LEXUS RC F (2019 year). Instruction - part 11

174

RC F_U

3-4. Adjusting the steering wheel and mirrors



Manual type
Hold the steering wheel and push
the lever down.

Adjust to the ideal position by mov-
ing the steering wheel horizontally
and vertically.

After adjustment, pull the lever up to

secure the steering wheel.



Power type

Operating the switch moves the steering wheel in the following directions:

Up
Down
Toward the driver
Away from the driver

Steering wheel

Adjustment procedure

2
3
4

175

3-4. Adjusting the steering wheel and mirrors

Op
era
tio

n of
ea

RC F_U

To sound the horn, press on or close to
the

mark.

■

The steering wheel can be adjusted when (power type)
The engine switch is in ACCESSORY or IGNITION ON mode

: If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of

engine switch mode.

■

Automatic adjustment of the steering position (if equipped)
A desired steering position can be entered to memory and recalled automatically by the

driving position memory system. (

P. 166)

■

Power easy access system (power type)
The steering wheel and driver’s seat move in accordance with engine switch mode and

the driver’s seat belt condition. (

P. 166)

Horn

WARNING

■

Caution while driving
Do not adjust the steering wheel while driving.

Doing so may cause the driver to mishandle the vehicle and cause an accident, result-

ing in death or serious injury.

■

After adjusting the steering wheel (manual type)
Make sure that the steering wheel is securely locked.

Otherwise, the steering wheel may move suddenly, possibly causing an accident, and

resulting in death or serious injury. Also, the horn may not sound if the steering wheel is

not securely locked.

176

3-4. Adjusting the steering wheel and mirrors

RC F_U

The height of the rear view mirror can be adjusted to suit your driving posture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness of the headlights of vehicles behind, the
reflected light is automatically reduced.
Changing automatic anti-glare func-
tion mode
ON/OFF

When the automatic anti-glare function

is in ON mode, the indicator illuminates.

The function will set to ON mode each

time the engine switch is turned to

IGNITION ON mode.

Pressing the button turns the function to

OFF mode. (The indicator also turns

off.)

Inside rear view mirror

The rear view mirror’s position can be adjusted to enable sufficient confirma-
tion of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

Indicator

177

3-4. Adjusting the steering wheel and mirrors

Op
era
tio

n of
ea

RC F_U

■

To prevent sensor error
To ensure that the sensors operate properly, do

not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.

Doing so may lead to mishandling of the vehicle and cause an accident, resulting in

death or serious injury.

178

3-4. Adjusting the steering wheel and mirrors

RC F_U

To select a mirror to adjust, press the
switch.

Left
Right

Pressing the same switch again will

put the switch in neutral.

To adjust the mirror, press the switch.

Up
Right
Down
Left

Outside rear view mirrors

Adjustment procedure

2
3
4

179

3-4. Adjusting the steering wheel and mirrors

Op
era
tio

n of
ea

RC F_U

Push the mirror back in the direction of
the vehicle’s rear.

When either “L” or “R” of the mirror select switch is selected, the outside rear
view mirrors will automatically angle downwards when the vehicle is reversing in
order to give a better view of the ground.
To disable this function, select neither “L” nor “R”.

■

Adjusting the mirror angle when the vehicle is reversing
With the shift lever in R, adjust the mirror angle at a desired position.
The adjusted angle will be memorized and the mirror will automatically tilt to
the memorized angle whenever the shift lever is shifted to R from next time.

The memorized downward tilt position of the mirror is linked to the normal position

(angle adjusted with the shift lever in other than R). Therefore, if the normal posi-

tion is changed after adjustment, the tilt position will also change.
When the normal position is changed, readjust the angle in reversing.

Folding the mirrors

Linked mirror function when reversing (if equipped)

180

3-4. Adjusting the steering wheel and mirrors

RC F_U

■

Mirror angle can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode.

■

When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the

rear window defogger to turn on the outside rear view mirror defoggers. (

P. 338)

■

Automatic adjustment of the mirror angle (if equipped)
A desired mirror face angle can be entered to memory and recalled automatically by the

driving position memory. (

P. 166)

■

Auto anti-glare function (if equipped)
When the anti-glare inside rear view mirror is set to automatic mode, the outside rear

view mirrors will activate in conjunction with the anti-glare inside rear view mirror to

reduce reflected light. (

P. 176)

181

3-4. Adjusting the steering wheel and mirrors

Op
era
tio

n of
ea

RC F_U

WARNING

■

Important points while driving
Observe the following precautions while driving.

Failure to do so may result in loss of control of the vehicle and cause an accident, result-

ing in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly adjusted

before driving.

■

When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot and burn you.

182

RC F_U

3-5. Opening, closing the windows and moon roof

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing
One-touch closing

Opening
One-touch opening

: To stop the window partway, operate the

switch in the opposite direction.

Press the switch to lock the passenger
window.

The indicator will come on.
Use this switch to prevent children from

accidentally opening or closing a pas-

senger window.
The passenger window can still be

opened and closed using the driver’s

switch even if the lock switch is on.

Power windows

Opening and closing procedures

2
3
4

Window lock switch

Indicator

183

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RC F_U

■

The power windows can be operated when
The engine switch is in IGNITION ON mode.

■

Operating the power windows after turning the engine off
The power windows can be operated for approximately 45 seconds after the engine

switch is turned to ACCESSORY mode or turned off. They cannot, however, be oper-

ated once either door is opened.

■

Jam protection function
If an object becomes jammed between the window and the window frame while the win-

dow is closing, window movement is stopped and the window is opened slightly.

■

Catch protection function
If an object becomes caught between the door and window while the window is opening,

window movement is stopped.

■

When the window cannot be opened or closed
When the jam protection function or catch protection function operates unusually and

the door window cannot be opened or closed, perform the following operations with the

power window switch of that door.

●

Stop the vehicle. With the engine switch in IGNITION ON mode, within 4 seconds of

the jam protection function or catch protection function activating, continuously oper-

ate the power window switch in the one-touch closing direction or one-touch opening

direction so that the door window can be opened and closed.

●

If the door window cannot be opened and closed even when performing the above

operations, perform the following procedure for function initialization.

Turn the engine switch to IGNITION ON mode.
Pull and hold the power window switch in the one-touch closing direction and com-

pletely close the door window.
Release the power window switch for a moment, resume pulling the switch in the

one-touch closing direction, and hold it there for approximately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direction. After

the door window is completely opened, continue holding the switch for an additional

1 second or more.
Release the power window switch for a moment, resume pushing the switch in the

one-touch opening direction, and hold it there for approximately 4 seconds or

more.
Pull and hold the power window switch in the one-touch closing direction again.

After the door window is completely closed, continue holding the switch for a fur-

ther 1 second or more.

If you release the switch while the window is moving, start again from the beginning.

If the window reverses and cannot be fully closed or opened, have the vehicle inspected

by your Lexus dealer.

184

3-5. Opening, closing the windows and moon roof

RC F_U

■

Door lock linked window operation

●

The power windows can be opened and closed using the mechanical key.

(

P. 519)

●

The power windows can be opened using the wireless remote control.

(

P. 145)

: These settings must be customized at your Lexus dealer.

■

When the battery is disconnected
The window lock switch is disabled. If necessary, press the window lock switch after

reconnecting the battery.

■

Power windows open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in the instru-

ment cluster when the engine switch is turned off and the driver’s door is opened with the

power windows open.

■

Customization
Settings (e.g. linked door lock operation) can be changed.

(Customizable features:

P. 569)

185

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RC F_U

WARNING

Observe the following precautions.

Failure to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the operation

for the passengers. In order to prevent accidental operation, especially by a child, do

not let a child operate the power windows. It is possible for children and other passen-

gers to have body parts caught in the power window. Also, when riding with a child, it

is recommended to use the window lock switch. (

P. 182)

●

Check to make sure that all passengers do not have any part of their body in a posi-

tion where it could be caught when a window is being operated.

●

When using the wireless remote control or mechanical key and operating the power

windows, operate the power window after checking to make sure that there is no pos-

sibility of any passenger having any of their body parts caught in the window. Also do

not let a child operate window by the wireless remote control or mechanical key. It is

possible for children and other passengers to get caught in the power window.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit the vehicle

along with the child. There may be accidental operation, due to mischief, etc., that

may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection function.

●

The jam protection function may not work if something gets jammed just before the

window is fully closed. Be careful not to get any part of your body jammed in the win-

dow.

■

Catch protection function

●

Never use any part of your body or clothing to intentionally activate the catch protec-

tion function.

●

The catch protection function may not work if something gets caught just before the

window is fully opened. Be careful not to get any part of your body or clothing caught

in the window.

186

3-5. Opening, closing the windows and moon roof

RC F_U

Opens the moon roof

The moon roof tilts up and then fully

opens.

Closes the moon roof

: Lightly press either way of the moon

roof switch to stop the moon roof part-
way.

Tilts the moon roof up

Tilts the moon roof down

: Lightly press either way of the moon

roof switch to stop the moon roof part-
way.

Moon roof



: If equipped

Use the overhead switches to open and close the moon roof and tilt it up and
down.

Opening and closing

Tilting up and down

187

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RC F_U

■

The moon roof can be operated when
The engine switch is in IGNITION ON mode.

■

Operating the moon roof after turning the engine off
The moon roof can be operated for approximately 45 seconds after the engine switch is

turned to ACCESSORY mode or turned off. It cannot, however, be operated once either

door is opened.

■

Jam protection function
If an object is detected between the moon roof and the frame while the moon roof is clos-

ing or tilting down, travel is stopped and the moon roof opens slightly.

■

Sunshade
The sunshade can be opened and closed manually. However, the sunshade will open

automatically when the moon roof is opened.

■

Door lock linked moon roof operation

●

The moon roof can be opened and closed using the mechanical key.

(

P. 519)

●

The moon roof can be opened using the wireless remote control.

(

P. 145)

: These settings must be customized at your Lexus dealer.

■

If the moon roof does not close normally
Perform the following procedure:

Stop the vehicle.
Press and hold the “CLOSE” switch.

The moon roof will close, reopen and pause for approximately 10 seconds. Then it will

close again and stop at the completely closed position.
Check to make sure that the moon roof is completely closed and then release the

switch.

: If the switch is released at the incorrect time, the procedure will have to be performed

again from the beginning.

If the moon roof does not fully close even after performing the above procedure cor-

rectly, have the vehicle inspected by your Lexus dealer.

188

3-5. Opening, closing the windows and moon roof

RC F_U

■

If the moon roof does not move normally
If the moon roof does not open or close normally or the automatic opening function does

not operate, perform the following initialization procedure.

Turn the engine switch to IGNITION ON mode.
Operate the moon roof.

Depending on the kind of malfunction perform either of the following:



If the moon roof does not open when the “OPEN” switch is pressed
Press and hold the “DOWN” switch or “CLOSE” switch until the moon roof is com-

pletely closed.

The moon roof will open and close a few times before it closes completely.
Confirm that the moon roof has completely stopped and release the switch.



If the moon roof does not open completely automatically even though it tilts up and

opens while the “OPEN” switch is being pressed and held
Press and hold the “OPEN” switch until the moon roof opens completely.
Press and hold the “CLOSE” switch until the moon roof closes completely.
Press and hold the “UP” switch until the moon roof tilts up and stops.
Press and hold the “DOWN” switch until the moon roof tilts down and stops at the

completely closed position.

If you release the switch while the moon roof is moving, perform the procedure again

from the beginning.
If, after performing the above procedures correctly, the moon roof still does not open or

close normally or the automatic opening function does not operate, have the vehicle

inspected by your Lexus dealer.

■

Moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display in the instru-

ment cluster when the engine switch is turned off and the driver’s door is opened with the

moon roof open.

■

Customization
Settings (e.g. linked door lock operation) can be changed.

(Customizable features:

P. 569)

3
4
5
6

189

3-5. Opening, closing the windows and moon roof

Op
era
tio

n of
ea

RC F_U

WARNING

Observe the following precautions.

Failure to do so may cause death or serious injury.

■

Opening the moon roof

●

Do not allow any passengers to put their hands or heads outside the vehicle while it is

moving.

●

Do not sit on top of the moon roof.

■

Closing the moon roof

●

The driver is responsible for moon roof opening and closing operations.

In order to prevent accidental operation, especially by a child, do not let a child oper-

ate the moon roof. It is possible for children and other passengers to have body parts

caught in the moon roof.

●

Check to make sure that all passengers do not have any part of their body in a posi-

tion where it could be caught when the moon roof is being operated.

●

When using the wireless remote control or mechanical key and operating the moon

roof, operate the moon roof after checking to make sure that there is no possibility of

any passenger having any of their body parts caught in the moon roof. Also, do not let

a child operate moon roof by the wireless remote control or mechanical key. It is pos-

sible for children and other passengers to get caught in the moon roof.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit the vehicle

along with the child. There may be accidental operation, due to mischief, etc., that

may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection function.

●

The jam protection function may not work if something gets caught just before the

moon roof is fully closed. Also, the jam protection function is not designed to operate

while the moon roof switch is being pressed. Take care so that your fingers, etc. do not

get caught.

NOTICE

■

To prevent damage to the moon roof

●

Before opening, make sure that there are no foreign objects such as stones or ice

around the opening.

●

Do not hit the face or edge of the moon roof with hard objects.

■

Operating the moon roof
There is the possibility that water or rain will get into the vehicle if you operate the

moon roof after a rainfall, snowfall or car wash. Wipe the moon roof dry with a cloth

before operating it.

Content .. 9 10 11 12 ..
