CHASSIS AND BODY

9.

Fit  the  bezels  to  the  locking  button  and

Fitting regulator

remote control lever.

10.

Fit  the  single screw  behind the remote control

lever.

channel.

11.

Fit  the  door  pull  and  secure  with  two  screws

and finishers.

12.

Fit  the  window  regulator  handle  and  retain
with  the single screw  and finisher.

5.

Insert  the  lifting  arm  button  into

the  lifting

REMOVING WINDOW

REGULATORS

DEFENDER 110 - Rear

side door

Remove

1.

Remove the door  trim.

2.

Remove the protective weather  sheet.

3.

Temporarily

fit

the  handle  and  wind  the

window  up to its fullest  extent  and support the
glass  in this  position, with  a  length

of

timber,

6.

Position the  regulator

so

that  the  fixing  holes

to  prevent  it  falling  when  removing  the

line-up with the holes in the  mounting panel.

regulator.

7.

Secure  with  the  four  screws  and  tighten

regulator to  the  mounting panel and  withdraw

8.

Temporarily  fit  the  handle  and  check  that

the  regulator  whilst  sliding  the  lifting

arm

glass

can

be  raised  and  lowered  smoothly

button

from

the  lifting  channel.

To

assist  this

without tight  spots.

operation,  remove  the  timber  and  lower  the

9.  Fit the weather protection sheet with adhesive

glass.

10.

Fit  the  door  trim,  regulator  handle, door  pull,
and bezels.

4.

Remove  the  four  screws  retaining  the

evenly.

REVISED: OCT

1993

CHASSIS AND BODY

REMOVING  EXTERIOR  HANDLE
DEFENDER 110  -  rear  side  door

Remove

Remove

REMOVING DOOR LOCKING BUTTON
DEFENDER  110 - Rear side door

1.

Remove  the  door  trim,  regulator  handle,  door

1.

Remove the  door  trim,  regulator  handle, door

pull and bezels.

pull and bezels.

2.

Peel  back  sufficient  of  the  weather  protection

2.

Peel  back  sufficient  of  the  weather  protection

sheet  to

gain  access  to  the  handle

sheet to  reveal the mechanism

mechanism.

3.

Release the  spring  clip  securing  the  button to

3.  Disconnect the  actuating  rod  from  the  handle

the  operating  rod  and  withdraw

the

rod

from

operating lever.

the button.

4.

Remove  the  two  screws  and  withdraw  the

4.

Remove the two  screws securing

the

button to

handle and bezels.

the door  panel and remove

the

button

Fitting  handle

5.

Fit  the  handle  to  the  door  ensuring  that  the

two

bezels  are i n  position  -  flat faces towards

the door  and secure with  the two screws.

Fitting locking button

5.

Secure  the  locking  button  assembly

to

the

door panel with the two  screws.

6.

Fit

the  operating  rod  to  the  button  assembly

and secure with the spring clip

7 .   Re-seal  the  weather  protection  sheet  and

fit

the  door  trim,  door  pull,  regulator  handle  and
bezels.

6.  Connect  the  actuating  rod  to  the  handle

operating lever and secure with spring clip.

Re-seal the weather protection sheet.

8.  Fit  the  door  trim.  regulator  handle,  door  pull

and bezels.

REVISED: OCT

1993

CHASSIS

AND BODY

Fitting control lever

REMOVING REMOTE

CONTROL LEVER

DEFENDER  110 -

Rear side door

9.

Fit  the  plastic  retaining  clips  to

the

rod

Remove

assembly  into  position  and  secure

with  the

two  screws.

1.

Remove  the  door  trim,  door  pull,  regulator

10,  Connect  the  control  rods  to  the  latch

handle and bezels.

assembly and secure with the clips

2.  Peel-back  sufficient

of

the  weather  protection

11.

Fit  the  plastic  retaining  rod  clips  to  the

sheet to  gain access to  the remote lever.

mounting panel.

3.

Remove  the  spring  clip  and  disconnect  the

12.  Connect  the  control  rod

to

the  locking  button

control

rod from the locking button.

and secure with the clip.

13.  Re-seal  the  weather  protection  sheet  and

fit

the trim  panel,  regulator  handle, door  pull and

bezels.

REMOVING DOOR  LATCH ASSEMBLY
DEFENDER  110 -

Rear

side door

Remove

1.

Remove  the  door  pull.  regulator  handle,
bezels and door

trim.

2.

Peel-back  sufficient

of

the  weather  protection

sheet to  reveal the latch.

3.  Release the  remote control  lever  rod from  the

latch assembly.

4.

Disconnect the  door  outer  handle  control  rod
from the latch assembly.

5.  Disconnect  the  door  locking  button  remote

control rod from the latch mechanism.

6.

Remove  the  three  retaining  screws  and
withdraw the latch assembly

from

the door

4.  Release  the  spring  clip  and  disconnect  the

short

locking button control rod from  the latch

mechanism.

5.

Disconnect  the  long  remote  control  rod  from
the latch assembly.

6.  Remove  the

two

screws  securing  the  remote

control lever

to

the mounting panel.

7.  Release  the  control

rods

from  the  plastic

retaining clips located in

the

mounting panel.

8.  Withdraw  the  remote  control  lever  and

rods

from the door.

10

REVISED: OCT 1993

CHASSIS

AND

BODY

Fitting

the  latch

7.

Remove  the  four  screws  retaining

the

mounting  panel  to  the  door  and  remove

the

panel complete with  rods and control lever

7.

Fit

the  latch  assembly to  the  door  and  secure

with  the  three  screws,  noting  that  the
uppermost screw  is longer.

8.

Connect the  remote control  levers to  the  latch
mechanism reversing instructions 3, 4 and 5.

9.

Re-seal  the  weather  protection  sheet  and

fit

the  regulator  handle,  door  pull,  door  trim  and
bezels.

REMOVING DOOR

GLASS

DEFENDER  110

Rear

side

door

Remove

1.

Disconnect the  door  check  rod  from  the  door

post.

2.

Remove  the  regulator  handle,  door  pull,

bezels and door trim.

3.

Remove the weather  protection sheet.

4.

Remove the window  regulator assembly.

5.

Disconnect  and  remove  the  door  locking

button.

6.

Disconnect the control rods from the latch and

door outer  handle mechanism.

8.

Remove  the  single  self  tapping  screw

to

remove the water channel.

9.  Remove the door check torsion bar

10.

Remove the  door  check  rod  by  bending back
the  end  stop  to  enable  the  rod

to

be

withdrawn.

REVISED:

OCT

1993
