LEXUS NX 300 (2019 year). Instruction

236

4-5. Using the driving support systems

LEXUS NX300 Owners Manu-

al_USA_M78285_en

■

Operation of the air conditioning sys-

tem in Eco mode

Eco mode controls the heating/cooling

operations and fan speed of the air condi-

tioning system to enhance fuel efficiency. To

improve air conditioning performance,

adjust the fan speed or turn off Eco mode.

■

When canceling Eco mode/Sport mode

●

Select another driving mode. Also, Sport

mode will be canceled automatically

when the engine switch is turned off.

●

Normal mode and Eco mode will not be

canceled automatically until another driv-

ing mode is selected, even if the engine

switch is turned off.

■

Operating the ASC (Active Sound

Control)

If the ASC is ON, an electronic sound plays

when the Sport S+ mode is selected.

■

ABS (Anti-lock Brake System)

Helps to prevent wheel lock when the
brakes are applied suddenly, or if the
brakes are applied while driving on a
slippery road surface

■

Brake assist

Generates an increased level of brak-
ing force after the brake pedal is
depressed when the system detects a
panic stop situation.

■

VSC (Vehicle Stability Control)

Helps the driver to control skidding
when swerving suddenly or turning on
slippery road surfaces

■

Enhanced VSC (Enhanced Vehi-
cle Stability Control)

Provides cooperative control of the
ABS, TRAC, VSC and EPS.
Helps to maintain directional stability
when swerving on slippery road sur-
faces by controlling steering perfor-
mance.

Driving assist systems

To keep driving safety and perfor-
mance, the following systems oper-
ate automatically in response to
various driving situations. Be aware,
however, that these systems are
supplementary and should not be
relied upon too heavily when oper-
ating the vehicle.

Summary of the driving assist
systems

237

4-5. Using the driving support systems

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Driving

■

Trailer Sway Control

Helps the driver to control trailer sway
by selectively applying brake pressure
for individual wheels and reducing
driving torque when trailer sway is
detected.

■

TRAC (Traction Control)

Helps to maintain drive power and pre-
vent the drive wheels from spinning
when starting the vehicle or accelerat-
ing on slippery roads

■

Hill-start assist control

Helps to reduce the backward move-
ment of the vehicle when starting on an
uphill

■

EPS (Electric Power Steering)

Employs an electric motor to reduce
the amount of effort needed to turn the
steering wheel

■

Dynamic Torque Control AWD
system (if equipped)

Automatically switches from front-
wheel drive to all-wheel drive (AWD)
according to the driving conditions,
helping to ensure reliable handling and
stability. Examples of conditions where
the system will switch to AWD are
when cornering, going uphill, starting
off or accelerating, and when the road
surface is slippery due to snow, rain,
etc.

■

AVS (Adaptive Variable Suspen-
sion system) (if equipped)

By independently controlling the
damping force of the shock absorbers
for each of the 4 wheels according to
the road and driving conditions, this

system helps riding comfort with supe-
rior vehicle stability, and helps good
vehicle posture. If Sport S+ mode is
selected using the driving mode select
switch, the damping force will become
more suitable for sporty driving.
(

P.234)

■

PCS (Pre-Collision System)

P.188

■

BSM (Blind Spot Monitor) (if
equipped)

P.227

■

When the TRAC/VSC/Trailer Sway

Control systems are operating

The slip indicator light will flash while the

TRAC/VSC/Trailer Sway Control systems

are operating.

■

Disabling the TRAC system

If the vehicle gets stuck in mud, dirt or snow,
the TRAC system may reduce power from
the engine to the wheels. Pressing

turn the system off may make it easier for
you to rock the vehicle in order to free it.
To turn the TRAC system off, quickly press
and release

The “Traction Control Turned Off” will be
shown on the multi-information display.
Press

again to turn the system back on.

238

4-5. Using the driving support systems

LEXUS NX300 Owners Manu-

al_USA_M78285_en

■

Turning off both TRAC, VSC and Trailer

Sway Control systems

To turn the TRAC, VSC and Trailer Sway
Control systems off, press and hold

for

more than 3 seconds while the vehicle is
stopped.
The VSC off indicator will come on and the
“Traction Control Turned Off” will be shown
on the multi-information display.

Press

again to turn the systems back on.

: On vehicles with pre-collision system,

pre-collision brake assist and pre-colli-
sion braking will also be disabled. The
PCS warning light will come on and the
message will be shown on the multi-infor-
mation display. (

P.194)

■

When the message is displayed on the

multi-information display showing that
TRAC has been disabled even if

has

not been pressed

TRAC cannot be operated. Contact your

Lexus dealer.

■

Sounds and vibrations caused by the

ABS, brake assist, VSC, Trailer Sway

Control, TRAC and hill-start assist con-

trol systems

●

A sound may be heard from the engine

compartment when the brake pedal is

depressed repeatedly, when the engine is

started or just after the vehicle begins to

move. This sound does not indicate that a

malfunction has occurred in any of these

systems.

●

Any of the following conditions may

occur when the above systems are oper-

ating. None of these indicates that a mal-

function has occurred.

• Vibrations may be felt through the vehicle

body and steering.

• A motor sound may be heard also after

the vehicle comes to a stop.

• The brake pedal may pulsate slightly after

the ABS is activated.

• The brake pedal may move down slightly

after the ABS is activated.

■

EPS operation sound

When the steering wheel is operated, a

motor sound (whirring sound) may be

heard. This does not indicate a malfunction.

■

Reduced effectiveness of the EPS sys-

tem

The effectiveness of the EPS system is

reduced to prevent the system from over-

heating when there is frequent steering

input over an extended period of time. The

steering wheel may feel heavy as a result.

Should this occur, refrain from excessive

steering input or stop the vehicle and turn

the engine off. The EPS system should

return to normal within 10 minutes.

■

Automatic reactivation of TRAC, Trailer

Sway Control and VSC systems

After turning the TRAC, Trailer Sway Con-

trol and VSC systems off, the systems will

be automatically re-enabled in the following

situations:

●

When the engine switch is turned off

●

If only the TRAC system is turned off, the

TRAC will turn on when vehicle speed

increases

If both the TRAC and VSC systems are

turned off, automatic re-enabling will not

occur when vehicle speed increases.

■

Operating conditions of hill-start assist

control

When the following four conditions are met,

the hill-start assist control will operate:

●

The shift lever is in a position other than P

or N (when starting off forward/back-

ward on an upward incline).

239

4-5. Using the driving support systems

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Driving

●

The vehicle is stopped.

●

The accelerator pedal is not depressed.

●

The parking brake is not engaged.

■

Automatic system cancelation of hill-

start assist control

The hill-start assist control will turn off in any

of the following situations:

●

The shift lever is shifted to P or N.

●

The accelerator pedal is depressed.

●

The parking brake is engaged.

●

2 seconds at maximum elapsed after the

brake pedal is released

WARNING

■

The ABS does not operate effectively

when

●

The limits of tire gripping performance

have been exceeded (such as exces-

sively worn tires on a snow covered

road).

●

The vehicle hydroplanes while driving

at high speed on wet or slick roads.

■

Stopping distance when the ABS is

operating may exceed that of normal

conditions

The ABS is not designed to shorten the

vehicle’s stopping distance. Always main-

tain a safe distance from the vehicle in

front of you, especially in the following

situations:

●

When driving on dirt, gravel or snow-

covered roads

●

When driving with tire chains

●

When driving over bumps in the road

●

When driving over roads with potholes

or uneven surfaces

■

TRAC/VSC may not operate effec-

tively when

Directional control and power may not

be achievable while driving on slippery

road surfaces, even if the TRAC/VSC

system is operating.

Drive the vehicle carefully in conditions

where stability and power may be lost.

■

Hill-start assist control does not oper-

ate effectively when

●

Do not overly rely on hill-start assist

control. Hill-start assist control may

not operate effectively on steep

inclines and roads covered with ice.

●

Unlike the parking brake, hill-start

assist control is not intended to hold

the vehicle stationary for an extended

period of time. Do not attempt to use

hill-start assist control to hold the vehi-

cle on an incline, as doing so may lead

to an accident.

■

When the TRAC/VSC/ Trailer Sway

Control is activated

The slip indicator light flashes. Always

drive carefully. Reckless driving may

cause an accident. Exercise particular

care when the indicator light flashes.

■

When the TRAC/VSC/Trailer Sway

Control systems are turned off

Be especially careful and drive at a speed

appropriate to the road conditions. As

these are the systems to help ensure

vehicle stability and driving force, do not

turn the TRAC/VSC/Trailer Sway Con-

trol systems off unless necessary.

Trailer Sway Control is part of the VSC

system and will not operate if VSC is

turned off or experiences a malfunction.

240

4-5. Using the driving support systems

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Press the switch.

The torque of the engine is distributed to
the rear wheels to the maximum extent
possible in accordance with driving condi-
tions.
Pressing the switch again cancels all-wheel
drive lock mode and returns the Dynamic
Torque Control AWD system to normal
mode. (

P.237)

■

All-wheel drive lock mode can be oper-

ated when

The engine switch is in IGNITION ON

mode.

■

Automatic release for the all-wheel

drive lock mode

●

All-wheel drive lock mode is canceled

when the brakes are applied to ensure

the ABS and VSC systems operate effec-

tively.

●

All-wheel drive lock mode is canceled

WARNING

■

Replacing tires

Make sure that all tires are of the speci-

fied size, brand, tread pattern and total

load capacity. In addition, make sure that

the tires are inflated to the recom-

mended tire inflation pressure level.

The ABS, TRAC, Trailer Sway Control

and VSC systems will not function cor-

rectly if different tires are installed on the

vehicle.

Contact your Lexus dealer for further

information when replacing tires or

wheels.

■

Handling of tires and the suspension

Using tires with any kind of problem or

modifying the suspension will affect the

driving assist systems, and may cause a

system to malfunction.

■

Trailer Sway Control precaution

The Trailer Sway Control system is not

able to reduce trailer sway in all situa-

tions. Depending on many factors such

as the conditions of the vehicle, trailer,

road surface and driving environment,

the Trailer Sway Control system may not

be effective. Refer to your trailer owner’s

manual for information on how to tow

your trailer properly.

■

If trailer sway occurs

Observe the following precautions.

Failing to do so may cause death or seri-

ous injury.

●

Firmly grip the steering wheel. Steer

straight ahead. Do not try to control

trailer sway by turning the steering

wheel.

●

Begin releasing the accelerator pedal

immediately but very gradually to

reduce speed.

Do not increase speed. Do not apply

vehicle brakes.

If you make no extreme correction with

the steering or brakes, your vehicle and

trailer should stabilize. (

P.237)

All-wheel drive lock switch
(AWD models)

All-wheel drive lock mode can be
used when a large amount of drive
power needs to be applied to all the
wheels, such as when the vehicle
gets stuck in mud and you need to
free it.

Using All-wheel drive lock mode

242

4-6. Driving tips

LEXUS NX300 Owners Manu-

al_USA_M78285_en

4-6.Driving tips

 Use fluids that are appropriate to

the prevailing outside temperatures.

• Engine oil
• Engine coolant
• Washer fluid

 Have a service technician inspect

the condition of the battery.

 Have the vehicle fitted with four

snow tires or purchase a set of tire
chains for the front tires

Ensure that all tires are the same size and
brand, and that chains match the size of the
tires.

: Tire chains cannot be mounted on the

225/60R18 tires.
Snow tires should be used instead.

Perform the following according to the
driving conditions:
 Do not try to forcibly open a window

or move a wiper that is frozen. Pour
warm water over the frozen area to
melt the ice. Wipe away the water

Winter driving tips

Carry out the necessary prepara-
tions and inspections before driving
the vehicle in winter. Always drive
the vehicle in a manner appropriate
to the prevailing weather condi-
tions.

Preparation for winter

WARNING

■

Driving with snow tires

Observe the following precautions to

reduce the risk of accidents.

Failure to do so may result in a loss of

vehicle control and cause death or seri-

ous injury.

●

Use tires of the specified size.

●

Maintain the recommended level of air

pressure.

●

Do not drive in excess of 75 mph (120

km/h), regardless of the type of snow

tires being used.

●

Use snow tires on all, not just some

wheels.

■

Driving with tire chains

Observe the following precautions to

reduce the risk of accidents.

Failure to do so may result in the vehicle

being unable to be driven safely, and may

cause death or serious injury.

●

Do not drive in excess of the speed

limit specified for the tire chains being

used, or 30 mph (50 km/h), which-

ever is lower.

●

Avoid driving on bumpy road surfaces

or over potholes.

●

Avoid sudden acceleration, abrupt

steering, sudden braking and shifting

operations that cause sudden engine

braking.

●

Slow down sufficiently before entering

a curve to ensure that vehicle control is

maintained.

NOTICE

■

Repairing or replacing snow tires

Request repairs or replacement of snow

tires from Lexus dealers or legitimate tire

retailers.

This is because the removal and attach-

ment of snow tires affects the operation

of the tire pressure warning valves and

transmitters.

Before driving the vehicle

243

4-6. Driving tips

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Driving

immediately to prevent it from
freezing.

 To ensure proper operation of the

climate control system fan, remove
any snow that has accumulated on
the air inlet vents in front of the
windshield.

 Check for and remove any excess

ice or snow that may have accumu-
lated on the exterior lights, vehicle’s
roof, chassis, around the tires or on
the brakes.

 Remove any snow or mud from the

bottom of your shoes before getting
in the vehicle.

Accelerate the vehicle slowly, keep a
safe distance between you and the
vehicle ahead, and drive at a reduced
speed suitable to road conditions.

 Park the vehicle and move the shift

lever to P without setting the park-
ing brake. The parking brake may
freeze up, preventing it from being
released. If the vehicle is parked
without setting the parking brake,
make sure to block the wheels.
Failure to do so may be dangerous
because it may cause the vehicle to
move unexpectedly, possibly lead-
ing to an accident.

When the parking brake is in automatic
mode, release the parking brake after shift-
ing the shift lever to P. (

P.162)

 If the vehicle is left parked with the

brakes damp in cold temperatures,
there is a possibility of the brakes
freezing.

 If the vehicle is parked without set-

ting the parking brake, confirm that
the shift lever cannot be moved out
of P

: The shift lever will be locked if it is

attempted to be shifted from P to any
other position without depressing the
brake pedal. If the shift lever can be
shifted from P, there may be a problem
with the shift lock system. Have the vehi-
cle inspected by your Lexus dealer
immediately.

Use the correct tire chain size when
mounting the tire chains. Chain size is
regulated for each tire size.



Vehicles with 225/65R17 and
235/55R18 tires

When driving the vehicle

When parking the vehicle

WARNING

■

When parking the vehicle

When parking the vehicle without apply-

ing the parking brake, make sure to

chock the wheels. If you do not chock the

wheels, the vehicle may move unexpect-

edly, possibly resulting in an accident.

Selecting tire chains

244

4-6. Driving tips

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Side chain:

0.12 in. (3 mm) in diameter
0.39 in. (10 mm) in width
0.98 in. (25 mm) in length

Cross chain:

0.16 in. (4 mm) in diameter
0.55 in. (14 mm) in width
0.98 in. (25 mm) in length



Vehicles with 225/60R18 tires

Tire chains cannot be mounted on the
225/60R18 tires.
Snow tires should be used instead.

Regulations regarding the use of tire
chains vary depending on location and
type of road. Always check local regu-
lations before installing chains.

■

Tire chain installation

Observe the following precautions when

installing and removing chains:

●

Install and remove tire chains in a safe

location.

●

Install tire chains on the front tires only.

Do not install tire chains on the rear tires.

●

Install tire chains on front tires as tightly as

possible. Retighten chains after driving 1/

4 - 1/2 mile (0.5 - 1.0 km).

●

Install tire chains following the instruc-

tions provided with the tire chains.

 Specific design characteristics give

it a higher center of gravity than
ordinary passenger cars. This vehi-
cle design feature causes this type
of vehicle to be more likely to roll-
over. Utility vehicles have a signifi-
cantly higher rollover rate than
other types of vehicles.

 An advantage of the higher ground

clearance is a better view of the
road allowing you to anticipate
problems.

 It is not designed for cornering at

the same speeds as ordinary pas-
senger cars any more than low-
slung sports cars designed to per-
form satisfactorily under off-road
conditions. Therefore, sharp turns at
excessive speeds may cause roll-
over.

Regulations on the use of tire
chains

NOTICE

■

Fitting tire chains

The tire pressure warning valves and

transmitters may not function correctly

when tire chains are fitted.

A
B
C

E
F

Utility vehicle precautions

This vehicle belongs to the utility
vehicle class, which has higher
ground clearance and narrower
tread in relation to the height of its
center of gravity.

Utility vehicle feature

245

4-6. Driving tips

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Driving

Your vehicle is not designed to be
driven off-road. However, in the event
that off-road driving cannot be
avoided, please observe the following
precautions to help avoid the areas
prohibited to vehicles.

 Drive your vehicle only in areas

where off-road vehicles are permit-
ted to travel.

 Respect private property. Get

owner’s permission before entering
private property.

 Do not enter areas that are closed.

Honor gates, barriers and signs that
restrict travel.

 Stay on established roads. When

conditions are wet, driving tech-
niques should be changed or travel
delayed to prevent damage to
roads.

■

Additional information for off-road driv-

ing



For owners in U.S. mainland, Hawaii and

Puerto Rico:

To obtain additional information pertaining

to driving your vehicle off-road, consult the

following organizations.

●

State and Local Parks and Recreation

Departments

●

State Motor Vehicle Bureau

●

Recreational Vehicle Clubs

●

U.S. Forest Service and Bureau of Land

Management

WARNING

■

Utility vehicle precautions

Always observe the following precau-

tions to minimize the risk of death or seri-

ous injury or damage to your vehicle:

●

In a rollover crash, an unbelted person

is significantly more likely to die than a

person wearing a seat belt. Therefore,

the driver and all passengers should

always fasten their seat belts.

●

Avoid sharp turns or abrupt maneu-

vers, if at all possible.

Failure to operate this vehicle correctly

may result in loss of control or vehicle

rollover causing death or serious

injury.

●

Loading cargo on the roof luggage

carrier (if equipped) will make the cen-

ter of the vehicle gravity higher. Avoid

high speeds, sudden starts, sharp

turns, sudden braking or abrupt

maneuvers, otherwise it may result in

loss of control or vehicle rollover due

to failure to operate this vehicle cor-

rectly.

●

Always slow down in gusty crosswinds.

Because of its profile and higher cen-

ter of gravity, your vehicle is more sen-

sitive to side winds than an ordinary

passenger car. Slowing down will allow

you to have better control.

●

Do not drive horizontally across steep

slopes. Driving straight up or straight

down is preferred. Your vehicle (or any

similar off-road vehicle) can tip over

sideways much more easily than for-

ward or backward.

Off-road driving

WARNING

■

Off-road driving precautions

Always observe the following precau-

tions to minimize the risk of death or seri-

ous injury or damage to your vehicle:

●

Drive carefully when off the road. Do

not take unnecessary risks by driving in

dangerous places.

●

Do not grip the steering wheel spokes

when driving off-road. A bad bump

could jerk the wheel and injure your

hands. Keep both hands and especially

your thumbs on the outside of the rim.

246

4-6. Driving tips

LEXUS NX300 Owners Manu-

al_USA_M78285_en

WARNING

●

Always check your brakes for effec-

tiveness immediately after driving in

sand, mud, water or snow.

●

After driving through tall grass, mud,

rock, sand, water, etc., check that there

is no grass, bush, paper, rags, stone,

sand, etc. adhering or trapped to the

underbody. Clear off any such matter

from the underbody. If the vehicle is

used with these materials trapped or

adhering to the underbody, a break-

down or fire could occur.

●

When driving off-road or in rugged

terrain, do not drive at excessive

speeds, jump, make sharp turns, strike

objects, etc. This may cause loss of

control or vehicle rollover causing

death or serious injury. You are also

risking expensive damage to your

vehicle’s suspension and chassis.

NOTICE

■

To prevent water damage

Take all necessary safety measures to

ensure that water damage to the engine

or other components does not occur.

●

Water entering the engine air intake

will cause severe engine damage.

●

Water entering the automatic trans-

mission will cause deterioration in shift

quality, locking up of your transmission

accompanied by vibration, and ulti-

mately damage.

●

Water can wash the grease from wheel

bearings, causing rusting and prema-

ture failure, and may also enter the dif-

ferentials, transmission and transfer

case, reducing the gear oil’s lubricating

qualities.

■

When you drive through water

If driving through water, such as when

crossing shallow streams, first check the

depth of the water and the bottom of the

riverbed for firmness. Drive slowly and

avoid deep water.

■

Inspection after off-road driving

●

Sand and mud that has accumulated

around brake discs may affect braking

efficiency and may damage brake sys-

tem components.

●

Always perform a maintenance

inspection after each day of off-road

driving that has taken you through

rough terrain, sand, mud, or water. For

scheduled maintenance information,

refer to the “Warranty and Services

Guide/Owner’s Manual Supplement/
Scheduled Maintenance

”

247

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Interio

r fe

atures

Interior features

5-1. Remote Touch

Remote Touch............................

248

5-2. Using the air conditioning system

and defogger

Automatic air conditioning system

........................................................

252

Heated steering wheel/seat heat-

ers/seat ventilators................

259

5-3. Using the interior lights

Interior lights list.........................

262

5-4. Using the storage features

List of storage features............

265

Luggage compartment features

........................................................

268

5-5. Using the other interior features

Other interior features ...........

272

Garage door opener...............

282

Compass.......................................

287

Lexus Enform Safety Connect

........................................................

290

Lexus Enform Remote ............

295

Lexus Enform Service Connect

........................................................

296

248

5-1. Remote Touch

LEXUS NX300 Owners Manu-

al_USA_M78285_en

5-1.Remote Touch

■

Switches



10.3-inch display model

“MAP” button

Press this button to display the vehicle’s
current position.



8-inch display model

“HOME” button

Press this button to display the home
screen.

“MENU” button

Press this button to display the menu
screen.

Back button

Press this button to display the previous

Touchpad

Slide your finger on the touchpad and
move the pointer to select a function, letter

and screen button.
Press the touchpad to enter the selected
function, letter or screen button. Certain
finger movements on the touchpad can
perform functions, such as changing map
scalings and scrolling list screens.

Sub function button

When

is displayed on the screen, a

function screen assigned to the screen can
be displayed.

■

Using the touchpad

Select: Touch the touchpad to
select the desired button on the
screen.

Enter: The buttons on the screen
can be selected by either depress-
ing or double tapping on the touch-
pad. Once a button has been
selected, the screen will change.

■

Touch operation

Operations are performed by touching
the touchpad with your finger.
 Trace

Trace the pad surface while maintaining
contact with the touchpad. Moving the
cursor and the pointer.

Remote Touch

The Remote Touch can be used to
operate the navigation/multimedia
system display. Owners of models
equipped with a navigation system
should refer to the “NAVIGATION
AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

Remote Touch operation

249

5-1. Remote Touch

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Interio

r fe

atures

 Double tap

Tap the touchpad twice, quickly. Select the
button on the screen.

 Flick

Quick and long movement along the
touchpad with your finger. Move the list
screen or map screen.

 Pinch in/Pinch out

Slide fingers toward each other or apart on
the touchpad. Change the scale of the
map.

Press the “MENU” button on the
Remote Touch to display the menu
screen.
The display may differ depending on
the type of the system.



8-inch display model

NOTICE

■

To prevent damage to the Remote

Touch

Observe the following precautions. Fail-

ure to do so may cause damage to the

Remote Touch.

●

Do not allow the Remote Touch to

come into contact with food, liquid,

stickers or lit cigarettes.

●

Do not subject the Remote Touch to

excessive pressure or strong impact.

●

Do not push the touchpad with a

strong force or use a sharp pointed

object to operate the pad.

Menu screen

250

5-1. Remote Touch

LEXUS NX300 Owners Manu-

al_USA_M78285_en



10.3-inch display model

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

: This function is not made available on

some models.



8-inch display models

The home screen can be display multiple information screens. For details about the
functions and operation of the display, refer to the respective section and “NAVI-
GATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”



10.3-inch display models

 Split-screen display

Different information can be displayed on the left and right of the screen. For example, air
conditioning system screen can be displayed and operated while the fuel consumption
information screen is being displayed. The large screen on the left of the display is called

Switch

Function

Select to display the “Destina-
tion” screen.

Select to display the radio con-
trol screen.

Select to display the media con-
trol screen.

Select to display the hands-free
operation screen.

Select to display the “Apps”
screen.

*1, 2

Select to display the “Informa-
tion” screen.

(

P.82)

Select to display the “Setup”
screen.

Select to display the air condi-
tioning control screen.
(

P.255)

Select to adjust the contrast and
brightness of the screens, turn
the screen off, etc.

*1, 2

Switch

Function

Display overview

251

5-1. Remote Touch

LEXUS NX300 Owners Manu-

al_USA_M78285_en

Interio

r fe

atures

the main display, and the small screen to the right is called the side display.

 Main display

For details about the functions and opera-
tion of the main display, refer to the respec-
tive section and “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

 Side display

The following functions can be displayed
and operated on the side display.

Select

to display the desired

screen.

Navigation system

Audio

Vehicle information
Air conditioning system (

P.255)

Show/hide the side display.

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

■

Screen display during low temperatures

When the ambient temperature is

extremely low, screen response may be

delayed even if the Remote Touch is oper-

ated.

A
B
C
D

LEXUS NX 300 (2019 year). Instruction - part 15
