STARTING AND OPERATING

155

The following indicators should be used to ensure

that you have properly engaged the transmission

into the PARK position:



When shifting into PARK, push the lock button

on the gear selector and firmly move the gear

selector all the way forward until it stops and is

fully seated.



Look at the transmission gear position display

and verify that it indicates the PARK position (P),

and is not blinking.



With the brake pedal released, verify that the

gear selector will not move out of PARK.

REVERSE (R)
This range is for moving the vehicle backward.

Shift into REVERSE only after the vehicle has come

to a complete stop.

NEUTRAL (N)
Use this range when the vehicle is standing for

prolonged periods with the engine running. Apply

the parking brake and shift the transmission into

PARK if you must exit the vehicle.

DRIVE (D)
This range should be used for most city and

highway driving. It provides the smoothest upshifts

and downshifts, and the best fuel economy. The

transmission automatically upshifts through all

forward gears. The DRIVE position should be used

for all normal operating conditions.
When frequent transmission shifting occurs (such

as when operating the vehicle under heavy loading

conditions, in hilly terrain, traveling into strong

head winds, or while towing a heavy trailer), use

the AutoStick shift control to select a lower gear

page 156. Under these conditions, using a lower

gear will improve performance and extend

transmission life by reducing excessive shifting

and heat build-up.
During extremely cold temperatures (-22°F

[-30°C] or below), transmission operation may be

modified depending on engine and transmission

temperature as well as vehicle speed. Normal

operation will resume once the transmission

temperature has risen to a suitable level.
MANUAL (M)
The MANUAL (M, +/-) position (beside the DRIVE

position) enables full manual control of

transmission shifting also known as AutoStick

mode. Toggling the gear selector forward (-) or

rearward (+) while in the MANUAL (AutoStick)

position will manually select the transmission gear,

and will display the current gear in the instrument

cluster

page 156.

CAUTION!



Before moving the transmission gear selector

out of PARK, you must start the engine, and

also press the brake pedal. Otherwise,

damage to the gear selector could result.



DO NOT race the engine when shifting from

PARK or NEUTRAL into another gear range, as

this can damage the drivetrain.

WARNING!

Do not coast in NEUTRAL and never turn off the

ignition to coast down a hill. These are unsafe

practices that limit your response to changing

traffic or road conditions. You might lose control

of the vehicle and have a collision.

CAUTION!



Towing the vehicle, coasting, or driving for any

other reason with the transmission in

NEUTRAL can cause severe transmission

damage.



For Recreational Towing

page 198.



For Towing A Disabled Vehicle

page 344.

156

STARTING AND OPERATING

Transmission Limp Home Mode

Transmission function is monitored electronically

for abnormal conditions. If a condition is detected

that could result in transmission damage,

Transmission Limp Home mode is activated. In this

mode, the transmission may operate only in

certain gears, or may not shift at all. Vehicle

performance may be severely degraded and the

engine may stall. In some situations, the

transmission may not re-engage if the engine is

turned off and restarted. The Malfunction Indicator

Light (MIL) may be illuminated. A message in the

instrument cluster will inform the driver of the

more serious conditions, and indicate what actions

may be necessary.
In the event of a momentary problem, the

transmission can be reset to regain all forward

gears by performing the following steps:

NOTE:



In cases where the instrument cluster message

indicates the transmission may not re-engage

after engine shutdown, perform this procedure

only in a desired location (preferably, at an

authorized dealer).



Even if the transmission can be reset, we recom

mend that you visit an authorized dealer at your

earliest possible convenience. An authorized

dealer has diagnostic equipment to assess the

condition of your transmission.



If the transmission cannot be reset, authorized

dealer service is required.

1. Stop the vehicle.
2. Shift the transmission into PARK, if possible. If

not, shift the transmission to NEUTRAL.

3. Push and hold the ignition switch until the

engine turns off.

4. Wait approximately 30 seconds.
5. Restart the engine.
6. Shift into the desired gear range. If the

problem is no longer detected, the

transmission will return to normal operation.

AutoStick

AutoStick is a driver-interactive transmission

feature providing manual shift control, giving you

more control of the vehicle. AutoStick allows you to

maximize engine braking, eliminate undesirable

upshifts and downshifts, and improve overall

vehicle performance. This feature can also provide

you with more control during passing, city driving,

cold slippery conditions, mountain driving, trailer

towing, and many other situations.
Operation
To activate AutoStick mode, move the gear

selector into the MANUAL (M) position (beside the

DRIVE position). The current transmission gear will

be displayed in the instrument cluster. In AutoStick

mode, you can use the gear selector (in the

MANUAL position) to manually shift the

transmission.
AutoStick mode has the following operational

benefits:



The transmission will automatically downshift

as the vehicle slows (to prevent engine lugging)

and will display the current gear.



The transmission will automatically downshift to

FIRST gear when coming to a stop. After a stop,

the driver should manually upshift (+) the trans

mission as the vehicle is accelerated.



You can start out, from a stop, in FIRST or

SECOND gear (or THIRD gear, in 4L range).

Tapping (+) (at a stop) will allow starting in

SECOND gear. Starting out in SECOND or THIRD

gear can be helpful in snowy or icy conditions.



If a requested downshift would cause the

engine to overspeed, that shift will not occur.



The system will ignore attempts to upshift at too

low of a vehicle speed.



Holding the gear selector in the (-) position will

downshift the transmission to the lowest gear

possible at the current speed.



Transmission shifting will be more noticeable

when AutoStick is enabled.



The system may revert to automatic shift mode

if a fault or overheat condition is detected.

STARTING AND OPERATING

157

NOTE:

When Hill Descent Control is enabled, AutoStick is

not active.
To disengage AutoStick mode, return the gear

selector to the DRIVE position. You can shift in or

out of the AutoStick position at any time without

taking your foot off the accelerator pedal.

FOUR–WHEEL DRIVE OPERATION

OUR

-P

OSITION

RANSFER

ASE

—

QUIPPED

Four-Wheel Drive Gear Selector

The transfer case provides four positions:



2H — Two-Wheel Drive High Range



4H — Four-Wheel Drive High Range



N (Neutral)



4L — Four-Wheel Drive Low Range

For additional information on the appropriate use

of each transfer case position, see the following:
2H
Two-Wheel Drive High Range — This range is for

normal street and highway driving on dry, hard

surfaced roads.

4H
Four-Wheel Drive High Range — This range

maximizes torque to the front driveshaft, forcing

the front and rear wheels to rotate at the same

speed. This range provides additional traction for

loose, slippery road surfaces only.
N (Neutral)

N (Neutral) — This range disengages both the front

and rear driveshafts from the powertrain. To be

used for flat towing behind another vehicle

page 198.

WARNING!

Do not downshift for additional engine braking

on a slippery surface. The drive wheels could

lose their grip and the vehicle could skid,

causing a collision or personal injury.

WARNING!

Failure to engage a transfer case position

completely can cause transfer case damage or

loss of power and vehicle control. You could have

a collision. Do not drive the vehicle unless the

transfer case is fully engaged.

WARNING!

You or others could be injured or killed if you

leave the vehicle unattended with the transfer

case in the (N) Neutral position without first fully

engaging the parking brake. The transfer case

(N) Neutral position disengages both the front

and rear driveshafts from the powertrain, and

will allow the vehicle to roll, even if the automatic

transmission is in PARK (or manual transmission

is in gear). The parking brake should always be

applied when the driver is not in the vehicle.

158

STARTING AND OPERATING

4L
Four-Wheel Drive Low Range — This range provides

low speed four-wheel drive. It maximizes torque to

the front driveshaft, forcing the front and rear

wheels to rotate at the same speed. This range

provides additional traction and maximum pulling

power for loose, slippery road surfaces only. Do not

exceed 25 mph (40 km/h).
The transfer case is intended to be driven in the 2H

position for normal street and highway conditions,

such as hard-surfaced roads.
In the event that additional traction is required, the

transfer case 4H and 4L positions can be used to

lock the front and rear driveshafts together, forcing

the front and rear wheels to rotate at the same

speed. The 4H and 4L positions are intended for

loose, slippery road surfaces only and not intended

for normal driving. Driving in the 4H and 4L

positions on hard-surfaced roads will cause

increased tire wear and damage to the driveline

components. For further information on shifting

into 4H or 4L

page 158.

The instrument cluster alerts the driver that the

vehicle is in four-wheel drive, and the front and

rear driveshafts are locked together. The light will

illuminate when the transfer case is shifted into

the 4H position.
When operating your vehicle in 4L, the engine

speed will be approximately three times (four times

for Rubicon models) that of the 2H or 4H positions

at a given road speed. Take care not to overspeed

the engine.
Proper operation of four-wheel drive vehicles

depends on tires of equal size, type, and

circumference on each wheel. Any difference will

adversely affect shifting and cause damage to the

transfer case.
Because four-wheel drive provides improved

traction, there is a tendency to exceed safe turning

and stopping speeds. Do not go faster than road

conditions permit.

Shifting Procedures

2H TO 4H OR 4H TO 2H

Shifting between 2H and 4H can be made with the

vehicle stopped or in motion. The preferred shifting

speed would be 0 to 45 mph (72 km/h). With the

vehicle in motion, the transfer case will engage/

disengage faster if you momentarily release the

accelerator pedal after completing the shift. Do not

accelerate while shifting the transfer case. Apply a

constant force when shifting the transfer case lever.

NOTE:



Do not attempt to make a shift while only the

front or rear wheels are spinning. The front and

rear driveshaft speeds must be equal for the

shift to take place. Shifting while only the front

or rear wheels are spinning can cause damage

to the transfer case.



Delayed shifts out of four-wheel drive may be

experienced due to uneven tire wear, low or

uneven tire pressures, excessive vehicle

loading, or cold temperatures.



Shifting effort will increase with speed, this is

normal.

During cold weather, you may experience

increased effort in shifting until the transfer case

fluid warms up. This is normal.

4H TO 4L OR 4L TO 4H

With the vehicle rolling at 1 to 3 mph (2 to 5 km/h),

shift an automatic transmission into NEUTRAL (N),

or press the clutch pedal on a manual transmission.

While the vehicle is coasting at 1 to 3 mph (2 to

5 km/h), shift the transfer case lever firmly to the

desired position. Do not pause with the transfer

case in N (Neutral). Once the shift is completed,

place the automatic transmission into DRIVE or

release the clutch pedal on a manual transmission.

NOTE:

Shifting into or out of 4L is possible with the vehicle

completely stopped; however, difficulty may occur

due to the mating teeth not being properly aligned.

Several attempts may be required for clutch teeth

alignment and shift completion to occur. The

preferred method is with the vehicle rolling at 1 to

3 mph (2 to 5 km/h). Avoid attempting to engage

or disengage 4L with the vehicle moving faster

than 1 to 3 mph (2 to 5 km/h).

STARTING AND OPERATING

159

During cold weather, you may experience

increased effort in shifting until the transfer case

fluid warms up. This is normal.

IVE

-P

OSITION

RANSFER

ASE

—

QUIPPED

Four-Wheel Drive Gear Selector

The transfer case provides five mode positions:



2H — Two-Wheel Drive High Range



4H AUTO — Four-Wheel Drive Auto High Range



4H PART TIME — Four-Wheel Drive Part Time

High Range



N (Neutral)



4L — Four-Wheel Drive Low Range

For additional information on the appropriate use

of each transfer case mode position, see the

following:
2H
Two-Wheel Drive High Range — This range is for

normal street and highway driving on dry, hard

surfaced roads.
4H AUTO
Four-Wheel Drive Auto High Range — This range

sends power to the front wheels. The four-wheel

drive system will be automatically engaged when

the vehicle senses a loss of traction. Additional

traction for varying road conditions.
4H PART TIME
Four-Wheel Drive Part Time High Range — This

range maximizes torque to the front driveshaft,

forcing the front and rear wheels to rotate at the

same speed. This range provides additional

traction for loose, slippery road surfaces only.

N (Neutral)

Neutral — This range disengages both the front and

rear driveshafts from the powertrain. To be used

for flat towing behind another vehicle

page 198.

4L
Four-Wheel Drive Low Range — This range provides

low speed four-wheel drive. It maximizes torque to

the front driveshaft, forcing the front and rear

wheels to rotate at the same speed. This range

provides additional traction and maximum pulling

power for loose, slippery road surfaces only. Do not

exceed 25 mph (40 km/h).
This transfer case is designed to be driven in the

two-wheel drive position (2H) or four-wheel drive

position (4H AUTO) for normal street and highway

WARNING!

Failure to engage a transfer case position

completely can cause transfer case damage or

loss of power and vehicle control. You could have

a collision. Do not drive the vehicle unless the

transfer case is fully engaged.

WARNING!

You or others could be injured or killed if you

leave the vehicle unattended with the transfer

case in the (N) Neutral position without first fully

engaging the parking brake. The transfer case

(N) Neutral position disengages both the front

and rear driveshafts from the powertrain, and

will allow the vehicle to roll, even if the automatic

transmission is in PARK (or manual transmission

is in gear). The parking brake should always be

applied when the driver is not in the vehicle.

160

STARTING AND OPERATING

conditions on dry hard surfaced roads. Driving the

vehicle in 2H will have greater fuel economy

benefits as the front axle is not engaged in 2H.
For variable driving conditions, the 4H AUTO mode

can be used. In this mode, the front axle is

engaged, but the vehicle's power is sent to the rear

wheels. Four-wheel drive will be automatically

engaged when the vehicle senses a loss of

traction. Because the front axle is engaged, this

mode will result in lower fuel economy than the 2H

mode.
In the event that additional traction is required, the

transfer case 4H and 4L positions can be used to

lock the front and rear driveshafts together, forcing

the front and rear wheels to rotate at the same

speed. The 4H and 4L positions are intended for

loose, slippery road surfaces only and not intended

for normal driving. Driving in the 4H and 4L

positions on hard-surfaced roads will cause

increased tire wear and damage to the driveline

components. For further information on shifting

into 4H or 4L

page 160.

The instrument cluster alerts the driver that the

vehicle is in four-wheel drive, and the front and

rear driveshafts are locked together. The light will

illuminate when the transfer case is shifted into

the 4H position.

When operating your vehicle in 4L, the engine

speed will be approximately three times (four times

for Rubicon models) that of the 2H or 4H positions

at a given road speed. Take care not to overspeed

the engine.
Proper operation of four-wheel drive vehicles

depends on tires of equal size, type, and

circumference on each wheel. Any difference will

adversely affect shifting and cause damage to the

transfer case.
Because four-wheel drive provides improved

traction, there is a tendency to exceed safe turning

and stopping speeds. Do not go faster than road

conditions permit.

Shifting Procedures

2H TO 4H AUTO OR 4H AUTO TO 2H

Shifting between 2H and 4H AUTO can be made

with the vehicle stopped or in motion. The

preferred shifting speed would be 0 to 45 mph

(72 km/h). With the vehicle in motion, the transfer

case will engage/disengage faster if you

momentarily release the accelerator pedal after

completing the shift. Do not accelerate while

shifting the transfer case. Apply a constant force

when shifting the transfer case lever.

2H/4H AUTO TO 4H PART TIME OR 4H PART

TIME TO 2H/4H AUTO

Shifting between 2H/4H AUTO to 4H PART TIME

can be made with the vehicle stopped or in motion.

The preferred shifting speed would be 0 to 45 mph

(72 km/h). With the vehicle in motion, the transfer

case will engage/disengage faster if you

momentarily release the accelerator pedal after

completing the shift. Do not accelerate while

shifting the transfer case. Apply a constant force

when shifting the transfer case lever.

NOTE:



Do not attempt to make a shift while only the

front or rear wheels are spinning. The front and

rear driveshaft speeds must be equal for the

shift to take place. Shifting while only the front

or rear wheels are spinning can cause damage

to the transfer case.



Delayed shifts out of four-wheel drive may be

experienced due to uneven tire wear, low or

uneven tire pressures, excessive vehicle

loading, or cold temperatures.



Shifting effort will increase with speed, this is

normal.

During cold weather, you may experience

increased effort in shifting until the transfer case

fluid warms up. This is normal.

STARTING AND OPERATING

161

4H PART TIME/4H AUTO TO 4L OR 4L TO 4H

PART TIME/4H AUTO

With the vehicle rolling at 1 to 3 mph (2 to 5 km/h),

shift an automatic transmission into NEUTRAL (N),

or press the clutch pedal on a manual

transmission. While the vehicle is coasting at 1 to

3 mph (2 to 5 km/h), shift the transfer case lever

firmly to the desired position. Do not pause with

the transfer case in N (Neutral). Once the shift is

completed, place the automatic transmission into

DRIVE or release the clutch pedal on a manual

transmission.

NOTE:

Shifting into or out of 4L is possible with the vehicle

completely stopped; however, difficulty may occur

due to the mating teeth not being properly aligned.

Several attempts may be required for clutch teeth

alignment and shift completion to occur. The

preferred method is with the vehicle rolling at 1 to

3 mph (2 to 5 km/h). Avoid attempting to engage

or disengage 4L with the vehicle moving faster

than 1 to 3 mph (2 to 5 km/h).

RAC

-L

EAR

XLE

— I

QUIPPED

The Trac-Lok rear axle provides a constant driving

force to both rear wheels and reduces wheel spin

caused by the loss of traction at one driving wheel.

If traction differs between the two rear wheels, the

differential automatically proportions the usable

torque by providing more torque to the wheel that

has traction.
Trac-Lok is especially helpful during slippery

driving conditions. With both rear wheels on a

slippery surface, a slight application of the

accelerator will supply maximum traction.

XLE

OCK

-L

) F

RONT

EAR

— I

QUIPPED

The AXLE LOCK switch is located on the instrument

panel (to the right of the steering column).

Axle Lock Switch Panel

This feature will only activate when the following

conditions are met:



Ignition in RUN position, vehicle in 4L.



Vehicle speed should be 10 mph (16 km/h) or

less.



Both right and left wheels on axle are at the

same speed.

To activate the system, push the AXLE LOCK switch

down to lock the rear axle only (the “REAR ONLY”

will illuminate), push the switch up to lock the front

axle and rear axle (the “FRONT + REAR” will

WARNING!

Failure to engage a transfer case position

completely can cause transfer case damage or

loss of power and vehicle control. You could have

a collision. Do not drive the vehicle unless the

transfer case is fully engaged.

WARNING!

On vehicles equipped with a limited-slip

differential, never run the engine with one rear

wheel off the ground. The vehicle may drive

through the rear wheel remaining on the ground

and cause you to lose control of your vehicle.

162

STARTING AND OPERATING

illuminate). When the rear axle is locked, pushing

the bottom of switch again will lock or unlock the

front axle.

NOTE:

The indicator lights will flash until the axles are fully

locked or unlocked.
To unlock the axles, push the AXLE LOCK OFF

button.
Axle Lock will disengage if the vehicle is taken out

of 4L, or the ignition switch is turned to the OFF

position.
The Axle Lock disengages at speeds above 30 mph

(48 km/h), and will automatically re-lock once

vehicle speed is less than 10 mph (16 km/h).

XLE

OCK

-L

) R

EAR

NLY

—

QUIPPED

The rear axle may be locked in 4H if the proper

conditions are met.

The AXLE LOCK switch is located on the instrument

panel (to the right of the steering column).

Axle Lock Switch Panel

This feature will only activate when the following

conditions are met:



Ignition in RUN position, vehicle in 4H.



The vehicle must be in Off Road+ active

page 163.



Vehicle must be in ESC “Full Off” mode

page 278.



Vehicle must not be actively in a high wheel slip

or tight cornering condition.

To activate the system, push the AXLE LOCK switch

down to lock the rear axle only (“REAR ONLY” will

illuminate).

To unlock the rear axle, push the AXLE LOCK OFF

button.
Axle Lock will disengage if the vehicle is taken out

of 4H, Off Road+ is turned off by the driver, ESC

“Full Off” is exited, or the ignition switch is turned

to the OFF position.

NOTE:

The indicator lights will flash until the rear axle is

fully locked or unlocked.
The rear Axle Lock system may temporarily

disengage the rear locker under some conditions.
If this occurs, the rear axle will automatically

re-lock as soon as the system allows.

LECTRONIC

WAY

ISCONNECT

—

QUIPPED

Your vehicle may be equipped with an electronic

disconnecting stabilizer/sway bar. This system

allows greater front suspension travel in off-road

situations.
This system is controlled by the SWAY BAR switch

located on the instrument panel (to the right of the

steering column).

WARNING!

This mode is intended for off-highway or off-road

use only and should not be used on any public

roadways.

STARTING AND OPERATING

163

SWAY BAR Switch

Push the SWAY BAR switch to activate the system.

Push the switch again to deactivate the system.

The Sway Bar Indicator Light (located in the

instrument cluster) will illuminate when the bar is

disconnected. The Sway Bar Indicator Light will

flash during activation transition, or when

activation conditions are not met. The stabilizer/

sway bar should remain in on-road mode during

normal driving conditions.

To disconnect the stabilizer/sway bar, shift to

either 4H or 4L and push the SWAY BAR switch to

obtain the off-road position

page 157. The Sway

Bar Indicator Light will flash until the stabilizer/

sway bar has been fully disconnected.

NOTE:

The stabilizer/sway bar may be torque locked due

to left and right suspension height differences.

This condition is due to driving surface differences

or vehicle loading. In order for the stabilizer/sway

bar to disconnect/reconnect, the right and left

halves of the bar must be aligned. This alignment

may require that the vehicle be driven onto level

ground or rocked from side to side.
To return to on-road mode, push the SWAY BAR

switch again.

OAD

+ — I

QUIPPED

OFF ROAD+ Switch

WARNING!

Ensure the stabilizer/sway bar is reconnected

before driving on hard surfaced roads or at

speeds above 18 mph (29 km/h); a discon

nected stabilizer/sway bar may contribute to the

loss of vehicle control, which could result in seri

ous injury. Under certain circumstances, the

front stabilizer/sway bar enhances vehicle sta

bility and assists with vehicle control. The sys

tem monitors vehicle speed and will attempt to

reconnect the stabilizer/sway bar at speeds over

18 mph (29 km/h). This is indicated by a flash

ing or solid Sway Bar Indicator Light. Once vehi

cle speed is reduced below 14 mph (22 km/h),

the system will once again attempt to return to

off-road mode.

WARNING!

If the stabilizer/sway bar will not return to

on-road mode, the Sway Bar Indicator Light will

flash in the instrument cluster and vehicle stabil

ity may be reduced. Do not attempt to drive the

vehicle over 18 mph (29 km/h). Driving faster

than 18 mph (29 km/h) with a disconnected sta

bilizer/sway bar may contribute to the loss of

vehicle control, which could result in serious

injury.

164

STARTING AND OPERATING

When activated, Off Road+ is designed to improve

the user experience when using specific Off Road

driving modes. To activate Off Road+, push the

OFF ROAD+ switch in the switch bank. The

vehicle’s performance will improve depending on

which Four-Wheel Drive (4WD) mode is activated.

NOTE:

Off Road+ will not function in 2H mode. If the

button is pushed while in 2H mode, the cluster

display will show the message “Off Road+

Unavailable Shift to 4WD”.
When Off Road+ is active, the following features

will activate:



The Off Road+ telltale will illuminate in the

instrument cluster display



A mode-specific message will display the instru

ment cluster display



Off-Road Pages will launch on the radio

head-unit if selected in radio settings



The Off-Road Camera will launch if selected in

radio settings

Once in Off Road+, the vehicle will begin to behave

in different ways depending on the 4WD mode in

use. The following enhancements will occur when

using Off Road+.



Engine/Transmission Calibration: Rock Crawl

and controllability focus, change in shifting

schedule when rock crawling, pedal calibration

shifted to de-gain and low range, operates at

lower vehicle speeds



Traction Control: Aggressive brake lock differen

tial tuning at slower speed or FIRST gear



Off Road+: Recall the last status between igni

tion cycles



Engine/Transmission Calibration: Improved

sand performance/wheel slip focus, change in

shift schedule for sport mode, pedal calibration

set to aggressive, operates at elevated vehicle

speeds



Traction Control: High wheel speed, slip tuning

brake lock differential with no engine manage

ment



Electronic Stability Control: ESC Off with unlim

ited speed



Off Road+: Will default to OFF between ignition

cycles

Cruise Control and Adaptive Cruise Control (ACC)

will not function while using Off Road+. A dedicated

cluster message will display indicating this if either

feature is activated while in Off Road+.

If the ESC OFF button is pushed while in Off Road+,

the following will occur on the vehicle:



Push of the ESC OFF Button: Traction Control

will turn off, but Stability Control will remain

active.



Hold the ESC OFF Button for five seconds: Trac

tion Control and Stability Control will turn off.

ELECTRO-HYDRAULIC POWER STEERING

Your vehicle is equipped with an Electro-Hydraulic

Power Steering system that provides increased

vehicle response and ease of maneuverability. The

system adapts to different driving conditions. If the

Electro-Hydraulic Power Steering system

experiences a fault that prevents it from providing

power steering assist, then the system will provide

mechanical steering capability.

CAUTION!

Extreme steering maneuvers may cause the

electrically driven pump to reduce or stop power

steering assistance in order to prevent damage

to the system. Normal operation will resume

once the system is allowed to cool.

STARTING AND OPERATING

165

If the “SERVICE POWER STEERING” message and

a flashing icon are displayed on the instrument

cluster screen, it indicates that the vehicle needs

to be taken to an authorized dealer for service. It is

likely the vehicle has lost power steering

assistance

page 120.

If the “POWER STEERING HOT” message and an

icon are displayed on the instrument cluster

screen, it indicates that extreme steering

maneuvers may have occurred, which caused an

over temperature condition in the power steering

system. You will lose power steering assistance

momentarily until the over temperature condition

no longer exists. Once driving conditions are safe,

pull over and let vehicle idle for a few moments

until the light turns off

page 120.

NOTE:



Even if power steering assistance is no longer

operational, it is still possible to steer the

vehicle. Under these conditions there will be a

substantial increase in steering effort, espe

cially at very low vehicle speeds and during

parking maneuvers.



If the condition persists, see an authorized

dealer for service.

STOP/START SYSTEM — AUTOMATIC

TRANSMISSION (IF EQUIPPED)

The Engine Stop/Start (ESS) function is developed

to reduce fuel consumption. The system will stop

the engine automatically during a vehicle stop if

the required conditions are met. Releasing the

brake pedal or pressing the accelerator pedal will

automatically restart the engine.
ESS vehicles have been upgraded with a

heavy-duty starter, enhanced battery, and other

upgraded engine parts, to handle the additional

engine starts. Vehicles equipped with eTorque

contain a heavy-duty motor generator and an

additional hybrid electric battery to store energy

from vehicle deceleration for use on engine startup

after a stop as well as providing launch torque

assist.

NOTE:

It is recommended that Stop/Start system be

disabled during off-road use.
Secondary Battery
Your vehicle may be equipped with a secondary

battery used to power the Stop/Start system and

the 12 Volt vehicle electrical system. The

secondary battery is located behind the wheel well

for the front passenger wheel.

Battery Locations

UTOSTOP

ODE

1 — Primary Battery
2 — Secondary Battery

WARNING!



Vehicles with the Stop/Start system will be

equipped with two batteries. Both the main

and the supplemental batteries must be

disconnected to completely de-energize the

12 Volt electrical system.



Serious injury or death could result if you do

not disconnect both batteries. To learn how to

properly disconnect, see an authorized dealer.

166

STARTING AND OPERATING

The Stop/Start feature is enabled after every driver

ignition start. At that time, the system will go into

STOP/START READY and if all other conditions are

met, can go into a STOP/START AUTOSTOP ACTIVE

Autostop mode.
To Activate The Autostop Mode, The Following

Must Occur:



The system must be in STOP/START READY

state. A STOP/START READY message will be

displayed in the instrument cluster display

within the Stop/Start section

page 120.



The vehicle must be completely stopped.



The shifter must be in a forward gear and the

brake pedal pressed.

OSSIBLE

EASONS

NGINE

OES

UTOSTOP

Prior to engine shut down, the system will check

many safety and comfort conditions to see if they

are fulfilled. Detailed information about the

operation of the Stop/Start system may be viewed

in the instrument cluster display Stop/Start

Screen. Situations when the engine will not stop

include (but not limited to):



Driver’s seat belt is not buckled.



Driver’s door is not closed.



Battery temperature is too warm or cold.



Battery charge is low.



The vehicle is on a steep grade.



Cabin heating or cooling is in process and an

acceptable cabin temperature has not been

achieved.



Gear selector is in MANUAL (M) mode.



HVAC is set to full defrost mode at a high blower

speed.



HVAC is set to MAX A/C.



Engine has not reached normal operating

temperature.



Engine or exhaust temperature is too high.



The transmission is not in a forward gear.



Hood is open.



Transfer case is in 4L or N (Neutral).



Brake pedal is not pressed with sufficient pres

sure.



Accelerator pedal input.



Vehicle speed threshold has not been achieved

from previous Autostop.



Steering angle is beyond threshold (ESS Models

Only).



ACC is on and speed is set.



Vehicle is at high altitude.



System fault is present.

It may be possible for the vehicle to be driven

several times without the Stop/Start system going

into a STOP/START READY state under more

extreme conditions of the items listed above.

TART

NGINE

HILE

UTOSTOP

ODE

While in a forward gear, the engine will start when

the brake pedal is released or the throttle pedal is

pressed. The transmission will automatically

re-engage upon engine restart.
Conditions That Will Cause The Engine To Start

Automatically While In Autostop Mode:



The transmission selector is moved out of

DRIVE.



To maintain cabin temperature comfort.



Actual cabin temperature is significantly

different than temperature set on Auto HVAC.



HVAC is set to full defrost mode.



HVAC system temperature or fan speed is

manually adjusted higher.



Battery voltage drops too low.



Stop/Start OFF switch is pushed.



A Stop/Start system error occurs.



Stop/Start Autostop Active time exceeds five

minutes.



Transfer case is in 4L or N (Neutral).



Steering wheel is turned beyond threshold (ESS

Models Only).

STARTING AND OPERATING

167

ANUALLY

URN

TOP

TART

YSTEM

Stop/Start OFF Switch

Push the Stop/Start OFF switch (located on the

switch bank). The light on the switch will illuminate.

The “Stop/Start OFF” message will appear in

instrument cluster display within the Stop/Start

section, and the autostop function will be disabled

page 120.

NOTE:

The Stop/Start system will reset itself back to an

ON condition every time the ignition is turned off

and back on.

ANUALLY

URN

TOP

TART

YSTEM

Push the Stop/Start OFF switch (located on the

switch bank). The light on the switch will turn off.

YSTEM

ALFUNCTION

If there is a malfunction in the Stop/Start system,

the system will not shut down the engine. A

“SERVICE STOP/START SYSTEM” message and a

yellow Stop/Start telltale will appear in the

Instrument Cluster Display

page 120.

If the “SERVICE STOP/START SYSTEM” message

appears in the instrument cluster display, have the

system checked by an authorized dealer.
If a malfunction occurs during an autostop, the

vehicle may not auto start and will need a key start.

STOP/START SYSTEM — MANUAL

TRANSMISSION (IF EQUIPPED)

The Engine Stop/Start (ESS) function is developed

to reduce fuel consumption. The system will stop

the engine automatically during a vehicle stop if

the required conditions are met. Pressing the

clutch pedal will automatically restart the vehicle.
ESS vehicles have been upgraded with a

heavy-duty starter, enhanced battery, and other

upgraded engine parts, to handle the additional

engine starts. Vehicles equipped with eTorque

contain a heavy duty motor generator and an

additional hybrid electric battery to store energy

from vehicle deceleration for use on engine startup

after a stop as well as providing launch torque

assist.

NOTE:

It is recommended that Stop/Start be disabled

during off-road use.
Secondary Battery
Your vehicle may be equipped with a secondary

battery used to power the Stop/Start system and

the 12 Volt vehicle electrical system. The

secondary battery is located behind the wheel well

for the front passenger wheel.

Battery Locations

1 — Primary Battery
2 — Secondary Battery

168

STARTING AND OPERATING

UTOSTOP

ODE

The Stop/Start feature is enabled after every driver

ignition start. It will remain in STOP/START NOT

READY until you drive forward with a vehicle speed

greater than 5 mph (8 km/h). At that time, the

system will go into STOP/START READY and if all

other conditions are met, can go into an STOP/

START AUTO STOP ACTIVE mode.
To Activate The STOP/START AUTOSTOP ACTIVE

Mode, The Following Must Occur:



The system must be in STOP/START READY state.

A STOP/START READY message will be displayed

in the instrument cluster

page 120.



Vehicle speed must be less than 2 mph

(3 km/h).



The gear selector must be in the NEUTRAL posi

tion and the clutch pedal must be fully released.

OSSIBLE

EASONS

NGINE

OES

UTOSTOP

Prior to engine shut down, the system will check

many safety and comfort conditions to see if they

are fulfilled. Situations when the engine will not

stop include (but not limited to):



Driver’s seat belt is not buckled.



Outside temperature is less than 10°F (–12°C)

or greater than 109°F (43°C).



Actual cabin temperature is significantly

different than temperature set on Auto HVAC.



HVAC is set to full defrost mode.



Engine has not reached normal operating

temperature.



Battery is discharged.



When driving in REVERSE.



Hood is open.



Transfer case is in 4L or N (Neutral).



Driver's seat is not occupied or driver’s door is

open.



Vehicle is at high altitude.



The vehicle is on a steep grade.



Forward Gear is engaged.



Steering angle is beyond threshold (ESS Models

Only).



System fault is present.



HVAC is set to MAX A/C.

It may be possible for the vehicle to be driven

several times without the Stop/Start system going

into a STOP/START READY state under more

extreme conditions of the items listed above.

TART

NGINE

HILE

UTOSTOP

ODE

When the gear selector is in NEUTRAL, the engine

will start when the clutch pedal is pressed (does

not require complete/full pedal press). The vehicle

will go into STOP/START SYSTEM NOT READY

mode until the vehicle speed is greater than 5 mph

(8 km/h).
Conditions that will cause the engine to start

automatically while in STOP/START AUTOSTOP

ACTIVE mode
The Engine Will Start Automatically When:



Actual cabin temperature is significantly

different than temperature set on Auto HVAC.



HVAC is set to full defrost mode.



HVAC system temperature or fan speed is

manually adjusted higher.



Stop/Start Autostop Active time exceeds five

minutes.



Battery voltage drops too low.

WARNING!



Vehicles with the Stop/Start system will be

equipped with two batteries. Both the main

and the supplemental batteries must be

disconnected to completely de-energize the

12 Volt electrical system.



Serious injury or death could result if you do

not disconnect both batteries. To learn how to

properly disconnect, see an authorized dealer.

STARTING AND OPERATING

169



Vehicle is moving faster than 5 mph (8 km/h).



STOP/START OFF switch is pressed.



Transfer case is in 4L or N (Neutral).



Steering wheel is turned beyond threshold (ESS

Models Only).

ANUALLY

URN

TOP

TART

YSTEM

1. Push the Stop/Start OFF switch (located on

the switch bank). The light on the switch will

illuminate.

Stop/Start OFF Switch

2. The STOP/START OFF message will appear in

the instrument cluster

page 120.

3. At the next vehicle stop (after turning off the

Stop/Start system), the engine will not be

stopped.

4. If the Stop/Start system is manually turned off,

the engine can only be started and stopped by

cycling the ignition switch.

5. The Stop/Start system will reset itself back to

an ON condition every time the ignition is

turned off and back on.

ANUALLY

URN

TOP

TART

YSTEM

Push the Stop/Start OFF switch (located on the

switch bank). The light on the switch will turn off.

YSTEM

ALFUNCTION

If there is a malfunction in the Stop/Start system,

the system will not shut down the engine. A

“SERVICE STOP/START SYSTEM” message and a

yellow Stop/Start telltale will appear in the

Instrument Cluster Display

page 120.

If the “SERVICE STOP/START SYSTEM” message

appears in the instrument cluster display, have the

system checked by an authorized dealer.
If a malfunction occurs during an autostop, the

vehicle may not auto start and will need a key start.

CRUISE CONTROL SYSTEMS — IF EQUIPPED

Your vehicle may be equipped with the Cruise

Control system, or the Adaptive Cruise Control

(ACC) system:



Cruise Control will keep your vehicle at a

constant preset speed.



Adaptive Cruise Control (ACC) will adjust the

vehicle speed up to the preset speed to main

tain a distance with the vehicle ahead.

NOTE:



In vehicles equipped with ACC, if ACC is not

enabled, Fixed Speed Cruise Control will not

detect vehicles directly ahead of you. Always be

aware of the feature selected.



Only one Cruise Control feature can operate at a

time. For example, if Fixed Speed Cruise Control

is enabled, Adaptive Cruise Control will be

unavailable, and vice versa.

RUISE

ONTROL

When engaged, the Cruise Control takes over

accelerator operations at speeds greater than

20 mph (32 km/h).
The Cruise Control buttons are located on the right

side of the steering wheel.

170

STARTING AND OPERATING

Cruise Control Buttons

To Activate

Push the on/off button to activate the Cruise

Control. The cruise indicator light in the instrument

cluster display will illuminate. To turn the system

off, push the on/off button a second time. The

cruise indicator light will turn off. The system

should be turned off when not in use.

To Set A Desired Speed

Turn the Cruise Control on.

NOTE:

The vehicle should be traveling at a steady speed

and on level ground before pushing the SET (+) or

SET (-) button.
When the vehicle has reached the desired speed,

push the SET (+) or SET (-) button and release.

Release the accelerator and the vehicle will

operate at the selected speed.

To Vary The Speed Setting

To Increase Or Decrease The Set Speed
When the Cruise Control is set, you can increase

speed by pushing the SET (+) button, or decrease

speed by pushing the SET (-) button.
U.S. Speed (mph)



Pushing the SET (+), or SET (-) button once will

result in a 1 mph speed adjustment. Each

subsequent tap of the button results in an

adjustment of 1 mph.



If the button is continually pushed, the set

speed will continue to adjust in 5 mph incre

ments until the button is released, then the new

set speed will be established.

Metric Speed (km/h)



Pushing the SET (+), or SET (-) button once will

result in a 1 km/h speed adjustment. Each

subsequent tap of the button results in an

adjustment of 1 km/h.



If the button is continually pushed, the set

speed will continue to adjust in 10 km/h incre

ments until the button is released, then the new

set speed will be established.

1 — SET (+)/Accel
2 — CANC/Cancel
3 — SET (-)/Decel
4 — On/Off
5 — RES/Resume

WARNING!

Cruise Control can be dangerous where the

system cannot maintain a constant speed. Your

vehicle could go too fast for the conditions, and

you could lose control and have an accident. Do

not use Cruise Control in heavy traffic or on

roads that are winding, icy, snow-covered or

slippery.

WARNING!

Leaving the Cruise Control system on when not

in use is dangerous. You could accidentally set

the system or cause it to go faster than you

want. You could lose control and have an

accident. Always leave the system off when you

are not using it.

Jeep Wrangler (2022 year). Manual in english - page 10
