Install the rear differential rear bush retaining bolts.
Torque: 110 Nm
Install the LH halfshaft.
Refer to:
Rear Halfshaft LH
(205-05 Rear Drive Halfshafts, Removal
and Installation).
9.
Connect the Active On-demand Coupling module electrical connector.
10.
Install the driveshaft rear support bracket.
Torque: 35 Nm
11.
12.
CAUTION: Make sure that new bolts are
installed.
Connect the driveshaft to the rear flange.
Torque: 40 Nm
12.
Install the rear muffler.
Refer to:
Exhaust System
(309-00A Exhaust System - I6 3.2L Petrol,
Removal and Installation).
13.
Install the LH rear wheel and tire.
Refer to:
Wheel and Tire
(204-04 W heels and Tires, Removal and
Installation).
14.
Check and top-up the active on-demand coupling fluid level.
Refer to:
Active On-Demand Coupling Filling
(205-02 Rear Drive
Axle/Differential, General Procedures).
15.
Fill the differential case with fluid.
Refer to:
Differential Draining and Filling
(205-02 Rear Drive
Axle/Differential, General Procedures).
16.
