TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

F–18

414

Wire Harness Repair Manual (RM1022E)

Press Sleeve

Color

YELLOW

BLUE

P/N

82999–12030

82999–12020

Color

RED

P/N

82999–12010

F–1

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

Wire Harness Repair Manual (RM1022E)

379

Repair Wire (Waterproof Type)

Type

1.0II

Male

Female

Sleeve : Medium (Blue)

P/N

82998–24060

Type

1.0III

Male

Female

Sleeve : Medium (Blue)

Sleeve : Medium (Blue)

P/N

82998–12710

82998–12720
82998–12730*

Type

1.3

Male

Female

Sleeve : Medium (Blue)

Sleeve : Medium (Blue)

P/N

82998–12630

82998–12650

F

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

F–2

380

Wire Harness Repair Manual (RM1022E)

Repair Wire (Waterproof Type)

Type

1.8

Male

Female

Sleeve : Medium (Blue)

P/N

82998–12620

Type

2.3

Male

Female

Sleeve : Medium (Blue)

Sleeve : Medium (Blue)

P/N

82998–12260
82998–24070*

82998–12270

(160mm)

   82998–12600

(500mm)

82998–24080*

Type

2.3II (6mm Pitch Type)

Male

Female

Sleeve : Medium (Blue) or Large (Yellow)

Sleeve : Medium (Blue) or Large (Yellow)

P/N

82998–12430
82998–12450*

82998–12440

(160mm)

   82998–12590

(500mm)

82998–12460*

F

F–3

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

Wire Harness Repair Manual (RM1022E)

381

Repair Wire (Waterproof Type)

Type

2.3II (5mm Pitch Type)

Male

Female

Sleeve : Medium (Blue) or Large (Yellow)

P/N

82998–12790
82998–12780*

Type

4.8

Male

Female

Sleeve : Large (Yellow)

Sleeve : Large (Yellow)

P/N

82998–12470

82998–12480

Type

6.3

Male

Female

Sleeve : Large (Yellow)

P/N

82998–12540

F
