Defender 90 / 110 / 130. Manual - part 91





TRANSFER

BOX

cross-shaft housing removal

18.  Remove  the  six  bolts  and  washers  retaining  the

Remove

gasket and cross-shaft  housing.

cross-shaft housing and earth lead.

Front output housing removal

20.  Remove the eight bolts and washers and detach t h e

output housing from the transfer

box

casing, taking

care not to mislay the dowel.

Centre differential removal

21.

Remove

selector shaft dctent plug, spring

and retrieve the ball with a suitable magnet.

22.  Withdraw the centre differential and sclcctor

fork assembly.

Rear output housing removal

23.  Remove six  bolts and washers and dctach  the  rear

output  housing  and  shaft  assembly

from  the

transfer casing.

24.

Remove the gasket.

Transfer case overhaul

dismantling

25.  Remove the studs and dowels.
26.  Remove  the  magnetic  drain  plug  and

93

TRANSFER

BOX

27.  Drift

differential rear bearing track.

28.  Clean  all  areas

of  the  transfer  casing  ensuring  all

traces

of  “Loctite”  are  removed  from  faces  and

threads.

Transfer case overhaul

re-assembling

29.

Fit  studs and  dowels  to  front  face  of

t h e

transfer

casing

NOTE: The position of the  radial dowel  blade is set
in  line  with  the  circle which

is

formed  by  the  front

output housing fixing holes.

30.

Refit  magnetic drain  plug  with  new  copper washer
and  tighten

t o

the  specified  torque,  loosely

f i t

the

plug.

29

output housing overhaul -dismantling

Using  flange wrench

1861205 and socket  spanner,

remove  the  flange  nut,  steel  and  felt  washers.
Ensure  flange  bolts  are  fully  engaged  in  the

wrench.

2.  Remove  output  flange  with  circlips  attached.

If

necessary, use a two-legged puller.

NOTE:  The  circlip  need  only  be  released  if  the
flange bolts are to be renewed.

94

3 .   Remove  speedo-drive  housing. This can  be  prised

out with a screwdriver.

4.

Remove  housing  from  the  vice  and  drift  out  the

output shaft, by  striking the flange

of

shaft.

Carefully  prise  off

oil  catch  ring  using  a

screwdriver

in

the slot provided.

Prise  out  and  discard  the  seal  from  the  output

7.  Using  circlip  pliers

the  circlip

housing using

tool

retaining the bearing.

95

Slide drive gear and spacer on to

output shaft.

21.  Locate output shaft into the bearing in t h e  housing

and drift into position.

22.  Locate  speedometer  gcar

(driven)

housing

assembly into the output housing and

in until

flush with

housing face.

TRANSFER

BOX

5.  Remove the high  range gear and  bush, taking care

not to disturb the

sleeve.

6.  Mark

the relationship  of the

sleeve

to

the

hub and then remove the sleeve.

7.  Using

suitable  press  behind

low  range  gear

carefully  remove  the

hub  and  low  range

gcar.

Centre differential

unit

overhaul -dismantling

1.  Secure  centre  diffcrential  unit  to a  vice fitted  with

soft jaws, and release stake nut from recess.

2.  Remove stake nut using  tool

and

socket wrench.

3.

Removc

diffcrential unit  from the vice.

4.

Secure  hand  press

MS47  in  vice

with

collars

and  using  button

the

rear taper bearing and collars.

8.  Substituting  collar

remove  front  taper

9.  Remove hand press from the vice.

vice by gripping the hub splines.

roller bearing.

10.  Using  soft  jaws  secure  the  differential  unit  in  the
