Discovery 2. Manual - part 276
BODY SEALING MATERIALS
MATERIALS AND APPLICATIONS
77-3-7
Hook nozzle on flexible lance
The rigid hook produces a highly atomised, forward-directed, fully conical spray pattern having long range and good
dispersion characteristics. This combination has good directional capabilities for treating short, narrow sections, and
may also be used for direct spraying of inner wheel arches etc.
In use, position the flat area at the end of the lance at 180
°
to the nozzle spray direction. This will help to guide the
spray more accurately when it is concealed in a box section or access hole.
For general spraying, move the nozzle in an arc from side to side as required, to ensure full coverage.
NOTE: Always clean gun after use with appropriate solvent to maintain efficiency.
