STARTING AND OPERATING

171

NOTE:

Shifting into or out of 4L is possible with the vehicle

completely stopped; however, difficulty may occur

due to the mating teeth not being properly aligned.

Several attempts may be required for clutch teeth

alignment and shift completion to occur. The

preferred method is with the vehicle rolling at

1 to 3 mph (2 to 5 km/h). Avoid attempting to

engage or disengage 4L with the vehicle moving

faster than 1 to 3 mph (2 to 5 km/h).
During cold weather, you may experience

increased effort in shifting until the transfer case

fluid warms up. This is normal.

IVE

-P

OSITION

RANSFER

ASE

— I

QUIPPED

Four-Wheel Drive Gear Selector

The transfer case provides five positions:



2H (Two-Wheel Drive High Range)



4H AUTO (Four-Wheel Drive Auto High Range)



4H PART TIME (Four-Wheel Drive Part Time High

Range)



N (Neutral)



4L (Four-Wheel Drive Low Range)

For additional information on the appropriate use

of each transfer case position, see the information

below:

2H
Two-Wheel Drive High Range — This range is for

normal street and highway driving on dry, hard

surfaced roads.
4H AUTO
Four-Wheel Drive Auto High Range — This range

sends power to the front wheels. The four-wheel

drive system will be automatically engaged when

the vehicle senses a loss of traction. This range

provides additional traction for varying road

conditions.
4H PART TIME
Four-Wheel Drive Part Time High Range — This

range maximizes torque to the front driveshaft,

forcing the front and rear wheels to rotate at the

same speed. This range provides additional

traction for loose, slippery road surfaces only.

WARNING!

Failure to engage a transfer case position

completely can cause transfer case damage or

loss of power and vehicle control. You could have

a collision. Do not drive the vehicle unless the

transfer case is fully engaged.

172

STARTING AND OPERATING

N (Neutral)

Neutral — This range disengages both the front and

rear driveshafts from the powertrain. To be used

for flat towing behind another vehicle

page 217.

4L
Four-Wheel Drive Low Range — This range provides

low speed four-wheel drive. It maximizes torque to

the front driveshaft, forcing the front and rear

wheels to rotate at the same speed. This range

provides additional traction and maximum pulling

power for loose, slippery road surfaces only. Do not

exceed 25 mph (40 km/h).

This transfer case is designed to be driven in the

two-wheel drive position (2H) or four-wheel drive

position (4H AUTO) for normal street and highway

conditions on dry hard surfaced roads. Driving the

vehicle in 2H will have greater fuel economy

benefits as the front axle is not engaged in 2H.
For variable driving conditions, the 4H AUTO mode

can be used. In this mode, the front axle is

engaged, but the vehicle's power is sent to the rear

wheels. Four-wheel drive will be automatically

engaged when the vehicle senses a loss of

traction. Because the front axle is engaged, this

mode will result in lower fuel economy than the 2H

mode.
In the event that additional traction is required, the

transfer case 4H and 4L positions can be used to

lock the front and rear driveshafts together, forcing

the front and rear wheels to rotate at the same

speed. The 4H and 4L positions are intended for

loose, slippery road surfaces only and not intended

for normal driving. Driving in the 4H and 4L

positions on hard-surfaced roads will cause

increased tire wear and damage to the driveline

components. For further information on shifting

into 4H or 4L

page 172.

The instrument cluster alerts the driver that the

vehicle is in four-wheel drive, and the front and

rear driveshafts are locked together. The light will

illuminate when the transfer case is shifted into

the 4H position.

When operating your vehicle in 4L, the engine

speed will be approximately three times (four times

for Rubicon models) that of the 2H or 4H positions

at a given road speed. Take care not to overspeed

the engine.
Proper operation of four-wheel drive vehicles

depends on tires of equal size, type, and

circumference on each wheel. Any difference will

adversely affect shifting and cause damage to the

transfer case.
Because four-wheel drive provides improved

traction, there is a tendency to exceed safe turning

and stopping speeds. Do not go faster than road

conditions permit.

Shifting Procedures

2H TO 4H AUTO OR 4H AUTO TO 2H

Shifting between 2H and 4H AUTO can be made

with the vehicle stopped or in motion. The

preferred shifting speed would be 0 to 45 mph

(72 km/h). With the vehicle in motion, the transfer

case will engage/disengage faster if you

momentarily release the accelerator pedal after

completing the shift. Do not accelerate while

shifting the transfer case. Apply a constant force

when shifting the transfer case lever.

WARNING!

You or others could be injured or killed if you

leave the vehicle unattended with the transfer

case in the N (Neutral) position without first fully

engaging the parking brake. The transfer case N

(Neutral) position disengages both the front and

rear driveshafts from the powertrain, and will

allow the vehicle to roll, even if the automatic

transmission is in PARK (or manual transmission

is in gear). The parking brake should always be

applied when the driver is not in the vehicle.

STARTING AND OPERATING

173

2H/4H AUTO TO 4H PART TIME OR 4H PART

TIME TO 2H/4H AUTO

Shifting between 2H/4H AUTO to 4H PART TIME

can be made with the vehicle stopped or in motion.

The preferred shifting speed would be 0 to 45 mph

(72 km/h). With the vehicle in motion, the transfer

case will engage/disengage faster if you

momentarily release the accelerator pedal after

completing the shift. Do not accelerate while

shifting the transfer case. Apply a constant force

when shifting the transfer case lever.

NOTE:



Do not attempt to make a shift while only the

front or rear wheels are spinning. The front and

rear driveshaft speeds must be equal for the

shift to take place. Shifting while only the front

or rear wheels are spinning can cause damage

to the transfer case.



Delayed shifts out of four-wheel drive may be

experienced due to uneven tire wear, low or

uneven tire pressures, excessive vehicle

loading, or cold temperatures.



Shifting effort will increase with speed, this is

normal.

During cold weather, you may experience

increased effort in shifting until the transfer case

fluid warms up. This is normal.

4H PART TIME/4H AUTO TO 4L OR 4L TO 4H

PART TIME/4H AUTO

With the vehicle rolling at 1 to 3 mph (2 to 5 km/h),

shift an automatic transmission into NEUTRAL (N),

or press the clutch pedal on a manual

transmission. While the vehicle is coasting at 1 to

3 mph (2 to 5 km/h), shift the transfer case lever

firmly to the desired position. Do not pause with

the transfer case in N (Neutral). Once the shift is

completed, place the automatic transmission into

DRIVE or release the clutch pedal on a manual

transmission.

NOTE:

Shifting into or out of 4L is possible with the vehicle

completely stopped; however, difficulty may occur

due to the mating teeth not being properly aligned.

Several attempts may be required for clutch teeth

alignment and shift completion to occur. The

preferred method is with the vehicle rolling at 1 to

3 mph (2 to 5 km/h). Avoid attempting to engage

or disengage 4L with the vehicle moving faster

than 1 to 3 mph (2 to 5 km/h).
During cold weather, you may experience

increased effort in shifting until the transfer case

fluid warms up. This is normal.

RAC

-L

EAR

XLE

— I

QUIPPED

The Trac-Lok rear axle provides a constant driving

force to both rear wheels and reduces wheel spin

caused by the loss of traction at one driving wheel.

If traction differs between the two rear wheels, the

differential automatically proportions the usable

torque by providing more torque to the wheel that

has traction.
Trac-Lok is especially helpful during slippery

driving conditions. With both rear wheels on a

slippery surface, a slight application of the

accelerator will supply maximum traction.

WARNING!

Failure to engage a transfer case position

completely can cause transfer case damage or

loss of power and vehicle control. You could have

a collision. Do not drive the vehicle unless the

transfer case is fully engaged.

WARNING!

On vehicles equipped with a limited-slip

differential, never run the engine with one rear

wheel off the ground. The vehicle may drive

through the rear wheel remaining on the ground

and cause you to lose control of your vehicle.

174

STARTING AND OPERATING

XLE

OCK

-L

) F

RONT

EAR

— I

QUIPPED

The AXLE LOCK switch is located on the instrument

panel (to the right of the steering column).

Axle Lock Switch Panel

This feature will only activate when the following

conditions are met:



Ignition in ON/RUN position, vehicle in 4L

(Four-Wheel Drive Low Range).



Vehicle speed should be 10 mph (16 km/h) or

less.



Both right and left wheels on axle are at the

same speed.

To activate the system, push the AXLE LOCK switch

down to lock the rear axle only (the “REAR ONLY”

will illuminate), push the switch up to lock the front

axle and rear axle (the “FRONT + REAR” will

illuminate). When the rear axle is locked, pushing

the bottom of switch again will lock or unlock the

front axle.

NOTE:

The indicator lights will flash until the axles are fully

locked or unlocked.
To unlock the axles, push the AXLE LOCK OFF

button.
Axle Lock will disengage if the vehicle is taken out

of 4L (Four-Wheel Drive Low Range), or the ignition

switch is turned to the OFF position.
The Axle Lock disengages at speeds above 30 mph

(48 km/h), and will automatically re-lock once

vehicle speed is less than 10 mph (16 km/h).

XLE

OCK

-L

) R

EAR

NLY

—

QUIPPED

The rear axle may be locked in 4H if the proper

conditions are met.

The AXLE LOCK switch is located on the instrument

panel (to the right of the steering column).

Axle Lock Switch Panel

This feature will only activate when the following

conditions are met:



Ignition in RUN position, vehicle in 4H

(Four-Wheel Drive High Range).



The vehicle must be in OFF ROAD+ active

page 176.



Vehicle must be in ESC “Full Off” mode

page 308.



Vehicle must not be actively in a high wheel slip

or tight cornering condition.

To activate the system, push the AXLE LOCK switch

down to lock the rear axle only (“REAR ONLY” will

illuminate).

WARNING!

This mode is intended for off-highway or off-road

use only and should not be used on any public

roadways.

STARTING AND OPERATING

175

To unlock the rear axle, push the AXLE LOCK OFF

button.
Axle Lock will disengage if the vehicle is taken out

of 4H (Four-Wheel Drive High Range), OFF ROAD+

is turned off by the driver, ESC “Full Off” is exited,

or the ignition switch is turned to the OFF position.

NOTE:

The indicator lights will flash until the rear axle is

fully locked or unlocked.
The rear Axle Lock system may temporarily

disengage the rear locker under some conditions.
If this occurs, the rear axle will automatically

re-lock as soon as the system allows.
If an Axle Lock request cannot be completed by the

system within 5 seconds due to vehicle operating

conditions not being correct, the request will be

canceled and the driver may need to re-request the

locker to be activated.

LECTRONIC

WAY

ISCONNECT

— I

QUIPPED

Your vehicle may be equipped with an electronic

disconnecting stabilizer/sway bar. This system

allows greater front suspension travel in off-road

situations.

This system is controlled by the SWAY BAR switch

located on the instrument panel (to the right of the

steering column).

SWAY BAR Switch

Push the SWAY BAR switch to disconnect or

connect the sway bar. The Sway Bar Indicator Light

(located in the instrument cluster) will illuminate

when the bar is disconnected. The Sway Bar

Indicator Light will flash during activation

transition, or when activation conditions are not

met. The stabilizer/sway bar should remain in

on-road mode during normal driving conditions.

To disconnect the stabilizer/sway bar, shift to

either 4H or 4L and push the SWAY BAR switch to

obtain the off-road position

page 169. The Sway

Bar Indicator Light will flash until the stabilizer/

sway bar has been fully disconnected.

WARNING!

Ensure the stabilizer/sway bar is reconnected

before driving on hard surfaced roads or at

speeds above 18 mph (29 km/h); a

disconnected stabilizer/sway bar may contribute

to the loss of vehicle control, which could result

in serious injury. Under certain circumstances,

the front stabilizer/sway bar enhances vehicle

stability and assists with vehicle control. The

system monitors vehicle speed and will attempt

to reconnect the stabilizer/sway bar at speeds

over 18 mph (29 km/h). This is indicated by a

flashing or solid Sway Bar Indicator Light. Once

vehicle speed is reduced below 14 mph

(22 km/h), the system will once again attempt to

return to off-road mode.

176

STARTING AND OPERATING

NOTE:

The stabilizer/sway bar may be torque locked due

to left and right suspension height differences.

This condition is due to driving surface differences

or vehicle loading. In order for the stabilizer/sway

bar to disconnect/reconnect, the right and left

halves of the bar must be aligned. This alignment

may require that the vehicle be driven onto level

ground or rocked from side to side.
To return to on-road mode, push the SWAY BAR

switch again.

OFF ROAD+ — I

QUIPPED

OFF ROAD+ Switch

When activated, OFF ROAD+ is designed to

improve the user experience when using specific

Off Road driving modes. To activate Off Road+,

push the OFF ROAD+ switch in the switch bank.

The vehicle’s performance will improve depending

on which Four-Wheel Drive (4WD) mode is

activated.

NOTE:

OFF ROAD+ will not function in Two-Wheel Drive

High (2H) mode. If the button is pushed while in 2H

mode, the cluster display will show the message

“OFF ROAD+ Unavailable Shift to 4WD”.

When OFF ROAD+ is active, the following features

will activate:



The OFF ROAD+ telltale will illuminate in the

Instrument Cluster Display



A mode specific message will display the Instru

ment Cluster Display



Off Road pages will launch on the radio

head-unit (if equipped)



The Off Road Camera will launch (if equipped)

Once in OFF ROAD+, the vehicle will begin to

behave in different ways depending on the 4WD

mode in use. The following enhancements will

occur when using OFF ROAD+.
4L



Engine/Transmission Calibration: Rock Crawl

and controllability focus, change in shifting

schedule when rock crawling, pedal calibration

shifted to de-gain and low range, operates at

lower vehicle speeds



Traction Control: Aggressive brake lock differen

tial tuning at slower speed or FIRST gear



OFF ROAD+: Recall the last status between igni

tion cycles

WARNING!

If the stabilizer/sway bar will not return to

on-road mode, the Sway Bar Indicator Light will

flash in the instrument cluster and vehicle

stability may be reduced. Do not attempt to drive

the vehicle over 18 mph (29 km/h). Driving

faster than 18 mph (29 km/h) with a

disconnected stabilizer/sway bar may contribute

to the loss of vehicle control, which could result

in serious injury.

STARTING AND OPERATING

177



Engine/Transmission Calibration: Improved

sand performance/wheel slip focus, change in

shift schedule for sport mode, pedal calibration

set to aggressive, operates at elevated vehicle

speeds



Traction Control: High wheel speed, slip tuning

brake lock differential with no engine manage

ment



Electronic Stability Control: ESC Off with unlim

ited speed



OFF ROAD+: Will default to OFF between ignition

cycles

Cruise Control and Adaptive Cruise Control (ACC)

will not function while using OFF ROAD+. A

dedicated cluster message will display indicating

this if either feature is activated while in OFF

ROAD+.
If the ESC OFF button is pushed while in OFF

ROAD+, the following will occur on the vehicle:



Push of the ESC OFF Button: Traction Control

will turn off, but Stability Control will remain

active.



Hold the ESC OFF Button for five seconds:

Traction Control and Stability Control will

turn off.

ELECTRO-HYDRAULIC POWER STEERING

Your vehicle is equipped with an Electro-Hydraulic

Power Steering system that will provide increased

vehicle response and ease of maneuverability. If

the Electro-Hydraulic Power Steering system

experiences a fault that prevents it from providing

power steering assist, then the system will provide

mechanical steering capability.

If the “SERVICE POWER STEERING”

message and a flashing icon are

displayed on the instrument cluster

screen, it indicates that the vehicle

needs to be taken to an authorized dealer for

service. It is likely the vehicle has lost power

steering assistance

page 128.

If the “POWER STEERING HOT” message and an

icon are displayed on the instrument cluster

screen, it indicates that extreme steering

maneuvers may have occurred, which caused an

over temperature condition in the power steering

system. You will lose power steering assistance

momentarily until the over temperature condition

no longer exists. Once driving conditions are safe,

pull over and let vehicle idle for a few moments

until the light turns off

page 128.

NOTE:



Even if power steering assistance is no longer

operational, it is still possible to steer the

vehicle. Under these conditions there will be a

substantial increase in steering effort, espe

cially at very low vehicle speeds and during

parking maneuvers.



If the condition persists, see an authorized

dealer for service.

CAUTION!

Extreme steering maneuvers may cause the

electrically driven pump to reduce or stop power

steering assistance in order to prevent damage

to the system. Normal operation will resume

once the system is allowed to cool.

178

STARTING AND OPERATING

STOP/START SYSTEM — AUTOMATIC

TRANSMISSION (IF EQUIPPED)

The Engine Stop/Start (ESS) function is developed

to reduce fuel consumption. The system will stop

the engine automatically during a vehicle stop if

the required conditions are met. Releasing the

brake pedal or pressing the accelerator pedal will

automatically restart the engine.
ESS vehicles have been upgraded with a

heavy-duty starter, enhanced battery, and other

upgraded engine parts, to handle the additional

engine starts.

NOTE:

It is recommended that the Stop/Start system be

disabled during off-road use.
Secondary Battery
Your vehicle may be equipped with a secondary

battery used to power the Stop/Start system and

the 12 Volt vehicle electrical system. The

secondary battery is located behind the wheel well

for the front passenger wheel.

Battery Locations

UTOSTOP

ODE

The Stop/Start feature is enabled after every

normal customer engine start. At that time, the

system will go into STOP/START READY.
To Activate The Autostop Mode, The Following

Must Occur:



The system must be in STOP/START READY

state. A STOP/START READY message will be

displayed in the instrument cluster display

within the Stop/Start section

page 128.



The vehicle must be completely stopped.



The gear selector must be in a forward gear and

the brake pedal pressed.

The engine will shut down, the tachometer will

move to the zero position and the Stop/Start

telltale will illuminate indicating you are in

Autostop. Customer settings will be maintained

upon return to an engine-running condition.

1 — Primary Battery
2 — Secondary Battery

WARNING!



Vehicles with the Stop/Start system will be

equipped with two batteries. Both the main

and the supplemental batteries must be

disconnected to completely de-energize the

12 Volt electrical system.



Serious injury or death could result if you do

not disconnect both batteries. To learn how to

properly disconnect, see an authorized dealer.

STARTING AND OPERATING

179

OSSIBLE

EASONS

NGINE

OES

UTOSTOP

Prior to engine shut down, the system will check

many safety and comfort conditions to see if they

are fulfilled. Detailed information about the

operation of the Stop/Start system may be viewed

in the instrument cluster display Stop/Start

Screen. In the following situations, the engine will

not stop:



Driver’s seat belt is not buckled



Driver’s door is not closed



Battery temperature is too warm or cold



Battery charge is low



The vehicle is on a steep grade



Cabin heating or cooling is in process and an

acceptable cabin temperature has not been

achieved



HVAC is set to full defrost mode at a high blower

speed



HVAC is set to MAX A/C



Engine has not reached normal operating

temperature



Engine or exhaust temperature is too high



The transmission is not in a forward gear



Hood is open



Transfer case is in 4L or N (Neutral)



Brake pedal is not pressed with sufficient

pressure



Accelerator pedal input



Vehicle speed threshold has not been achieved

from previous Autostop



Steering angle is beyond threshold



ACC is on and speed is set



Vehicle is at high altitude



System fault is present

It may be possible for the vehicle to be driven

several times without the Stop/Start system going

into a STOP/START READY state under more

extreme conditions of the items listed above.

TART

NGINE

HILE

UTOSTOP

ODE

While in a forward gear, the engine will start when

the brake pedal is released or the throttle pedal is

pressed. The transmission will automatically

re-engage upon engine restart.
Conditions That Will Cause The Engine To Start

Automatically While In Autostop Mode:



The transmission selector is moved out of

DRIVE



To maintain cabin temperature comfort



Actual cabin temperature is significantly

different than temperature set on Auto HVAC



HVAC is set to full defrost mode



HVAC system temperature or fan speed is

manually adjusted



Battery voltage drops too low



Stop/Start OFF switch is pushed



A Stop/Start system error occurs



Stop/Start Autostop Active time exceeds five

minutes



Transfer case is in 4L or N (Neutral)



Steering wheel is turned beyond threshold

180

STARTING AND OPERATING

ANUALLY

URN

TOP

TART

YSTEM

Stop/Start OFF Switch

Push the Stop/Start OFF switch (located on the

switch bank). The light on the switch will illuminate.

The “Stop/Start OFF” message will appear in

instrument cluster display within the Stop/Start

section, and the autostop function will be disabled

page 128.

NOTE:

The Stop/Start system will reset itself back to an

ON condition every time the ignition is turned off

and back on.

ANUALLY

URN

TOP

TART

YSTEM

Push the Stop/Start Off switch (located on the

switch bank). The light on the switch will turn off.

YSTEM

ALFUNCTION

If there is a malfunction in the Stop/Start system,

the system will not shut down the engine. A

“SERVICE STOP/START SYSTEM” message and a

yellow Stop/Start telltale will appear in the

instrument cluster display

page 128.

If the “SERVICE STOP/START SYSTEM” message

appears in the instrument cluster display, have the

system checked by an authorized dealer.

STOP/START SYSTEM — MANUAL

TRANSMISSION (IF EQUIPPED)

The Engine Stop/Start (ESS) function is developed

to reduce fuel consumption. The system will stop

the engine automatically during a vehicle stop if

the required conditions are met. Pressing the

clutch pedal will automatically restart the vehicle.

NOTE:

It is recommended that the Stop/Start system be

disabled during off-road use.

Secondary Battery
Your vehicle may be equipped with a secondary

battery used to power the Stop/Start system and

the 12 Volt vehicle electrical system. The

secondary battery is located behind the wheel well

for the front passenger wheel.

Battery Locations

1 — Primary Battery
2 — Secondary Battery

STARTING AND OPERATING

181

UTOSTOP

ODE

The Stop/Start feature is enabled after every

normal customer engine start. It will remain in

STOP/START NOT READY until you drive forward

with a vehicle speed greater than 5 mph (8 km/h).

At that time, the system will go into STOP/START

READY and if all other conditions are met, can go

into an STOP/START AUTOSTOP ACTIVE mode.
To Activate The STOP/START AUTOSTOP ACTIVE

Mode, The Following Must Occur:



The system must be in STOP/START READY

state. A STOP/START READY message will be

displayed in the instrument cluster

page 128.



Vehicle speed must be less than 2 mph

(3 km/h).



The gear selector must be in the NEUTRAL posi

tion and the clutch pedal must be fully released.

The engine will shut down, the tachometer will fall

to the Stop/Start position, the STOP/START

AUTOSTOP ACTIVE message will appear, and the

heater/air conditioning (HVAC) air flow will be

reduced.

OSSIBLE

EASONS

NGINE

OES

UTOSTOP

Prior to engine shut down, the system will check

many safety and comfort conditions to see if they

are fulfilled. In following situations the engine will

not stop:



Driver’s seat belt is not buckled



Outside temperature is less than 10°F (–12°C)

or greater than 109°F (43°C)



Actual cabin temperature is significantly

different than temperature set on Auto HVAC



HVAC is set to full defrost mode



Engine has not reached normal operating

temperature



Battery is discharged



When driving in REVERSE



Hood is open



Transfer case is in 4L or N (Neutral)



Driver's seat is not occupied or driver door is

open



Vehicle is at high altitude



The vehicle is on a steep grade



Forward Gear is engaged



Steering angle is beyond threshold



System fault is present



HVAC is set to MAX A/C

It may be possible for the vehicle to be driven

several times without the Stop/Start system going

into a STOP/START READY state under more

extreme conditions of the items listed above.

TART

NGINE

HILE

UTOSTOP

ODE

When the gear selector is in NEUTRAL, the engine

will start when the clutch pedal is pressed (does

not require complete/full pedal press). The vehicle

will go into STOP/START SYSTEM NOT READY

mode until the vehicle speed is greater than 5 mph

(8 km/h).

WARNING!



Vehicles with the Stop/Start system will be

equipped with two batteries. Both the main

and the supplemental batteries must be

disconnected to completely de-energize the

12 Volt electrical system.



Serious injury or death could result if you do

not disconnect both batteries. To learn how to

properly disconnect, see an authorized dealer.

182

STARTING AND OPERATING

Conditions that will cause the engine to start

automatically while in STOP/START AUTOSTOP

ACTIVE mode, the engine will start automatically

when:



Actual cabin temperature is significantly

different than temperature set on Auto HVAC



HVAC is set to full defrost mode



Stop/Start Autostop Active time exceeds five

minutes



Battery voltage drops too low



Vehicle is moving faster than 5 mph (8 km/h)



Stop/Start OFF switch is pressed



Transfer case is in 4L or N (Neutral)



Steering wheel is turned beyond threshold (ESS

Models Only)

ANUALLY

URN

TOP

TART

YSTEM

Stop/Start OFF Switch

Push the Stop/Start OFF switch (located on the

switch bank). The light on the switch will illuminate.

The “Stop/Start OFF” message will appear in

instrument cluster display within the Stop/Start

section, and the Autostop function will be disabled

page 128.

NOTE:

The Stop/Start system will reset itself back to an

ON condition every time the ignition is turned off

and back on.

ANUALLY

URN

TOP

TART

YSTEM

Push the Stop/Start Off switch (located on the

switch bank). The light on the switch will turn off.

YSTEM

ALFUNCTION

If there is a malfunction in the Stop/Start system,

the system will not shut down the engine. A

“SERVICE STOP/START SYSTEM” message and a

yellow Stop/Start telltale will appear in the

instrument cluster display

page 128.

If the “SERVICE STOP/START SYSTEM” message

appears in the instrument cluster display, have the

system checked by an authorized dealer.

STARTING AND OPERATING

183

CRUISE CONTROL SYSTEMS — IF EQUIPPED

Your vehicle may be equipped with the Cruise

Control system, or the Adaptive Cruise Control

(ACC) system:



Cruise Control will keep your vehicle at a

constant preset speed.



Adaptive Cruise Control (ACC) will adjust the

vehicle speed up to the preset speed to main

tain a distance with the vehicle ahead.

NOTE:



In vehicles equipped with ACC, if ACC is not

enabled, Fixed Speed Cruise Control will not

detect vehicles directly ahead of you. Always be

aware of the feature selected.



Only one Cruise Control feature can operate at a

time. For example, if Fixed Speed Cruise Control

is enabled, Adaptive Cruise Control will be

unavailable, and vice versa.

RUISE

ONTROL

When engaged, the Cruise Control system takes

over accelerator operations at speeds greater than

20 mph (32 km/h).
The Cruise Control buttons are located on the right

side of the steering wheel.

Cruise Control Buttons

To Activate

Push the on/off button to activate the Cruise

Control. The cruise indicator light in the instrument

cluster display will illuminate. To turn the system

off, push the on/off button a second time. The

cruise indicator light will turn off. The system

should be turned off when not in use.

To Set A Desired Speed

Turn the Cruise Control on.

NOTE:

The vehicle should be traveling at a steady speed

and on level ground before pushing the SET (+) or

SET (-) button.
When the vehicle has reached the desired speed,

push the SET (+) or SET (-) button and release.

Release the accelerator and the vehicle will

operate at the selected speed.

1 — SET (+)/Accel
2 — CANC/Cancel
3 — SET (-)/Decel
4 — On/Off
5 — RES/Resume

WARNING!

Cruise Control can be dangerous where the

system cannot maintain a constant speed. Your

vehicle could go too fast for the conditions, and

you could lose control and have an accident. Do

not use Cruise Control in heavy traffic or on

roads that are winding, icy, snow-covered or

slippery.

WARNING!

Leaving the Cruise Control system on when not

in use is dangerous. You could accidentally set

the system or cause it to go faster than you

want. You could lose control and have an

accident. Always ensure the system is off when

you are not using it.

184

STARTING AND OPERATING

To Vary The Speed Setting

To Increase Or Decrease The Set Speed
When the Cruise Control is set, you can increase

speed by pushing the SET (+) button, or decrease

speed by pushing the SET (-) button.
U.S. Speed (mph)



Pushing the SET (+), or SET (-) button once will

result in a 1 mph speed adjustment. Each

subsequent tap of the button results in an

adjustment of 1 mph.



If the button is continually pushed, the set

speed will continue to adjust in 5 mph incre

ments until the button is released, then the new

set speed will be established.

Metric Speed (km/h)



Pushing the SET (+), or SET (-) button once will

result in a 1 km/h speed adjustment. Each

subsequent tap of the button results in an

adjustment of 1 km/h.



If the button is continually pushed, the set

speed will continue to adjust in 10 km/h incre

ments until the button is released, then the new

set speed will be established.

To Accelerate For Passing

While the Cruise Control is set, press the

accelerator to pass as you would normally. When

the pedal is released, the vehicle will return to the

set speed.

USING CRUISE CONTROL ON HILLS

The transmission may downshift on hills to

maintain the vehicle set speed.
The Cruise Control system maintains speed up and

down hills. A slight speed change on moderate hills

is normal. On steep hills, a greater speed loss or

gain may occur so it may be preferable to drive

without Cruise Control.

To Resume Speed

To resume a previously set speed, push the RES

button and release. Resume can be used at any

speed above 20 mph (32 km/h).

To Deactivate

A soft tap on the brake pedal, pushing the CANC

(cancel) button, or normal brake pressure while

slowing the vehicle will deactivate the Cruise

Control without erasing the set speed from

memory.

The following conditions will also deactivate the

Cruise Control without erasing the set speed from

memory:



Vehicle parking brake is applied



Stability event occurs



Gear selector is moved out of DRIVE



Engine overspeed occurs



Clutch pedal is pressed (manual transmission

only)



Vehicle is operating at a low RPM (manual trans

mission only)

Pushing the on/off button or placing the ignition in

the OFF position, erases the set speed from

memory.

DAPTIVE

RUISE

ONTROL

(ACC)

Adaptive Cruise Control (ACC) increases the driving

convenience provided by Cruise Control while

traveling on highways and major roadways.

However, it is not a safety system and not designed

to prevent collisions. The Cruise Control function

performs differently if your vehicle is not equipped

with ACC

page 183.

WARNING!

Cruise Control can be dangerous where the

system cannot maintain a constant speed. Your

vehicle could go too fast for the conditions, and

you could lose control and have an accident. Do

not use Cruise Control in heavy traffic or on

roads that are winding, icy, snow-covered or

slippery.

STARTING AND OPERATING

185

(Continued)

ACC will allow you to keep Cruise Control engaged

in light to moderate traffic conditions without the

constant need to reset your speed. ACC utilizes a

radar sensor and a forward facing camera

designed to detect a vehicle directly ahead of you

to maintain a set speed.

NOTE:



If the ACC sensor detects a vehicle ahead, ACC

will apply limited braking or accelerate (not to

exceed the original set speed) automatically to

maintain a preset following distance, while

matching the speed of the vehicle ahead.



Any chassis/suspension or tire size modifica

tions to the vehicle will affect the performance

of the Adaptive Cruise Control and Forward Colli

sion Warning system.



Fixed Speed Cruise Control (ACC not enabled)

will not detect vehicles directly ahead of you.

Always be aware of the feature selected

page 465.

WARNING!



Adaptive Cruise Control (ACC) is a conve

nience system. It is not a substitute for active

driver involvement. It is always the driver’s

responsibility to be attentive of road, traffic,

and weather conditions, vehicle speed,

distance to the vehicle ahead; and, most

importantly, brake operation to ensure safe

operation of the vehicle under all road condi

tions. Your complete attention is always

required while driving to maintain safe control

of your vehicle. Failure to follow these warn

ings can result in a collision and death or

serious personal injury.



The ACC system:



Does not react to pedestrians, oncoming

vehicles, and stationary objects (e.g., a

stopped vehicle in a traffic jam or a

disabled vehicle).



Cannot take street, traffic, and weather

conditions into account, and may be

limited upon adverse sight distance condi

tions.



Does not always fully recognize complex

driving conditions, which can result in

wrong or missing distance warnings.

You should turn the ACC system off:



When driving in fog, heavy rain, heavy snow,

sleet, heavy traffic, and complex driving situa

tions (i.e., in highway construction zones).



When entering a turn lane or highway off

ramp; when driving on roads that are winding,

icy, snow-covered, slippery, or have steep

uphill or downhill slopes.



When towing a trailer up or down steep slopes.



When circumstances do not allow safe driving

at a constant speed.

WARNING!

186

STARTING AND OPERATING

Adaptive Cruise Control (ACC) Operation

The buttons on the right side of the steering wheel

operate the ACC system.

Adaptive Cruise Control Buttons

Adaptive Cruise Control (ACC) Menu

The instrument cluster display will show the

current ACC system settings. The instrument

cluster display is located in the center of the

instrument cluster. The information it displays

depends on ACC system status.

Push the Adaptive Cruise Control (ACC) on/off

button (located on the steering wheel) until one of

the following appears in the instrument cluster

display:
Adaptive Cruise Control Off
When ACC is deactivated, the display will read

“Adaptive Cruise Control Off.”
Adaptive Cruise Control Ready
When ACC is activated, but the vehicle speed

setting has not been selected, the display will read

“Adaptive Cruise Control Ready.”
Adaptive Cruise Control Set
When the SET (+) or the SET (-) button (located on

the steering wheel) is pushed, the display will read

“ACC SET.”
When ACC is set, the set speed will show in the

instrument cluster display.
The ACC screen may display once again if any of

the following ACC activity occurs:



System Cancel



Driver Override



System Off



ACC Proximity Warning



ACC Unavailable Warning

The instrument cluster display will return to the last

display selected after five seconds of no ACC

display activity.

Activating Adaptive Cruise Control (ACC)

The minimum set speed for the ACC system is

20 mph (32 km/h).
When the system is turned on and in the ready

state, the instrument cluster displays “ACC Ready.”
When the system is off, the instrument cluster

displays “Adaptive Cruise Control (ACC) Off.”

NOTE:

You cannot engage ACC under the following

conditions:



When in 4WD Low



When the brakes are applied



When the parking brake is applied



When the automatic transmission is in PARK,

REVERSE or NEUTRAL



When the manual transmission is in first gear



When the vehicle speed is below 20 mph

(32 km/h) (manual transmission)



When the vehicle speed is below the minimum

speed range



When the brakes are overheated



When the driver’s door is open at low speeds



When the driver’s seat belt is unbuckled at low

speeds



When ESC Full Off mode is active



When Off Road+ (if equipped) is active

1 — Distance Increase Button
2 — Adaptive Cruise Control On/Off
3 — Distance Decrease Button

Jeep Gladiator (2022 year). Manual in english - page 11
