70 BRAKES 8 REPAIR REV: 09/97 REAR BRAKE PADS Service repair no - 70.40.03 Service tool: Remove 1. Remove rear road wheels. springs. Note differences between 90 and 4. Remove brake pads. fluid. Wipe away excess with a lint free cloth. 6. Using piston clamp LRT-70-500 press each piston back into its bore. Ensure that displaced Refit 7. Insert brake pads. pins. 9. Apply service brake pedal several times to locate pads. 10. Fit road wheels, remove chassis stands and jack. Tighten wheel nuts to correct torque: 130 Nm (96 lbf/ft) Steel wheels - 100 Nm (80 lbf/ft) Heavy duty wheels - 170 Nm (125 lbf/ft) 11. Check fluid reservoir, top up if necessary, using correct grade of fluid See LUBRICANTS, FLUIDS AND CAPACITIES, Information, 90 Models 110/130 Models |
