SERVICE SPECIFICATIONS
AUTOMATIC TRANSMISSION / TRANSAXLE
21
U150E A/T REPAIR MANUAL (RM913U)
U/D planetary gear
Preload (at 60 rpm)
2.140 - 5.40 N
⋅
m (21.8 - 55.1 kgf
⋅
cm, 0.24 - 0.61 in.
⋅
lbf)
Front planetary gear
Turning torque (at 60 rpm)
New Bearing
Used Bearing
0.51 - 1.02 N
⋅
m (5.1 - 10.0 kgf
⋅
cm, 4.4 - 8.7 in.
⋅
lbf)
0.26 - 0.51 N
⋅
m (2.7 - 5.2 kgf
⋅
cm, 2.3 - 4.5 in.
⋅
lbf)
Input shaft
End play
0.262 - 1.249 mm (0.0103 - 0.0492 in.)
Transaxle rear cover
Bearing press fit depth
20.55 - 21.25 mm (0.8091 - 0.8366 in.)
Transmission valve body
Valve body installation bolt length
A
B
C
25 mm (0.984 in.)
57 mm (2.244 in.)
41 mm (1.614 in.)
Accumulator
Spring
Free length/Outer diameter
Color
B
3
Inner
Outer
62.00 (2.4409) / 15.50 (0.610)
74.23 (2.9224) / 16.50 (0.649)
Purple
Purple
C
2
60.96 (2.3999) / 14.10 (0.555)
Yellow
C
3
72.20 (2.8425) / 19.0 (0.748)
Colorless
Front differential
Backlash
0.05 - 0.20 mm (0.0020 - 0.0079 in.)
Thrust washer thickness
Mark
-
-
-
1.625 mm (0.0640 in.)
1.725 mm (0.0679 in.)
1.825 mm (0.0719 in.)
Praload (at 60 rpm)
New bearing
Used bearing
0.20 - 0.69 N
⋅
m (2.0 - 7.0 kgf
⋅
cm, 1.8 - 6.1 in.
⋅
lbf)
0.10 - 0.35 N
⋅
m (1.0 - 3.6 kgf
⋅
cm, 0.9 - 3.1 in.
⋅
lbf)
Flange thickness
Mark
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G
H
2.00 mm (0.0787 in.)
2.05 mm (0.0807 in.)
2.10 mm (0.0827 in.)
2.15 mm (0.0846 in.)
2.20 mm (0.0866 in.)
2.25 mm (0.0886 in.)
2.30 mm (0.0906 in.)
2.35 mm (0.0925 in.)
2.40 mm (0.0945 in.)
2.45 mm (0.0965 in.)
2.50 mm (0.0984 in.)
2.55 mm (0.1004 in.)
2.60 mm (0.1024 in.)
2.65 mm (0.1043 in.)
2.70 mm (0.1063 in.)
2.75 mm (0.1083 in.)
2.80 mm (0.1102 in.)
2.85 mm (0.1122 in.)
