   CONNECTOR DETAILS

DEFENDER 90 NAS

C960

C960
SPEED SENSOR
HARNESS TO MAIN
HARNESS
6 Way
Male
BLACK
Beneath front passenger's
seat

Cav

Color Cct

1

G

ALL

2

B

ALL

3

YR

ALL

5

WK

ALL

6

WLG

ALL

CONNECTOR DETAILS

REV: 9/97

DEFENDER NAS 90

C971

C971
BRAKE LAMP - HIGH
MOUNTED
1 Way
Female
BLACK
Behind RH rear speaker

Cav

Color Cct

1

R

ALL

   CONNECTOR DETAILS

DEFENDER 90 NAS

REV: 9/97

C972

C972
BRAKE LAMP - HIGH
MOUNTED
1 Way
Female
BLACK
Top of tail door

No connector face view

Cav

Color Cct

1

R

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C999

C999
SOLDERED JOINT

Rear RH side of engine
compartment

t:\compuset\erl\faceview\51160386.tif

Cav

Color Cct

1

SCR

ALL

1

W

ALL
