PP3DO–01

PP–28

–

PREPARATION

CHARGING

LEXUS RX300   (RM785E)

CHARGING

SST (Special Service Tools)

09223–00010

Cover & Seal Replacer

Rotor front bearing

09285–76010

Injection Pump Camshaft Bearing

Cone Replacer

Rotor rear bearing cover

09820–00021

Alternator Rear Bearing Puller

09820–00030

Alternator Rear Bearing Replacer

Rotor rear bearing

09820–63010

Alternator Pulley Set Nut Wrench

Set

09950–40011

Puller B Set

(09951–04020)

Hanger 200

Rectifier end frame

(09952–04010)

Slide Arm

Rectifier end frame

(09953–04020)

Center Bolt 150

Rectifier end frame

(09954–04010)

Arm 25

Rectifier end frame

(09955–04071)

Claw No.7

Rectifier end frame

(09958–04011)

Holder

Rectifier end frame

–

PREPARATION

CHARGING

PP–29

LEXUS RX300   (RM785E)

09950–60010

Replacer Set

(09951–00480)

Replacer 48

Rotor front bearing

PP1DI–01

PP–30

–

PREPARATION

CHARGING

LEXUS RX300   (RM785E)

RECOMMENDED TOOLS

09082–00040

TOYOTA Electrical Tester.

PP1DJ–02

–

PREPARATION

CHARGING

PP–31

LEXUS RX300   (RM785E)

EQUIPMENT

Ammeter(A)

Belt tension gauge

Torque wrench

Vernier calipers

Rotor (Slip ring), Brush
