ZF AUTO
37
REPAIR
6. Disconnect and remove speed sensor from
harness.
Refit
7. Connect speed sensor to harness multiplug.
8. Position harness to valve body.
9. Connect multiplugs to shift control solenoid
valves MV 1 and MV 2 and lock-up solenoid
valve.
10. Connect multiplug to pressure regulator solenoid
valve and secure solenoid valve harness with
clip to valve body.
11. Position and secure harness in clips on valve
body.
12. Fit valve body assembly.
See this section.
ELECTRONIC CONTROL UNIT
Service repair no - 44.15.46
Remove
1. Move left hand front seat fully rearwards. Raise
cushion for access.
2. Disconnect battery negative lead.
3. Remove 3 fixings securing trim to seat base.
Remove trim.
4. Remove 2 screws securing cover to ECU.
Remove cover.
5. Release multiplug from ECU.
