LEXUS GX 460 (2019 year). Instruction - part 25

392

5-1. Using the air conditioning system and defogger

Press

to operate the speech

command system. (Refer to the
“NAVIGATION SYSTEM OWNER’S
MANUAL”.)

■

Using the automatic mode

Press the “AUTO” button.

Press

to switch to automatic air intake mode. (if equipped)

The air conditioning system automatically switches between outside air and recir-

culated air modes.

Adjust the temperature setting.
To stop the operation, press the “OFF” button.

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated is maintained.

■

Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)/driver, passenger and rear seats separately (“3-ZONE”
mode)
To turn on the “DUAL”/“3-ZONE” mode, perform any of the following proce-
dures:

●

Press the “DUAL”/“3-ZONE” button.

●

Select “DUAL”/“3-ZONE” on the option control screen.

●

Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL”/“3-ZONE” mode is on.
While in “DUAL” mode, the temperature of the rear air outlets is set at the
passenger’s side temperature setting.

Using the speech command system

Air conditioning controls

3
4

393

5-1. Using the air conditioning system and defogger

Inte
rior fe

ature

Touch

to display the rear air conditioning control screen.

■

Control screen

Adjust the fan speed setting
Adjust the rear seats temperature setting
Display the rear seats temperature setting
Turn the fan off
Select to set automatic mode

■

Using the automatic mode

Touch “REAR AUTO”.
Touch

to increase the temperature and

to decrease the tem-

perature.
To stop the operation, touch “REAR OFF”.

■

If the system is operated manually in automatic mode
If the fan speed setting is operated, the automatic mode indicator goes off.
However, automatic mode for functions other than that operated are main-
tained.

Changing the rear seat settings (vehicles with rear air conditioning sys-
tem)



Without a navigation system



With a navigation system

2
3
4
5

394

5-1. Using the air conditioning system and defogger

■

Switching between outside air and recirculated air modes



Vehicles without rear air conditioning system

Press .

The mode switches between

(recirculated air mode) and

(outside

air mode) modes each time the button is pressed.



Vehicles with rear air conditioning system

Press .

The mode switches among

(recirculated air mode), automatic and

(outside air mode) modes each time the button is pressed.

When the system is switched to automatic mode, the air conditioning system oper-

ates automatically.

■

Defogging the windshield
Defoggers are used to defog the windshield and front side windows.

Press .

Set the outside/recirculated air mode button to outside air mode if the recirculated

air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-

ture up.
To return to the previous mode,

press again when the windshield is

defogged.

Other functions

395

5-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove raindrops, dew
and frost from the outside rear view mirrors.

Press .

The defoggers will automatically turn off after a period of time.

■

Micro dust and pollen filter mode
Pollen is removed from the air and the air flows to the upper part of the body.

Touch

on the option control screen.

When the micro dust and pollen filter mode is on,

is displayed on the air

conditioning control screen.
In order to prevent the windshield from fogging up when the outside air is cold, the

dehumidification function may operate.
The pollens are filtered out even if the micro dust and pollen filter mode is turned

off.

■

Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield and
wiper blades.
Touch

on the option control screen.

When the windshield wiper de-icer is on,

is displayed on the air condition-

ing control screen.
The windshield wiper de-icer will automatically turn off after a period of time.

396

5-1. Using the air conditioning system and defogger

■

Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.

: Some models

■

Adjusting the air flow direction and opening/closing the air outlets

Air outlets



Front outlets



Rear outlets (vehicles without
rear air conditioning system)

Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.

397

5-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Registering air conditioning settings to electronic keys

●

Unlocking the vehicle using an electronic key and turning the engine switch to

IGNITION ON mode will recall that key’s registered air conditioning settings.

●

When the engine switch is turned off, the current air conditioning settings will automat-

ically be registered to the electronic key that was used to unlock the vehicle.

The system may not operate correctly if more than one electronic key is in the vicinity or

if the smart access system with push-button start is used to unlock a passenger door.
Settings for the electronic key and the corresponding door can be changed.

Contact your Lexus dealer.

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and the ambi-

ent conditions.

Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately

after the “AUTO” button is pressed.

■

When the outside temperature exceeds 75

F (24C) and the air conditioning system

is on

●

In order to reduce the air conditioning power consumption, the air conditioning system

may switch to recirculated air mode automatically.

This may also reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the engine switch is turned to

IGNITION ON mode.

●

It is possible to switch to outside air mode at any time by pressing

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high. Touching “A/C”

on will dehumidify the air from the outlets and defog the windshield effectively.

●

If you turn “A/C” off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads such as tunnels or in heavy traffic, set the outside/recircu-

lated air mode button to the recirculated air mode. This is effective in preventing out-

side air from entering the vehicle interior. During cooling operation, setting the

recirculated air mode will also cool the vehicle interior effectively.

●

Outside/recirculated air mode may automatically switch depending on the tempera-

ture setting or the inside temperature.

398

5-1. Using the air conditioning system and defogger

■

Automatic mode for air intake control (vehicles with rear air conditioning system)
In automatic mode, the system detects exhaust gas and other pollutants and automati-

cally switches between outside air and recirculated air modes.
When the dehumidification function is off, and the fan is operating, turning automatic

mode on will activate the dehumidification function.

■

When the outside temperature is low
The dehumidification function may not operate even when “A/C” is touched.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into and accu-

mulate in the air conditioning system. This may then cause odor to be emitted from the

vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior

to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time immediately

after the air conditioning system is started in automatic mode.

■

Air conditioning filter
P. 487

■

Customization
Settings (e.g. A/C automatic mode switch operation) can be changed.

(Customizable features:

P. 592)

399

5-1. Using the air conditioning system and defogger

Inte
rior fe

ature

CAUTION

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather. The differ-

ence between the temperature of the outside air and that of the windshield can cause

the outer surface of the windshield to fog up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mirror defog-

gers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the front pillars

when the windshield wiper de-icer is on. (vehicles with windshield wiper de-icer)

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine is

off.

●

Do not place anything on the instrument

panel which may cover the air outlets. Other-

wise, air flow may be obstructed, preventing

the windshield defoggers from defogging.

400

5-1. Using the air conditioning system and defogger

Rear air conditioning system



■

Adjusting the temperature setting
Press “

” on the “TEMP” button to increase the temperature and “” to

decrease the temperature.

Touch

on the climate screen to display the option control screen. (

P. 391)

If the “A/C” indicator is turned off, the system will blow ambient temperature air or

heated air.

■

Adjusting the fan speed setting
Press “

” on

to increase the fan speed and “

” to decrease the fan

speed.
Press the “OFF” button to turn the fan off.

■

Changing the air flow mode
Press .
The air flow mode switch each time the button is pressed.



: If equipped

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.

401

5-1. Using the air conditioning system and defogger

Inte
rior fe

ature

■

Using the automatic mode

Press the “AUTO” button.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.

■

If the system is operated manually in automatic mode
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated are maintained.

■

Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.

■

Adjusting the air flow direction and opening/closing the air outlets

Direct air flow to the left or right,
up or down.
Turn the knob fully to the back of
the vehicle to close the vent.

Air conditioning controls

Air outlets

2
3

402

5-1. Using the air conditioning system and defogger

■

Registering air conditioning settings to electronic keys

●

Unlocking the vehicle using an electronic key and turning the engine switch to

IGNITION ON mode will recall that key’s registered air conditioning settings.

●

When the engine switch is turned off, the current air conditioning settings will automat-

ically be registered to the electronic key that was used to unlock the vehicle.

The system may not operate correctly if more than one electronic key is in the vicinity or

if the smart access system with push-button start is used to unlock a passenger door.
Settings for the electronic key and the corresponding door can be changed.

Contact your Lexus dealer.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the engine is

off.

403

5-1. Using the air conditioning system and defogger

Inte
rior fe

ature

Heated steering wheel



/seat heaters



/seat

ventilators



Turns the heated steering wheel on/off

The indicator light comes on when the

heated steering wheel is operating.



: If equipped

Heated steering wheel and seat heaters heat the side grips of the steering
wheel and seats. Seat ventilators maintain good airflow by blowing air from
the seats.

CAUTION

●

Care should be taken to prevent injury if anyone in the following categories comes in

contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged

• Persons with sensitive skin

• Persons who are fatigued

• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold

remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do not stick

sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is off.

Heated steering wheel (if equipped)

404

5-1. Using the air conditioning system and defogger

●

The heated steering wheel can be used when the engine switch is in IGNITION ON

mode.

●

The heated steering wheel will automatically turn off after about 30 minutes.

●

If the indicator light flashes, press the switch to turn the heated steering wheel off and

then press the switch again. If the indicator light still flashes, a malfunction may be

occurring. Turn the heated steering wheel off and have the vehicle inspected by your

Lexus dealer.

■

Front seat
Turns the seat heater on

The indicator light comes on.

The higher the number of dots, the

warmer the seat becomes.

■

Rear seat

For left second seat
For right second seat
High heating temperature
Low heating temperature

To turn on the seat heater, press “HI”

or “LO”.

The indicator light on “HI” or “LO”

switch indicates that the seat heater

is on.

Off

To turn off, press “OFF”.

The seat heaters can be used when the engine switch is in IGNITION ON mode.

Seat heaters (if equipped)

2
3
4

405

5-1. Using the air conditioning system and defogger

Inte
rior fe

ature

Heats the seat

The indicator light comes on.

The higher the number of dots, the

warmer the airflow becomes.

Blows air from the seat

The indicator light comes on.

The higher the number of dots, the

stronger the airflow becomes.

The seat heaters and ventilators can be used when the engine switch is in IGNITION

ON mode.

Seat heaters and ventilators (if equipped)

406

5-2. Using the interior lights

Interior lights list

Personal/interior lights (

P. 408)

Inside door handle lights
Shift lever light
Engine switch light

Scuff lights
Footwell lights
Door courtesy lights
Running board lights

2
3
4

5
6
7
8

407

5-2. Using the interior lights

Inte
rior fe

ature

Off
The personal/Interior lights and interior light can be individually turned on or
off.
Door position
The personal/interior lights come on when a door is opened. They turn off
when the doors are closed.
On
The personal/interior lights cannot be individually turned off.

Personal/interior lights main switch

Content .. 23 24 25 26 ..
