HARNESSES
REPAIRS
86-7-7
Refit
1. With assistance, position harness to air
conditioning ducting and secure with cable ties.
2. Secure harness to sunroof harness with cable
clips.
3. Connect multiplug to RF receiver.
4. Feed harness to LH and RH upper 'E' posts.
5. Feed harness through 'E' post to tail lamp and
rear bumper and secure with grommet.
6. Connect multiplug to fuel flap solenoid and
alarm sounder.
7. Position alarm sounder to rear quarter and
secure with nut to 9 Nm (7 lbf.ft).
8. Position both RH earth header to 'E' post and
tighten nut to 10 Nm (7 lbf.ft).
9. Feed tail door harness through 'E' post and
secure with grommet.
10. Position harness sleeve to outer edge of door
and pull harness through door.
11. Secure harness to tail door with clips.
12. Connect washer tube to rear of wiper arm.
13. Remove tape from draw string and secure to
CHMSL harness.
14. Draw harness through tail door and connect
Lucars to CHMSL.
15. Fit CHMSL cover and secure with screws.
16. Connect multiplug to door lock switch.
17. Connect Lucars to HRW.
18. Connect multiplug to rear wiper motor.
19. Connect multiplug to door latch.
20. Fit plastic sheet to tail door, ensuring it aligns
with witness marks.
21. Fit tail door trim casing.
DOORS, REPAIRS, Trim casing - tail
22. Connect Lucar to radio aerial RH amplifier.
23. Secure harness to RH side of body with clips
and retainers.
24. Position both LH earth header to 'E' post and
tighten nut to 10 Nm (7 lbf.ft).
25. Connect multiplugs to both tail/flasher lamps
and secure harness to bumper with clips.
26. Fit both rear tail lamps.
LIGHTING, REPAIRS, Lamp - tail.
27. Secure harness to rear LH side of body with 6
cable clips.
28. Connect 2 Lucars to rear air conditioning unit.
29. Fit both luggage compartment trim casings.
REPAIRS, Trim casing - side - loadspace.
30. Feed harness into position for rear interior light.
31. Connect Lucar to radio aerial LH amplifier.
32. Secure harness to body with cable ties clips
and retainers.
33. Secure air conditioning ducting to body with
rivets.
34. Feed harness to LH lower 'A' post.
35. Secure harness to LH side of body with cable
tie clips and retainers.
36. Connect and secure multiplugs to lower LH 'A'
post.
37. Feed harness through roof to centre.
38. Secure harness behind bonnet release cable.
39. Connect rear washer pipe at lower 'A' post and
secure with clip.
40. Secure harness to roof with clips.
41. Connect multiplug to interior mirror, ARC
accelerometer.
42. Position sound deadening panels and secure
with clips.
43. Fit headlining.
44. Fit fascia panel.
