C0558

CONNECTOR

DEFENDER 1999 MY

Earth

Eyelet
TIN-PLATE

Below RH rear wheel arch

P5585

C0558

Cav

Col

CCT

1

B

ALL

CONNECTOR

C0559

DEFENDER 1999 MY

Earth

Eyelet
TIN-PLATE

Centre of tail door, behind
trim panel

P5650

C0559

Cav

Col

CCT

1

B

ALL

C0560

CONNECTOR

DEFENDER 1999 MY

Earth - Td5

Eyelet
TIN-PLATE

Beneath RH seat

P5777

C0560

Cav

Col

CCT

1

B

ALL

CONNECTOR

C0567

DEFENDER 1999 MY

Sensor - Inlet Air
Temperature (IAT) and
Manifold Absolute Pressure
(MAP) - Td5

Female
BLACK

Top of engine - RH side

P5387

C567

Cav

Col

CCT

1

KB

ALL

2

GB

ALL

3

KP

ALL

4

WY

ALL
