TRANSMISSION

...

, ,

.  .

......

5.  Clean  all  components and  ensure  that  the

two

oil-ways  in  the  input  shaft  are  clear  by  blowing
through  with  an  air  line.

9.

Check,  with  a  feeler  gauge,  the  clearance
between  the  bearing  and  washer.

the

clearance

is

in  excess

of

remove  the

circlip  and  washer  and  select  and  measure

new washer

to

take-up t h e  excess clearance.

Continued

.^.

17

TRAN

SMI

SS

I

ON

10.  Fit  t h e   new  selective

with  the

circlip  and

that  the  above  clearance  is

maintained.

11.  Lubricate  the  mainshaft  pilot  bearing  and  fit

to

the  mainshaft.

12.  Fit  t h e   fourth  gear  baulk  ring  t o   the  input

shaft.

13.

Fit  t h e   snap ring  t o  the  bearing.

4.

invert  the  mainshaft  assembly,  in  t h e  vice,  and
remove  the  mainshaft  rear  bearing  circlip.

Mainshaft

Secure  the  mainshaft  assembly  in

vice  and

remove  the  circlip  retaining  the
synchromech  hub  and  gear  assembly.

2.

Remove  t h e   selective  washer,
synchromesh  assembly  and  baulk  ring.

3.  Remove  t h e   third  gear,  spacer,  and  needle

roller  bearing.

Continued

18

.. .

...

...

TRANSMISSION

5.

Using  press  MS

47,  and  a  support  under  t h e

first  gear,  press  t h e   mainshaft  assembly  from

7.  In  addition  remove  t h e  remaining  items:-

the  rear  bearing.

6.

Separate  the  following  components  from  t h e
assembly:-

A.

First  gear.
First  gear  bush.

C.

Spacer.

needle

roller.

E.  Selective washer.
F.  Rear  bearing  snap ring.

A.

First  gear baulk  ring.
First  and  second  synchromesh.

C.

Second  gear baulk  ring.
Second  gear spacer.

E.

Second  gear needle roller  bearing.

F.

Second  gear.

8.

Clean  the  mainshaft  and  all  components  and
examine

for

obvious  wear.

19

synchromesh

assembly.

TRANSMISSION

1.

Before  dismantling,  mark  the  relationship

of

the synchromesh  h u b  t o  the sleeve.

2.

Fit

t h e   baulk  rings  t o   the  synchro-  mesh

assemblies  t o   facilitate  dismantling  and  t o
prevent  damage

to

the springs.

3 .

Place  the  synchromesh  assembly  in  a  clear
plastic  bag,

to

prevent  the  components  being

lost  and  whilst

in

the

bag,  press  the  sleeve

from  the hub.

4.

5.

6 .

7.

8.

9.

10.

11.

Retrieve  the  synchromesh  balls,  springs  and
slipper pads  and  remove  t h e  baulk  ring.
Clean

all

the

synchromesh

assembly

components.

Before  reassembling  the  synchromesh  units
carry  o u t  the  checks

for

third  and  second  gear

end  floats  as  described  under  t h e   heading

"Mainshaft  and  gear train  clearance  checks".

Fit  t h e   synchromesh  hub

to

t h e   sleeve

ensuring that  the alignment marks  line-up.
Place  the hub and  sleeve o n  a

level

block.

With  the  hub  resting

on

the  block  adjust  t h e

height

of  the  hub  sufficiently  t o  fit  t h e  springs.

Locate  the

slipper

t h e   springs  and

press  the  balls  d o w n   t o   b e   retained  by  the
synchromesh  sleeve.
Fit  t h e  baulk  ring

to

the  hub  and  sleeve.

10

12.

13.

14.

Carefully  invert  the  synchromesh  assembly  and
fit  the second  baulk  ring.
Press  the  synchromesh  sleeve  over  the  hub  t o
locate the  balls  in  position.
Remove  the  baulk  rings.

Thirdtfourth synchromesh  assembly.

2.

Repeat  the  instructions  as

for  t h e

synchromesh  assembly  but  omit  the  gear
end-float  checks.

when  reassembling  t h e   synchromesh  unit,

ensure  that  t h e   large  chamfer  on  the  sleeve
faces  the small  boss  on t h e  hub.

Fifth  gear  sychromesh  assembly.

Repeat

the

instructions

relating

t o   the

synchromesh  assembly.

Note  that  when  reassembling  t h e   fifth  gear

chamfer  on  t h e  hub,  faces

to

the  rear.

20
