STARTING AND OPERATING

137

(Continued)

AUTOMATIC TRANSMISSION — IF EQUIPPED

You must press and hold the brake pedal while shifting out

of PARK.

GNITION

ARK

NTERLOCK

This vehicle is equipped with an Ignition Park Interlock

which requires the transmission to be in PARK before the

ignition can be turned to the OFF position. This helps the

driver avoid inadvertently leaving the vehicle without

placing the transmission in PARK. This system also locks

the transmission in PARK whenever the ignition is in the

OFF position.

NOTE:

The transmission is NOT locked in PARK when the ignition

is in the ACC position (even though the engine will be off).

Ensure that the transmission is in PARK, and the ignition

is OFF (not in ACC position) before exiting the vehicle.

WARNING!



Never use the PARK position as a substitute for the

parking brake. Always apply the parking brake fully

when exiting the vehicle to guard against vehicle

movement and possible injury or damage.



Your vehicle could move and injure you and others if

it is not in PARK. Check by trying to move the trans

mission gear selector out of PARK with the brake

pedal released. Make sure the transmission is in

PARK before exiting the vehicle.



The transmission may not engage PARK if the vehicle

is moving. Always bring the vehicle to a complete

stop before shifting to PARK, and verify that the

transmission gear position indicator solidly indicates

PARK (P) without blinking. Ensure that the vehicle is

completely stopped, and the PARK position is prop

erly indicated, before exiting the vehicle.



It is dangerous to shift out of PARK or NEUTRAL if the

engine speed is higher than idle speed. If your foot is

not firmly pressing the brake pedal, the vehicle could

accelerate quickly forward or in reverse. You could

lose control of the vehicle and hit someone or some

thing. Only shift into gear when the engine is idling

normally and your foot is firmly pressing the brake

pedal.



Unintended movement of a vehicle could injure

those in or near the vehicle. As with all vehicles, you

should never exit a vehicle while the engine is

running. Before exiting a vehicle, always come to a

complete stop, then apply the parking brake, shift

the transmission into PARK, and turn the ignition

OFF. When the ignition is in the OFF position, the

transmission is locked in PARK, securing the vehicle

against unwanted movement.



When exiting the vehicle, always make sure the igni

tion is in the OFF position, remove the key fob from

the vehicle, and lock the vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Allowing children to

be in a vehicle unattended is dangerous for a

number of reasons. A child or others could be seri

ously or fatally injured. Children should be warned

not to touch the parking brake, brake pedal or the

transmission gear selector.



Do not leave the key fob in or near the vehicle (or in

a location accessible to children), and do not leave

the ignition in the ACC or ON/RUN position. A child

could operate power windows, other controls, or

move the vehicle.

WARNING!

CAUTION!

Damage to the transmission may occur if the following

precautions are not observed:



Shift into or out of PARK or REVERSE only after the

vehicle has come to a complete stop.



Do not shift between PARK, REVERSE, NEUTRAL, or

DRIVE when the engine is above idle speed.



Before shifting into any gear, make sure your foot is

firmly pressing the brake pedal.

138

STARTING AND OPERATING

RAKE

RANSMISSION

HIFT

NTERLOCK

(BTSI) S

YSTEM

This vehicle is equipped with a BTSI system that holds the

transmission gear selector in PARK unless the brakes are

applied. To shift the transmission out of PARK, the engine

must be running and the brake pedal must be pressed.

The brake pedal must also be pressed to shift from

NEUTRAL into DRIVE or REVERSE when the vehicle is

stopped or moving at low speeds.

8–S

PEED

UTOMATIC

RANSMISSION

The transmission gear range (PRNDM) is displayed both

beside the gear selector and in the instrument cluster. To

select a gear range, push the lock button on the gear

selector and move the selector rearward or forward. To

shift the transmission out of PARK, the engine must be

running and the brake pedal must be pressed. You must

also press the brake pedal to shift from NEUTRAL into

DRIVE or REVERSE when the vehicle is stopped or moving

at low speeds. Select the DRIVE range for normal driving.

NOTE:

In the event of a mismatch between the gear selector

position and the actual transmission gear (for example,

driver selects PARK while driving), the position indicator

will blink continuously until the selector is returned to the

proper position, or the requested shift can be completed.
The electronically controlled transmission adapts its shift

schedule based on driver inputs, along with environmental

and road conditions. The transmission electronics are

self-calibrating; therefore, the first few shifts on a new

vehicle may be somewhat abrupt. This is a normal

condition, and precision shifts will develop within a few

hundred miles (kilometers).
Only shift from DRIVE to PARK or REVERSE when the

accelerator pedal is released and the vehicle is stopped.

Be sure to keep your foot on the brake pedal when shifting

between these gears.
The transmission gear selector provides PARK, REVERSE,

NEUTRAL, DRIVE and MANUAL (AutoStick) shift positions.

Manual shifts can be made using the AutoStick shift control.

Toggling the gear selector forward (-) or rearward (+) while in

the MANUAL (AutoStick) position (beside the DRIVE

position) will manually select the transmission gear, and will

display the current gear in the instrument cluster

page 140.

Transmission Gear Selector

NOTE:

If the gear selector cannot be moved to the PARK,

REVERSE, or NEUTRAL position (when pushed forward), it

is probably in the AutoStick (+/-) position (beside the

DRIVE position). In AutoStick mode, the transmission

gear (1, 2, 3, etc.) is displayed in the instrument cluster.

Move the gear selector to the right (into the DRIVE [D]

position) for access to PARK, REVERSE, and NEUTRAL.

Gear Ranges

Do not press the accelerator pedal when shifting out of

PARK or NEUTRAL.

NOTE:

After selecting any gear range, wait a moment to allow the

selected gear to engage before accelerating. This is espe

cially important when the engine is cold.
PARK (P)
This range supplements the parking brake by locking the

transmission. The engine can be started in this range.

Never attempt to use PARK while the vehicle is in motion.

Apply the parking brake when exiting the vehicle in this

range.
When parking on a hill, apply the parking brake before

shifting the transmission to PARK. As an added

precaution, turn the front wheels toward the curb on a

downhill grade and away from the curb on an uphill grade.
When exiting the vehicle, always:



Apply the parking brake.



Shift the transmission into PARK.



Turn the ignition OFF.



Remove the key fob from the vehicle.

NOTE:

On four-wheel drive vehicles, be sure that the transfer

case is in a drive position.

STARTING AND OPERATING

139

The following indicators should be used to ensure that you

have properly engaged the transmission into the PARK

position:



When shifting into PARK, push the lock button on the

gear selector and firmly move the gear selector all the

way forward until it stops and is fully seated.



Look at the transmission gear position display and

verify that it indicates the PARK position (P), and is not

blinking.



With the brake pedal released, verify that the gear

selector will not move out of PARK.

REVERSE (R)
This range is for moving the vehicle backward. Shift into

REVERSE only after the vehicle has come to a complete

stop.
NEUTRAL (N)
Use this range when the vehicle is standing for prolonged

periods with the engine running. Apply the parking brake

and shift the transmission into PARK if you must exit the

vehicle.

DRIVE (D)
This range should be used for most city and highway

driving. It provides the smoothest upshifts and downshifts,

and the best fuel economy. The transmission

automatically upshifts through all forward gears. The

DRIVE position should be used for all normal operating

conditions.
When frequent transmission shifting occurs (such as

when operating the vehicle under heavy loading

conditions, in hilly terrain, traveling into strong head

winds, or while towing a heavy trailer), use the AutoStick

shift control to select a lower gear

page 140. Under

these conditions, using a lower gear will improve

performance and extend transmission life by reducing

excessive shifting and heat buildup.
During extremely cold temperatures (-22°F [-30°C] or

below), transmission operation may be modified

depending on engine and transmission temperature as

well as vehicle speed. Normal operation will resume once

the transmission temperature has risen to a suitable level.
MANUAL (M)
The MANUAL (M, +/-) position (beside the DRIVE position)

enables full manual control of transmission shifting also

known as AutoStick mode. Toggling the gear selector

forward (-) or rearward (+) while in the MANUAL (AutoStick)

position will manually select the transmission gear, and

will display the current gear in the instrument cluster

page 140.

Transmission Limp Home Mode

Transmission function is monitored electronically for

abnormal conditions. If a condition is detected that could

result in transmission damage, Transmission Limp Home

mode is activated. In this mode, the transmission may

operate only in certain gears, or may not shift at all.

Vehicle performance may be severely degraded and the

engine may stall. In some situations, the transmission may

not re-engage if the engine is turned off and restarted. The

Malfunction Indicator Light (MIL) may be illuminated. A

message in the instrument cluster will inform the driver of

the more serious conditions, and indicate what actions

may be necessary.

CAUTION!



Before moving the transmission gear selector out of

PARK, you must start the engine, and also press the

brake pedal. Otherwise, damage to the gear selector

could result.



DO NOT race the engine when shifting from PARK or

NEUTRAL into another gear range, as this can

damage the drivetrain.

WARNING!

Do not coast in NEUTRAL and never turn off the ignition

to coast down a hill. These are unsafe practices that

limit your response to changing traffic or road

conditions. You might lose control of the vehicle and

have a collision.

CAUTION!



Towing the vehicle, coasting, or driving for any other

reason with the transmission in NEUTRAL can cause

severe transmission damage.



For Recreational Towing

page 176.



For Towing A Disabled Vehicle

page 303.

140

STARTING AND OPERATING

In the event of a momentary problem, the transmission

can be reset to regain all forward gears by performing the

following steps:

NOTE:



In cases where the instrument cluster message indi

cates the transmission may not re-engage after engine

shutdown, perform this procedure only in a desired

location (preferably, at an authorized dealer).



Even if the transmission can be reset, we recommend

that you visit an authorized dealer at your earliest

possible convenience. An authorized dealer has diag

nostic equipment to assess the condition of your trans

mission.



If the transmission cannot be reset, authorized dealer

service is required.

1. Stop the vehicle.
2. Shift the transmission into PARK, if possible. If not,

shift the transmission to NEUTRAL.

3. Push and hold the ignition switch until the engine

turns off.

4. Wait approximately 30 seconds.
5. Restart the engine.
6. Shift into the desired gear range. If the problem is no

longer detected, the transmission will return to

normal operation.

AutoStick

AutoStick is a driver-interactive transmission feature

providing manual shift control, giving you more control of

the vehicle. AutoStick allows you to maximize engine

braking, eliminate undesirable upshifts and downshifts,

and improve overall vehicle performance. This feature can

also provide you with more control during passing, city

driving, cold slippery conditions, mountain driving, trailer

towing, and many other situations.
Operation
To activate AutoStick mode, move the gear selector into

the MANUAL (M) position (beside the DRIVE position). The

current transmission gear will be displayed in the

instrument cluster. In AutoStick mode, you can use the

gear selector (in the MANUAL position) to manually shift

the transmission.
AutoStick mode has the following operational benefits:



The transmission will automatically downshift as the

vehicle slows (to prevent engine lugging) and will

display the current gear.



The transmission will automatically downshift to FIRST

gear when coming to a stop. After a stop, the driver

should manually upshift (+) the transmission as the

vehicle is accelerated.



You can start out, from a stop, in FIRST or SECOND gear

(or THIRD gear, in 4L range). Tapping (+) (at a stop) will

allow starting in SECOND gear. Starting out in SECOND

or THIRD gear can be helpful in snowy or icy conditions.



If a requested downshift would cause the engine to

overspeed, that shift will not occur.



The system will ignore attempts to upshift at too low of

a vehicle speed.



Holding the gear selector in the (-) position will down

shift the transmission to the lowest gear possible at the

current speed.



Transmission shifting will be more noticeable when

AutoStick is enabled.



The system may revert to automatic shift mode if a

fault or overheat condition is detected.

NOTE:

When Hill Descent Control is enabled, AutoStick is not

active.
To disengage AutoStick mode, return the gear selector to

the DRIVE position. You can shift in or out of the AutoStick

position at any time without taking your foot off the

accelerator pedal.

FOUR–WHEEL DRIVE OPERATION

WARNING!

Do not downshift for additional engine braking on a

slippery surface. The drive wheels could lose their grip

and the vehicle could skid, causing a collision or

personal injury.

WARNING!

Failure to engage a transfer case position completely

can cause transfer case damage or loss of power and

vehicle control. You could have a collision. Do not drive

the vehicle unless the transfer case is fully engaged.

STARTING AND OPERATING

141

OUR

-P

OSITION

RANSFER

ASE

—

QUIPPED

Four-Wheel Drive Gear Selector

The transfer case provides four positions:



2H — Two-Wheel Drive High Range



4H — Four-Wheel Drive High Range



N (Neutral)



4L — Four-Wheel Drive Low Range

For additional information on the appropriate use of each

transfer case position, see the following:
2H
Two-Wheel Drive High Range — This range is for normal

street and highway driving on dry, hard surfaced roads.
4H
Four-Wheel Drive High Range — This range maximizes

torque to the front driveshaft, forcing the front and rear

wheels to rotate at the same speed. This range provides

additional traction for loose, slippery road surfaces only.

N (Neutral)

N (Neutral) — This range disengages both the front and

rear driveshafts from the powertrain. To be used for flat

towing behind another vehicle

page 176.

4L
Four-Wheel Drive Low Range — This range provides low

speed four-wheel drive. It maximizes torque to the front

driveshaft, forcing the front and rear wheels to rotate at

the same speed. This range provides additional traction

and maximum pulling power for loose, slippery road

surfaces only. Do not exceed 25 mph (40 km/h).
The transfer case is intended to be driven in the 2H

position for normal street and highway conditions, such as

hard-surfaced roads.
In the event that additional traction is required, the

transfer case 4H and 4L positions can be used to lock the

front and rear driveshafts together, forcing the front and

rear wheels to rotate at the same speed. The 4H and 4L

positions are intended for loose, slippery road surfaces

only and not intended for normal driving. Driving in the 4H

and 4L positions on hard-surfaced roads will cause

increased tire wear and damage to the driveline

components. For further information on shifting into 4H or

page 141.

The instrument cluster alerts the driver that the vehicle is

in four-wheel drive, and the front and rear driveshafts are

locked together. The light will illuminate when the transfer

case is shifted into the 4H position.
When operating your vehicle in 4L, the engine speed will

be approximately three times (four times for Rubicon

models) that of the 2H or 4H positions at a given road

speed. Take care not to overspeed the engine.
Proper operation of four-wheel drive vehicles depends on

tires of equal size, type, and circumference on each wheel.

Any difference will adversely affect shifting and cause

damage to the transfer case.
Because four-wheel drive provides improved traction,

there is a tendency to exceed safe turning and stopping

speeds. Do not go faster than road conditions permit.

Shifting Procedures

2H TO 4H OR 4H TO 2H

Shifting between 2H and 4H can be made with the vehicle

stopped or in motion. The preferred shifting speed would

be 0 to 45 mph (72 km/h). With the vehicle in motion, the

transfer case will engage/disengage faster if you

momentarily release the accelerator pedal after

completing the shift. Do not accelerate while shifting the

transfer case. Apply a constant force when shifting the

transfer case lever.

WARNING!

You or others could be injured or killed if you leave the

vehicle unattended with the transfer case in the (N)

Neutral position without first fully engaging the parking

brake. The transfer case (N) Neutral position

disengages both the front and rear driveshafts from the

powertrain, and will allow the vehicle to roll, even if the

automatic transmission is in PARK (or manual

transmission is in gear). The parking brake should

always be applied when the driver is not in the vehicle.

142

STARTING AND OPERATING

NOTE:



Do not attempt to make a shift while only the front or

rear wheels are spinning. The front and rear driveshaft

speeds must be equal for the shift to take place.

Shifting while only the front or rear wheels are spinning

can cause damage to the transfer case.



Delayed shifts out of four-wheel drive may be experi

enced due to uneven tire wear, low or uneven tire pres

sures, excessive vehicle loading, or cold temperatures.



Shifting effort will increase with speed, this is normal.

During cold weather, you may experience increased effort

in shifting until the transfer case fluid warms up. This is

normal.

4H TO 4L OR 4L TO 4H

With the vehicle rolling at 1 to 3 mph (2 to 5 km/h), shift

an automatic transmission into NEUTRAL (N), or press the

clutch pedal on a manual transmission. While the vehicle

is coasting at 1 to 3 mph (2 to 5 km/h), shift the transfer

case lever firmly to the desired position. Do not pause with

the transfer case in N (Neutral). Once the shift is

completed, place the automatic transmission into DRIVE

or release the clutch pedal on a manual transmission.

NOTE:

Shifting into or out of 4L is possible with the vehicle

completely stopped; however, difficulty may occur due to

the mating teeth not being properly aligned. Several

attempts may be required for clutch teeth alignment and

shift completion to occur. The preferred method is with the

vehicle rolling at 1 to 3 mph (2 to 5 km/h). Avoid

attempting to engage or disengage 4L with the vehicle

moving faster than 1 to 3 mph (2 to 5 km/h).
During cold weather, you may experience increased effort

in shifting until the transfer case fluid warms up. This is

normal.

IVE

-P

OSITION

RANSFER

ASE

—

QUIPPED

Four-Wheel Drive Gear Selector

The transfer case provides five mode positions:



2H — Two-Wheel Drive High Range



4H AUTO — Four-Wheel Drive Auto High Range



4H PART TIME — Four-Wheel Drive Part Time High

Range



N (Neutral)



4L — Four-Wheel Drive Low Range

For additional information on the appropriate use of each

transfer case mode position, see the following:
2H
Two-Wheel Drive High Range — This range is for normal

street and highway driving on dry, hard surfaced roads.
4H AUTO
Four-Wheel Drive Auto High Range — This range sends

power to the front wheels. The four-wheel drive system will

be automatically engaged when the vehicle senses a loss

of traction. Additional traction for varying road conditions.
4H PART TIME
Four-Wheel Drive Part Time High Range — This range

maximizes torque to the front driveshaft, forcing the front

and rear wheels to rotate at the same speed. This range

provides additional traction for loose, slippery road

surfaces only.

WARNING!

Failure to engage a transfer case position completely

can cause transfer case damage or loss of power and

vehicle control. You could have a collision. Do not drive

the vehicle unless the transfer case is fully engaged.

STARTING AND OPERATING

143

N (Neutral)

Neutral — This range disengages both the front and rear

driveshafts from the powertrain. To be used for flat towing

behind another vehicle

page 176.

4L
Four-Wheel Drive Low Range — This range provides low

speed four-wheel drive. It maximizes torque to the front

driveshaft, forcing the front and rear wheels to rotate at

the same speed. This range provides additional traction

and maximum pulling power for loose, slippery road

surfaces only. Do not exceed 25 mph (40 km/h).
This transfer case is designed to be driven in the

two-wheel drive position (2H) or four-wheel drive position

(4H AUTO) for normal street and highway conditions on dry

hard surfaced roads.
For variable driving conditions, the 4H AUTO mode can be

used. In this mode, the front axle is engaged, but the

vehicle's power is sent to the rear wheels. Four-wheel drive

will be automatically engaged when the vehicle senses a

loss of traction. Because the front axle is engaged, this

mode will result in lower fuel economy than the 2H mode.
In the event that additional traction is required, the

transfer case 4H and 4L positions can be used to lock the

front and rear driveshafts together, forcing the front and

rear wheels to rotate at the same speed. The 4H and 4L

positions are intended for loose, slippery road surfaces

only and not intended for normal driving. Driving in the 4H

and 4L positions on hard-surfaced roads will cause

increased tire wear and damage to the driveline

components. For further information on shifting into 4H or

page 143.

The instrument cluster alerts the driver that the vehicle is

in four-wheel drive, and the front and rear driveshafts are

locked together. The light will illuminate when the transfer

case is shifted into the 4H position.
When operating your vehicle in 4L, the engine speed will

be approximately three times (four times for Rubicon

models) that of the 2H or 4H positions at a given road

speed. Take care not to overspeed the engine.
Proper operation of four-wheel drive vehicles depends on

tires of equal size, type, and circumference on each wheel.

Any difference will adversely affect shifting and cause

damage to the transfer case.
Because four-wheel drive provides improved traction,

there is a tendency to exceed safe turning and stopping

speeds. Do not go faster than road conditions permit.

Shifting Procedures

2H TO 4H AUTO OR 4H AUTO TO 2H

Shifting between 2H and 4H AUTO can be made with the

vehicle stopped or in motion. The preferred shifting speed

would be 0 to 45 mph (72 km/h). With the vehicle in

motion, the transfer case will engage/disengage faster if

you momentarily release the accelerator pedal after

completing the shift. Do not accelerate while shifting the

transfer case. Apply a constant force when shifting the

transfer case lever.

2H/4H AUTO TO 4H PART TIME OR 4H PART

TIME TO 2H/4H AUTO

Shifting between 2H/4H AUTO to 4H PART TIME can be

made with the vehicle stopped or in motion. The preferred

shifting speed would be 0 to 45 mph (72 km/h). With the

vehicle in motion, the transfer case will engage/disengage

faster if you momentarily release the accelerator pedal

after completing the shift. Do not accelerate while shifting

the transfer case. Apply a constant force when shifting the

transfer case lever.

NOTE:



Do not attempt to make a shift while only the front or

rear wheels are spinning. The front and rear driveshaft

speeds must be equal for the shift to take place.

Shifting while only the front or rear wheels are spinning

can cause damage to the transfer case.



Delayed shifts out of four-wheel drive may be experi

enced due to uneven tire wear, low or uneven tire pres

sures, excessive vehicle loading, or cold temperatures.



Shifting effort will increase with speed, this is normal.

During cold weather, you may experience increased effort

in shifting until the transfer case fluid warms up. This is

normal.

WARNING!

You or others could be injured or killed if you leave the

vehicle unattended with the transfer case in the (N)

Neutral position without first fully engaging the parking

brake. The transfer case (N) Neutral position

disengages both the front and rear driveshafts from the

powertrain, and will allow the vehicle to roll, even if the

automatic transmission is in PARK (or manual

transmission is in gear). The parking brake should

always be applied when the driver is not in the vehicle.

144

STARTING AND OPERATING

4H PART TIME/4H AUTO TO 4L OR 4L TO 4H

PART TIME/4H AUTO

With the vehicle rolling at 1 to 3 mph (2 to 5 km/h), shift

an automatic transmission into NEUTRAL (N), or press the

clutch pedal on a manual transmission. While the vehicle

is coasting at 1 to 3 mph (2 to 5 km/h), shift the transfer

case lever firmly to the desired position. Do not pause with

the transfer case in N (Neutral). Once the shift is

completed, place the automatic transmission into DRIVE

or release the clutch pedal on a manual transmission.

NOTE:

Shifting into or out of 4L is possible with the vehicle

completely stopped; however, difficulty may occur due to

the mating teeth not being properly aligned. Several

attempts may be required for clutch teeth alignment and

shift completion to occur. The preferred method is with the

vehicle rolling at 1 to 3 mph (2 to 5 km/h). Avoid

attempting to engage or disengage 4L with the vehicle

moving faster than 1 to 3 mph (2 to 5 km/h).

RAC

-L

EAR

XLE

— I

QUIPPED

The Trac-Lok rear axle provides a constant driving force to

both rear wheels and reduces wheel spin caused by the

loss of traction at one driving wheel. If traction differs

between the two rear wheels, the differential

automatically proportions the usable torque by providing

more torque to the wheel that has traction.
Trac-Lok is especially helpful during slippery driving

conditions. With both rear wheels on a slippery surface, a

slight application of the accelerator will supply maximum

traction.

XLE

OCK

-L

) F

RONT

EAR

— I

QUIPPED

The AXLE LOCK switch is located on the instrument panel

(to the right of the steering column).

Axle Lock Switch Panel

This feature will only activate when the following

conditions are met:



Ignition in RUN position, vehicle in 4L.



Vehicle speed should be 10 mph (16 km/h) or less.



Both right and left wheels on axle are at the same

speed.

To activate the system, push the AXLE LOCK switch down

to lock the rear axle only (the “REAR ONLY” will illuminate),

push the switch up to lock the front axle and rear axle (the

“FRONT + REAR” will illuminate). When the rear axle is

locked, pushing the bottom of switch again will lock or

unlock the front axle.

NOTE:

The indicator lights will flash until the axles are fully locked

or unlocked.
To unlock the axles, push the AXLE LOCK OFF button.
Axle Lock will disengage if the vehicle is taken out of 4L, or

the ignition switch is turned to the OFF position.
The Axle Lock disengages at speeds above 30 mph

(48 km/h), and will automatically re-lock once vehicle

speed is less than 10 mph (16 km/h).

XLE

OCK

-L

) R

EAR

NLY

—

QUIPPED

The rear axle may be locked in 4H if the proper conditions

are met.

WARNING!

Failure to engage a transfer case position completely

can cause transfer case damage or loss of power and

vehicle control. You could have a collision. Do not drive

the vehicle unless the transfer case is fully engaged.

WARNING!

On vehicles equipped with a limited-slip differential,

never run the engine with one rear wheel off the

ground. The vehicle may drive through the rear wheel

remaining on the ground and cause you to lose control

of your vehicle.

WARNING!

This mode is intended for off-highway or off-road use

only and should not be used on any public roadways.

STARTING AND OPERATING

145

The AXLE LOCK switch is located on the instrument panel

(to the right of the steering column).

Axle Lock Switch Panel

This feature will only activate when the following

conditions are met:



Ignition in RUN position, vehicle in 4H.



The vehicle must be in Off Road+ active

page 146.



Vehicle must be in ESC “Full Off” mode

page 246.



Vehicle must not be actively in a high wheel slip or tight

cornering condition.

To activate the system, push the AXLE LOCK switch down

to lock the rear axle only (“REAR ONLY” will illuminate).
To unlock the rear axle, push the AXLE LOCK OFF button.
Axle Lock will disengage if the vehicle is taken out of 4H,

Off Road+ is turned off by the driver, ESC “Full Off” is

exited, or the ignition switch is turned to the OFF position.

NOTE:

The indicator lights will flash until the rear axle is fully

locked or unlocked.

The rear Axle Lock system may temporarily disengage the

rear locker under some conditions.
If this occurs, the rear axle will automatically re-lock as

soon as the system allows.

LECTRONIC

WAY

ISCONNECT

—

QUIPPED

Your vehicle may be equipped with an electronic

disconnecting stabilizer/sway bar. This system allows

greater front suspension travel in off-road situations.
This system is controlled by the SWAY BAR switch located

on the instrument panel (to the right of the steering

column).

SWAY BAR Switch

Push the SWAY BAR switch to activate the system. Push

the switch again to deactivate the system. The Sway Bar

Indicator Light (located in the instrument cluster) will

illuminate when the bar is disconnected. The Sway Bar

Indicator Light will flash during activation transition, or

when activation conditions are not met. The stabilizer/

sway bar should remain in on-road mode during normal

driving conditions.

To disconnect the stabilizer/sway bar, shift to either 4H or

4L and push the SWAY BAR switch to obtain the off-road

position

page 140. The Sway Bar Indicator Light will

flash until the stabilizer/sway bar has been fully

disconnected.

NOTE:

The stabilizer/sway bar may be torque locked due to left

and right suspension height differences. This condition is

due to driving surface differences or vehicle loading. In

order for the stabilizer/sway bar to disconnect/reconnect,

the right and left halves of the bar must be aligned. This

alignment may require that the vehicle be driven onto level

ground or rocked from side to side.

WARNING!

Ensure the stabilizer/sway bar is reconnected before

driving on hard surfaced roads or at speeds above

18 mph (29 km/h); a disconnected stabilizer/sway bar

may contribute to the loss of vehicle control, which

could result in serious injury. Under certain

circumstances, the front stabilizer/sway bar enhances

vehicle stability and assists with vehicle control. The

system monitors vehicle speed and will attempt to

reconnect the stabilizer/sway bar at speeds over

18 mph (29 km/h). This is indicated by a flashing or

solid Sway Bar Indicator Light. Once vehicle speed is

reduced below 14 mph (22 km/h), the system will once

again attempt to return to off-road mode.

146

STARTING AND OPERATING

To return to on-road mode, push the SWAY BAR switch

again.

OAD

+ — I

QUIPPED

OFF ROAD+ Switch

When activated, Off Road+ is designed to improve the

user experience when using specific Off Road driving

modes. To activate Off Road+, push the OFF ROAD+ switch

in the switch bank. The vehicle’s performance will improve

depending on which Four-Wheel Drive (4WD) mode is

activated.

NOTE:

Off Road+ will not function in 2H mode. If the button is

pushed while in 2H mode, the cluster display will show the

message “Off Road+ Unavailable Shift to 4WD”.
When Off Road+ is active, the following features will

activate:



The Off Road+ telltale will illuminate in the instrument

cluster display



A mode-specific message will display the instrument

cluster display



Off-Road Pages will launch on the radio head-unit if

selected in radio settings



The Off-Road Camera will launch if selected in radio

settings

Once in Off Road+, the vehicle will begin to behave in

different ways depending on the 4WD mode in use. The

following enhancements will occur when using Off Road+.
4L



Engine/Transmission Calibration: Rock Crawl and

controllability focus, change in shifting schedule when

rock crawling, pedal calibration shifted to de-gain and

low range, operates at lower vehicle speeds



Traction Control: Aggressive brake lock differential

tuning at slower speed or FIRST gear



Off Road+: Recall the last status between ignition

cycles



Engine/Transmission Calibration: Improved sand

performance/wheel slip focus, change in shift

schedule for sport mode, pedal calibration set to

aggressive, operates at elevated vehicle speeds



Traction Control: High wheel speed, slip tuning brake

lock differential with no engine management



Electronic Stability Control: ESC Off with unlimited

speed



Off Road+: Will default to OFF between ignition cycles

Cruise Control and Adaptive Cruise Control (ACC) will not

function while using Off Road+. A dedicated cluster

message will display indicating this if either feature is

activated while in Off Road+.
If the ESC OFF button is pushed while in Off Road+, the

following will occur on the vehicle:



Push of the ESC OFF Button: Traction Control will turn

off, but Stability Control will remain active.



Hold the ESC OFF Button for five seconds: Traction

Control and Stability Control will turn off.

ELECTRO-HYDRAULIC POWER STEERING

Your vehicle is equipped with an Electro-Hydraulic Power

Steering system that provides increased vehicle response

and ease of maneuverability. The system adapts to

different driving conditions. If the Electro-Hydraulic Power

Steering system experiences a fault that prevents it from

providing power steering assist, then the system will

provide mechanical steering capability.

WARNING!

If the stabilizer/sway bar will not return to on-road mode,

the Sway Bar Indicator Light will flash in the instrument

cluster and vehicle stability may be reduced. Do not

attempt to drive the vehicle over 18 mph (29 km/h).

Driving faster than 18 mph (29 km/h) with a discon

nected stabilizer/sway bar may contribute to the loss of

vehicle control, which could result in serious injury.

CAUTION!

Extreme steering maneuvers may cause the electrically

driven pump to reduce or stop power steering

assistance in order to prevent damage to the system.

Normal operation will resume once the system is

allowed to cool.

STARTING AND OPERATING

147

If the “SERVICE POWER STEERING” message and a

flashing icon are displayed on the instrument cluster

screen, it indicates that the vehicle needs to be taken to

an authorized dealer for service. It is likely the vehicle has

lost power steering assistance

page 108.

If the “POWER STEERING HOT” message and an icon are

displayed on the instrument cluster screen, it indicates

that extreme steering maneuvers may have occurred,

which caused an over temperature condition in the power

steering system. You will lose power steering assistance

momentarily until the over temperature condition no

longer exists. Once driving conditions are safe, pull over

and let vehicle idle for a few moments until the light turns

off

page 108.

NOTE:



Even if power steering assistance is no longer opera

tional, it is still possible to steer the vehicle. Under

these conditions there will be a substantial increase in

steering effort, especially at very low vehicle speeds

and during parking maneuvers.



If the condition persists, see an authorized dealer for

service.

STOP/START SYSTEM — AUTOMATIC

TRANSMISSION (IF EQUIPPED)

The Engine Stop/Start (ESS) function is designed to

reduce fuel consumption. The system will stop the engine

automatically during a vehicle stop if the required

conditions are met. Releasing the brake pedal or pressing

the accelerator pedal will automatically restart the engine.

ESS vehicles have been upgraded with a heavy-duty

starter, enhanced battery, and other upgraded engine

parts, to handle the additional engine starts. Vehicles

equipped with eTorque contain a heavy-duty motor

generator and an additional hybrid electric battery to store

energy from vehicle deceleration for use on engine startup

after a stop as well as providing launch torque assist.

NOTE:

It is recommended that Stop/Start system be disabled

during off-road use.
Secondary Battery
Your vehicle may be equipped with a secondary battery

used to power the Stop/Start system and the 12 Volt

vehicle electrical system. The secondary battery is located

behind the wheel well for the front passenger wheel.

Battery Locations

UTOSTOP

ODE

The Stop/Start feature is enabled after every driver

ignition start. At that time, the system will go into STOP/

START READY and if all other conditions are met, can go

into a STOP/START AUTOSTOP ACTIVE Autostop mode.
To Activate The Autostop Mode, The Following Must Occur:



The system must be in STOP/START READY state. A

STOP/START READY message will be displayed in the

instrument cluster display within the Stop/Start

section

page 108.



The vehicle must be completely stopped.



The shifter must be in a forward gear and the brake

pedal pressed.

1 — Primary Battery
2 — Secondary Battery

WARNING!



Vehicles with the Stop/Start system will be equipped

with two batteries. Both the main and the supple

mental batteries must be disconnected to

completely de-energize the 12 Volt electrical system.



Serious injury or death could result if you do not

disconnect both batteries. To learn how to properly

disconnect, see an authorized dealer.

148

STARTING AND OPERATING

OSSIBLE

EASONS

NGINE

OES

UTOSTOP

Prior to engine shut down, the system will check many

safety and comfort conditions to see if they are fulfilled.

Detailed information about the operation of the Stop/Start

system may be viewed in the instrument cluster display

Stop/Start screen. Situations when the engine will not

stop include (but not limited to):



Driver’s seat belt is not buckled.



Driver’s door is not closed.



Battery temperature is too warm or cold.



Battery charge is low.



The vehicle is on a steep grade.



Cabin heating or cooling is in process and an accept

able cabin temperature has not been achieved.



Gear selector is in MANUAL (M) mode.



HVAC is set to full defrost mode at a high blower speed.



HVAC is set to MAX A/C.



Engine has not reached normal operating temperature.



Engine or exhaust temperature is too high.



The transmission is not in a forward gear.



Hood is open.



Transfer case is in 4L or N (Neutral).



Brake pedal is not pressed with sufficient pressure.



Accelerator pedal input.



Vehicle speed threshold has not been achieved from

previous Autostop.



Steering angle is beyond threshold (ESS Models Only).



ACC is on and speed is set.



Vehicle is at high altitude.



System fault is present.

It may be possible for the vehicle to be driven several

times without the Stop/Start system going into a STOP/

START READY state under more extreme conditions of the

previously listed items.

TART

NGINE

HILE

UTOSTOP

ODE

While in a forward gear, the engine will start when the

brake pedal is released or the throttle pedal is pressed.

The transmission will automatically re-engage upon

engine restart.
Conditions That Will Cause The Engine To Start

Automatically While In Autostop Mode:



The transmission selector is moved out of DRIVE.



To maintain cabin temperature comfort.



Actual cabin temperature is significantly different than

temperature set on Auto HVAC.



HVAC is set to full defrost mode.



HVAC system temperature or fan speed is manually

adjusted higher.



Battery voltage drops too low.



Stop/Start OFF switch is pushed.



A Stop/Start system error occurs.



Stop/Start Autostop Active time exceeds five minutes.



Transfer case is in 4L or N (Neutral).



Steering wheel is turned beyond threshold (ESS

Models Only).

ANUALLY

URN

TOP

TART

YSTEM

Stop/Start OFF Switch

Push the Stop/Start OFF switch (located on the switch

bank). The light on the switch will illuminate. The “Stop/

Start OFF” message will appear in instrument cluster

display within the Stop/Start section, and the autostop

function will be disabled

page 108.

NOTE:

The Stop/Start system will reset itself back to an ON

condition every time the ignition is turned off and back on.

STARTING AND OPERATING

149

ANUALLY

URN

TOP

TART

YSTEM

Push the Stop/Start OFF switch (located on the switch

bank). The light on the switch will turn off.

YSTEM

ALFUNCTION

If there is a malfunction in the Stop/Start system, the

system will not shut down the engine. A “SERVICE STOP/

START SYSTEM” message and a yellow Stop/Start telltale

will appear in the Instrument Cluster Display

page 108.

If the “SERVICE STOP/START SYSTEM” message appears

in the instrument cluster display, have the system

checked by an authorized dealer.
If a malfunction occurs during an autostop, the vehicle

may not auto start and will need a key start.

STOP/START SYSTEM — MANUAL

TRANSMISSION (IF EQUIPPED)

The Engine Stop/Start (ESS) function is designed to

reduce fuel consumption. The system will stop the engine

automatically during a vehicle stop if the required

conditions are met. Pressing the clutch pedal will

automatically restart the vehicle.
ESS vehicles have been upgraded with a heavy-duty

starter, enhanced battery, and other upgraded engine

parts, to handle the additional engine starts. Vehicles

equipped with eTorque contain a heavy duty motor

generator and an additional hybrid electric battery to store

energy from vehicle deceleration for use on engine startup

after a stop as well as providing launch torque assist.

NOTE:

It is recommended that Stop/Start be disabled during

off-road use.
Secondary Battery
Your vehicle may be equipped with a secondary battery

used to power the Stop/Start system and the 12 Volt

vehicle electrical system. The secondary battery is located

behind the wheel well for the front passenger wheel.

Battery Locations

UTOSTOP

ODE

The Stop/Start feature is enabled after every driver

ignition start. It will remain in STOP/START NOT READY

until you drive forward with a vehicle speed greater than

5 mph (8 km/h). At that time, the system will go into

STOP/START READY and if all other conditions are met,

can go into an STOP/START AUTO STOP ACTIVE mode.
To Activate The STOP/START AUTOSTOP ACTIVE Mode,

The Following Must Occur:



The system must be in STOP/START READY state. A

STOP/START READY message will be displayed in the

instrument cluster

page 108.



Vehicle speed must be less than 2 mph (3 km/h).



The gear selector must be in the NEUTRAL position and

the clutch pedal must be fully released.

1 — Primary Battery
2 — Secondary Battery

WARNING!



Vehicles with the Stop/Start system will be equipped

with two batteries. Both the main and the supple

mental batteries must be disconnected to

completely de-energize the 12 Volt electrical system.



Serious injury or death could result if you do not

disconnect both batteries. To learn how to properly

disconnect, see an authorized dealer.

150

STARTING AND OPERATING

OSSIBLE

EASONS

NGINE

OES

UTOSTOP

Prior to engine shut down, the system will check many

safety and comfort conditions to see if they are fulfilled.

Situations when the engine will not stop include (but not

limited to):



Driver’s seat belt is not buckled.



Outside temperature is less than 10°F (–12°C) or

greater than 109°F (43°C).



Actual cabin temperature is significantly different than

temperature set on Auto HVAC.



HVAC is set to full defrost mode.



Engine has not reached normal operating temperature.



Battery is discharged.



When driving in REVERSE.



Hood is open.



Transfer case is in 4L or N (Neutral).



Driver's seat is not occupied or driver’s door is open.



Vehicle is at high altitude.



The vehicle is on a steep grade.



Forward Gear is engaged.



Steering angle is beyond threshold (ESS Models Only).



System fault is present.



HVAC is set to MAX A/C.

It may be possible for the vehicle to be driven several

times without the Stop/Start system going into a STOP/

START READY state under more extreme conditions of the

previously listed items.

TART

NGINE

HILE

UTOSTOP

ODE

When the gear selector is in NEUTRAL, the engine will start

when the clutch pedal is pressed (does not require

complete/full pedal press). The vehicle will go into STOP/

START SYSTEM NOT READY mode until the vehicle speed

is greater than 5 mph (8 km/h).
Conditions that will cause the engine to start

automatically while in STOP/START AUTOSTOP ACTIVE

mode
The Engine Will Start Automatically When:



Actual cabin temperature is significantly different than

temperature set on Auto HVAC.



HVAC is set to full defrost mode.



HVAC system temperature or fan speed is manually

adjusted higher.



Stop/Start Autostop Active time exceeds five minutes.



Battery voltage drops too low.



Vehicle is moving faster than 5 mph (8 km/h).



STOP/START OFF switch is pressed.



Transfer case is in 4L or N (Neutral).



Steering wheel is turned beyond threshold (ESS

Models Only).

ANUALLY

URN

TOP

TART

YSTEM

1. Push the Stop/Start OFF switch (located on the

switch bank). The light on the switch will illuminate.

Stop/Start OFF Switch

2. The STOP/START OFF message will appear in the

instrument cluster

page 108.

3. At the next vehicle stop (after turning off the Stop/

Start system), the engine will not be stopped.

4. If the Stop/Start system is manually turned off, the

engine can only be started and stopped by cycling the

ignition switch.

5. The Stop/Start system will reset itself back to an ON

condition every time the ignition is turned off and

back on.

STARTING AND OPERATING

151

ANUALLY

URN

TOP

TART

YSTEM

Push the Stop/Start OFF switch (located on the switch

bank). The light on the switch will turn off.

YSTEM

ALFUNCTION

If there is a malfunction in the Stop/Start system, the

system will not shut down the engine. A “SERVICE STOP/

START SYSTEM” message and a yellow Stop/Start telltale

will appear in the Instrument Cluster Display

page 108.

If the “SERVICE STOP/START SYSTEM” message appears

in the instrument cluster display, have the system

checked by an authorized dealer.
If a malfunction occurs during an autostop, the vehicle

may not auto start and will need a key start.

CRUISE CONTROL SYSTEMS — IF EQUIPPED

Your vehicle may be equipped with the Cruise Control

system, or the Adaptive Cruise Control (ACC) system:



Cruise Control will keep your vehicle at a constant

preset speed.



Adaptive Cruise Control (ACC) will adjust the vehicle

speed up to the preset speed to maintain a distance

with the vehicle ahead.

NOTE:



In vehicles equipped with ACC, if ACC is not enabled,

Fixed Speed Cruise Control will not detect vehicles

directly ahead of you. Always be aware of the feature

selected.



Only one Cruise Control feature can operate at a time.

For example, if Fixed Speed Cruise Control is enabled,

Adaptive Cruise Control will be unavailable, and vice

versa.

RUISE

ONTROL

When engaged, the Cruise Control takes over accelerator

operations at speeds greater than 20 mph (32 km/h).
The Cruise Control buttons are located on the right side of

the steering wheel.

Cruise Control Buttons

To Activate

Push the on/off button to activate the Cruise Control. The

cruise indicator light in the instrument cluster display will

illuminate. To turn the system off, push the on/off button

a second time. The cruise indicator light will turn off. The

system should be turned off when not in use.

1 — SET (+)/Accel
2 — CANC/Cancel
3 — SET (-)/Decel
4 — On/Off
5 — RES/Resume

WARNING!

Cruise Control can be dangerous where the system

cannot maintain a constant speed. Your vehicle could

go too fast for the conditions, and you could lose control

and have an accident. Do not use Cruise Control in

heavy traffic or on roads that are winding, icy,

snow-covered or slippery.

WARNING!

Leaving the Cruise Control system on when not in use is

dangerous. You could accidentally set the system or

cause it to go faster than you want. You could lose

control and have an accident. Always leave the system

off when you are not using it.

152

STARTING AND OPERATING

To Set A Desired Speed

Turn the Cruise Control on.

NOTE:

The vehicle should be traveling at a steady speed and on

level ground before pushing the SET (+) or SET (-) button.
When the vehicle has reached the desired speed, push

the SET (+) or SET (-) button and release. Release the

accelerator and the vehicle will operate at the selected

speed.

To Vary The Speed Setting

To Increase Or Decrease The Set Speed
When the Cruise Control is set, you can increase speed by

pushing the SET (+) button, or decrease speed by pushing

the SET (-) button.
U.S. Speed (mph)



Pushing the SET (+), or SET (-) button once will result in

a 1 mph speed adjustment. Each subsequent tap of

the button results in an adjustment of 1 mph.



If the button is continually pushed, the set speed will

continue to adjust in 5 mph increments until the button

is released, then the new set speed will be established.

Metric Speed (km/h)



Pushing the SET (+), or SET (-) button once will result in

a 1 km/h speed adjustment. Each subsequent tap of

the button results in an adjustment of 1 km/h.



If the button is continually pushed, the set speed will

continue to adjust in 10 km/h increments until the

button is released, then the new set speed will be

established.

To Accelerate For Passing

While the Cruise Control is set, press the accelerator to

pass as you would normally. When the pedal is released,

the vehicle will return to the set speed.

USING CRUISE CONTROL ON HILLS

The transmission may downshift on hills to maintain the

vehicle set speed.
The Cruise Control system maintains speed up and down

hills. A slight speed change on moderate hills is normal.

On steep hills, a greater speed loss or gain may occur so it

may be preferable to drive without Cruise Control.

To Resume Speed

To resume a previously set speed, push the RES button

and release. Resume can be used at any speed above

20 mph (32 km/h).

To Deactivate

A tap on the brake pedal, pushing the CANC (cancel)

button, or normal brake pressure while slowing the vehicle

will deactivate the Cruise Control without erasing the set

speed from memory.

The following conditions will also deactivate the Cruise

Control without erasing the set speed from memory:



Vehicle parking brake is applied



Stability event occurs



Gear selector is moved out of DRIVE



Engine overspeed occurs



Clutch pedal is pressed (manual transmission only)



Vehicle is operating at a low RPM (manual transmis

sion only)

Pushing the on/off button or placing the ignition in the OFF

position erases the set speed from memory.

DAPTIVE

RUISE

ONTROL

(ACC)

Adaptive Cruise Control (ACC) increases the driving

convenience provided by Cruise Control while traveling on

highways and major roadways. However, it is not a safety

system and not designed to prevent collisions. The Cruise

Control function performs differently if your vehicle is not

equipped with ACC

page 151.

NOTE:



If the ACC sensor detects a vehicle ahead, ACC will

apply limited braking or accelerate (not to exceed the

original set speed) automatically to maintain a preset

following distance, while matching the speed of the

vehicle ahead.



Any chassis/suspension or tire size modifications to

the vehicle will affect the performance of the Adaptive

Cruise Control and Forward Collision Warning system.



Fixed Speed Cruise Control (ACC not enabled) will not

detect vehicles directly ahead of you. Always be aware

of the feature selected

page 381.

WARNING!

Cruise Control can be dangerous where the system

cannot maintain a constant speed. Your vehicle could

go too fast for the conditions, and you could lose control

and have an accident. Do not use Cruise Control in

heavy traffic or on roads that are winding, icy,

snow-covered or slippery.

Jeep Wrangler (2023 year). Manual in english - page 9
