C0278

CONNECTOR

DEFENDER 1999 MY

Switch - Wash / wipe -
Windscreen

Female
NATURAL

Behind steering column
cowl - RH side

Cav

Col

CCT

1

ULG

ALL

2

LGB

ALL

3

WG

ALL

4

YLG

ALL

5

RLG

ALL

6

WG

ALL

CONNECTOR

C0279

DEFENDER 1999 MY

Switch - Trinary

Female
BLACK

Behind RH side of fascia

P5766

C0134

C0279

C0023

C0068

Cav

Col

CCT

1

NG

1

2

UB

1

3

O

1

4

SR

1

C0280

CONNECTOR

DEFENDER 1999 MY

Fan - Condenser - Td5

Female
BLACK

In front of radiator

P5573

C0280

Cav

Col

CCT

1

BN

1

2

B

1

CONNECTOR

C0282

DEFENDER 1999 MY

Relay - Headlamp

Female
BLACK

Behind centre of fascia

P5660

C0068

C0730

C0151

C0731

C0044

C0282

Cav

Col

CCT

2

U

ALL

4

WG

ALL

6

B

ALL

8

U

ALL
