AUTOMATIC TRANSAXLE
SERVICE SPECIFICATIONS
-
AUTOMATIC TRANSAXLE
SERVICE SPECIFICATIONS
-
AX-17
Accumulator Spring
Spring
Free length mm (in.)
Color
C
0
Inner
Outer
47.5 (1.870)
16.3 (0.642)
White
None
C
1
73.6 (2.898)
None
C
2
51.8 (2.039)
Yellow / Purple
B
0
66.8 (2.630)
Red / Yellow
B
2
Inner
Outer
70.3 (2.767)
88.2 (3.473)
None
None
Differential Assembly
Drive pinion preload (at Starting)
New bearing
1.0 - 1.6 N·m
10 - 16 kgf·cm
8.7 - 13.9 in.·lbf
Reused bearing
0.5 - 0.8 N·m
5 - 8 kgf·cm
4.3 - 6.9 in.·lbf
Total preload (at starting)
New bearing
Drive pinion preload plus 0.3 - 0.4 N·m
2.8 - 4.4 kgf·cm 2.4 - 3.8 in.·lbf
Reused bearing
Drive pinion preload plus 0.1 - 0.2 N·m
1.4 - 2.2 kgf·cm 1.2 - 1.9 in.·lbf
Pinion to side gear backlash
0.05 - 0.20 mm
0.0020 - 0.0079 in.
Side gear thrust washer thickness
1.60 mm
0.0630 in.
1.70 mm
0.0670 in.
1.80 mm
0.0709 in.
Side bearing adjusting shim thickness
Mark
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
G
H
2.00 mm
0.0787 in.
2.05 mm
0.0807 in.
2.10 mm
0.0827 in.
2.15 mm
0.0846 in.
2.20 mm
0.0866 in.
2.25 mm
0.0886 in.
2.30 mm
0.0906 in.
2.35 mm
0.0925 in.
2.40 mm
0.0945 in.
2.45 mm
0.0965 in.
2.50 mm
0.0984 in.
2.55 mm
0.1004 in.
2.60 mm
0.1024 in.
2.65 mm
0.1043 in.
2.70 mm
0.1063 in.
2.75 mm
0.1083 in.
2.80 mm
0.1102 in.
2.85 mm
0.1122 in.
