IN CASE OF EMERGENCY

297

Rear Lifting Point

Rear Jacking Location

5. Raise the vehicle by turning the jack screw clockwise.

Raise the vehicle only until the tire just clears the

surface and enough clearance is obtained to install

the spare tire. Minimum tire lift provides maximum

stability.

6. Remove the lug nuts and wheel.
7. Mount the spare tire on the axle.
8. Install the lug nuts with the cone-shaped end toward

the wheel. Lightly tighten the lug nuts clockwise.

9. Lower the vehicle by turning the jack screw to the

counterclockwise, and remove the jack.

10. Finish tightening the wheel bolts. Push down on the

wrench while at the end of the handle for increased

leverage. Tighten the wheel bolts in a star pattern

until each wheel bolt has been tightened twice

page 368. If in doubt about the correct tightness,

have them checked with a torque wrench by an

authorized dealer or at a service station.

11. After 25 miles (40 km), check the lug nut torque with

a torque wrench to ensure that all lug nuts are

properly seated against the wheel.

12. Remove the jack assembly and wheel blocks.
13. Secure the jack and tools in their proper locations.
14. Secure the damaged wheel/tire on the spare tire

carrier. Torque down lug nuts and locking lug nut.

15. Return the lock bolt to the lock position on the

camera cover by turning the lock clockwise using the

provided #40 torx head driver and ratchet. Then,

reinstall the camera cover by slipping it over the

camera/tire carrier until it snaps into place.

Lock Bolt Location

WARNING!

Raising the vehicle higher than necessary can make the

vehicle less stable. It could slip off the jack and hurt

someone near it. Raise the vehicle only enough to

change the tire.

WARNING!

To avoid the risk of forcing the vehicle off the jack, do

not tighten the wheel nuts fully until the vehicle has

been lowered. Failure to follow this warning may result

in serious injury.

WARNING!

A loose tire or jack thrown forward in a collision or hard

stop, could endanger the occupants of the vehicle.

Always stow the jack parts and the spare tire in the

places provided.

298

IN CASE OF EMERGENCY

(Continued)

JUMP STARTING

If your vehicle has a discharged battery, it can be jump

started using a set of jumper cables and a battery in

another vehicle, or by using a portable battery booster

pack. Jump starting can be dangerous if done improperly,

so please follow the procedures in this section carefully.

NOTE:

When using a portable battery booster pack, follow the

manufacturer's operating instructions and precautions.

REPARATIONS

UMP

TART

Supplemental Battery – If Equipped

The battery in your vehicle is located in the right rear of the

engine compartment.

Positive (+) Battery Post – Gas Engine

WARNING!

Do not attempt jump starting if the battery is frozen. It

could rupture or explode and cause personal injury.

CAUTION!

Do not use a portable battery booster pack or any other

booster source with a system voltage greater than 12

Volts or damage to the battery, starter motor, alternator

or electrical system may occur.

WARNING!



Only use the positive battery post on the main battery

to jump start your vehicle. Serious injury or death

could result if you attempt to jump start using the

supplemental battery.



Battery gas is flammable and explosive. Keep flame

or sparks away from the battery. Do not use a

booster battery or any other booster source with an

output greater than 12 Volts. Do not allow cable

clamps to touch each other.



Battery posts, terminals, and related accessories

contain lead and lead compounds. Wash hands after

handling.



If a “fast charger” is used while the battery is in the

vehicle, disconnect both vehicle battery cables

before connecting the charger to the battery. Do not

use a “fast charger” to provide starting.

WARNING!

IN CASE OF EMERGENCY

299

Positive (+) Battery Post – Diesel Engine

NOTE:

The positive (+) battery post is covered with a protective

cap. Lift up on the cap to gain access to the post.
If your vehicle is equipped with a Stop/Start system, it will

be equipped with two batteries

page 147.

See the following steps to prepare for jump starting:
1. Apply the parking brake, shift the automatic

transmission into PARK (P) (manual transmission in

NEUTRAL) and turn the ignition OFF.

2. Turn off the heater, radio, and all electrical

accessories.

3. Pull upward and remove the protective cover over the

positive (+) battery post.

4. If using another vehicle to jump start the battery, park

the vehicle within the jumper cable’s reach, apply the

parking brake and make sure the ignition is OFF.

UMP

TARTING

ROCEDURE

Connecting The Jumper Cables
1. Connect the positive (+) end of the jumper cable to

the positive (+) post of the discharged vehicle.

2. Connect the opposite end of the positive (+) jumper

cable to the positive (+) post of the booster battery.

3. Connect the negative (-) end of the jumper cable to

the negative (-) post of the booster battery.

4. Connect the opposite end of the negative (-) jumper

cable to a good engine ground. A “ground” is an

exposed metallic/unpainted part of the engine, frame

or chassis, such as an accessory bracket or large bolt.

The ground must be away from the battery and the

fuel injection system.

Jump Starting Label

WARNING!



Take care to avoid the radiator cooling fan whenever

the hood is raised. It can start anytime the ignition

switch is ON. You can be injured by moving fan

blades.



Remove any metal jewelry such as rings, watch

bands and bracelets that could make an inadvertent

electrical contact. You could be seriously injured.



Batteries contain sulfuric acid that can burn your

skin or eyes and generate hydrogen gas which is

flammable and explosive. Keep open flames or

sparks away from the battery.

WARNING!

Do not allow vehicles to touch each other as this could

establish a ground connection and personal injury

could result.

WARNING!

Failure to follow this jump starting procedure could

result in personal injury or property damage due to

battery explosion.

WARNING!

Do not connect the jumper cable to the negative (-) post

of the discharged battery. The resulting electrical spark

could cause the battery to explode and could result in

personal injury.

300

IN CASE OF EMERGENCY

5. Start the engine in the vehicle that has the booster

battery, let the engine idle a few minutes, and then

start the engine in the vehicle with the discharged

battery.

6. Once the engine is started, remove the jumper cables

in the reverse sequence.

Disconnecting The Jumper Cables
1. Disconnect the negative (-) end of the jumper cable

from the engine ground of the vehicle with the

discharged battery.

2. Disconnect the opposite end of the negative (-)

jumper cable from the negative (-) post of the booster

battery.

3. Disconnect the positive (+) end of the jumper cable

from the positive (+) post of the booster battery.

4. Disconnect the opposite end of the positive (+)

jumper cable from the positive (+) post of the

discharged vehicle.

5. Reinstall the protective cover over the positive (+)

post of the discharged vehicle.

NOTE:

If frequent jump starting is required to start your vehicle

you should have the battery and charging system tested at

an authorized dealer.

IF YOUR ENGINE OVERHEATS

If the vehicle is overheating, it will need to be serviced by

an authorized dealer.
Potential signs of vehicle overheating:



Temperature gauge is at HOT (H)



Strong smell of coolant



White smoke coming from engine or exhaust



Coolant bottle coolant has bubbles present

In the event it is observed that the temperature gauge is

moving towards or close to the HOT (H) position, you can

reduce the potential for overheating by taking the

appropriate action.



On the highways — slow down.



In city traffic — while stopped, place the transmission in

NEUTRAL (N), but do not increase the engine idle speed

while preventing vehicle motion with the brakes.



If your Air Conditioner (A/C) is on, turn it off. The A/C

system adds heat to the engine cooling system and

turning the A/C off can help remove this heat.



You can also turn the temperature control to maximum

heat, the mode control to floor and the blower control

to high. This allows the heater core to act as a supple

ment to the radiator and aids in removing heat from the

engine cooling system.

CAUTION!

Make sure at all times that unused ends of jumper

cables are not contacting each other or either vehicle

while making connections. Failure to follow these

procedures could result in damage to the charging

system of the booster vehicle or the discharged vehicle.

CAUTION!

Do not run the booster vehicle engine above 2,000 RPM

since it provides no charging benefit, wastes fuel, and

can damage booster vehicle engine.

CAUTION!

Accessories plugged into the vehicle power outlets draw

power from the vehicle’s battery, even when not in use

(i.e., cellular devices, etc.). Eventually, if plugged in long

enough without engine operation, the vehicle’s battery

will discharge sufficiently to degrade battery life and/or

prevent the engine from starting.

WARNING!

You or others can be badly burned by hot engine

coolant (antifreeze) or steam from your radiator. If you

see or hear steam coming from under the hood, do not

open the hood until the radiator has had time to cool.

Never try to open a cooling system pressure cap when

the radiator or coolant bottle is hot.

IN CASE OF EMERGENCY

301

MANUAL PARK RELEASE

In order to move the vehicle in cases where the

transmission will not shift out of PARK (P) (such as a

depleted battery), a Manual Park Release is available.

See the following steps to use the Manual Park Release:
1. Firmly apply the parking brake.
2. Using a small screwdriver or similar tool, remove the

manual park release cover located in front of the gear

selector, to access the release tether strap.

Manual Park Release Cover

3. Fish the tether strap up through the opening in the

console base.

Tether Strap

4. Press and maintain firm pressure on the brake pedal.
5. Pull the tether strap up until the release lever locks

into place in the vertical position. The vehicle is now

out of PARK (P) and can be moved. Release the

parking brake only when the vehicle is securely

connected to a tow vehicle.

Vertical Released Position

CAUTION!

Driving with a hot cooling system could damage your

vehicle. If the temperature gauge reads “H,” pull over

and stop the vehicle. Idle the vehicle with the air condi

tioner turned off until the pointer drops back into the

normal range. If the pointer remains on the “H” and you

hear continuous chimes, turn the engine off immedi

ately and call for service.

WARNING!

Always secure your vehicle by fully applying the parking

brake before activating the Manual Park Release. In

addition, you should be seated in the driver’s seat with

your foot firmly on the brake pedal when activating the

Manual Park Release. Activating the Manual Park

Release will allow your vehicle to roll away if it is not

secured by the parking brake, or by proper connection

to a tow vehicle. Activating the Manual Park Release on

an unsecured vehicle could lead to serious injury or

death for those in or around the vehicle.

302

IN CASE OF EMERGENCY

To Reset The Manual Park Release:
1. Pull upward on the tether strap, releasing it from the

“locked” position.

2. Lower the Manual Park Release lever downward and

to the left, into its original position.

Original Tether Position

3. Tuck the tether strap into the base of the console,

and reinstall the cover.

NOTE:

When the lever is locked in the release position the access

cover cannot be reinstalled.

FREEING A STUCK VEHICLE

If your vehicle becomes stuck in mud, sand or snow, it can

often be moved using a rocking motion. Turn the steering

wheel right and left to clear the area around the front

wheels. For vehicles with automatic transmission, push

and hold the lock button on the gear selector. Then, shift

back and forth between DRIVE (D) and REVERSE (R) (with

automatic transmission) or SECOND (2) gear and

REVERSE (R) (with manual transmission), while gently

pressing the accelerator. Use the least amount of

accelerator pedal pressure that will maintain the rocking

motion, without spinning the wheels or racing the engine.

NOTE:



For vehicles with automatic transmission: Shifts

between DRIVE (D) and REVERSE (R) can only be

achieved at wheel speeds of 5 mph (8 km/h) or less.

Whenever the transmission remains in NEUTRAL (N)

for more than two seconds, you must press the brake

pedal to engage DRIVE (D) or REVERSE (R).



Push the ESC OFF button to place the Electronic

Stability Control (ESC) system in “Partial OFF” mode,

before rocking the vehicle

page 246. Once the

vehicle has been freed, push the ESC OFF button again

to restore “ESC On” mode.

WARNING!

Fast spinning tires can be dangerous. Forces generated

by excessive wheel speeds may cause damage, or even

failure, of the axle and tires. A tire could explode and

injure someone. Do not spin your vehicle's wheels

faster than 30 mph (48 km/h) or for longer than

30 seconds continuously without stopping when you

are stuck and do not let anyone near a spinning wheel,

no matter what the speed.

CAUTION!



Racing the engine or spinning the wheels may lead to

transmission overheating and failure. Allow the

engine to idle with the transmission in NEUTRAL for

at least one minute after every five rocking-motion

cycles. This will minimize overheating and reduce the

risk of clutch or transmission failure during

prolonged efforts to free a stuck vehicle.



When “rocking” a stuck vehicle by shifting between

DRIVE/SECOND gear and REVERSE, do not spin the

wheels faster than 15 mph (24 km/h), or drivetrain

damage may result.



Revving the engine or spinning the wheels too fast

may lead to transmission overheating and failure. It

can also damage the tires. Do not spin the wheels

above 30 mph (48 km/h) while in gear (no transmis

sion shifting occurring).

IN CASE OF EMERGENCY

303

TOWING A DISABLED VEHICLE

This section describes procedures for towing a disabled vehicle using a commercial towing service.
If the transmission and drivetrain are operable, disabled 4x4 vehicles may also be towed as described

page 176.

Proper towing or lifting equipment is required to prevent

damage to your vehicle. Use only tow bars and other

equipment designed for this purpose, following equipment

manufacturer’s instructions. Use of safety chains is

mandatory. Attach a tow bar or other towing device to

main structural members of the vehicle, not to fascia/

bumpers or associated brackets. State and local laws

regarding vehicles under tow must be observed.
If you must use the accessories (wipers, defrosters, etc.)

while being towed, the ignition must be in the ON/RUN

position, not the ACC position.
If the vehicle's battery is discharged, instructions on

shifting the automatic transmission out of PARK (P) in

order to move the vehicle

page 301.

OUR

–W

HEEL

RIVE

ODELS

FCA US LLC recommends towing with all wheels OFF the

ground. Acceptable methods are to tow the vehicle on a

flatbed or with one end of the vehicle raised and the

opposite end on a towing dolly.
If flatbed equipment is not available and the transfer case

is operable, the vehicle may be towed (in the forward

direction, with ALL wheels on the ground), IF the transfer

case is in NEUTRAL (N) and the transmission is in PARK (P)

(for automatic transmissions) or in gear NOT in NEUTRAL,

for manual transmissions)

page 176.

Towing Condition

Wheels OFF The Ground

4WD MODELS

Flat Tow

NONE



Automatic Transmission in PARK (P)



Manual Transmission in gear (NOT in NEUTRAL)



Transfer Case in NEUTRAL (N)



Tow in Forward direction

Wheel Lift Or Dolly Tow

Front

NOT ALLOWED

Rear

NOT ALLOWED

Flatbed

ALL

BEST METHOD

NOTE:

When towing your vehicle, always follow applicable state and provincial laws. Contact state and provincial Highway Safety offices for additional details.

CAUTION!



Do not use sling type equipment when towing.

Vehicle damage may occur.



When securing the vehicle to a flatbed truck, do not

attach to front or rear suspension components.

Damage to your vehicle may result from improper

towing.



If the vehicle being towed requires steering, the igni

tion switch must be in the ACC or ON/RUN mode, not

in the OFF mode.

304

IN CASE OF EMERGENCY

(Continued)

ITHOUT

Special care must be taken when the vehicle is towed with

the ignition in the OFF mode. The only approved method of

towing without the key fob is with a flatbed truck. Proper

towing equipment is necessary to prevent damage to the

vehicle.

MERGENCY

OOKS

—

QUIPPED

If your vehicle is equipped with tow hooks, they are

mounted in the front and the rear fascia/bumpers.

NOTE:

For off-road recovery, it is recommended to use both of the

front tow hooks to minimize the risk of damage to the

vehicle. Always use an appropriately rated tow strap.

Front Tow Hooks

Rear Tow Hook

CAUTION!



Front or rear wheel lifts must not be used (if the

remaining wheels are on the ground). Internal

damage to the transmission or transfer case will

occur if a front or rear wheel lift is used when towing.



Towing this vehicle in violation of the approved

requirements can cause severe transmission and/or

transfer case damage. Damage from improper

towing is not covered under the New Vehicle Limited

Warranty.

WARNING!



Stand clear of vehicles when pulling with tow hooks.

Tow straps may become disengaged, causing

serious injury.



Do not use a chain for freeing a stuck vehicle. Chains

may break, causing serious injury or death.



Failure to follow proper tow hook usage may cause

components to break resulting in serious injury or

death.

CAUTION!



Tow hooks are for emergency use only, to rescue a

vehicle stranded off road. Tow straps are recom

mended when towing the vehicle, chains may cause

vehicle damage.



The tow hooks must not be used to move the vehicle

off the road or where there are obstacles.



Do not use the tow hooks for tow truck hookup or

highway towing.



Do not use the tow hooks to pull a vehicle onto a

flatbed truck.



Do not use the tow hooks to free a stuck vehicle

page 302.



Damage to your vehicle may occur if these guidelines

are not followed

page 303.

WARNING!

306

SERVICING AND MAINTENANCE

SCHEDULED SERVICING — GASOLINE

ENGINE

Your vehicle is equipped with an automatic oil change

indicator system. The oil change indicator system will

remind you that it is time to take your vehicle in for

scheduled maintenance.
Based on engine operation conditions, the oil change

indicator message will illuminate. This means that service

is required for your vehicle. Operating conditions such as

frequent short-trips, trailer tow, extremely hot or cold

ambient temperatures will influence when the “Change

Oil” or “Oil Change Required” message is displayed. Have

your vehicle serviced as soon as possible, within the next

500 miles (805 km).

On vehicles equipped with instrument cluster display, “Oil

Change Required” will be displayed and a single chime will

sound, indicating that an oil change is necessary.
On non-instrument cluster display equipped vehicles,

“Change Oil” will flash in the instrument cluster odometer

and a single chime will sound, indicating that an oil

change is necessary.
An authorized dealer will reset the oil change indicator

message after completing the scheduled oil change. If a

scheduled oil change is performed by someone other than

an authorized dealer, the message can be reset by

referring to the steps described under Instrument Cluster

Display for further information

page 108.

NOTE:

Under no circumstances should oil change intervals

exceed 10,000 miles (16,000 km), 12 months or 350

hours of engine run time, whichever comes first. The 350

hours of engine run or idle time is generally only a concern

for fleet customers.
Once A Month Or Before A Long Trip:



Check the engine oil level.



Check the windshield washer fluid level.



Check the tire inflation pressures and look for unusual

wear or damage, rotate at the first sign of irregular

wear.



Check the fluid levels of the coolant reservoir, brake

master cylinder, and power steering, and fill as needed.



Check the function of all interior and exterior lights.

SERVICING AND MAINTENANCE

307

AINTENANCE

LAN

Refer to the maintenance plan for the required maintenance intervals.

NOTE:

Using white lithium grease, lubricate the door hinge joints twice a year to prevent premature wear.

At Every Oil Change Interval As Indicated By Oil Change Indicator System



Change oil and filter.



Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before the oil indicator system turns on.



Inspect battery and clean and tighten terminals as required.



Inspect the CV/Universal joints.



Inspect brake pads, shoes, rotors, drums, hoses and parking brake.



Inspect engine cooling system protection and hoses.



Inspect exhaust system.



Inspect engine air cleaner filter if using in dusty or off-road conditions; replace engine air cleaner filter if necessary.



Inspect all door latches for presence of grease; reapply if necessary.

308

SERVICING AND MAINTENANCE

Mileage Or Time Passed (Whichever Comes

First):

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

Additional Inspections
Inspect the CV/Universal joints.

Inspect front suspension, tie rod ends, rear suspension,

and replace if necessary.

Inspect the front and rear axle fluid.

Inspect the brake linings, replace as necessary.

Adjust parking brake on vehicles equipped with four

wheel disc brakes.

Inspect transfer case fluid.

Additional Maintenance
Replace engine air cleaner filter.

Replace cabin air filter.

To be replaced every 12,000 miles (19,000 km).

Replace Spark Plugs – 2.0L Engine.

Replace spark plugs – 3.6L Engine.

Flush and replace the engine, intercooler

(if equipped) coolant at 10 years or

150,000 miles (240,000 km) whichever comes first.

SERVICING AND MAINTENANCE

309

Change the manual transmission fluid if using your

vehicle for any of the following: trailer towing, snow

plowing, heavy loading, taxi, police, delivery service

(commercial service), off-road, desert operation or more

than 50% of your driving is at sustained high speeds

during hot weather, above 90°F (32°C).

Change transfer case fluid if using your vehicle for any of

the following: police, taxi, fleet, or frequent trailer towing.

Inspect and replace PCV valve if necessary.

Change front and rear axle fluid if using your vehicle for

police, taxi, fleet, off-road or frequent trailer towing.

1. The spark plug change interval is mileage based only; yearly intervals do not apply.

Mileage Or Time Passed (Whichever Comes

First):

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

WARNING!



You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your

ability to perform a service job, take your vehicle to a competent mechanic.



Failure to properly inspect and maintain your vehicle could result in a component malfunction and affect vehicle handling and performance. This could cause an accident.

310

SERVICING AND MAINTENANCE

SCHEDULED SERVICING — DIESEL ENGINE

Your vehicle is equipped with an automatic oil change

indicator system. The oil change indicator system will

remind you that it is time to take your vehicle in for

scheduled maintenance.
Based on engine operation conditions, the oil change

indicator message will illuminate. This means that service

is required for your vehicle. Operating conditions such as

frequent short-trips, trailer tow, extremely hot or cold

ambient temperatures will influence when the “Oil Change

Required” message is displayed. Have your vehicle

serviced as soon as possible, within the next 500 miles

(805 km).
An authorized dealer will reset the oil change indicator

message after completing the scheduled oil change. If a

scheduled oil change is performed by someone other than

an authorized dealer, to reset the message

page 108.

NOTE:

Under no circumstances should oil change intervals

exceed 10,000 miles (16,000 km) or 12 months,

whichever comes first.
Engine Oil Filter Replacement
Residual oil in the housing may spill from the housing

when the new filter is installed if the residual oil is not

either removed from the housing or enough time has not

elapsed to allow the oil to drain back into the engine.

When servicing the oil filter on this engine, open the filter

cap approximately six turns until the cap o-ring is visible

and stop. Wait five minutes with the cap in this position to

allow dirty engine oil to drain back into the engine. After

five minutes, the cap and filter assembly can be removed

and discarded. When installing the new oil filter cartridge

assembly, ensure the cap is tightened to the specified

torque to prevent low oil pressure conditions.

Once A Month Or Before A Long Trip:



Check engine oil level



Check windshield washer fluid level



Check the tire pressures and look for unusual wear or

damage



Check the fluid levels of the coolant reservoir, brake

master cylinder, and fill as needed



Check function of all interior and exterior lights

SERVICING AND MAINTENANCE

311

AINTENANCE

LAN

— D

IESEL

UEL

B5 B

IODIESEL

Refer to the maintenance plan for the required maintenance intervals.

At Every Oil Change Interval As Indicated By Oil Change Indicator System



Change oil and filter.



Completely fill the Diesel Exhaust Fluid tank.



Drain water from fuel filter assembly.



Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before the oil indicator system turns on.



Inspect battery and clean and tighten terminals as required.



Inspect the CV/Universal joints.



Inspect brake pads, shoes, rotors, drums, hoses and parking brake.



Inspect engine cooling system protection and hoses.



Inspect exhaust system.



Inspect engine air cleaner filter if using in dusty or off-road conditions; replace engine air cleaner filter if necessary.

At Every Second Oil Change Interval As Indicated By Oil Change Indicator System



Change fuel filter.

312

SERVICING AND MAINTENANCE

Mileage Or Time Passed (Whichever Comes First)

10,000

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

10 11 12 13 14 15

Or Kilometers:

16,000

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

Additional Inspections
Completely fill the Diesel Exhaust Fluid tank.

Inspect the CV/Universal joints.

Inspect front suspension, tie rod ends, and replace if necessary.

Inspect the front and rear axle fluid, change if using your vehicle for

police, taxi, fleet, off-road or frequent trailer towing.

Inspect the brake linings, parking brake function.

Inspect transfer case fluid.

Additional Maintenance
Drain water from fuel filter assembly.

Replace fuel filters and drain water from the fuel filter assembly.

Under normal conditions the diesel fuel filter should be replaced every other oil change and must not

exceed 20,000 miles (32,000 km) if using diesel fuel up to B5. If the vehicle is being used in severe

operating conditions, or in certain geographical areas of the country (Pennsylvania, New York, Ohio,

Maryland, West Virginia, Arkansas, Oklahoma, Kansas, Iowa, Missouri and Nebraska) due to fuel

cleanliness issues, it is recommended to replace the fuel filter every oil change and must not exceed

10,000 miles.

Replace engine air cleaner filter.

Replace the cabin air filter.

To be replaced every 12,000 miles (19,000 km).

Jeep Wrangler (2023 year). Manual in english - page 19
