur-

tain shield airbags deploy, these items may become projectiles, causing death or seri-

ous injury.

359

5-4. Using the other interior features

RC F_U

5

Inte
rior fe

ature

s

The HomeLink

®

 wireless control system in your vehicle has 3 buttons which can

be programmed to operate 3 different devices. Refer to the programming meth-
ods on the following pages to determine the method which is appropriate for the
device.

HomeLink

®

 indicator light

Garage door operation indicators
HomeLink

®

 icon

Illuminates while HomeLink

®

 is operat-

ing.

Buttons

■

Before programming HomeLink

®

●

During programming, it is possible that garage doors, gates, or other
devices may operate. For this reason, make sure that people and objects
are clear of the garage door or other devices to prevent injury or other
potential harm.

●

It is recommended that a new battery be placed in the remote control
transmitter for more accurate programming.

●

Garage door opener motors manufactured after 1995 may be equipped
with rolling code protection. If this is the case, you may need a stepladder
or other sturdy, safe device to reach the “Learn” or “Smart” button on the
garage door opener motor.

Garage door opener

The garage door opener can be programmed to operate garage doors, gates,
entry doors, door locks, home lighting systems, security systems, and other
devices.

Programming the HomeLink

®

1

2
3

4

360

5-4. Using the other interior features

RC F_U

■

Programming HomeLink

®

Steps   through

 must be performed within 60 seconds, otherwise the

indicator light will stop flashing and programming will not be able to be com-
pleted.

Press and release the HomeLink

®

 button you want to program and check

that the HomeLink

®

 indicator light flashes (orange).

Point the remote control transmit-
ter for the device at the rear view
mirror, 1 to 3 in. (25 to 75 mm)
from the HomeLink

®

 buttons.

Keep the HomeLink

®

 indicator light

in view while programming.

Program a device.



Programming a device other than an entry gate (for U.S.A. owners)

Press and hold the handheld transmitter button until the HomeLink

®

 indi-

cator light changes from slowly flashing orange to rapidly flashing green
(rolling code) or continuously lit green (fixed code), then release the but-
ton.



Programming an entry gate (for U.S.A. owners)/Programming a device
in the Canadian market

Press and release the remote control transmitter button at 2 second inter-
vals, repeatedly, until the HomeLink

®

 indicator light changes from slowly

flashing (orange) to rapidly flashing (green) (rolling code) or continuously
lit (green) (fixed code).

1

3

1

2

3

361

5-4. Using the other interior features

RC F_U

5

Inte
rior fe

ature

s

Test the HomeLink

®

 operation by pressing the newly programmed button

and observing the indicator light:

●

Indicator light illuminates: Programming of a fixed code device has com-
pleted. The garage door or other device should operate when a Home-
Link

®

 button is pressed and released.

●

Indicator light flashes rapidly: The garage door opener motor or other
device is equipped with a rolling code. To complete programming, firmly
press and hold the HomeLink

®

 button for 2 seconds then release it.

●

If the garage door or other device does not operate, proceed to “Pro-
gramming a rolling code system”.

Repeat the steps above to program another device for any of the remaining
HomeLink

®

 buttons.

4

5

362

5-4. Using the other interior features

RC F_U

■

Programming a rolling code system
2 or more people may be necessary to complete rolling code programming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found

where the hanging antenna wire is

attached to the unit. The name and

color of the button may vary by man-

ufacturer. Refer to the owner’s man-

ual supplied with the garage door

opener motor for details.

Press and release the “Learn” or
“Smart” button.
Perform   within 30 seconds
after performing  .

Press and hold the desired
HomeLink

®

 button (inside the

vehicle) for 2 seconds and
release it. Repeat this sequence
(press/hold/release) up to 3
times to complete programming.
If the garage door opener motor
operates when the HomeLink

®

button is pressed, the garage
door opener motor recognizes
the HomeLink

®

 signal.

1

2

3

2

3

363

5-4. Using the other interior features

RC F_U

5

Inte
rior fe

ature

s

■

Enabling 2-way communication with a garage door (only available for com-
patible devices)
When enabled, 2-way communication allows you to check the status of the
opening and closing of a garage door through indicators in your vehicle.
2-way communication is only available if the garage door opener motor used
is a compatible device. (To check device compatibility, refer to www.Home-
Link.com.)

Within 5 seconds after programming the garage door opener has been
completed, if the garage door opener motor is trained to HomeLink

®

,

both garage door operation indicators will flash rapidly (green) and the
light on the garage door opener motor will blink twice, indicating that 2-
way communication is enabled.

If the indicators do not flash, perform



and   within the first 10 presses of

the HomeLink

®

 button after programming has been completed.

Press a programmed HomeLink

®

 button to operate a garage door.

Within 1 minute of pressing the HomeLink

®

 button, after the garage door

operation has stopped, press the “Learn” or “Smart” button on the garage
door opener motor. Within 5 seconds of the establishment of 2-way com-
munication with the garage door opener, both garage door operation indi-
cators in the vehicle will flash rapidly (green) and the light on the garage
door opener motor will blink twice, indicating that 2-way communication is
enabled.

■

Reprogramming a single HomeLink

®

 button

When the following procedure is performed, buttons which already have
devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

®

 button.

When the HomeLink

®

 indicator starts flashing (orange), continue to hold

the HomeLink

®

 button and perform “Programming HomeLink

®

”

(it

takes 20 seconds for the HomeLink

®

 indicator to start flashing).

1

2

3

2
3

1

2

1

364

5-4. Using the other interior features

RC F_U

Press the appropriate HomeLink

®

 button. The HomeLink

®

 indicator light

should turn on.

The status of the opening and closing of
a garage door is shown by the indica-
tors.

Opening
Closing

This function is only available if the

garage door opener motor used is a

compatible device. (To check device

compatibility, refer to www.Home-

Link.com.)

The indicators can operate within approximately 820 ft. (250 m) of the garage
door. However, if there are obstructions between the garage door and the vehi-
cle, such as houses and trees, feedback signals from the garage door may not be
received.
To recall the previous door operation status, press and release either Home-

Link

®

 buttons

 and

 or

 and

 simultaneously. The

last recorded status will be displayed for 3 seconds.

Operating HomeLink

®

Garage door operation indicators

1

2

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

365

5-4. Using the other interior features

RC F_U

5

Inte
rior fe

ature

s

Press and hold the 2 outside buttons for
10 seconds until the HomeLink

®

 indi-

cator light changes from continuously
lit (orange) to rapidly flashing (green).

If you sell your vehicle, be sure to erase
the programs stored in the HomeLink

®

memory.

■

Codes stored in the HomeLink

®

 memory

●

The registered codes are not erased even if the battery cable is disconnected.

●

If learning failed when registering a different code to a HomeLink

®

 button that already

has a code registered to it, the already registered code will not be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The battery side of the transmitter must be pointed away from the HomeLink



.

■

When support is necessary
Visit on the web at www.homelink.com/lexus or call 1-800-355-3515.

Erasing the entire HomeLink

®

 memory (all three codes)

WARNING

■

When programming a garage door or other remote control device
The garage door or other device may operate, so ensure people and objects are out of

danger to prevent potential harm.

■

Conforming to federal safety standards
Do not use the HomeLink

®

 compatible transceiver with any garage door opener or

device that lacks safety stop and reverse features as required by federal safety stan-

dards.

This includes any garage door that cannot detect an interfering object. A door or

device without these features increases the risk of death or serious injury.

■

When operating or programming HomeLink

®

Never allow a child to operate or play with the HomeLink

®

 buttons.
