Connector: C0712

Description: Relay-Compressor clutch-Air conditioning (A/C)

Location: Beneath RH Front seat





Part No.:

AFU3271



Colour: YELLOW

Cavities: 5WY

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

30

YPL10045

2.5D

NS

14L

CTAP

30

YPL10045

2.5D

NS

14R

CTAP

85

AFU3120

2.0D

NO

14

S/JOINT SJ1

86

AFU3119

0.75D PW

14

C0872

87

AFU3120

1.5D

BG

14

C0448

Service Repair Kits

Connector: C0718

Description: Drivers seat recline motor

Location: Below RH rear wheelarch





Part No.:

YPC114860



Colour: DARK GREY

Cavities: 9WY

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPJ100890

1.5

GR

ALL C0499

2

YPJ100890

1.5

RB

ALL C0499

3

YPJ100890

1.5

GW

ALL C0499

4

YPJ100890

1.5

RO

ALL C0499

5

YPJ100890

1.5

GP

ALL C0499

6

YPJ100540

2.0

P

ALL C0596

7

YPJ100890

1.5

GN

ALL C0595

8

YPJ100890

1.5

RY

ALL C0439

9

YPJ100540

2.0

B

ALL C0499

Service Repair Kits

Connector: C0719

Description: Sensor-Ultrasonic

Location: Behind headlining top of RH 'B' post





Part No.:

YPC10199



Colour: BLACK

Cavities: 4WY

Harness:

ROOF FRONT HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

AFU3317

0.5D BN

4

C0259

2

AFU3317

0.5D B

4

C0259

3

AFU3317

0.5D WB

4

C0259

Service Repair Kits

Connector: C0723

Description: Header

Location: Behind LH side of dash





Part No.:

Colour:

Cavities:

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

Service Repair Kits
