IN CASE OF EMERGENCY

333

REFUELING IN EMERGENCY

The vehicle is equipped with a refueling funnel for

a Cap-Less Fuel System, which is located with the

jack and tools

page 324. If refueling is

necessary, while using an approved gas can,

please insert the refueling funnel into the filler

neck opening.

NOTE:

In certain cold conditions, ice may prevent the fuel

door from opening. If this occurs, lightly push

around the perimeter of the fuel door to break the

ice buildup and re-release the fuel door by pushing

on the rear outer edge near the center to unlatch.

Do not pry on the door. In the case of a power loss

to the vehicle

page 194.

Refueling Funnel

Emergency Gas Can Refueling
Most gas cans will not open the flapper doors. A

funnel is provided to allow emergency refueling

with a gas can.
See below steps for refueling:
1. Retrieve funnel from the spare tire storage

area.

2. Insert funnel into same filler pipe opening as

the fuel nozzle.

Inserting Funnel

3. Ensure funnel is inserted fully to hold flapper

doors open.

4. Pour fuel into funnel opening.
5. Remove funnel from filler pipe, clean off prior

to putting back in the spare tire storage area.

IF YOUR ENGINE OVERHEATS

If the vehicle is overheating, it will need to be

serviced by an authorized dealer.
In any of the following situations, you can reduce

the potential for overheating by taking the

appropriate action.

CAUTION!

To avoid fuel spillage and overfilling, do not “top

off” the fuel tank after filling.

WARNING!



Never have any smoking materials lit in or

near the vehicle when the fuel door is open or

the tank is being filled.



Never add fuel when the engine is running.

This is in violation of most state and federal

fire regulations and may cause the Malfunc

tion Indicator Light to turn on.



A fire may result if fuel is pumped into a

portable container that is inside of a vehicle.

You could be burned. Always place fuel

containers on the ground while filling.

334

IN CASE OF EMERGENCY



On the highways — slow down.



In city traffic — while stopped, place the trans

mission in NEUTRAL (N).

NOTE:

There are steps that you can take to slow down an

impending overheat condition:



If your Air Conditioner (A/C) is on, turn it off. The

A/C system adds heat to the engine cooling

system and turning the A/C off can help remove

this heat.



You can also turn the temperature control to

maximum heat, the mode control to floor and

the blower control to high. This allows the heater

core to act as a supplement to the radiator and

aids in removing heat from the engine cooling

system.

MANUAL PARK RELEASE

To move the vehicle in cases where the

transmission will not shift out of PARK (P) (such as

a depleted battery), a Manual Park Release is

available.
Follow These Steps To Activate The Manual Park

Release:
1. Apply firm pressure to the brake pedal while

seated in the driver’s seat.

2. Apply the parking brake, if possible.

Manual Park Release Location

WARNING!

You or others can be badly burned by hot engine

coolant (antifreeze) or steam from your radiator.

If you see or hear steam coming from under the

hood, do not open the hood until the radiator

has had time to cool. Never try to open a cooling

system pressure cap when the radiator or

coolant bottle is hot.

CAUTION!

Driving with a hot cooling system could damage

your vehicle. If the temperature gauge reads

HOT (H), as soon as it’s safe, pull over and stop

the vehicle. Idle the vehicle with the air

conditioner turned off until the pointer drops

back into the normal range. If the pointer

remains on HOT (H), and you hear continuous

chimes, turn the engine off immediately and call

for service.

WARNING!

You should be seated in the driver’s seat with

your foot firmly placed on the brake pedal to

maintain control of the vehicle before activating

the Manual Park Release. If possible, you should

apply the parking brake. Activating the Manual

Park Release will allow your vehicle to roll away if

it is not secured or properly connected to a tow

vehicle. Activating the Manual Park Release on

an unsecured vehicle could lead to serious

injury or death for those in or around the vehicle.

IN CASE OF EMERGENCY

335

3. Using a flathead screwdriver or similar tool,

remove the Manual Park Release access

cover, which is to the lower left of the steering

column, below the park brake switch.

Access Cover

4. To unlock handle, insert a flathead screwdriver

or similar tool into the lock release, rotate a

quarter turn counterclockwise and hold

simultaneously pulling on the tether strap.

Lock Release

5. Pull the tether strap out as far as it will go, then

release it. The transmission should now be in

NEUTRAL (N), allowing the vehicle to be

moved.

Tether Strap

6. Release the parking brake only when the

vehicle is securely connected to a tow vehicle.

To Reset The Manual Park Release:
1. Apply firm pressure to the brake pedal while

seated in the driver’s seat.

2. Pull the tether strap out again, then release it.
3. Allow the tether to retract with the lever back

to its original position.

4. Verify that the transmission is in PARK (P).
5. Confirm that the tether has retracted fully and

re-install the access cover. If the access cover

cannot be re-installed, repeat steps 1 through 4.

Tether Reinstalled

336

IN CASE OF EMERGENCY

NOTE:

When the lever is locked in the released position,

the tether will remain outside of the trim panel and

the access cover cannot be reinstalled.

FREEING A STUCK VEHICLE

If your vehicle becomes stuck in mud, sand or

snow, it can often be moved using a rocking

motion. Turn the steering wheel right and left to

clear the area around the front wheels. Push and

hold the lock button on the gear selector. Then,

shift back and forth between DRIVE (D) and

REVERSE (R) while gently pressing the accelerator.

NOTE:

Shifts between DRIVE (D) and REVERSE (R) can

only be achieved at wheel speeds of 5 mph

(8 km/h) or less. Whenever the transmission

remains in NEUTRAL (N) for more than two

seconds, you must press the brake pedal to

engage DRIVE (D) or REVERSE (R).
Use the least amount of accelerator pedal

pressure that will maintain the rocking motion

without spinning the wheels or racing the engine.

NOTE:

Push the ESC OFF button to place the Electronic

Stability Control (ESC) system in “Partial OFF”

mode, before rocking the vehicle

page 265.

Once the vehicle has been freed, push the ESC OFF

button again to restore “ESC On” mode.

WARNING!

Fast spinning tires can be dangerous. Forces

generated by excessive wheel speeds may

cause damage, or even failure, of the axle and

tires. A tire could explode and injure someone.

Do not spin your vehicle's wheels faster than

30 mph (48 km/h) or for longer than 30

seconds continuously without stopping when

you are stuck and do not let anyone near a

spinning wheel, no matter what the speed.

CAUTION!



Racing the engine or spinning the wheels may

lead to transmission overheating and failure.

Allow the engine to idle with the transmission

in NEUTRAL for at least one minute after every

five rocking-motion cycles. This will minimize

overheating and reduce the risk of transmis

sion failure during prolonged efforts to free a

stuck vehicle.



When “rocking” a stuck vehicle by shifting

between DRIVE and REVERSE, do not spin the

wheels faster than 15 mph (24 km/h), or

drivetrain damage may result.



Revving the engine or spinning the wheels too

fast may lead to transmission overheating and

failure. It can also damage the tires. Do not

spin the wheels above 30 mph (48 km/h)

while in gear (no transmission shifting occur

ring).

IN CASE OF EMERGENCY

337

TOWING A DISABLED VEHICLE

This section describes procedures for towing a disabled vehicle using a commercial towing service.
If the transmission and drivetrain are operable, disabled 4x4 vehicles may also be towed as described on

page 208.

Towing Condition

Wheels OFF The Ground

Rear-Wheel Drive Models

All-Wheel Drive Models With

Single-Speed Transfer Case

All-Wheel Drive Models With

Two-Speed Transfer Case

Flat Tow

NONE

If Transmission Is Operable:



Transmission in NEUTRAL



30 mph (48 km/h) max

speed



30 miles (48 km) max

distance

NOT ALLOWED

Detailed Instructions

page 208



Transmission in PARK



Transfer case in NEUTRAL

(N)



Tow in forward direction

Wheel Lift Or Dolly Tow

Front

If Transmission Is Operable:



Transmission in NEUTRAL



30 mph (48 km/h) max

speed



30 miles (48 km) max

distance

NOT ALLOWED

Rear

NOT ALLOWED

Flatbed

ALL

BEST METHOD

338

IN CASE OF EMERGENCY

Proper towing or lifting equipment is required to

prevent damage to your vehicle. Use only tow bars

and other equipment designed for this purpose,

following equipment manufacturer’s instructions.

Use of safety chains is mandatory. Attach a tow bar

or other towing device to main structural members

of the vehicle, not to fascia/bumpers or associated

brackets. State and local laws regarding vehicles

under tow must be observed.

NOTE:

Vehicle’s equipped with air suspension, must have

Tire Jack Mode

page 236 enabled to prevent air

suspension movement during towing.
If you must use the accessories (wipers,

defrosters, etc.) while being towed, the ignition

must be in the ON/RUN mode.
If the vehicle's battery is discharged, instructions

on shifting the automatic transmission out of PARK

(P) in order to move the vehicle

page 334.

EAR

HEEL

RIVE

ODELS

FCA US LLC recommends towing your vehicle with

all four wheels OFF the ground using a flatbed.
If flatbed equipment is not available, and the

transmission is operable, the vehicle may be towed

(with rear wheels on the ground) under the

following conditions:



The transmission must be in NEUTRAL (N). For

instructions on shifting the transmission to

NEUTRAL (N) when the engine is off

page 334.



The towing speed must not exceed 30 mph

(48 km/h).



The towing distance must not exceed 30 miles

(48 km).

CAUTION!



Do not use sling type equipment when towing.

Vehicle damage may occur.



When securing the vehicle to a flat bed truck,

always secure by tire/wheel straps. Do not

attach to front or rear suspension compo

nents, body or frame. Damage to your vehicle

will result from improper towing.

CAUTION!



Towing faster than 30 mph (48 km/h) or

farther than 30 miles (48 km) with rear

wheels on the ground can cause severe trans

mission damage. Damage from improper

towing is not covered under the New Vehicle

Limited Warranty.

IN CASE OF EMERGENCY

339

If the transmission is not operable, or the vehicle

must be towed faster than 30 mph (48 km/h) or

farther than 30 miles (48 km), tow with the rear

wheels OFF the ground. Acceptable methods are to

tow the vehicle on a flatbed, or with the front

wheels raised and the rear wheels on a towing

dolly, or (when using a suitable steering wheel

stabilizer to hold the front wheels in the straight

position) with the rear wheels raised and the front

wheels ON the ground.

HEEL

RIVE

ODELS

FCA US LLC recommends towing with all wheels

OFF the ground. Acceptable methods are to tow

the vehicle on a flatbed or with one end of the

vehicle raised and the opposite end on a towing

dolly.
If flatbed equipment is not available, and the

transfer case is operable, vehicles with a

two-speed transfer case may be towed (in the

forward direction, with ALL wheels on the ground),

IF the transfer case is in NEUTRAL (N) and the

transmission is in PARK

page 208.

Vehicles equipped with a single-speed transfer

case have no NEUTRAL (N) position, and therefore

must be towed will all four wheels OFF the ground.

MERGENCY

OOKS

—

QUIPPED

Your vehicle may be equipped with front and rear

recovery tow hooks. The front tow hooks will be

located in the lower fascia/bumper. The rear tow

hook is removable and is located within the jack

and tools storage bin under the load floor of the

rear cargo area

page 324.

Emergency Front Tow Hooks

NOTE:

For off road recovery, it is recommended to use

both of the front tow hooks to minimize the risk of

damage to the vehicle.

CAUTION!



Front or rear wheel lifts must not be used (if

the remaining wheels are on the ground).

Internal damage to the transmission or

transfer case will occur if a front or rear wheel

lift is used when towing.



Towing this vehicle in violation of the above

requirements can cause severe transmission

and/or transfer case damage. Damage from

improper towing is not covered under the New

Vehicle Limited Warranty.

WARNING!



Do not use a chain for freeing a stuck vehicle.

Chains may break, causing serious injury or

death.



Stand clear of vehicles when pulling with tow

hooks. Tow straps may become disengaged,

causing serious injury.

340

IN CASE OF EMERGENCY

The removable rear tow hook is designed to be

used in the receiver hitch as a recovery option. For

rear tow hook usage, remove the locking pin, place

the rear tow hook into the receiver hitch in any

direction and replace the locking pin.

Removable Rear Tow Hook

ENHANCED ACCIDENT RESPONSE SYSTEM

(EARS)

This vehicle is equipped with an Enhanced

Accident Response System.
This feature is a communication network that

takes effect in the event of an impact. Detailed

information can be found on

page 301.

EVENT DATA RECORDER (EDR)

This vehicle is equipped with an event data

recorder (EDR). The main purpose of an EDR is to

record data that will assist in understanding how a

vehicle’s systems performed under certain crash

or near crash-like situations, such as an air bag

deployment or hitting a road obstacle. Detailed

information can be found on

page 302.

CAUTION!

Tow hooks are for emergency use only, to rescue

a vehicle stranded off road. Do not use tow

hooks for tow truck hookup or highway towing.

You could damage your vehicle.

341

SERVICING AND MAINTENANCE

SCHEDULED SERVICING

Your vehicle is equipped with an automatic oil

change indicator system. The oil change indicator

system will remind you that it is time to take your

vehicle in for scheduled maintenance.
Based on engine operation conditions, the oil

change indicator message will illuminate. This

means that service is required for your vehicle.

Operating conditions such as frequent short-trips,

trailer tow, extremely hot or cold ambient

temperatures, and extended idling will influence

when the “Oil Change Required” message is

displayed. Have your vehicle serviced as soon as

possible, within the next 500 miles (805 km).

An authorized dealer will reset the oil change

indicator message after completing the scheduled

oil change or for engine oil life reset procedure

page 110.

NOTE:

Under no circumstances should oil change

intervals exceed 10,000 miles (16,000 km), or

12 months, whichever comes first. The engine

controller also monitors the number of hours of

engine run time, and will illuminate the oil change

indicator after 350 hours (which is not likely to be

exceeded except for certain fleet customers with

extended engine idling periods).

Once A Month Or Before A Long Trip:



Check engine oil level



Check windshield washer fluid level



Check the tire inflation pressures and look for

unusual wear or damage



Check the fluid levels of the coolant reservoir,

brake master cylinder and fill as needed.



Check function of all interior and exterior lights

342

SERVICING AND MAINTENANCE

AINTENANCE

LAN

Refer to the Maintenance Plans for the required maintenance intervals.

At Every Oil Change Interval As Indicated By Oil Change Indicator System:



Change oil and filter.



Rotate the tires at the first sign of irregular wear, even if it occurs before the oil indicator system turns on.



Inspect battery and clean and tighten terminals as required.



Inspect the CV/Universal joints.



Inspect brake pads, shoes, rotors, drums, hoses and parking brake.



Inspect engine cooling system protection and hoses.



Inspect exhaust system.



Inspect engine air cleaner filter if using in dusty or off-road conditions. Replace engine air cleaner filter, as necessary.

SERVICING AND MAINTENANCE

343

Mileage or time passed

(whichever comes first)

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

Additional Inspections
Inspect the CV/Universal joints.

Inspect front suspension, tie rod ends,

and replace if necessary.

Inspect the front and rear axle fluid,

change if using your vehicle for police,

taxi, fleet, off-road or frequent trailer

towing.

Inspect the brake linings, parking brake

function.

Inspect transfer case fluid.

Additional Maintenance
Replace engine air cleaner filter.

Replace the cabin air filter.

Replace spark plugs (5.7L Engine).

Replace spark plugs (6.4L Engine).

344

SERVICING AND MAINTENANCE

Flush and replace the engine coolant at

10 years or 150,000 miles (240,000 km)

whichever comes first.

Replace accessory drive belt.

Inspect accessory drive belt tensioner

and pulley, replace if necessary.

Change transfer case fluid.

Replace PCV valve.

1. The spark plug change interval is mileage based only, yearly intervals do not apply.

Mileage or time passed

(whichever comes first)

20,000

30,000

40,000

50,000

60,000

70,000

80,000

90,000

100,000

110,000

120,000

130,000

140,000

150,000

Or Years:

Or Kilometers:

32,000

48,000

64,000

80,000

96,000

112,000

128,000

144,000

160,000

176,000

192,000

208,000

224,000

240,000

WARNING!



You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have

any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.



Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This could

cause an accident.

SERVICING AND MAINTENANCE

345

ENGINE COMPARTMENT

5.7L E

NGINE

1 — Engine Air Cleaner Filter

6 — Engine Coolant Reservoir Cap

2 — Engine Oil Fill Cap

7 — Engine Coolant Pressure Cap

3 — Engine Oil Dipstick

8 — Power Distribution Center (Fuses)

4 — Brake Fluid Reservoir Cap

9 — Washer Fluid Reservoir Cap

5 — Battery

346

SERVICING AND MAINTENANCE

6.4L E

NGINE

1 — Engine Coolant Pressure Cap

5 — Battery

2 — Engine Oil Fill Cap

6 — Engine Air Cleaner Filter

3 — Engine Oil Dipstick

7 — Washer Fluid Reservoir Cap

4 — Brake Fluid Reservoir Cap

8 — Power Distribution Center (Fuses)

SERVICING AND MAINTENANCE

347

HECKING

EVEL

To ensure proper engine lubrication, the engine oil

must be maintained at the correct level. Check the

oil level at regular intervals, such as every fuel

stop. The best time to check the engine oil level is

about five minutes after a fully warmed up engine

is shut off.
Checking the oil while the vehicle is on level ground

will improve the accuracy of the oil level readings.
There are four possible dipstick types:



Crosshatched zone.



Crosshatched zone marked SAFE.



Crosshatched zone marked with MIN at the low

end of the range and MAX at the high end of the

range.



Crosshatched zone marked with dimples at the

MIN and the MAX ends of the range.

NOTE:

Always maintain the oil level within the crosshatch

markings on the dipstick.
Adding 1 quart (1 liter) of oil when the reading is at

the low end of the dipstick range will raise the oil

level to the high end of the range marking.

DDING

ASHER

LUID

The instrument cluster display will indicate when

the washer fluid level is low. When the sensor

detects a low fluid level, the windshield will light on

the vehicle graphic outline and the “WASHER

FLUID LOW” message will be displayed.
The fluid reservoir for the windshield washers and

the rear window washer is shared. The fluid

reservoir is located in the engine compartment, be

sure to check the fluid level at regular intervals. Fill

the reservoir with windshield washer solvent only

(not radiator antifreeze). When refilling the washer

fluid reservoir, take some washer fluid and apply it

to a cloth or towel and wipe clean the wiper blades,

this will help blade performance. To prevent

freeze-up of your windshield washer system in cold

weather, select a solution or mixture that meets or

exceeds the temperature range of your climate.

This rating information can be found on most

washer fluid containers.

AINTENANCE

-F

REE

ATTERY

Your vehicle is equipped with a maintenance-free

battery. Water will never have to be added, and

periodic maintenance is not required.

WARNING!

Commercially available windshield washer

solvents are flammable. They could ignite and

burn you. Care must be exercised when filling or

working around the washer solution.

WARNING!



Battery fluid is a corrosive acid solution and

can burn or even blind you. Do not allow

battery fluid to contact your eyes, skin, or

clothing. Do not lean over a battery when

attaching clamps. If acid splashes in eyes or

on skin, flush the area immediately with large

amounts of water. Refer to Jump Starting

Procedure

page 331.



Battery gas is flammable and explosive. Keep

flame or sparks away from the battery. Do not

use a booster battery or any other booster

source with an output greater than 12 Volts.

Do not allow cable clamps to touch each

other.



Battery posts, terminals, and related accesso

ries contain lead and lead compounds. Wash

hands after handling.

348

SERVICING AND MAINTENANCE

RESSURE

ASHING

Cleaning the engine compartment with a high

pressure washer is not recommended.

VEHICLE MAINTENANCE

An authorized dealer has the qualified service

personnel, special tools, and equipment to

perform all service operations in an expert

manner. Service Manuals are available which

include detailed service information for your

vehicle. Refer to these Service Manuals before

attempting any procedure yourself.

NOTE:

Intentional tampering with emissions control

systems may void your warranty and could result in

civil penalties being assessed against you.

NGINE

Engine Oil Selection

Use only the manufacturer's recommended fluids

page 408.

NOTE:

Hemi engines at times can tick right after startup

and then quiet down after approximately 30

seconds. This is normal and will not harm the

engine. This characteristic can be caused by short

drive cycles. For example, if the vehicle is started

then shut off after driving a short distance. Upon

restarting, you may experience a ticking sound.

Other causes could be if the vehicle is unused for

an extended period of time, incorrect oil, extended

oil changes or extended idling. If the engine

continues to tick or if the Malfunction Indicator

Light (MIL) comes on, see the nearest authorized

dealer.

American Petroleum Institute (API)

Approved Engine Oil

These symbols mean that the oil has been certified

by the API. The manufacturer only recommends API

trademark oils.

The API Starburst trademark certifies

0W-20, 0W-30 and 5W-30 engine oils.

The API Donut trademark certifies

0W-40 and 5W-40 engine oil.

CAUTION!



It is essential when replacing the cables on

the battery that the positive cable is attached

to the positive post and the negative cable is

attached to the negative post. Battery posts

are marked positive (+) and negative (-) and

are identified on the battery case. Cable

clamps should be tight on the terminal posts

and free of corrosion.



If a “fast charger” is used while the battery is

in the vehicle, disconnect both vehicle battery

cables before connecting the charger to the

battery. Do not use a “fast charger” to provide

starting voltage.

CAUTION!

Precautions have been taken to safeguard all

parts and connections however, the pressures

generated by these machines is such that

complete protection against water ingress

cannot be guaranteed.

WARNING!

You can be badly injured working on or around a

motor vehicle. Only do service work for which

you have the knowledge and the proper

equipment. If you have any doubt about your

ability to perform a service job, take your vehicle

to a competent mechanic.

Content .. 19 20 21 22 ..
