LEXUS GX 460 (2019 year). Instruction - part 26

408

5-2. Using the interior lights

■

Illuminated entry system
The lights automatically turn on/off according to engine switch mode, the presence of the

electronic key, whether the doors are locked/unlocked, and whether the doors are

open/closed.

■

To prevent battery discharge
If the following lights remain on when the engine switch is turned off the lights will go off

automatically after 20 minutes:

●

Personal/interior light

●

Inside door handle lights

●

Footwell lights

●

Running board lights

■

Customization
Settings (e.g. adjust the time elapsed before the interior lights automatically turn off) can

be changed. (Customizable features:

P. 592)

Personal/interior lights



Front



Rear

Turns the lights on/off

Turns the lights on/off

NOTICE

To prevent battery discharge, do not leave the lights on longer than necessary when the

engine is not running.

409

5-3. Using the storage features

5

Inte
rior fe

ature

s

List of storage features

Cup holders

(

P. 412)

Auxiliary boxes

(

P. 414)

Bottle holders/door pockets

(

P. 413)

Glove box

(

P. 410)

Console box (if equipped)

(

P. 410)

Cool box (if equipped)

(

P. 423)

Coin holder (if equipped)

(

P. 412)

CAUTION

●

Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause

the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact with other

stored items.

• Lighters or spray cans may explode. If they come into contact with other stored

items, the lighter may catch fire or the spray can may release gas, causing a fire

hazard.

●

When driving or when the storage compartments are not in use, keep the lids closed.

In the event of sudden braking or sudden swerving, an accident may occur due to an

occupant being struck by an open lid or the items stored inside.

1

2
3

4

5

6

410

5-3. Using the storage features

Unlock with the mechanical key
Lock with the mechanical key
Open (push the button)

The glove box light turns on when the tail lights are on.

Your vehicle is equipped with either a console box or cool box.
For vehicles with the cool box, refer to P. 423.
Lift the lid while pulling up the lower
lever to release the lock.

Glove box

1

2
3

Console box (if equipped)

411

5-3. Using the storage features

5

Inte
rior fe

ature

s

●

The console box light turns on when the tail lights are on.

●

When using the console box lid as an armrest,

slide the console box lid forward or backward

as needed. Slide the lid while pulling up the

upper lever to release the lock.

●

The tray in the console box slides forward/

backward.

●

To remove the tray, lift up.

NOTICE

Do not insert items exceeding the height of the tray. Doing so may prevent opening and

closing of the lid.

412

5-3. Using the storage features

The coin holder is located in the console box.

■

Cup holders

Coin holder (if equipped)

Cup holders/bottle holders/door pockets



Front seats



Second seats (7-passenger mod-
els)

Press down and release the cup
holder lid.

Pull the armrest down, and then press
in and release the button.



Second seats (6-passenger mod-
els)



Third seats (if equipped)

Pull the cup holder up.

413

5-3. Using the storage features

5

Inte
rior fe

ature

s

■

Bottle holders/door pockets

■

Cup holder lights (front seats)

●

The cup holder lights turn on when the tail lights are on.

●

The brightness of the cup holder lights change in conjunction with the instrument clus-

ter light. (

P. 88)

■

When using the holder as a bottle holder

●

Close the cap.

●

The bottle may not be stored depending on its size or shape.

■

Removing the cup holders (second seats for 6-passenger models)



Front



Rear

The cup holders can be removed.

CAUTION

■

Items unsuitable for the cup holders/bottle holders

●

Do not place anything other than cups or beverage cans in the cup holders. Even

when the lid is closed, items must not be stored in the cup holders.

Other items may be thrown out of the holders in the event of sudden braking, sudden

swerving or an accident, cause injury. If possible, cover hot drinks to prevent burns.

●

Do not place anything other than bottles in the bottle holders.

In the event of an accident or sudden braking, other items may be thrown out of the

holders and cause injury.

■

When not in use
Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an accident.

414

5-3. Using the storage features

NOTICE

●

To prevent damage, stow the rear cup holders before stowing the armrest. (second

seats for 7-passenger models)

●

To prevent damage, do not fold down the second seatbacks when using a cup holder

on the second seats. (6-passenger models)

●

To prevent damage, do not rest your hands on the cup holders or kick them.

●

Do not place open bottles or glass and paper cups containing liquid in the bottle hold-

ers. The contents may spill and glasses may break.

Auxiliary boxes



Type A



Type B

Press in the button and then pull down
the lid.

The overhead console is useful for tem-

porarily storing sunglasses and similar

small items.

Push the lid.



Type C (if equipped)

415

5-3. Using the storage features

5

Inte
rior fe

ature

s

■

Auxiliary box light (type B)

●

The auxiliary box light turns on when the tail lights are on.

●

The brightness of the auxiliary box light changes in conjunction with the instrument

cluster light. (

P. 88)

■

Closing the auxiliary box lid
Slide the auxiliary box lid forward.

CAUTION

■

Caution while driving
Do not place cups, beverage cans or bottles in the box. They may be thrown out of the

box in the event of sudden braking, sudden swerving or an accident, resulting in injury.

(type B and C)

■

Items unsuitable for storing (type A)

●

Do not store items heavier than 0.4 lb. (0.2 kg).

Doing so may cause the auxiliary box to open and the items inside may fall out, result-

ing in an accident.

●

Do not put large items in the overhead console.

The overhead console may not be able to be shut from the conversation mirror state.

416

5-3. Using the storage features

Luggage compartment features

Raise the hook to use.

The cargo hooks are provided for

securing loose items.
When using the deck hooks, the third

seat must be fold down. (

P. 134)

Open the cover.

Turn the knob clockwise.
Open the cover.

Secure the warning reflector.

The warning reflector itself is not

included as an original equipment.

Cargo hooks

Warning reflector holder

1

1

2

2

417

5-3. Using the storage features

5

Inte
rior fe

ature

s

To hang the cargo net, use the cargo net hooks.

The cargo net itself is not included as an original equipment.

Remove the cover.

Cargo net hooks

Auxiliary box (if equipped)

418

5-3. Using the storage features

■

Installing the luggage cover

Attach the hooks to the head
restraints.

When using the luggage cover, the

third seats must be folded down.

(

P. 134)

6-passenger models only: Secure
the middle part of the luggage
cover as shown.

Pull out the luggage cover and
hook it on the anchors.

■

Removing the luggage cover
Retract the cover and release both
ends, then lift it out.

Luggage cover (if equipped)

1

2

419

5-3. Using the storage features

5

Inte
rior fe

ature

s

■

Stowing the luggage cover

Push the case while pressing the
lock release button.

Vehicles without a rear automatic air

conditioning system: Shorten one

side only.
Vehicles with a rear automatic air

conditioning system: Shorten both

sides.

Push the case until it locks.

Check that the lock release button

can be seen.
Vehicles without a rear automatic air

conditioning system: Shorten one

side only.
Vehicles with a rear automatic air

conditioning system: Shorten both

sides.

Secure the luggage cover with
luggage cover restraining bands.

Check that luggage cover and lug-

gage cover restraining bands are

secured.

Fold over the cover and the sub
cover.

Lock release button

1

Lock release

button

2

3

4

420

5-3. Using the storage features

Stow the hooks.

Fold over the sub cover.

■

Extending the case

Push the lock release button.

Pull the case until it locks.

Check that the lock release button

can be seen.

5

6

Lock release

button

1

Lock release button

2

421

5-3. Using the storage features

5

Inte
rior fe

ature

s

■

Adjusting the sub cover

Fasten the button when the second seats are in the rear-most position.
Unfasten the buttons before sliding the second seats forward.

CAUTION

●

To avoid injury, always return the cargo hooks to their stowed positions when not in

use.

●

Keep the auxiliary box closed. In the event of sudden braking or sudden swerving, an

accident may occur due to an occupant being struck by an open auxiliary box or the

items stored inside.

●

Keep the both sides of the luggage cover case locked. Otherwise, the luggage cover

may fly out in case of the sudden braking, sudden swerving or an accident, resulting in

death or serious injury.

●

When stowing the luggage cover in the luggage compartment, use the luggage

cover restraining bands to secure the left and right sides of the luggage cover. Other-

wise, the luggage cover may fly out in case of the sudden braking, sudden swerving or

an accident, resulting in death or serious injury.

●

Do not allow children to climb on the luggage cover. Climbing on the luggage cover

could result in damage to the luggage cover, possibly causing death or serious injury

to the child.

422

5-3. Using the storage features

NOTICE

■

To prevent damage to the luggage cover
When stowing the luggage cover, do not put luggage on the luggage cover.

●

Do not use the luggage cover restraining bands for anything other than securing the

luggage cover.

●

Do not insert coins etc. into the area shown in

the illustration.

423

5-4. Using the other interior features

5

Inte
rior fe

ature

s

Other interior features

Lift the lid while pulling up the lower
lever to release the lock.

Turns the cool box on/off

When on, the indicator light comes on.

■

The cool box can be operated when
The engine switch is in IGNITION ON mode.

■

If the front air conditioning system is not in use when the cool box is turned on
The front air conditioning system is automatically turned on.

Cool box (if equipped)

1

2
