it receives an alarm signal from the CJB or the tilt sensor
the power supply or the LIN bus link to the CJB is disrupted.
The tilt sensor measures the longitudinal and lateral angle of the vehicle over a range of ±16 degrees from the horizontal.
When the active anti-theft system is armed in volumetric mode, the tilt sensor stores the current vehicle angles in its
memory and monitors the tilt sensor readings. If the vehicle angle changes in either direction by more than the alarm
limit, the tilt sensor activates the sounder.
If the alarm system is active and the battery or the battery backed sounder is disconnected, the sounder will operate
without the visual indication of the turn signal indicators flashing.
Global Open/Close
The global open/close feature allows the user to fully raise/lower the windows with a single press of a remote handset
button. The button must be pressed and held for more than 2 seconds. Either or both global open/close functions can be
disabled using a Land Rover approved diagnostic system.
• NOTE: Remote global close is not available in certain markets, North American Specification (NAS) for example.
Single Point Entry
The single point entry feature only unlocks the driver's door and the liftgate, all other doors remain locked. A single press
of the unlock button on the remote handset will unlock only the driver's door and the liftgate, a second press is required to
unlock the remaining doors.
If the vehicle is double locked, the first press of the unlock button on the remote handset unlocks the driver's door and the
liftgate. The remaining doors revert to the single locked state and can therefore be unlocked using the interior door
handles, the remote handset unlock button or the unlock switch on the instrument panel switchpack.
Changing from central locking to single point entry can be carried out by pressing the lock and unlock buttons on the
remote handset simultaneously. The turn signal indicators will flash to confirm that the function change has been
performed.
Drive Away Locking
The drive away door locking feature locks the doors and the liftgate if they are unlocked when the vehicle reaches a certain
speed.
On vehicles with automatic transmission, with all the doors, liftgate and hood closed and the gear selector not in 'P' Park
or 'N' Neutral position, if the CJB detects, via a high speed CAN message from the Anti-lock Brake System (ABS) module,
that the vehicle speed is more than 7 km/h (5 mph), the doors will automatically lock.
On vehicles with manual transmission, with all the doors, liftgate and hood closed, if the CJB detects, via a high speed
CAN message from the ABS module, that the vehicle speed is more than 7 km/h (5 mph), the doors will automatically lock.
Remote Handset Additional Features
The remote handset has convenience buttons in addition to the lock and unlock buttons.
Panic Alarm
The panic alarm feature allows the user to activate the vehicle alarm system using the remote handset. The 'panic button',
identified by a triangle symbol, can be pressed 3 times within 3 seconds or pressed and held for more than 3 seconds to
activate the panic alarm.
Global Open/Close
A global open and close feature can be operated from the remote handset. This feature allows the vehicle windows to be
opened/closed by a single press of the lock or unlock button. The button must be pressed and held for more than 2
seconds to activate the global open/close feature. The global open/close feature is not available in all markets.
Liftgate Release
A liftgate release button can pressed to unlock and release the liftgate latch only. This will operate with the vehicle locked
and alarmed or unlocked. If the vehicle is locked and alarmed, when the liftgate release button is pressed, the liftgate can
be opened without triggering the alarm system. W hen the liftgate is subsequently closed, the alarm will be re-activated.
Headlamp Convenience
A headlamp convenience button can be pressed to operate the headlamps to assist departure or approach to the vehicle. A
single press of the button will operate the headlamps for approximately 25 seconds, after which time they will
automatically turn off. A second press of the button will turn off the headlamps if the 25 second period has not been
reached. Pressing the stop/start button within the 25 second period will also turn off the headlamp convenience feature.
Convenience mode
When the vehicle is unlocked using the unlock button on the remote handset, the vehicle's electrical system initiates
convenience mode. The following systems become active:
Memory - seat adjustment and mirror position
Interior and exterior lighting
Audio system
Instrument cluster message centre
Horn
Cigar lighter/power socket.
