PP3DN–01

PP–32

–

PREPARATION

AUTOMATIC TRANSAXLE

LEXUS RX300   (RM785E)

AUTOMATIC TRANSAXLE

SST (Special Service Tools)

09223–46011

Crankshaft Front Oil Seal

Replacer

09308–00010

Oil Seal Puller

09325–20010

Transmission Oil Plug

09350–32014

TOYOTA Automatic Transmission

Tool Set

(09351–32111)

Side Bearing Race Replacer

(09351–32130)

Handle

(09351–32010)

One–way Clutch Test Tool

(09351–32020)

Stator Stopper

09992–00095

Automatic Transmission Oil

Pressure Gauge Set

(09992–00231)

Adaptor C

(09992–00271)

Gauge Assy

PP1DP–02

–

PREPARATION

AUTOMATIC TRANSAXLE

PP–33

LEXUS RX300   (RM785E)

RECOMMENDED TOOLS

09082–00040

TOYOTA Electrical Tester.

09090–04020

Engine Sling Device

PP1DQ–05

PP–34

–

PREPARATION

AUTOMATIC TRANSAXLE

LEXUS RX300   (RM785E)

EQUIPMENT

Straight edge

Torque converter

Vernier calipers

Torque converter

Dial indicator or dial indicator with magnetic base

Drive plate

Hexagon Wrench (10 mm)

Torque wrench

OBD scan tool

PP1EZ–02

–

PREPARATION

AUTOMATIC TRANSAXLE

PP–35

LEXUS RX300   (RM785E)

LUBRICANT

Item

Capacity

Classification

Automatic transaxle fluid

 Dry fill

 Drain and refill

8.9 liters (9.41 US qts, 7.83 Imp. qts)

3.9 liters (4.1 US qts, 3.4 Imp. qts)

ATF TYPE T–IV or equivalent

Transfer oil

0.9 liters (0.95 US qts, 0.71 Imp. qts)

APL GL–5

SAE 75W – 90
