LEXUS LX 570 (2019 year). Instruction - part 10

WARNING

■

Seat adjustment
To reduce the risk of sliding under the lap belt during a collision, do not recline the seat

more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces

directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk

of death or serious injury in the event of an accident.
Adjustments should not be made while driving as the seat may unexpectedly move and

cause the driver to lose control of the vehicle.

■

When the seatback is folded

●

Do not sit on or place anything on the seatback while driving.

●

Be sure to install the seat hook covers on the seat hooks, or you may get burned when

they become hot.

■

When returning the seatbacks to their original position
Observe the following precautions. Failure to do so may result in death or serious

injury.

●

Be careful not to get your hands or feet pinched in the seat.

●

Make sure the seats are securely locked. Failure to do so will prevent the seat belt

from operating properly.

●

Check that the seat belts are not twisted or caught under the seat.

●

Arrange the seat belts in the proper positions for ready use.

■

Avoiding damage to seat components
Do not hang or attach anything on the seatback striker.

NOTICE

■

Before tumbling, folding up the seats
The seat belts and buckles must be stowed.

■

After returning the third seat (if equipped)
Make sure that the handle on the rear of the seatback has been secured.

157

Driving position memory

The seat and steering wheel are automatically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the driver’s seat and steer-
ing wheel are automatically adjusted to
a position that allows driver to enter
and exit the vehicle easily.

• The shift lever has been shifted to P.
• The engine switch has been turned

off.

• The driver’s seat belt has been unfas-

tened.

When any of the following has been performed, the driver’s seat and steering
wheel automatically return to their original positions.

• The engine switch has been turned to ACCESSORY mode or IGNITION

ON mode.

• The driver’s seat belt has been fastened.

■

Operation of the power easy access system
When exiting the vehicle, the power easy access system may not operate if the seat is

already close to the rearmost position, etc.

■

Customization
The seat movement amount settings of the power easy access system can be custom-

ized. (Customizable features:

P. 584)

This feature automatically adjusts the driver’s seats, steering wheel and out-
side rear view mirrors to make entering and exiting the vehicle easier or to
suit your preferences.

Power easy access system

158

Your preferred driving position (the position of the driver’s seat, steering wheel,
outside rear view mirrors and HUD [head-up display] [if equipped]) can be
entered into the computer’s memory and recalled with the touch of a button. It is
also possible to set this function to activate automatically when the doors are
unlocked.
Three different driving positions can be recorded into memory.

■

Recording procedure

Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Adjust the driver’s seat, steering wheel, outside rear view mirrors and HUD
(head-up display) (if equipped) to the desired positions.
While pressing the “SET” button,
or within 3 seconds after the
“SET” button is pressed, press
button “1”, “2” or “3” until the
buzzer sounds.

If the selected button has already

been preset, the previously recorded

position will be overwritten.

■

Recall procedure

Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

Driving position memory

2
3

159

■

To stop the position recall operation part-way through
Perform any of the following:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Operate any of the seat adjustment switches (only cancels seat position recall).

●

Operate the tilt and telescopic steering control switch (only cancels steering wheel

position recall).

■

Operating the driving position memory after turning the engine switch off
Recorded seat positions can be activated up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is closed again.

■

If the battery is disconnected
The memorized positions must be reset because the computer’s memory is erased when

the battery is disconnected.

Each electronic key can be registered to recall your preferred driving position.

■

Registering procedure
Record your driving position to button “1”, “2” or “3” before performing the
following:
Carry only the key you want to register, and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be recorded
properly.

Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
While pressing the recalled but-
ton, press and hold the door lock
switch (either lock or unlock) until
the buzzer sounds.

If the button could not be registered,

the buzzer sounds continuously for

approximately 3 seconds.

Memory recall function (driver’s side only)

2
3

160

■

Recall procedure

Make sure that the doors are locked before recalling the driving position.
Carry the electronic key that has been registered to the driving position,
and then unlock and open the driver’s door using the smart access system
with push-button start or wireless remote control.

The driving position will move to the recorded position (not including the steering

wheel and HUD [head-up display] [if equipped]). However, the seat will move to a

position slightly behind the recorded position in order to make entering the vehicle

easier.
If the driving position is in a position that has already been recorded, the seat and

outside rear view mirrors will not move.

Turn the engine switch to ACCESSORY mode or IGNITION ON mode,
or fasten a seat belt.

The seat, steering wheel and HUD (head-up display) (if equipped) will move to the

recorded position.

■

Cancelation procedure
Carry only the key you want to cancel and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be canceled
properly.

Turn the engine switch to IGNITION ON mode.
While pressing the “SET” button, press and hold the door lock switch
(either lock or unlock) until the buzzer sounds twice.

If the button could not be canceled, the buzzer sounds continuously for approxi-

mately 3 seconds.

■

Recalling the driving position using the memory recall function

●

Different driving positions can be registered for each electronic key. Therefore, the

driving position that is recalled may be different depending on the key being carried.

●

If a door other than the driver’s door is unlocked with the smart access system with

push-button start, the driving position cannot be recalled. In this case, press the driving

position button which has been set.

■

Customization
The unlock door settings of the memory recall function can be customized.

(Customizable features:

P. 584)

WARNING

■

Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear passenger or

squeeze your body against the steering wheel.

161

Head restraints

Vertical adjustment

Pull the head restraints up.

Down

Push the head restraint down while

pushing the lock release button.

Angle adjustment (if equipped)

Pull the head restraints up.

Down

Push the head restraint down while

pushing the lock release button.

Head restraints are provided for all seats.

Front seats

Lock release button

Second seats

Lock release button

162

To fold the head restraints, pull the head
restraint angle lever

■

Adjusting the height of the head restraints

■

Removing the head restraints



Front seats

While pressing in the flathead screwdriver, pull up the head restraint.



Second seats

Third outboard seats (if equipped)

Make sure that the head restraints are adjusted

so that the center of the head restraint is closest

to the top of your ears.

Push a flathead screwdriver into the slot. The

slot is located on the right side of the right

head restraint anchor.

Pull the head restraint up while pressing the lock

release button.

Lock release button

163



Third center seat (if equipped)



Third outboard seats (if equipped)

The head restraint cannot be removed.

■

Installing the head restraints (except for the third outboard seats)

Align the head restraint with the installation holes.
Push down the head restraint to the lock position.
Press and hold the lock release button when lowering the head restraint.

■

When not using the third center seat head restraint (if equipped)

Pull the head restraint up while pressing the lock

release button.

Open the zipper on the back of the third seat

and stow the head restraint inside.

WARNING

■

Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to do so may

result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After adjusting the head restraints, push down on them and make sure they are

locked in position.

●

Do not drive with the head restraints removed.

Lock

release

button

164

Steering wheel

Operating the switch moves the steer-
ing wheel in the following directions:

Up
Down
Toward the driver
Away from the driver

To sound the horn, press on or close to
the

mark.

Adjustment procedure

2
3
4

Horn

165

■

The steering wheel can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode

: If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of

engine switch mode.

■

Automatic adjustment of the steering position
A desired steering position can be entered to memory and recalled automatically by the

driving position memory system. (

P. 157)

■

Power easy access system
The steering wheel and driver’s seat move in accordance with engine switch mode and

the driver’s seat belt condition. (

P. 157)

WARNING

Do not adjust the steering wheel while driving.

Doing so may cause the driver to mishandle the vehicle and cause an accident, result-

ing in death or serious injury.

166

Inside rear view mirror

The height of the rear view mirror can be adjusted to suit your driving posture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness of the headlights of vehicles behind, the
reflected light is automatically reduced.
Changing automatic anti-glare func-
tion mode
ON/OFF

When the automatic anti-glare function

is in ON mode, the indicator illuminates.

The function will set to ON mode each

time the engine switch is turned to

IGNITION ON mode.

Pressing the button turns the function to

OFF mode. (The indicator also turns

off.)

■

To prevent sensor error

The rear view mirror’s position can be adjusted to enable sufficient confirma-
tion of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

Indicator

To ensure that the sensors operate properly, do

not touch or cover them.

167

WARNING

Do not adjust the position of the mirror while driving.

Doing so may lead to mishandling of the vehicle and an accident, resulting in death or

serious injury.

168

Outside rear view mirrors

To select a mirror to adjust, press the
switch.

Left
Right

Pressing the same switch again will

put the switch in neutral.

To adjust the mirror, press the switch.

Up
Right
Down
Left

■

Using the switch
Press the switch to fold the mirrors.

Press it again to extend them to the

original position.

Adjustment procedure

2
3
4

Automatically folding and extending the mirrors

169

■

Setting automatic mode
Automatic mode allows the folding or extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode.

The indicator will come on.
Pressing the switch once more will

return to manual mode.

When either “L” or “R” of the mirror select switch is selected, the outside rear
view mirrors will automatically angle downwards when the vehicle is reversing in
order to give a better view of the ground.
To disable this function, select neither “L” nor “R”.

■

Adjusting the mirror angle when the vehicle is reversing
With the shift lever in R, adjust the mirror angle at a desired position. The
adjusted angle will be memorized and the mirror will automatically tilt to the
memorized angle whenever the shift lever is shifted to R from next time.

The memorized downward tilt position of the mirror is linked to the normal position

(angle adjusted with the shift lever in other than R). Therefore, if the normal posi-

tion is changed after adjustment, the tilt position will also change.
When the normal position is changed, readjust the angle in reversing.

■

Mirror angle can be adjusted when
The engine switch is in ACCESSORY or IGNITION ON mode.

■

When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the

rear window defogger to turn on the outside rear view mirror defoggers. (

P. 411)

■

Automatic adjustment of the mirror angle
A desired mirror face angle can be entered to memory and recalled automatically by the

driving position memory. (

P. 157)

■

Auto anti-glare function
When the anti-glare inside rear view mirror is set to automatic mode, the outside rear

view mirrors will activate in conjunction with the anti-glare inside rear view mirror to

reduce reflected light. (

P. 166)

Indicator

Linked mirror function when reversing

170
