Frelander 2. Manual - part 352
Attach the clear bleed tube to the clutch bleed screw
and immerse the free end of the bleed tube in a bleed
jar containing a small quantity of approved brake fluid.
5.
Loosen the bleed screw by two complete turns.
6.
7.
CAUTION: The brake fluid reservoir must remain full with
new, clean brake fluid at all times during bleeding.
Depress the clutch pedal steadily through its full stroke. W ith the
pedal held down, close the bleed screw. W hen the bleed screw is
fully closed, allow the clutch pedal to return to the rest position.
Repeat the procedure until a flow of clean, air-free fluid is being
pumped into the bleed jar.
7.
8.
CAUTION: Make sure the bleed screw cap is installed after
bleeding. This will prevent corrosion to the bleed screw.
W ith the clutch pedal fully depressed, tighten the bleed screw.
Torque: 10 Nm
8.
Fill the brake fluid reservoir to the MAX mark.
9.
