LEXUS GX 460 (2019 year). Instruction - part 31

Slide and pull out the filter. Replace
the filter with a new one.

The “

UP” marks shown on the filter

should be pointing up.

■

Changing interval
Inspect and replace the air conditioning filter according to the maintenance schedule. In

dusty areas or areas with heavy traffic flow, early replacement may be required.

(For scheduled maintenance information, please refer to the “Owner’s Manual

Supplement” or “Scheduled Maintenance”.)

■

If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.

NOTICE

■

When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the system.

489

Main

Electronic key battery

●

Flathead screwdriver

●

Small Phillips-head screwdriver

●

Lithium battery (CR1632)

Take out the mechanical key.

Remove the cover.

To prevent damage to the key, cover the

tip of the screwdriver with a rag.

Remove the depleted battery.

Insert a new battery with the “+” termi-

nal facing up.

Replace the battery with a new one if it is depleted.

You will need the following items:

Replacing the battery

490

■

Use a CR1632 lithium battery

●

Batteries can be purchased at your Lexus dealer, local electrical appliance shops or

camera stores.

●

Replace only with the same or equivalent type recommended by the manufacturer.

●

Dispose of used batteries according to the local laws.

■

If the electronic key battery is depleted
The following symptoms may occur:

●

The smart access system with push-button start and wireless remote control will not

function properly.

●

The operational range will be reduced.

CAUTION

■

Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking. Keep away

from children. Failure to do so could result in death or serious injury.

NOTICE

■

For normal operation after replacing the battery
Observe the following precautions to prevent accidents:

●

Always work with dry hands.

Moisture may cause the battery to rust.

●

Do not touch or move any other component inside the remote control.

●

Do not bend either of the battery terminals.

491

Main

Checking and replacing fuses

Turn the engine switch off.
Open the fuse box cover.

Remove the fuse with the pull-out tool.

Only type A fuse can be removed using
the pull-out tool.

If any of the electrical components do not operate, a fuse may have blown. If
this happens, check and replace the fuses as necessary.



Engine compartment



Driver’s side instrument panel

Push the tab in and lift the lid off.

Remove the lid.

492

Check if the fuse is blown.

Normal fuse
Blown fuse

Type A:

Replace the blown fuse with a new fuse of an appropriate amperage rating. The

amperage rating can be found on the fuse box lid.
Type B, C and D:

Contact your Lexus dealer.



Type A



Type B



Type C



Type D

493

Main

■

After a fuse is replaced

●

If the lights do not turn on even after the fuse has been replaced, a bulb may need

replacement. (

P. 496)

●

If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer.

■

If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.

CAUTION

■

To prevent system breakdowns and vehicle fire
Observe the following precautions.

Failure to do so may cause damage to the vehicle, and possibly a fire or injury.

●

Never use a fuse of a higher amperage rating than indicated, or use any other object

in place of a fuse.

●

Always use a genuine Lexus fuse or equivalent.

Never replace a fuse with a wire, even as a temporary fix.

●

Do not modify the fuses or the fuse boxes.

NOTICE

■

Before replacing fuses
Have the cause of electrical overload determined and repaired by your Lexus dealer,

as soon as possible.

494

Headlight aim

Adjustment bolt A
Adjustment bolt B

Make sure the vehicle has a full tank of gasoline and the area around the
headlight is not deformed.
Park the vehicle on level ground.
Sit in the driver’s seat.
Bounce the vehicle several times.

Vertical movement adjusting bolts

Before checking the headlight aim

2
3
4

495

Main

Using a Phillips-head screwdriver, turn bolt A in either direction.

Remember the turning direction and the number of turns.

Turn bolt B the same number of turns
and in the same direction as step .

If the headlight cannot be adjusted using

this procedure, take the vehicle to your

Lexus dealer to adjust the headlight aim.

Adjusting the headlight aim



Left-hand side



Right-hand side

496
