LEXUS LS 500 (2019 year). Instruction - part 3

1-1. For safe use

LS500_OM_(U)_1809

Exhaust gas precautions

Harmful substance to the human
body is included in exhaust gases if
inhaled.

WARNING

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.

Failure to do so may cause exhaust gases

enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

■

Important points while driving

●

Keep the trunk lid closed.

●

If you smell exhaust gases in the vehi-

cle even when the trunk lid is closed,

open the windows and have the vehi-

cle inspected at your Lexus dealer as

soon as possible.

■

When parking

●

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the engine.

●

Do not leave the vehicle with the

engine on for a long time.

If such a situation cannot be avoided,

park the vehicle in an open space and

ensure that exhaust fumes do not enter

the vehicle interior.

●

Do not leave the engine running in an

area with snow build-up, or where it is

snowing. If snowbanks build up around

the vehicle while the engine is running,

exhaust gases may collect and enter

the vehicle.

■

Exhaust pipe

The exhaust system needs to be checked

periodically. If there is a hole or crack

caused by corrosion, damage to a joint

or abnormal exhaust noise, be sure to

have the vehicle inspected and repaired

by your Lexus dealer.

1-2. Child safety

LS500_OM_(U)_1809

For safety and security

1-2.Child safety

Points to remember: P.45
Child restraint system: P.46
When using a child restraint system:
P.47
Child restraint system installation
method
• Fixed with a seat belt: P.49
• Fixed with a child restraint LATCH

anchor: P.53

• Using an anchor bracket (for top

tether strap): P.55

The laws of all 50 states of the U.S.A.
as well as Canada now require the use
of child restraint systems.
 Prioritize and observe the warn-

ings, as well as the laws and regula-

Riding with children

Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.

 It is recommended that children

sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch etc.

 Use the rear door child-protector

lock or the window lock switch to
avoid children opening the door
while driving or operating the
power window accidentally.
(

P.103, 144)

 Do not let small children operate

equipment which may catch or
pinch body parts, such as the
power window, hood, trunk, seats
etc.

WARNING

■

When children are in the vehicle

Never leave children unattended in the

vehicle, and never allow children to have

or use the key.
Children may be able to start the vehicle

or shift the vehicle into neutral. There is

also a danger that children may injure

themselves by playing with the windows,

the moon roof or panoramic moon roof,

or other features of the vehicle. In addi-

tion, heat build-up or extremely cold

temperatures inside the vehicle can be

fatal to children.

Child restraint systems

Before installing a child restraint
system in the vehicle, there are pre-
cautions that need to be observed,
different types of child restraint sys-
tems, as well as installation meth-
ods, etc., written in this manual.

Use a child restraint system when
riding with a small child that cannot
properly use a seat belt. For the
child’s safety, install the child restraint
system to a rear seat. Be sure to fol-
low the installation method that is in
the operation manual enclosed with
the restraint system.

Table of contents

Points to remember

1-2. Child safety

LS500_OM_(U)_1809

tions for child restraint systems.

 Use a child restraint system until the

child becomes large enough to
properly wear the vehicle’s seat belt.

 Choose a child restraint system that

suits your vehicle and is appropriate
to the age and size of the child.

■

Types of child restraint system installation methods

Confirm with the operation manual enclosed with the child restraint system about
the installation of the child restraint system.

WARNING

■

When a child is riding

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

For effective protection in automobile

accidents and sudden stops, a child

must be properly restrained, using a

seat belt or child restraint system

which is correctly installed. For installa-

tion details, refer to the operation man-

ual enclosed with the child restraint

system. General installation instruction

is provided in this manual.

●

Lexus strongly urges the use of a

proper child restraint system that con-

forms to the weight and size of the

child, installed on the rear seat.

According to accident statistics, the

child is safer when properly restrained

in the rear seat than in the front seat.

●

Holding a child in your or someone

else’s arms is not a substitute for a child

restraint system. In an accident, the

child can be crushed against the wind-

shield or between the holder and the

interior of the vehicle.

■

Handling the child restraint system

If the child restraint system is not prop-

erly fixed in place, the child or other pas-

sengers may be seriously injured or even

killed in the event of sudden braking, sud-

den swerving, or an accident.

●

If the vehicle were to receive a strong

impact from an accident, etc., it is pos-

sible that the child restraint system has

damage that is not readily visible. In

such cases, do not reuse the restraint

system.

●

Make sure you have complied with all

installation instructions provided with

the child restraint system manufac-

turer and that the system is properly

secured.

●

Keep the child restraint system prop-

erly secured on the seat even if it is not

in use. Do not store the child restraint

system unsecured in the passenger

compartment.

●

If it is necessary to detach the child

restraint system, remove it from the

vehicle or store it securely in the trunk.

Child restraint system

1-2. Child safety

LS500_OM_(U)_1809

For safety and security

■

When installing a child restraint
system to a front passenger seat

For the safety of a child, install child
restraint systems to a rear seats. When
installing child restraint system to a
front passenger seat is unavoidable,
adjust the seat as follows and install the
child restraint system.

 Move the front seat fully rearward.
 Adjust the seatback angle to the

most upright position.

 Adjust the front of the seat cushion

to the lowest position.

 Adjust the seat height to the upper-

most position.

 Adjust the lumbar support to the

lowest position.

 Adjust the shoulder bolster to the

Installation method

Page

Seat belt attachment

P.49

Child restraint LATCH

anchors attachment

P.53

Anchor brackets (for top

tether strap) attachment

P.55

When using a child restraint sys-
tem

1-2. Child safety

LS500_OM_(U)_1809

lowest position (if equipped).

 Adjust the pelvic support to the low-

est position.

 Adjust the seatback side bolster to

the widest position (if equipped).

 Adjust the seat cushion side bolster

to the lowest position (if equipped).

 Adjust the hip support to the lowest

position (if equipped).

 If the head restraint interferes with

the child restraint system installa-
tion and the head restraint can be
removed, remove the head restraint.
Otherwise, put the head restraint in
the upper most position.

■

When installing a child restraint
system to a power rear seat (if
equipped)

When using a child restraint system in
an outer rear seat, adjust the seat as
follows and install the child restraint
system.
 Adjust the seat cushion to the fully

rearward position.

 Adjust the upper seatback to the

rearmost position.

 Adjust the front of the seat cushion

to the lowest position.

 Adjust the head restraint to the low-

est and rearmost position.

 Adjust the shoulder bolster to the

lowest position.

 Adjust the lumbar support to the

lowest position.

 Adjust the pelvic support to the low-

est position.

 Disable the automatic rear seat

operation. (

P.308)

 For the rear seat with an ottoman (if

equipped): Adjust the seatback to
the most upright position and otto-
man (footrest) to the stowed posi-
tion.

WARNING

■

When using a child restraint system

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Never install a rear-facing child

restraint system on the front passenger

seat even if the “AIR BAG OFF” indi-

cator light is illuminated. In the event of

an accident, the force of the rapid infla-

tion of the front passenger airbag can

cause death or serious injury to the

child if the rear-facing child restraint

system is installed on the front passen-

ger seat.

1-2. Child safety

LS500_OM_(U)_1809

For safety and security

A child restraint system for a small
child or baby must itself be properly
restrained on the seat with the lap por-
tion of the lap/shoulder belt.

■

Installing child restraint system
using a seat belt (child restraint
lock function belt)

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.

WARNING

●

A forward-facing child restraint system

may be installed on the front passen-

ger seat only when it is unavoidable. A

child restraint system that requires a

top tether strap should not be used in

the front passenger seat since there is

no top tether strap anchor for the front

passenger seat.

●

A forward-facing child restraint system

may be installed on the front passen-

ger seat only when it is unavoidable.

When installing a forward-facing child

restraint system on the front passenger

seat, adjust the seatback angle to the

most upright position, move the seat to

the rearmost position, and raise the

seat to the upper most position, even if

the “AIR BAG OFF” indicator light is

illuminated.

●

Do not allow the child to lean his/her

head or any part of his/her body

against the door or the area of the seat,

front or rear pillars, or roof side rails

from which the SRS side airbags or

SRS curtain shield airbags deploy even

if the child is seated in the child

restraint system. It is dangerous if the

SRS side and curtain shield airbags

inflate, and the impact could cause

death or serious injury to the child.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

●

Use child restraint system suitable to

the age and size of the child and install

it to the rear seat.

●

If the driver’s seat interferes with the

child restraint system and prevents it

from being attached correctly, attach

the child restraint system to the

right-hand rear seat.

●

Adjust the front passenger seat so that

it does not interfere with the child

restraint system.

Child restraint system fixed with
a seat belt

1-2. Child safety

LS500_OM_(U)_1809

■

Rear-facing

 Infant seat/con-

vertible seat

Adjust the rear seat

Vehicles with power rear seat: If there is a

gap between the child seat and the seat-

back, adjust the seatback angle until good

contact is achieved.

Place the child restraint system on
the rear seat facing the rear of the
vehicle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock

mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system down into the rear seat,
allow the shoulder belt to retract
until the child restraint system is
securely in place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(

P.53)

■

Forward-facing

 Convertible

seat

Adjust the seat



When using the front passenger
seat

If installing the child restraint system to
the front passenger seat is unavoid-

1-2. Child safety

LS500_OM_(U)_1809

For safety and security

able, refer to P.47 for front passenger
seat adjustment.



When using the rear seat

If there is a gap between the child seat
and the seatback, adjust the seatback
angle until good contact is achieved.

Place the child restraint system on
the seat facing the front of the vehi-
cle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock

mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system into the rear seat, allow the
shoulder belt to retract until the
child restraint system is securely in
place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

If the child restraint has a top tether
strap, follow the child restraint man-
ufacturer’s operation manual
regarding the installation, using the
top tether strap to latch onto the
top tether strap anchor. (

P.55)

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(

P.53)

1-2. Child safety

LS500_OM_(U)_1809

■

Booster seat

If installing the child restraint sys-
tem to the front passenger seat is
unavoidable, refer to P.47 for front
passenger seat adjustment.

Place the child restraint system on
the seat facing the front of the vehi-
cle.



Booster type



High back type

Sit the child in the child restraint
system. Fit the seat belt to the child
restraint system according to the
manufacturer’s instructions and
insert the plate into the buckle.
Make sure that the belt is not
twisted.

Check that the shoulder belt is correctly

positioned over the child’s shoulder and

that the lap belt is as low as possible.

(

P.24)

■

Removing a child restraint system
installed with a seat belt

Press the buckle release button and
fully retract the seat belt.

When releasing the buckle, the child
restraint system may spring up due to the
rebound of the seat cushion. Release the
buckle while holding down the child
restraint system.
Since the seat belt automatically reels itself,
slowly return it to the stowing position.

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

1-2. Child safety

LS500_OM_(U)_1809

For safety and security

■

Child restraint LATCH anchors

LATCH anchors are provided for the
outboard rear seat. (Buttons displaying
the location of the anchors are
attached to the seats.)

■

Installation with LATCH system

Install the child restraint system in

WARNING

●

Do not allow children to play with the

seat belt. If the seat belt becomes

twisted around a child’s neck, it may

lead to choking or other serious inju-

ries that could result in death.

If this occurs and the buckle cannot be

unfastened, scissors should be used to

cut the belt.

●

Ensure that the belt and plate are

securely locked and the seat belt is not

twisted.

●

Shake the child restraint system left

and right, and forward and backward

to ensure that it has been securely

installed.

●

After securing a child restraint system,

never adjust the seat.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

●

When securing some types of child

restraint systems in rear seats, it may

not be possible to properly use the

seat belts in positions next to the child

restraint without interfering with it or

affecting seat belt effectiveness. Be

sure your seat belt fits snugly across

your shoulder and low on your hips. If it

does not, or if it interferes with the

child restraint, move to a different posi-

tion. Failure to do so may result in

death or serious injury.

●

When installing a child restraint system

in the rear center seat, adjust both seat

cushions to the same position and

align both seatbacks at the same

angle. Otherwise, the child restraint

system cannot be securely restrained

and this may cause death or serious

injuries in the event of sudden braking,

sudden swerving or an accident.

■

When installing a booster seat

To prevent the belt from going into ALR

lock mode, do not fully extend the shoul-

der belt. ALR mode causes the belt to

tighten only. This could cause injury or

discomfort to the child. (

P.26)

■

Do not use a seat belt extender

If a seat belt extender is used when

installing a child restraint system, the seat

belt will not securely hold the child

restraint system, which could cause

death or serious injury to the child or

other passengers in the event of sudden

braking, sudden swerving or an accident.

Child restraint system fixed with
a child restraint LATCH anchor

1-2. Child safety

LS500_OM_(U)_1809

accordance to the operation manual
enclosed with the child restraint sys-
tem.

Vehicles with power rear seat:
Adjust the seat

If there is a gap between the child seat and

the seatback, adjust the seatback angle

until good contact is achieved. (

P.48)

Open the cover.

Insert the tab into the slit of
the cover.

The cover will be held open.



Type A

Latch the hooks of the lower straps
onto the LATCH anchors.
For owners in Canada:
The symbol on a child restraint sys-
tem indicates the presence of a
lower connector system.

Canada only



Type B

Latch the buckles onto the LATCH
anchors.
For owners in Canada:
The symbol on a child restraint sys-

1-2. Child safety

LS500_OM_(U)_1809

For safety and security

tem indicates the presence of a
lower connector system.

Canada only

P.55)

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(

P.53)

■

Laws and regulations pertaining to

anchors

The LATCH system conforms to

FMVSS225 or CMVSS210.2.

Child restraint systems conforming to

FMVSS213 or CMVSS213 specifications

can be used.

This vehicle is designed to conform to SAE

J1819.

■

Anchor brackets (for top tether
strap)

Anchor brackets are provided for each
rear seat.
Use anchor brackets when fixing the
top tether strap.

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

After securing a child restraint system,

never adjust the seat.

●

When using the LATCH anchors, be

sure that there are no foreign objects

around the anchors and that the seat

belt is not caught behind the child

restraint system.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

●

When securing some types of child

restraint systems in rear seats, it may

not be possible to properly use the

seat belts in positions next to the child

restraint without interfering with it or

affecting seat belt effectiveness. Be

sure your seat belt fits snugly across

your shoulder and low on your hips. If it

does not, or if it interferes with the

child restraint, move to a different posi-

tion. Failure to do so may result in

death or serious injury.

Using an anchor bracket (for top
tether strap)

1-2. Child safety

LS500_OM_(U)_1809



Outboard rear seats

Anchor brackets
Top tether strap



Rear center seat

Anchor bracket
Top tether strap

■

Fixing the top tether strap to the
anchor bracket

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.
Open the anchor bracket cover, latch
the hook onto the anchor bracket and
tighten the top tether strap.

Make sure the top tether strap is securely
latched. (

P.53)



Outboard rear seats

Hook
Top tether strap



Rear center seat

Hook
Top tether strap

■

Laws and regulations pertaining to

anchors

The LATCH system conforms to

FMVSS225 or CMVSS210.2.

Child restraint systems conforming to

FMVSS213 or CMVSS213 specifications

can be used.

This vehicle is designed to conform to SAE

J1819.

A
B

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

A
B

1-2. Child safety

LS500_OM_(U)_1809

For safety and security

WARNING

●

Firmly attach the top tether strap and

make sure that the belt is not twisted.

●

Do not attach the top tether strap to

anything other than the anchor

bracket.

●

After securing a child restraint system,

never adjust the seat.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

●

Be sure to have the top tether strap

pass over the top of the head restraint.

If the belt passes below the head

restraint, it is possible that the child

restraint system may not be securely

fixed.

NOTICE

■

Anchor brackets (for top tether

strap)

When not in use, make certain to close

the lid. If it remains open, the lid may be

damaged.

1-3. Lexus Enform

LS500_OM_(U)_1809

1-3.Lexus Enform

: If equipped

“SOS” button
LED light indicators
Microphone

Lexus Enform Safety Con-
nect

Safety Connect is a subscrip-
tion-based telematics service that
uses Global Positioning System
(GPS) data and embedded cellular
technology to provide safety and
security features to subscribers.
Safety Connect is supported by
Lexus’ designated response center,
which operates 24 hours per day, 7
days per week.

Safety Connect service is available
by subscription on select, telemat-
ics hardware-equipped vehicles.

By using the Safety Connect ser-
vice, you are agreeing to be bound
by the Telematics Subscription Ser-
vice Agreement and its Terms and
Conditions, as in effect and
amended from time to time, a cur-
rent copy of which is available at
Lexus.com. All use of the Safety
Connect service is subject to such
then-applicable Terms and Condi-
tions.

System components

A
B
C

1-3. Lexus Enform

LS500_OM_(U)_1809

For safety and security

■

Certification for Lexus Enform

Subscribers have the following Safety
Connect services available:

 Automatic Collision Notification

Helps drivers receive necessary response
from emergency service providers.
(



P.61

)

Services

Content .. 1 2 3 4 ..
