STARTING AND OPERATING

Gross Trailer Weight (GTW)

The GTW is the weight of the trailer plus the weight

of all cargo, consumables and equipment

(permanent or temporary) loaded in or on the

trailer in its "loaded and ready for operation"

condition.
The recommended way to measure GTW is to put

your fully loaded trailer on a vehicle scale. The

entire weight of the trailer must be supported by

the scale.

Gross Combination Weight Rating (GCWR)

The GCWR is the total allowable weight of your

vehicle and trailer when weighed in combination.

Gross Axle Weight Rating (GAWR)

The GAWR is the maximum capacity of the front

and rear axles. Distribute the load over the front

and rear axles evenly. Make sure that you do not

exceed either front or rear GAWR

page 186.

Tongue Weight (TW)

The TW is the downward force exerted on the hitch

ball by the trailer. You must consider this as part of

the load on your vehicle.

Trailer Frontal Area

The frontal area is the maximum height multiplied

by the maximum width of the front of a trailer.

Trailer Sway Control (TSC)

The TSC can be a mechanical telescoping link that

can be installed between the hitch receiver and the

trailer tongue that typically provides adjustable

friction associated with the telescoping motion to

dampen any unwanted trailer swaying motions

while traveling.
The electronic TSC (if equipped) recognizes a

swaying trailer and automatically applies individual

wheel brakes and/or reduces engine power to

attempt to eliminate the trailer sway.

Weight-Carrying Hitch

A weight-carrying hitch supports the trailer tongue

weight, just as if it were luggage located at a hitch

ball or some other connecting point of the vehicle.

These kinds of hitches are used to tow small and

medium sized trailers.

Weight-Distributing Hitch

A weight-distributing system works by applying

leverage through spring (load) bars. They are

typically used for heavier loads to distribute trailer

tongue weight to the tow vehicle's front axle and

the trailer axle(s). When used in accordance with

the manufacturer's directions, it provides for a

more level ride, offering more consistent steering

and brake control thereby enhancing towing

safety. The addition of a friction/hydraulic sway

control also dampens sway caused by traffic and

crosswinds and contributes positively to tow

vehicle and trailer stability. Trailer Sway Control

(TSC) and a weight-distributing (load equalizing)

hitch are recommended for heavier Tongue

Weights (TW) and may be required depending on

vehicle and trailer configuration/loading to comply

with Gross Axle Weight Rating (GAWR)

requirements.

WARNING!

If the gross trailer weight is 5,000 lb (2,267 kg)

or more, it is recommended to use a

weight-distributing hitch to ensure stable

handling of your vehicle. If you use a standard

weight-carrying hitch, you could lose control of

your vehicle and cause a collision.

WARNING!

It is important that you do not exceed the

maximum front or rear GAWR. A dangerous

driving condition can result if either rating is

exceeded. You could lose control of the vehicle

and have a collision.

STARTING AND OPERATING

189

RECOMMENDED DISTRIBUTION HITCH

ADJUSTMENT

1. Verify that the vehicle is at the normal ride

height.

NOTE:

The vehicle must remain in the engine run position

with all doors closed while attaching a trailer for

proper leveling of the air suspension system.
2. Position the vehicle to be ready to connect to

the trailer (do not connect the trailer).

3. For vehicles equipped with Quadra-Lift air

suspension, use the touchscreen radio

settings to enable Tire/Jack mode. Tire/Jack

mode will be canceled and the procedure must

be restarted if the vehicle is driven at speeds

above 5mph (8 km/h).

4. Measure the height from the top of the front

wheel opening on the fender to ground; this is

height H1.

Measuring Height (H)

5. Attach the trailer to the vehicle without the

weight distribution bars connected.

6. Measure the height from the top of the front

wheel opening on the fender to the ground;

this is height H2.

7. Install and adjust the tension in the weight

distributing bars per the manufacturer’s

recommendations so that the height of the

front fender is approximately (H2-H1)/2+H1

(about 1/2 the difference between H2 and H1

above Normal Ride Height [H1]).

8. Use the touchscreen radio settings and switch

off Tire/Jack mode. Make sure the truck

returns to Normal Ride Height. Perform a

visual inspection of the trailer and

weight-distributing hitch to confirm the

manufacturers’ recommendations have been

met.

9. The vehicle can now be driven.

WARNING!



An improperly adjusted weight-distributing

hitch system may reduce handling, stability,

braking performance, and could result in a

collision.



Weight-distributing systems may not be

compatible with surge brake couplers. Consult

with your hitch and trailer manufacturer or a

reputable Recreational Vehicle dealer for

additional information.

Measurement

Example

Example Height (mm)

925

946

H2-H1

(H2-H1)/2

10.5

(H2-H1)/2 + H1

935.5

190

STARTING AND OPERATING

RAILER

ITCH

LASSIFICATION

The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting

the correct trailer hitch for your intended towing condition.

RAILER

OWING

EIGHTS

AXIMUM

RAILER

EIGHT

ATINGS

)

Trailer Hitch Classification Definitions

Class

Max. Trailer Hitch Industry Standards

Class I - Light Duty

2,000 lb (907 kg)

Class II - Medium Duty

3,500 lb (1,587 kg)

Class III - Heavy Duty

6,000 lb (2,722kg)

Class IV - Extra Heavy Duty

10,000 lb (4,535 kg)

Refer to the “Trailer Towing Weights (Maximum Trailer Weight Ratings)” chart for the Maximum Gross Trailer Weight (GTW) towable for your given drivetrain.
All trailer hitches should be professionally installed on your vehicle.

Engine

Model

GCWR

Frontal Area

Maximum GTW

Maximum Trailer TW (See Note)

2.0L (2nd Row)

AWD

12,125 lb

(5,568 kg)

40 sq ft

(3.72 sq m)

6,000 lb

(2,722 kg)

600 lb (272 kg)

3.6L (2nd Row)

AWD Light Duty

Cooling

8,600 lb

(3,901 kg)

30 sq ft

(2.79 sq m)

3,500 lb

(1,588 kg)

350 lb (159 kg)

3.6L (2nd Row)

AWD

11,300 lb

(5,126 kg)

40 sq ft

(3.72 sq m)

6,200 lb

(2,812 kg)

620 lb (281 kg)

3.6L (2nd Row)

RWD Light Duty

Cooling

8,500 lb

(3,856 kg)

30 sq ft

(2.79 sq m)

3,500 lb

(1,588 kg)

350 lb (159 kg)

STARTING AND OPERATING

191

NOTE:



The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the

Tire and Loading Information placard

page 378. The addition of passengers and cargo may require reducing trailer tongue weight and Gross Trailer Weight

(GTW). Redistributing cargo (to the trailer) may be necessary to avoid exceeding Rear Gross Axle Weight Rating (GAWR) of 3,800 lb (1,769 kg).



Vehicles not factory-equipped with the trailer tow package are limited to 3,500 lb (1,588 kg) GTW and 350 lb (158 kg) TW.

3.6L (2nd Row)

RWD

11,200 lb

(5,080 kg)

40 sq ft

(3.72 sq m)

6,200 lb

(2,812 kg)

620 lb (281 kg)

5.7L (2nd Row)

AWD

12,700 lb

(5,761 kg)

40 sq ft

(3.72 sq m)

7,200 lb

(3,266 kg)

720 lb (327 kg)

3.6L (3rd Row)

RWD Light Duty

Cooling

9,000 lb

(4,082 kg)

30 sq ft

(2.79 sq m)

3,500 lb

(1,588 kg)

350 lb (159 kg)

3.6L (3rd Row)

RWD

11,700 lb

(5,307 kg)

40 sq ft

(3.72 sq m)

6,200 lb

(2,812 kg)

620 lb (281 kg)

3.6L (3rd Row)

AWD Light Duty

Cooling

9,000 lb

(4,082 kg)

30 sq ft

(2.79 sq m)

3,500 lb

(1,588 kg)

350 lb (159 kg)

3.6L (3rd Row)

AWD

11,700 lb

(5,307 kg)

40 sq ft

(3.72 sq m)

6,200 lb

(2,812 kg)

620 lb (281 kg)

5.7L (3rd Row)

AWD

13,100 lb

(5,942 kg)

40 sq ft

(3.72 sq m)

7,200 lb

(3,266 kg)

720 lb (327 kg)

Refer to local laws for maximum trailer towing speeds.

Engine

Model

GCWR

Frontal Area

Maximum GTW

Maximum Trailer TW (See Note)

192

STARTING AND OPERATING

RAILER

ITCH

ECEIVER

OVER

EMOVAL

— I

QUIPPED

Your vehicle may be equipped with a trailer hitch

receiver cover, this must be removed to access the

trailer hitch receiver. This cover is located at the

bottom center of the rear fascia/bumper.
1. Turn the two locking retainers located at the

bottom of the hitch receiver cover a quarter

turn counterclockwise and pull bottom of the

hitch receiver cover outward (towards you).

2. Pull the bottom of the cover outward (towards

you) then downwards to disengage the tabs

located at the top of the hitch receiver cover to

remove.

Hitch Receiver Cover

To reinstall the cover after towing repeat the

procedure in reverse order.

NOTE:

Be sure to engage all tabs of the hitch receiver

cover in the fascia/bumper prior to installation.

RAILER

ONGUE

EIGHT

Never exceed the maximum tongue weight

stamped on your fascia/bumper or trailer hitch.

Weight Distribution

Consider the following items when computing the

weight on the rear axle of the vehicle:



The tongue weight of the trailer.



The weight of any other type of cargo or equip

ment put in or on your vehicle.



The weight of the driver and all passengers.

NOTE:

Remember that everything put into or on the trailer

adds to the load on your vehicle. Also, additional

factory-installed options or dealer-installed options

must be considered as part of the total load on

your vehicle. Refer to the “Tire And Loading Infor

mation” placard for the maximum combined

weight of occupants and cargo for your vehicle.

1 — Hitch Receiver Cover
2 — Locking Retainers

CAUTION!

Always load a trailer with 60% of the weight in

the front of the trailer. This places 10% of the

GTW on the tow hitch of your vehicle. Loads

balanced over the wheels or heavier in the rear

can cause the trailer to sway severely side to

side which will cause loss of control of the

vehicle and trailer. Failure to load trailers heavier

in front is the cause of many trailer collisions.

STARTING AND OPERATING

193

(Continued)

OWING

EQUIREMENTS

To promote proper break-in of the new vehicle

drivetrain components, the following guidelines

are recommended.

Perform the maintenance listed in the Scheduled

Servicing

page 334. When towing a trailer,

never exceed the GAWR or GCWR ratings.

CAUTION!



Do not tow a trailer at all during the first

500 miles (805 km) the new vehicle is driven.

The engine, axle or other parts could be

damaged.



Then, during the first 500 miles (805 km) that

a trailer is towed, do not drive over 50 mph

(80 km/h) and do not make starts at full

throttle. This helps the engine and other parts

of the vehicle wear in at the heavier loads.

WARNING!



Make certain that the load is secured in the

trailer and will not shift during travel. When

trailering cargo that is not fully secured,

dynamic load shifts can occur that may be

difficult for the driver to control. You could lose

control of your vehicle and have a collision.



When hauling cargo or towing a trailer, do not

overload your vehicle or trailer. Overloading

can cause a loss of control, poor performance

or damage to brakes, axle, engine, transmis

sion, steering, suspension, chassis structure

or tires.



Safety chains must always be used between

your vehicle and trailer. Always connect the

chains to the hook retainers of the vehicle

hitch. Cross the chains under the trailer

tongue and allow enough slack for turning

corners.



Vehicles with trailers should not be parked on

a grade. When parking, apply the parking

brake on the tow vehicle. Put the tow vehicle

transmission in PARK (P). For four-wheel drive

vehicles, make sure the transfer case is not in

NEUTRAL (N). Always, block or "chock" the

trailer wheels.



GCWR must not be exceeded.



Total weight must be distributed between the

tow vehicle and the trailer such that the

following four ratings are not exceeded:



GVWR



GTW



GAWR



Tongue weight rating for the trailer hitch

utilized.

WARNING!

194

STARTING AND OPERATING

Towing Requirements — Tires



Do not attempt to tow a trailer while using a

compact spare tire.



Do not drive more than 50 mph (80 km/h) when

towing while using a full size spare tire.



Proper tire inflation pressures are essential to

the safe and satisfactory operation of your

vehicle.



Check the trailer tires for proper tire inflation

pressures before trailer usage.



Check for signs of tire wear or visible tire

damage before towing a trailer.



Replacing tires with a higher load carrying

capacity will not increase the vehicle's GVWR

and GAWR limits.



For further information

page 378.

Towing Requirements — Trailer Brakes



Do not interconnect the hydraulic brake system

or vacuum system of your vehicle with that of

the trailer. This could cause inadequate braking

and possible personal injury.



An electronically actuated trailer brake

controller is required when towing a trailer with

electronically actuated brakes. When towing a

trailer equipped with a hydraulic surge actuated

brake system, an electronic brake controller is

not required.



Trailer brakes are recommended for trailers

over 1,000 lb (453 kg) and required for trailers

in excess of 2,000 lb (907 kg).

Towing Requirements — Trailer Lights And

Wiring

Whenever pulling a trailer, regardless of the trailer

size, stop lights and turn signals on the trailer are

required for motoring safety.
The Trailer Tow Package may include a four- and

seven-pin wiring harness. Use a factory approved

trailer harness and connector.

NOTE:

Do not cut or splice wiring into the vehicle’s wiring

harness.
The electrical connections are all complete to the

vehicle but you must mate the harness to a trailer

connector. Refer to the following illustrations.

WARNING!



Do not connect trailer brakes to your vehicle's

hydraulic brake lines. It can overload your

brake system and cause it to fail. You might

not have brakes when you need them and

could have an accident.



Towing any trailer will increase your stopping

distance. When towing, you should allow for

additional space between your vehicle and the

vehicle in front of you. Failure to do so could

result in an accident.

CAUTION!

If the trailer weighs more than 1,000 lb (453 kg)

loaded, it should have its own brakes and they

should be of adequate capacity. Failure to do

this could lead to accelerated brake lining wear,

higher brake pedal effort, and longer stopping

distances.

STARTING AND OPERATING

195

NOTE:



Disconnect trailer wiring connector from the

vehicle before launching a boat (or any other

device plugged into vehicle’s electrical connect)

into water.



Be sure to reconnect once clear from water

area.

Four-Pin Connector

Seven-Pin Connector

OWING

IPS

Before towing, practice turning, stopping, and

backing up the trailer in an area located away from

heavy traffic.

Automatic Transmission

Select the DRIVE (D) range when towing. The

transmission controls include a drive strategy to

avoid frequent shifting when towing. However, if

frequent shifting does occur while in DRIVE, you

can use the AutoStick shift control to manually

select a lower gear.

NOTE:

Using a lower gear while operating the vehicle

under heavy loading conditions, will improve

performance and extend transmission life by

reducing excessive shifting and heat build-up. This

action will also provide better engine braking.

Cruise Control — If Equipped



Do not use on hilly terrain or with heavy loads.



When using the Cruise Control, if you experience

speed drops greater than 10 mph (16 km/h),

disengage until you can get back to cruising

speed.



Use Cruise Control in flat terrain and with light

loads to maximize fuel efficiency.

1 — Ground
2 — Park
3 — Left Stop/Turn
4 — Right Stop/Turn

1 — Backup Lamps
2 — Running Lamps
3 — Left Stop/Turn
4 — Ground
5 — Battery
6 — Right Stop/Turn
7 — Electric Brakes

196

STARTING AND OPERATING

RECREATIONAL TOWING (BEHIND MOTORHOME)

OWING

HIS

EHICLE

EHIND

NOTHER

EHICLE

NOTE:



When towing your vehicle, always follow applicable state and provincial laws. Contact state and provincial Highway Safety offices for additional details.



Vehicles equipped with Quadra-Lift must be placed in Transport Mode before tying them down (from the body) on a trailer or flatbed truck

page 138. If the

vehicle cannot be placed in Transport mode (for example, engine will not run), tie-downs should be fastened over the tires using specific straps (not to the

body). Failure to follow these instructions may cause fault codes to be set and/or cause loss of proper tie-down tension.

Towing Condition

Wheels OFF The Ground

Two-Wheel Drive Models

Four-Wheel Drive Models

Without 4WD LOW Range

Four-Wheel Drive Models

With 4WD LOW Range

Flat Tow

NONE

NOT ALLOWED

See Instructions



Transmission in PARK



Transfer case in N

(NEUTRAL)



Tow in forward direction

Dolly Tow

Front

NOT ALLOWED

Rear

NOT ALLOWED

On Trailer

ALL

STARTING AND OPERATING

197

(Continued)

ECREATIONAL

OWING

— T

-W

HEEL

RIVE

ODELS

DO NOT flat tow this vehicle. Damage to the

drivetrain will result.
Recreational towing (for two-wheel drive models) is

allowed ONLY if the rear wheels are OFF the

ground. This may be accomplished using a tow

dolly or vehicle trailer. If using a tow dolly, follow

this procedure:
1. Properly secure the dolly to the tow vehicle,

following the dolly manufacturer's

instructions.

NOTE:

If vehicle is equipped with Quadra-Lift air

suspension, ensure the vehicle is set to Normal

Ride Height.
2. Drive the rear wheels onto the tow dolly.
3. Firmly apply the parking brake. Shift the

transmission into PARK.

4. Turn the ignition OFF.
5. Properly secure the rear wheels to the dolly,

following the dolly manufacturer’s

instructions.

6. Install a suitable clamping device, designed for

towing, to secure the front wheels in the

straight position.

ECREATIONAL

OWING

—

UADRA

-T

RAC

I (S

INGLE

-S

PEED

RANSFER

ASE

WITHOUT

4WD LOW

ANGE

) F

OUR

-W

HEEL

RIVE

ODELS

Recreational towing is not allowed. These models

do not have a N (NEUTRAL) position in the transfer

case.

NOTE:

This vehicle may be towed on a flatbed or vehicle

trailer provided all four wheels are OFF the ground.

ECREATIONAL

OWING

—

UADRA

–T

RAC

WITH

4WD LOW

ANGE

The transfer case must be shifted into N

(NEUTRAL) and the transmission must be in PARK

(P) for recreational towing. The N (NEUTRAL)

selection button is adjacent to the air suspension

switch. Shifts into and out of transfer case N

(NEUTRAL) can take place with the selector switch

in any mode position.

CAUTION!

Towing with the rear wheels on the ground will

cause severe transmission damage. Damage

from improper towing is not covered under the

New Vehicle Limited Warranty.

CAUTION!

Towing this vehicle in violation of the above

requirements can cause severe transmission

and/or transfer case damage. Damage from

improper towing is not covered under the New

Vehicle Limited Warranty.

CAUTION!



DO NOT dolly tow any 4WD vehicle. Towing

with only one set of wheels on the ground

(front or rear) will cause severe transmission

and/or transfer case damage. Tow with all

four wheels either ON the ground, or OFF the

ground (using a vehicle trailer).



Tow only in a forward direction. Towing this

vehicle backwards can cause severe damage

to the transfer case.



The transmission must be in PARK for recre

ational towing.

198

STARTING AND OPERATING

Shifting Into Transfer Case N (NEUTRAL)

Use the following procedure to prepare your

vehicle for recreational towing:
1. Bring the vehicle to a complete stop on level

ground, with the engine running.

2. Press and hold the brake pedal.
3. Shift the transmission into NEUTRAL.
4. If vehicle is equipped with Quadra-Lift air

suspension, ensure the vehicle is set to

Normal Ride Height.

NOTE:



Steps 1 through 4 are requirements that

must be met before pushing the N

(NEUTRAL) button, and must continue to be

met until the shift has been completed. If

any of these requirements are not met

before pushing the N (NEUTRAL) button or

are no longer met during the shift, then the

N (NEUTRAL) indicator light will flash contin

uously until all requirements are met or until

the N (NEUTRAL) button is released.



The ignition must be in the ON/RUN position

for a shift to take place and for the position

indicator lights to be operable. If the ignition

is not in the ON/RUN position, the shift will

not take place and no position indicator

lights will be on or flashing.



A flashing N (NEUTRAL) position indicator

light indicates that shift requirements have

not been met.



If the vehicle is equipped with Quadra-Lift

air suspension, the engine should be

started and left running for a minimum of

60 seconds (with all the doors closed) at

least once every 24 hours. This process

allows the air suspension to adjust the

vehicle’s ride height to compensate for

temperature effects.

5. Using a ballpoint pen or similar object, push

and hold the recessed transfer case N

(NEUTRAL) button (located by the selector

switch) for more than four seconds. The light

behind the N symbol will blink, indicating shift

in progress. The light will stop blinking (stay on

solid) when the shift to N (NEUTRAL) is

complete. A “FOUR WHEEL DRIVE SYSTEM IN

NEUTRAL” message will appear in the

instrument cluster.



Before recreational towing, perform the proce

dure outlined under “Shifting into N

(NEUTRAL)” to be certain that the transfer

case is fully in N (NEUTRAL). Otherwise,

internal damage will result.



Towing this vehicle in violation of the above

requirements can cause severe transmission

and/or transfer case damage. Damage from

improper towing is not covered under the New

Vehicle Limited Warranty.



Do not use a bumper-mounted clamp-on tow

bar on your vehicle. The bumper face bar will

be damaged.

WARNING!

You or others could be injured or killed if you

leave the vehicle unattended with the transfer

case in the N (NEUTRAL) position without first

fully engaging the parking brake. The transfer

case N (NEUTRAL) position disengages both the

front and rear driveshafts from the powertrain

and will allow the vehicle to roll, even if the

transmission is in PARK. The parking brake

should always be applied when the driver is not

in the vehicle.

CAUTION!

It is necessary to follow these steps to be certain

that the transfer case is fully in N (NEUTRAL)

before recreational towing to prevent damage to

internal parts.

STARTING AND OPERATING

199

N (NEUTRAL) Button

6. After the shift is completed and the N

(NEUTRAL) light stays on, release the N

(NEUTRAL) button.

7. Shift the transmission into REVERSE or DRIVE.
8. Release the brake pedal for five seconds and

ensure that there is no vehicle movement.

9. Press and hold the brake pedal. Shift the

transmission back into NEUTRAL.

10. Firmly apply the parking brake.
11. With the transmission and transfer case in N

(NEUTRAL), push and hold the ENGINE START/

STOP button until the engine turns off.

12. Place the transmission gear selector in PARK.

Release the brake pedal.

13. Push the ENGINE START/STOP button twice

(without pressing the brake pedal), to turn the

ignition to the off position.

14. Attach the vehicle to the tow vehicle using a

suitable tow bar.

15. Release the parking brake.

Shifting Out Of Transfer Case N (NEUTRAL)

Use the following procedure to prepare your

vehicle for normal use:
1. Bring the vehicle to a complete stop, leaving

it connected to the tow vehicle.

2. Firmly apply the parking brake.
3. Start the engine.

NOTE:



Steps 1 through 5 are requirements that

must be met before pushing the N

(NEUTRAL) button, and must continue to be

met until the shift has been completed. If

any of these requirements are not met

before pushing the N (NEUTRAL) button or

are no longer met during the shift, the N

(NEUTRAL) indicator light will flash continu

ously until all requirements are met or until

the N (NEUTRAL) button is released.



The ignition must be in the ON/RUN position

for a shift to take place and for the position

indicator lights to be operable. If the ignition

is not in the ON/RUN position, the shift will

not take place and no position indicator

lights will be on or flashing.



A flashing N (NEUTRAL) position indicator

light indicates that shift requirements have

not been met.

4. Press and hold the brake pedal.
5. Shift the transmission into NEUTRAL.
6. Using a ballpoint pen or similar object, push

and hold the recessed transfer case N

(NEUTRAL) button (located by the selector

switch) for one second.

N (NEUTRAL) Button

7. When the N (NEUTRAL) indicator light turns off,

release the N (NEUTRAL) button. After the N

(NEUTRAL) button has been released, the

transfer case will always shift to 4WD HI.

8. Shift the transmission into PARK. Turn the

engine off.

9. Release the brake pedal.

200

STARTING AND OPERATING

10. Disconnect vehicle from the tow vehicle.
11. Start the engine.
12. Press and hold the brake pedal.
13. Release the parking brake.
14. Shift the transmission into REVERSE or DRIVE,

release the brake pedal, and check that the

vehicle operates normally.

DRIVING TIPS

-R

OAD

RIVING

IPS

Utility vehicles have higher ground clearance and a

narrower track to make them capable of

performing in a wide variety of off-road

applications. Specific design characteristics give

them a higher center of gravity than conventional

passenger cars.
An advantage of the higher ground clearance is a

better view of the road, allowing you to anticipate

problems. They are not designed for cornering at

the same speeds as conventional passenger cars

any more than low-slung sports cars are designed

to perform satisfactorily in off-road conditions.

Avoid sharp turns or abrupt maneuvers. As with

other vehicles of this type, failure to operate this

vehicle correctly may result in loss of control or

vehicle rollover.

-R

OAD

RIVING

IPS

Quadra-Lift — If Equipped

When off-roading, it is recommended that the

lowest useable vehicle height that will clear the

current obstacle or terrain be selected. The vehicle

height should then be raised as required by the

changes in terrain.
The Selec-Terrain switch will automatically change

the vehicle to the optimized height based on the

Selec-Terrain switch position. The vehicle height

can be changed from the default height for each

Selec-Terrain mode by normal use of the air

suspension switches

page 134.

When To Use 4WD LOW Range —

If Equipped

When off-road driving, shift to 4WD LOW for

additional traction. This range should be limited to

extreme situations such as deep snow, mud, or

sand where additional low speed pulling power is

needed. Vehicle speeds in excess of 25 mph

(40 km/h) should be avoided when in 4WD LOW

range.

Driving Through Water

Although your vehicle is capable of driving through

water, there are a number of precautions that

must be considered before entering the water.

NOTE:

Your vehicle is capable of water fording in up to

24 inches (61 cm) with air suspension or

21 inches (53 cm) without air suspension, of water

while crossing small rivers or streams. To maintain

optimal performance of your vehicle's heating and

ventilation system it is recommended to switch the

system into recirculation mode during water

fording. Be sure to avoid lowering the vehicle in

water, ensure that the easy exit entry setting is

turned off in Uconnect settings.

WARNING!

Do not drive in 4WD LOW range on dry

pavement; driveline damage may result. 4WD

LOW range locks front and rear drivelines

together and does not allow for differential

action between the front to rear driveshafts.

Driving in 4WD LOW on pavement will cause

driveline binding; use only on wet or slippery

surfaces.

STARTING AND OPERATING

201

Driving through water more than a few inches/

centimeters deep will require extra caution to

ensure safety and prevent damage to your vehicle.

If you must drive through water, try to determine

the depth and the bottom condition (and location

of any obstacles) prior to entering. Proceed with

caution and maintain a steady controlled speed

less than 5 mph (8 km/h) in deep water to

minimize wave effects.
Flowing Water
If the water is swift flowing and rising (as in storm

run-off), avoid crossing until the water level

recedes and/or the flow rate is reduced. If you

must cross flowing water avoid depths in excess of

9 inches (23 cm). The flowing water can erode the

streambed, causing your vehicle to sink into

deeper water. Determine exit point(s) that are

downstream of your entry point to allow for drifting.

Standing Water
Avoid driving in standing water deeper than

24 inches (61 cm) with air suspension or

21 inches (53 cm) without air suspension, and

reduce speed appropriately to minimize wave

effects. Maximum speed is 5 mph (8 km/h).
Maintenance
After driving through deep water, inspect your

vehicle fluids and lubricants (engine oil,

transmission oil, axle, transfer case) to ensure the

fluids have not been contaminated. Contaminated

fluid (milky, foamy in appearance) should be

flushed/changed as soon as possible to prevent

component damage.

Driving In Snow, Mud And Sand

In heavy snow, when pulling a load, or for

additional control at slower speeds, shift the

transmission to a low gear and shift the transfer

case to 4WD LOW if necessary

page 134. Only

shift into a lower gear to maintain forward motion.

Over-revving the engine can spin the wheels and

traction will be lost.
Avoid abrupt downshifts on icy or slippery roads,

because engine braking may cause skidding and

loss of control.

Hill Climbing

NOTE:

Before attempting to climb a hill, determine the

conditions at the crest and/or on the other side.
Before climbing a steep hill, shift the transmission

to a lower gear and shift the transfer case to 4WD

LOW. Use FIRST gear and 4WD LOW for very steep

hills.
If you stall or begin to lose forward motion while

climbing a steep hill, allow your vehicle to come to

a stop and immediately apply the brakes. Restart

the engine, and shift into REVERSE (R). Back slowly

down the hill, allowing the compression braking of

the engine to help regulate your speed. If the

brakes are required to control vehicle speed, apply

them lightly and avoid locking or skidding the tires.

CAUTION!

When driving through water, do not exceed

5 mph (8 km/h). Always check water depth

before entering as a precaution, and check all

fluids afterward. Driving through water may

cause damage that may not be covered by the

New Vehicle Limited Warranty.

WARNING!

If the engine stalls, you lose forward motion, or

cannot make it to the top of a steep hill or grade,

never attempt to turn around. To do so may

result in tipping and rolling the vehicle. Always

back carefully straight down a hill in REVERSE

gear. Never back down a hill in NEUTRAL using

only the brake.

202

STARTING AND OPERATING

Remember, never drive diagonally across a hill.

Always drive straight up or down.
If the wheels start to slip as you approach the crest

of a hill, ease off the accelerator and maintain

forward motion by turning the front wheels slowly.

This may provide a fresh “bite” into the surface and

will usually provide traction to complete the climb.

Traction Downhill

When descending mountains or hills, use Hill

Descent Control or Selec-Speed Control to avoid

repeated heavy braking.
If not equipped with Hill Descent Control or

Selec-Speed Control use the following procedure:
Shift the transmission into a low gear, and the

transfer case into 4WD LOW range. Let the vehicle

go slowly down the hill with all four wheels turning

against engine compression drag. This will permit

you to control the vehicle speed and direction.
When descending mountains or hills, repeated

braking can cause brake fade with loss of braking

control. Avoid repeated heavy braking by

downshifting the transmission whenever possible.

After Driving Off-Road

Off-road operation puts more stress on your

vehicle than does most on-road driving. After going

off-road, it is always a good idea to check for

damage. That way you can get any problems taken

care of right away and have your vehicle ready

when you need it.



Completely inspect the underbody of your

vehicle. Check tires, body structure, steering,

suspension, and exhaust system for damage.



Inspect the radiator for mud and debris and

clean as required.



Check threaded fasteners for looseness, partic

ularly on the chassis, drivetrain components,

steering, and suspension. Retighten them, if

required, and torque to the values specified in

the Service Manual.



Check for accumulations of plants or brush.

These things could be a fire hazard. They might

hide damage to fuel lines, brake hoses, axle

pinion seals, and propeller shafts.



After extended operation in mud, sand, water, or

similar dirty conditions, have the radiator, fan,

brake rotors, wheels, brake linings, and axle

yokes inspected and cleaned as soon as

possible.



If you experience unusual vibration after driving

in mud, slush or similar conditions, check the

wheels for impacted material. Impacted mate

rial can cause a wheel imbalance and freeing

the wheels of it will correct the situation.

WARNING!

Abrasive material in any part of the brakes may

cause excessive wear or unpredictable braking.

You might not have full braking power when you

need it to prevent a collision. If you have been

operating your vehicle in dirty conditions, get

your brakes checked and cleaned as necessary.

203

MULTIMEDIA

UCONNECT SYSTEMS

For detailed information about your Uconnect

5/5 NAV With 8.4-inch Display or Uconnect

5/5 NAV With 10.1-inch Display system, refer to

your Uconnect Owner’s Manual Supplement.

NOTE:

Uconnect screen images are for illustration

purposes only and may not reflect exact software

for your vehicle.

CYBERSECURITY

Your vehicle may be a connected vehicle and may

be equipped with both wired and wireless

networks. These networks allow your vehicle to

send and receive information. This information

allows systems and features in your vehicle to

function properly.

Your vehicle may be equipped with certain security

features to reduce the risk of unauthorized and

unlawful access to vehicle systems and wireless

communications. Vehicle software technology

continues to evolve over time and FCA US LLC,

working with its suppliers, evaluates and takes

appropriate steps as needed.
The risk of unauthorized and unlawful access to

your vehicle systems may still exist, even if the

most recent version of vehicle software (such as

Uconnect software) is installed.

NOTE:



To help further improve user experience,

features, stability, etc., and minimize the poten

tial risk of a security breach, vehicle owners

should:



Routinely check

www.driveuconnect.com

(US Residents) or

www.driveuconnect.ca

(Canadian Residents) to learn about avail

able Uconnect software updates.



Only connect and use trusted media

devices (e.g. personal mobile phones,

USBs, CDs).

WARNING!



ONLY insert trusted devices/components into

your vehicle. Media of unknown origin could

possibly contain malicious software, and if

installed in your vehicle, it may increase the

possibility for vehicle systems to be breached.



As always, if you experience unusual vehicle

behavior, take your vehicle to your nearest

authorized dealer immediately.

Jeep Grand Cherokee (2022 year). Manual in english - page 12
