GETTING TO KNOW YOUR VEHICLE

ROGRAMMING

OME

INK

® T

ARAGE

OOR

PENER

To program any of the HomeLink® buttons to

activate your garage door opener motor, follow the

steps below:

NOTE:

All HomeLink® buttons are programmed using this

procedure. You do not need to erase all channels

when programming additional buttons.
1. Place the ignition switch into the ON/RUN

position.

2. Place the garage door opener transmitter 1 to

3 inches (3 to 8 cm) away from the

HomeLink® button you wish to program, while

keeping the HomeLink® indicator light in view.

3. Push and hold the HomeLink® button you

want to program while you push and hold the

garage door opener transmitter button you are

trying to replicate.

4. Continue to hold both buttons and observe the

HomeLink® indicator light. The HomeLink®

indicator light will flash slowly and then rapidly.

Once this happens, release both buttons.

NOTE:

Make sure the garage door opener motor is

plugged in before moving on to the rolling code/

non-rolling code final steps.

Rolling Code Garage Door Opener Final Steps

NOTE:

You have 30 seconds in which to initiate rolling

code final step 2, after completing rolling code

final step 1.
1. At the garage door opener motor (in the

garage), locate the “LEARN” or “TRAIN”

button. This can usually be found where the

hanging antenna wire is attached to the

garage door opener motor. Firmly push and

release the “LEARN” or “TRAIN” button.

2. Return to the vehicle and push the

programmed HomeLink® button three times

(holding the button for two seconds each

time). If the garage door opener motor

operates, programming is complete.

3. Push the programmed HomeLink® button to

confirm that the garage door opener motor

operates. If the garage door opener motor

does not operate, repeat the final steps for the

rolling code procedure.

Non-Rolling Code Garage Door Opener Final Steps
1. Push and hold the programmed HomeLink®

button and observe the HomeLink® indicator

light. If the HomeLink® indicator light stays

on constantly, programming is complete.

2. Push the programmed HomeLink® button to

confirm that the garage door opener motor

operates. If the garage door opener motor

does not operate, repeat the steps from the

beginning.

ROGRAMMING

OME

INK

® T

ISCELLANEOUS

EVICE

Follow the procedure on programming HomeLink®

to a garage door opener

page 42. Be sure to

determine if the device has a rolling code, or

non-rolling code before beginning the

programming process.

WARNING!



Your motorized door or gate will open and

close while you are programming the universal

transceiver. Do not program the transceiver if

people or pets are in the path of the door or

gate.



Do not run your vehicle in a closed garage or

confined area while programming the trans

ceiver. Exhaust gas from your vehicle contains

Carbon Monoxide (CO) which is odorless and

colorless. Carbon Monoxide is poisonous

when inhaled and can cause you and others to

be severely injured or killed.

GETTING TO KNOW YOUR VEHICLE

NOTE:

Canadian radio frequency laws require transmitter

signals to time-out (or quit) after several seconds

of transmission, which may not be long enough for

HomeLink® to pick up the signal during

programming. Similar to this Canadian law, some

U.S. gate operators are designed to time-out in the

same manner. The procedure may need to be

performed multiple times to successfully pair the

device to your HomeLink® buttons.

EPROGRAMMING

A S

INGLE

OME

INK

® B

UTTON

To reprogram a single HomeLink® button that has

been previously trained, without erasing all the

channels, follow the procedure below. Be sure to

determine whether the new device you want to

program the HomeLink® button to has a rolling

code or non-rolling code.
1. Place the ignition in the ON/RUN position,

without starting the engine.

2. Push and hold the desired HomeLink® button

until the HomeLink® Indicator light begins to

flash after 20 seconds. Do not release the

button.

3. Without releasing the button, proceed with

Step 2 in “Programming HomeLink® To A

Garage Door Opener” and follow all remaining

steps.

ANADIAN

ATE

PERATOR

ROGRAMMING

For programming transmitters in Canada/United

States that require the transmitter signals to

“time-out” after several seconds of transmission.
Canadian Radio Frequency (RF) laws require

transmitter signals to time-out (or quit) after

several seconds of transmission – which may not

be long enough for HomeLink® to pick up the

signal during programming. Similar to this

Canadian law, some US gate operators are

designed to time-out in the same manner.
It may be helpful to unplug the device during the

cycling process to prevent possible overheating of

the garage door or gate motor.
1. Place the ignition in the ON/RUN position.
2. Place the hand-held transmitter 1 to 3 inches

(3 to 8 cm) away from the HomeLink® button

you wish to program while keeping the

HomeLink® indicator light in view.

3. Continue to press and hold the HomeLink®

button, while you press and release (cycle) your

hand-held transmitter every two seconds until

HomeLink® has successfully accepted the

frequency signal. The indicator light will flash

slowly and then rapidly when fully trained.

4. Watch for the HomeLink® indicator to change

flash rates. When it changes, it is

programmed. It may take up to 30 seconds or

longer in rare cases. The garage door may

open and close while you are programming.

5. Press and hold the programmed HomeLink®

button and observe the indicator light.

NOTE:



If the indicator light stays on constantly,

programming is complete and the garage

door/device should activate when the

HomeLink® button is pressed.



To program the two remaining HomeLink®

buttons, repeat each step for each remaining

button. DO NOT erase the channels.

If you unplugged the garage door opener/device

for programming, plug it back in at this time.
Reprogramming A Single HomeLink® Button

(Canadian/Gate Operator)
To reprogram a channel that has been previously

trained, follow these steps:
1. Place the ignition in the ON/RUN position.
2. Press and hold the desired HomeLink® button

until the indicator light begins to flash after

20 seconds. Do not release the button.

3. Without releasing the button, proceed with

“Canadian/Gate Operator Programming” step

2 and follow all remaining steps.

GETTING TO KNOW YOUR VEHICLE

ECURITY

It is advised to erase all channels before you sell or

turn in your vehicle.
To do this, push and hold the two outside buttons

for 20 seconds until the indicator flashes. Note

that all channels will be erased. Individual

channels cannot be erased.
The HomeLink® Universal Transceiver is disabled

when the Vehicle Security system is active.

ROUBLESHOOTING

IPS

If you are having trouble programming

HomeLink®, here are some of the most common

solutions:



Replace the battery in the garage door opener

hand-held transmitter.



Push the LEARN button on the garage door

opener to complete the training for a rolling

code.



Did you unplug the device for programming and

remember to plug it back in?

If you have any problems, or require assistance,

please call toll-free 1-800-355-3515 or, on the

Internet at

HomeLink.com

for information or

assistance.

EXTERIOR LIGHTS

EADLIGHT

WITCH

The headlight switch is located on the left side of

the instrument panel, next to the steering wheel.

The headlight switch controls the operation of the

headlights, parking lights, instrument panel lights,

cargo lights, and fog lights (if equipped).

Headlight Switch

WARNING!



Vehicle exhaust contains carbon monoxide, a

dangerous gas. Do not run your vehicle in the

garage while programming the transceiver.

Exhaust gas can cause serious injury or death.



Your motorized door or gate will open and

close while you are programming the universal

transceiver. Do not program the transceiver if

people, pets or other objects are in the path of

the door or gate. Only use this transceiver with

a garage door opener that has a “stop and

reverse” feature as required by Federal safety

standards. This includes most garage door

opener models manufactured after 1982.

Do not use a garage door opener without

these safety features.

1 — Rotate Headlight Switch
2 — Push Front Fog Light
3 — Instrument Panel Dimmer Control

GETTING TO KNOW YOUR VEHICLE

Headlight Switch (Vehicles Sold In Canada)

NOTE:

Vehicles sold in Canada are equipped with a head

light switch with an AUTO and ON detent but

without an OFF detent. Headlights will be deacti

vated when the headlight switch is placed in the

parking lights position. However, the Daytime

Running Lights (DRLs) will be activated along with

the front and rear marker lights. The DRLs may be

deactivated when the parking brake is engaged.
To turn on the headlights, rotate the headlight

switch clockwise. When the headlight switch is on,

the parking lights, taillights, license plate light and

instrument panel lights are also turned on. To turn

off the headlights, rotate the headlight switch back

to the O (off) position.

NOTE:

For vehicles sold in Canada, rotate the headlight

switch clockwise from the AUTO position to the first

detent to turn on parking lights and instrument

panel lights. Rotate the headlight switch to the

second detent to turn on headlights, parking lights,

and instrument panel lights.

NOTE:



Your vehicle is equipped with plastic headlight

and fog light (if equipped) lenses that are lighter

and less susceptible to stone breakage than

glass lights. Plastic is not as scratch resistant as

glass and therefore different lens cleaning

procedures must be followed.



To minimize the possibility of scratching the

lenses and reducing light output, avoid wiping

with a dry cloth. To remove road dirt, wash with

a mild soap solution followed by rinsing.

ULTIFUNCTION

EVER

The multifunction lever is located on the left side of

the steering column.

Multifunction Lever

AYTIME

UNNING

IGHTS

(DRL

)

The Daytime Running Lights (DRLs) (low intensity)

come on whenever the engine is running, and the

transmission is not in the PARK position. The lights

will remain on until the ignition is placed in the OFF

or ACC position, or the parking brake is engaged.

NOTE:



For vehicles sold in Canada, the Daytime

Running Lights will automatically deactivate

when the front fog lights are turned on.



On some vehicles, the Daytime Running Lights

may deactivate or reduce intensity on one side

of the vehicle (when a turn signal is activated on

that side), or on both sides of the vehicle (when

the hazard warning lights are activated).

1 — Rotate Headlight Switch
2 — Push Front Fog Light
3 — Instrument Panel Dimmer Control

CAUTION!

Do not use abrasive cleaning components,

solvents, steel wool or other abrasive materials

to clean the lenses.

GETTING TO KNOW YOUR VEHICLE



Where allowed by law, the DRLs function may be

disabled through the Uconnect system

page 155.

IGH

EAM

WITCH

Push the multifunction lever toward the instrument

panel to switch the headlights to high beams.

Pulling the multifunction lever back will turn the

low beams on.

UTOMATIC

IGH

EAM

— I

QUIPPED

The Automatic High Beam Headlamp Control

system provides increased forward lighting at night

by automatically controlling the high beams

through the use of a camera mounted on the

inside rearview mirror. This camera detects vehicle

specific light and automatically switches from high

beams to low beams until the approaching vehicle

is out of view.

NOTE:



The Automatic High Beam Headlamp Control

can be turned on or off by selecting “ON” under

“Auto Dim High Beams” within your Uconnect

Settings

page 155, as well as turning the

headlight switch to the AUTO position.



Broken, muddy, or obstructed headlights and

taillights of vehicles in the field of view will

cause headlights to remain on longer (closer to

the vehicle). Also, dirt, film, and other obstruc

tions on the windshield or camera lens will

cause the system to function improperly.



If the windshield or Automatic High Beam Head

lamp Control mirror is replaced, the mirror must

be re-aimed to ensure proper performance. See

a local authorized dealer.



To opt out of the Advanced Auto High-Beam

Sensitivity Control (default) and enter Reduced

High-Beam Sensitivity Control (not recom

mended), toggle the high beam lever six full on/

off cycles within 10 seconds of ignition ON. The

system will return to the default setting upon

ignition off.

LASH

-T

-P

ASS

You can signal another vehicle with your headlights

by lightly pulling the multifunction lever toward you.

This will cause the high beam headlights to turn on,

and remain on, until the lever is released.

UTOMATIC

EADLIGHTS

— I

QUIPPED

This system automatically turns the headlights on

or off according to ambient light levels. To turn the

system on, rotate the headlight switch to the A

(auto) position.
When the system is on, the Headlight Delay feature

is also on. This means the headlights will stay on

for up to 90 seconds after you place the ignition

into the OFF position. To turn the automatic

headlights off, turn the headlight switch out of the

AUTO position.

NOTE:

The engine must be running before the headlights

will turn on in the Automatic Mode.

ARKING

IGHTS

ANEL

IGHTS

To turn on the parking lights and instrument panel

lights, rotate the headlight switch clockwise. To

turn off the parking lights, rotate the headlight

switch back to the O (off) position.

NOTE:

Vehicles sold in Canada are equipped with a head

light switch with an AUTO and ON detent but

without an OFF detent. Headlights will be deacti

vated when the headlight switch is placed in the

parking lights position. However, the Daytime

Running Lights (DRLs) will be activated along with

the front and rear marker lights. The DRLs may be

deactivated when the parking brake is engaged.

UTOMATIC

EADLIGHTS

ITH

IPERS

If your vehicle is equipped with Automatic

Headlights, it also has this

customer-programmable feature. When your

headlights are in the automatic mode and the

engine is running, they will automatically turn on

when the wiper system is on. This feature is

programmable through the Uconnect system

page 155.

GETTING TO KNOW YOUR VEHICLE

If your vehicle is equipped with Rain Sensing

Wipers

page 50, and it is activated, the

headlights will automatically turn on after the

wipers complete five wipe cycles within

approximately one minute. They will turn off

approximately four minutes after the wipers

completely stop.

NOTE:

When your headlights come on during the daytime,

the instrument panel lights will automatically dim

to the lower nighttime intensity.

EADLIGHT

ELAY

To assist when exiting the vehicle, the headlight

delay feature will leave the headlights on for up to

90 seconds. This delay is initiated when the

ignition is placed in the OFF position while the

headlight switch is on, and then the headlight

switch is cycled off. Headlight delay can be

canceled by either turning the headlight switch on

then off, or by placing the ignition in the ON

position.

NOTE:



This feature can be programmed through the

Uconnect system

page 155.



The headlight delay feature is automatically

activated if the headlight switch is left in the

A (auto) position when the ignition is placed in

the OFF position.

IGHTS

-O

EMINDER

If the headlights, parking lights, or cargo lights are

left on after the ignition is placed in the OFF

position, the vehicle will chime when the driver’s

door is opened and a message will appear in the

instrument cluster display.

IGHTS

— I

QUIPPED

The fog lights are turned on by rotating the

headlight switch to the parking lights or headlights

position and pushing in the headlight rotary

control.

Fog Light Operation

Fog Light Operation (Vehicles Sold In Canada)

The fog lights will operate only when the parking

lights are on or when the vehicle headlights are on

low beam. An indicator light located in the

instrument cluster will illuminate when the fog

lights are on. The fog lights will turn off when the

switch is pushed a second time, when the

headlight switch is rotated to the off position, or

the high beam is selected.

URN

IGNALS

Move the multifunction lever up or down to

activate the turn signals. The arrows on each side

of the instrument cluster flash to show proper

operation.

NOTE:

If either light remains on and does not flash, or

there is a very fast flash rate, check for a defective

outside light bulb.

GETTING TO KNOW YOUR VEHICLE

ANE

HANGE

SSIST

— I

QUIPPED

Lightly push the multifunction lever up or down,

without moving beyond the detent, and the turn

signal will flash three times then automatically

turn off.

ATTERY

AVER

Timers are set to both the interior and exterior

lights to protect the life of your vehicle’s battery.
After 10 minutes, if the ignition is in the OFF

position and any door is left open or the dimmer

control is rotated all the way up to the dome light

on position, the interior lights will automatically

turn off.

NOTE:

Battery saver mode is canceled if the ignition is ON.
If the headlights remain on while the ignition is

placed in the OFF position, the exterior lights will

automatically turn off after eight minutes. If the

headlights are turned on and left on for eight

minutes while the ignition is OFF, the exterior lights

will automatically turn off.

INTERIOR LIGHTS

Courtesy and dome lights are turned on when the

front doors are opened or when the dimmer control

is rotated to its upward most position. If your

vehicle is equipped with a key fob and the unlock

button is pushed, the courtesy and dome lights will

turn on. When a door is open and the interior lights

are on, rotating the dimmer control all the way

down, to the O (off) position, will cause all the

interior lights to go out. This allows the doors to

stay open for extended periods of time without

discharging the vehicle’s battery.

NTERIOR

OURTESY

IGHTS

The courtesy lights can be turned on by pushing

the top corner of the lens. To turn the lights off,

push the lens a second time.

Courtesy Lights

Front Map/Reading Lights

The front map/reading lights are mounted in the

overhead console.

Front Map/Reading Lights

Each light can be turned on by pushing a switch on

either side of the console. These buttons are

backlit for night time visibility. To turn the lights off,

push the switch a second time. The lights will also

turn on when the unlock button on the key fob is

pushed.

Front Map/Reading Light Switches

GETTING TO KNOW YOUR VEHICLE

Ambient Light — If Equipped

The overhead console is equipped with an ambient

light feature. This light illuminates for improved

visibility of the floor and center console area.

Ambient Light

Dimmer Control

The brightness of the instrument panel lighting can

be regulated by rotating the dimmer control up

(brighter) or down (dimmer). When the headlights

are on you can supplement the brightness of the

odometer, trip odometer, radio and overhead

console by rotating the control to its upward most

position until you hear a click. This is useful when

headlights are required during the day.

Dimmer Control

Dimmer Control (Vehicles Sold In Canada)

WINDSHIELD WIPERS AND WASHERS

The windshield wiper/washer controls are located

on the windshield wiper/washer lever located on

the left side of the steering column. The front

wipers are operated by rotating a switch, located

on the end of the lever.

Windshield Wiper/Washer Lever

1 — Push End Of Lever And Hold For Front Washer
2 — Rotate Downward For Mist
3 — Rotate For Rear Wiper/Washer Operation
4 — Rotate For Front Wiper Operation

GETTING TO KNOW YOUR VEHICLE

INDSHIELD

IPER

PERATION

Rotate the end of the lever to one of the first four

detent positions for intermittent settings, the fifth

detent for low wiper operation and the sixth detent

for high wiper operation.

Intermittent Wipers
Use one of the four intermittent wiper settings

when weather conditions permit. At driving speeds

above 10 mph (16 km/h), the delay can be

regulated from a maximum of approximately

18 seconds between cycles (first detent), to a cycle

every one second (fourth detent). If the vehicle is

moving less than 10 mph (16 km/h), delay times

will be doubled.
Windshield Washers
To use the washer, push on the end of the lever

(toward the steering wheel) and hold. If the lever is

pushed while in the intermittent setting, the wipers

will turn on and operate for several cycles after the

end of the lever is released, and then resume the

intermittent interval previously selected.
If the end of the lever is pushed while the wipers

are in the off position, the wipers will operate for

several cycles, then turn off.

NOTE:

As a protective measure, the washer will stop if the

switch is held for more than 20 seconds. Once the

switch is released the washer will resume normal

operation.

Mist
Rotate the end of the lever downward to the MIST

position and release for a single wiping cycle.

NOTE:

The Mist feature does not activate the washer

pump; therefore, no washer fluid will be sprayed on

the windshield. The wash function must be used in

order to spray the windshield with washer fluid.
For information on wiper care and replacement,

see

page 269.

AIN

ENSING

IPERS

— I

QUIPPED

This feature senses rain or snowfall on the

windshield and automatically activates the wipers.

Rotate the end of the multifunction lever to one of

four detent positions to activate this feature.
The sensitivity of the system can be adjusted with

the multifunction lever. Wiper delay position one is

the least sensitive, and wiper delay detent position

four is the most sensitive.
Wiper delay position three should be used for

normal rain conditions.

NOTE:



The Rain Sensing feature will not operate when

the wiper switch is in the low or high-speed posi

tion.



The Rain Sensing feature may not function prop

erly when ice, or dried salt water is present on

the windshield.



Use of Rain-X or products containing wax or sili

cone may reduce Rain Sensing performance.



The Rain Sensing feature can be turned on and

off using the Uconnect system

page 155.

CAUTION!

Always remove any buildup of snow that

prevents the windshield wiper blades from

returning to the “park” position. If the windshield

wiper switch is turned off, and the blades cannot

return to the “park” position, damage to the

wiper motor may occur.

WARNING!

Sudden loss of visibility through the windshield

could lead to a collision. You might not see other

vehicles or other obstacles. To avoid sudden

icing of the windshield during freezing weather,

warm the windshield with the defroster before

and during windshield washer use.

GETTING TO KNOW YOUR VEHICLE

The Rain Sensing system has protection features

for the wiper blades and arms, and will not operate

under the following conditions:



Low Ambient Temperature — When the ignition

is first placed in the ON position, the Rain

Sensing system will not operate until the wiper

switch is moved, vehicle speed is greater than

3 mph (5 km/h), or the outside temperature is

greater than 32°F (0°C).



Transmission In NEUTRAL Position — When the

ignition is ON, and the automatic transmission

is in the NEUTRAL position, the Rain Sensing

system will not operate until the wiper switch is

moved, vehicle speed is greater than 3 mph

(5 km/h), or the gear selector is moved out of

the NEUTRAL position.



Remote Start Mode Inhibit — On vehicles

equipped with the Remote Start system, Rain

Sensing wipers are not operational when the

vehicle is in the Remote Start mode.

EAR

INDOW

IPER

ASHER

The rear wiper/washer controls are located on the

multifunction lever on the left side of the steering

column. The rear wiper/washer is operated by

rotating a switch, located at the middle of the lever.

Rotate the center portion of the lever

upward to the first detent for intermittent

operation and to the second detent for

continuous rear wiper operation.
Rotate the center portion of the lever

upward to the third detent to activate the

washer. The washer will continue to

operate as long as the switch is held.

Rotate the center portion downward from the

OFF position to activate the rear washer. The

washer will continue to operate as long as the

switch is held.

NOTE:

As a protective measure, the pump will stop if the

switch is held for more than 20 seconds. Once the

switch is released the pump will resume normal

operation.
If the rear wiper is operating when the ignition is

placed in the OFF position, the wiper will

automatically return to the “park” position.

CLIMATE CONTROLS

The Climate Control system allows you to regulate

the temperature, air flow, and direction of air

circulating throughout the vehicle. The controls are

located on the touchscreen and on the instrument

panel below the radio.

UTOMATIC

LIMATE

ONTROL

ESCRIPTIONS

UNCTIONS

Uconnect 4C/4C NAV With 8.4-inch Display Automatic

Climate Controls

MAX A/C Button

Press and release the MAX A/C button on

the touchscreen to change the current

setting to the coldest output of air.

The MAX A/C indicator illuminates when

MAX A/C is on. Pressing the button again will cause

the MAX A/C operation to exit. Pressing other

settings will cause the MAX A/C to exit.

NOTE:

The MAX A/C button is only available on the touch

screen.
MAX A/C sets the control for maximum cooling

performance.

GETTING TO KNOW YOUR VEHICLE

A/C Button

Press and release this button on the

touchscreen, or push the button on the

faceplate to change the current setting.

The A/C indicator illuminates when

A/C is ON.
The Air Conditioning (A/C) button allows the

operator to manually activate or deactivate the air

conditioning system. When the air conditioning

system is turned on, cool dehumidified air will flow

through the outlets into the cabin.

NOTE:



For Manual Climate Controls, if the system is in

Mix, Floor or Defrost Mode, the A/C can be

turned off, but the A/C system shall remain

active to prevent fogging of the windows.



If fog or mist appears on the windshield or side

glass, select Defrost mode, and increase blower

speed if needed.



If your air conditioning performance seems

lower than expected, check the front of the A/C

condenser (located in front of the radiator), for

an accumulation of dirt or insects. Clean with a

gentle water spray from the front of the radiator

and through the condenser.

Recirculation Button

Press and release this button on the

touchscreen, or push the button on the

faceplate to change the system between

recirculation mode and outside air mode.

The Recirculation indicator and the A/C indicator

illuminate when the Recirculation button is

pressed. Recirculation can be used when outside

conditions such as smoke, odors, dust, or high

humidity are present. Recirculation can be used in

all modes. Recirculation may be unavailable

(button on the touchscreen greyed out) if

conditions exist that could create fogging on the

inside of the windshield. The A/C can be

deselected manually without disturbing the mode

control selection. Continuous use of the

Recirculation mode may make the inside air stuffy

and window fogging may occur. Extended use of

this mode is not recommended. Recirculation

mode may automatically adjust to optimize

customer experience for warming, cooling,

dehumidification, etc.
In cold weather, use of Recirculation mode may

lead to excessive window fogging. The

Recirculation feature may be unavailable if

conditions exist that could create fogging on the

inside of the windshield.

AUTO Button

Set your desired temperature and press

and release this button on the

touchscreen, or push the button on the

faceplate, to change the current setting.

The AUTO indicator illuminates when AUTO is on.

Auto will achieve and maintain your desired

temperature by adjusting distribution and blower

speed. Air Conditioning (A/C) may be active during

AUTO operation to improve performance. Toggling

this function will cause the system to switch

between manual mode and automatic modes

page 54. Auto mode is highly recommended for

efficiency.

Front Defrost Button

Press and release the touchscreen

button, or push and release the button

on the faceplate, to change the current

airflow setting to Defrost mode. The Front

Defrost indicator illuminates when Front Defrost is

on. Air comes from the windshield and side window

demist outlets. When the defrost button is

selected, the blower level may increase. Use

Defrost mode with maximum temperature settings

for best windshield and side window defrosting

and defogging. When toggling the front defrost

mode button, the Climate Control system will

return to the previous setting.

GETTING TO KNOW YOUR VEHICLE

Rear Defrost Button

Press and release the button on the

touchscreen, or push and release the

button on the faceplate, to turn on the

rear window defroster and the heated

outside mirrors (if equipped). The Rear Defrost

indicator illuminates when the rear window

defroster is on. The rear window defroster

automatically turns off after 10 minutes.

Driver And Passenger Up And Down

Buttons

These buttons provide the driver and passenger

with independent temperature control.

Push the Up button on the faceplate or

press and slide the temperature bar

towards the red arrow button on the

touchscreen for warmer temperature

settings.

Push the Down button on the faceplate or

press and slide the temperature bar

towards the blue arrow button on the

touchscreen for cooler temperature

settings.

SYNC Button

Press the SYNC button on the

touchscreen to toggle the Sync feature

on/off. The SYNC indicator is illuminated

when SYNC is on. SYNC is used to

synchronize the passenger temperature setting

with the driver temperature setting. Changing the

passenger temperature setting while in SYNC will

automatically exit this feature.

NOTE:

The SYNC button is only available on the touch

screen.

Blower Control

Blower Control is used to regulate the

amount of air forced through the Climate

Control system. There are seven blower

speeds available. Adjusting the blower

will cause automatic mode to switch to manual

operation. The speeds can be selected using either

the blower control knob on the faceplate or the

buttons on the touchscreen.
Faceplate
The blower speed increases as you turn the blower

control knob clockwise from the lowest blower

setting. The blower speed decreases as you turn

the blower control knob counterclockwise.
Touchscreen
Use the small blower icon to reduce the blower

setting and the large blower icon to increase the

blower setting. Blower can also be selected by

pressing the blower bar area between the icons.

Mode Control

Select Mode by pressing one of the Mode

buttons on the touchscreen to change

the airflow distribution mode. The airflow

distribution mode can be adjusted so air

comes from the instrument panel outlets, floor

outlets, defrost outlets and demist outlets.

CAUTION!

Failure to follow these cautions can cause

damage to the heating elements:



Use care when washing the inside of the rear

window. Do not use abrasive window cleaners

on the interior surface of the window. Use a

soft cloth and a mild washing solution, wiping

parallel to the heating elements. Labels can

be peeled off after soaking with warm water.



Do not use scrapers, sharp instruments, or

abrasive window cleaners on the interior

surface of the window.



Keep all objects a safe distance from the

window.

GETTING TO KNOW YOUR VEHICLE

Panel Mode

Air comes from the outlets in the

instrument panel. Each of these outlets

can be individually adjusted to direct the

flow of air. The air vanes of the center

outlets and outboard outlets can be moved up and

down or side to side to regulate airflow direction.

There is a shut-off wheel located below the air

vanes to shut off or adjust the amount of airflow

from these outlets.

Bi-Level Mode

Air comes from the instrument panel

outlets and floor outlets. A slight amount

of air is directed through the defrost and

side window demister outlets.

NOTE:

Bi-Level mode is designed under comfort condi

tions to provide cooler air out of the panel outlets

and warmer air from the floor outlets.

Floor Mode

Air comes from the floor outlets. A slight

amount of air is directed through the

defrost and side window demister

outlets.

Mix Mode

Air is directed through the floor, defrost,

and side window demister outlets. This

setting works best in cold or snowy

conditions that require extra heat to the

windshield. This setting is good for maintaining

comfort while reducing moisture on the

windshield.

Climate Control OFF Button

Press and release this button on the

touchscreen or push the OFF button on

the faceplate to turn the Climate Control

ON/OFF.

UTOMATIC

EMPERATURE

ONTROL

(ATC)

Automatic Operation

1. Push the AUTO button on the faceplate, or the

AUTO button on the touchscreen on the

Automatic Temperature Control (ATC) Panel.

2. Next, adjust the temperature that you would

like the system to maintain by adjusting the

driver and passenger temperature control

buttons. Once the desired temperature is

displayed, the system will achieve and

automatically maintain that comfort level.

3. When the system is set up for your comfort

level, it is not necessary to change the

settings. You will experience the greatest

efficiency by simply allowing the system to

function automatically.

NOTE:



It is not necessary to move the temperature

settings for cold or hot vehicles. The system

automatically adjusts the temperature, mode,

and blower speed to provide comfort as quickly

as possible.



The temperature can be displayed in US or

Metric units within Uconnect Settings

page 155.

To provide you with maximum comfort in the

Automatic mode during cold start-ups, the blower

fan will remain on low until the engine warms up.

The blower will increase in speed and transition

into Auto mode.

Manual Operation Override

This system offers a full complement of manual

override features. The AUTO symbol in the front

ATC display will be turned off when the system is

being used in the manual mode.

LIMATE

OICE

OMMANDS

Adjust vehicle temperatures hands-free and keep

everyone comfortable while you keep moving

ahead.
Push the VR button. After the beep, say one of the

following commands:



“Set the driver temperature to 70 degrees”



“Set the passenger temperature to 70 degrees”

GETTING TO KNOW YOUR VEHICLE

Did You Know: Voice Command for Climate may

only be used to adjust the interior temperature of

your vehicle. Voice Command will not work to

adjust the heated seats or steering wheel if

equipped.

PERATING

IPS

NOTE:

Refer to the chart at the end of this section for

suggested control settings for various weather

conditions.

Summer Operation

The engine cooling system must be protected with

a high-quality antifreeze coolant to provide proper

corrosion protection and to protect against engine

overheating. OAT coolant (conforming to

MS.90032) is recommended.

Winter Operation

To ensure the best possible heater and defroster

performance, make sure the engine cooling

system is functioning properly and the proper

amount, type, and concentration of coolant is

used. Use of the Air Recirculation mode during

Winter months is not recommended, because it

may cause window fogging.

Vacation/Storage

For information on maintaining the Climate Control

system when the vehicle is being stored for an

extended period of time, see

page 309.

Window Fogging

Vehicle windows tend to fog on the inside in mild,

rainy, and/or humid weather. To clear the

windows, select Defrost or Mix mode and increase

the front blower speed. Do not use the

Recirculation mode without A/C for long periods,

as fogging may occur.

Outside Air Intake

Make sure the air intake, located directly in front of

the windshield, is free of obstructions, such as

leaves. Leaves collected in the air intake may

reduce airflow, and if they enter the air distribution

box, they could plug the water drains. In Winter

months, make sure the air intake is clear of ice,

slush, and snow.

Cabin Air Filter

The climate control system filters out dust and

pollen from the air. Contact an authorized dealer to

service your cabin air filter, and to have it replaced

when needed.

Stop/Start System — If Equipped

While in an Autostop, the Climate Control system

may automatically adjust airflow to maintain cabin

comfort. Customer settings will be maintained

upon return to an engine running condition.

Operating Tips Chart

WEATHER

CONTROL SETTINGS

Hot Weather And

Vehicle Interior Is

Very Hot

Set the mode control to

(Panel Mode),

(MAX A/C) on, and

blower on high. Roll

down the windows for a

minute to flush out the

hot air. Adjust the

controls as needed to

achieve comfort.

Warm Weather

Turn (A/C) on and

set the mode control to

(Panel Mode).

Cool Sunny

Operate in (Bi-Level

Mode).

Cool & Humid

Conditions

Set the mode control to

(Floor Mode) and

turn (A/C) on to

keep windows clear.

Cold Weather

Set the mode control to

(Floor Mode). If

windshield fogging

starts to occur, move

the control to (Mix

Mode).

GETTING TO KNOW YOUR VEHICLE

INTERIOR STORAGE AND EQUIPMENT

TORAGE

Glove Compartment

The glove compartment is located on the

passenger side of the instrument panel.

Glove Compartment

To open the glove compartment, pull the release

handle.

Door Storage

Large storage areas are built into the door panels

for easy access.

Console Features

The center console contains both an upper and a

lower storage area.

Storage Compartment

Storage Compartment Latches

To open the upper storage compartment, pull

upward on the small latch located on the lid.

WARNING!

Do not operate this vehicle with a glove

compartment in the open position. Driving with

the glove compartment open may result in injury

in a collision.

1 — Upper Storage Compartment Latch
2 — Lower Storage Compartment Latch

GETTING TO KNOW YOUR VEHICLE

Lift upward on the larger of the latches to access

the lower storage compartment.

Lower Storage Compartment

Overhead Sunglasses Storage

At the front of the console, a compartment is

provided for storing a pair of sunglasses. The

storage compartment access is a “push/push”

design. Push the pad on the door to open. Push the

chrome pad on the door to close.

Sunglasses Bin Door

IGHTED

UPHOLDERS

— I

QUIPPED

On some vehicles, the front cupholders are

equipped with a light ring that illuminates the

cupholders for the front passengers.

Light Ring In Front Cupholder

USB/AUX C

ONTROL

— I

QUIPPED

Connecting The External USB/AUX Device

Use the connection cable to connect an external

USB device to the vehicle’s USB/AUX connector

port which is located in the center console.
The USB ports on the media hub are equipped with

a Smart Electronic Voltage Regulator (Smart

Charge) feature. This feature allows a device to

charge for up to one hour after the vehicle is

powered off.

Integrated Center Console USB/AUX Media HUB

WARNING!

Do not operate this vehicle with a console

compartment lid in the open position. Driving

with the console compartment lid open may

result in injury in a collision.

1 — USB Port One
2 — AUX Port
3 — USB Port Two

Jeep Grand Cherokee WK (2022 year). Manual in english - page 3
