Jeep Compass (2022 year). Manual in english - page 1

9

SYMBOLS KEY

If you do not read this entire Owner’s Manual, you may miss important

information. Observe all Cautions and Warnings.

ROLLOVER WARNING

Utility vehicles have a significantly higher rollover rate than other types of

vehicles. This vehicle has a higher ground clearance and a higher center of

gravity than many passenger vehicles. It is capable of performing better in a

wide variety of off-road applications. Driven in an unsafe manner, all vehicles

can go out of control. Because of the higher center of gravity, if this vehicle is

out of control it may roll over while some other vehicles may not.
Do not attempt sharp turns, abrupt maneuvers, or other unsafe driving actions

that can cause loss of vehicle control. Failure to operate this vehicle safely may

result in a collision, rollover of the vehicle, and severe or fatal injury. Drive

carefully.

Rollover Warning Label

Failure to use the driver and passenger seat belts provided is a major cause of

severe or fatal injury. In fact, the US government notes that the universal use

of existing seat belts could cut the highway death toll by 10,000 or more each

year and could reduce disabling injuries by two million annually. In a rollover

crash, an unbelted person is significantly more likely to die than a person

wearing a seat belt. Always buckle up.

WARNING!

These statements are against operating

procedures that could result in a collision, bodily

injury and/or death.

CAUTION!

These statements are against procedures that

could result in damage to your vehicle.

NOTE:

A suggestion which will improve installation,

operation, and reliability. If not followed, may

result in damage.

TIP:

General ideas/solutions/suggestions on easier

use of the product or functionality.

PAGE REFERENCE

ARROW

Follow this reference for additional information on

a particular feature.

FOOTNOTE

Supplementary and relevant information

pertaining to the topic.

1

10

VEHICLE MODIFICATIONS/ALTERATIONS

SYMBOL GLOSSARY

Some car components have colored labels with symbols indicating

precautions to be observed when using this component. It is important to

follow all warnings when operating your vehicle. See below for the definition of

each symbol

NOTE:

Warning and Indicator lights are different based upon equipment options and

current vehicle status. Some telltales are optional and may not appear.

WARNING!

Any modifications or alterations to this vehicle could seriously affect its

roadworthiness and safety and may lead to a collision resulting in serious

injury or death.

Red Warning Lights

Air Bag Warning Light

Brake Warning Light

Battery Charge Warning Light

Door Open Warning Light

Drowsiness Detected Warning

Electric Power Steering (EPS) Fault Warning Light

Electronic Throttle Control (ETC) Warning Light

Engine Temperature Warning Light

Hood Open Warning Light

Liftgate Open Warning Light

Oil Pressure Warning Light

Red Warning Lights

11

Oil Temperature Warning Light

Seat Belt Reminder Warning Light

Transmission Fault Warning Light

Transmission Temperature Warning Light

Vehicle Security Warning Light

Yellow Warning Lights

Anti-Lock Brake System (ABS) Warning Light

Electronic Park Brake Warning Light

Red Warning Lights

Electronic Stability Control (ESC) Active Warning Light

Electronic Stability Control (ESC) OFF Warning Light

Fuel Cutoff Warning Light

Active Lane Management Warning Light

Service Active Lane Management Warning Light

Low Coolant Level Warning Light

Low Fuel Warning Light

Low Washer Fluid Warning Light

Yellow Warning Lights

1

12

Engine Check/Malfunction Indicator (MIL) Warning Light

Service 4WD Warning Light

Service Forward Collision Warning (FCW) Light

Service Stop/Start System Warning Light

Tire Pressure Monitoring System (TPMS) Warning Light

Towing Hook Breakdown Warning Light

Yellow Indicator Lights

4WD Low Indicator Light

Yellow Warning Lights

4WD Lock Indicator Light

Auto HOLD! Fault Indicator Light

Forward Collision Warning (FCW) Indicator Light

Forward Collision Warning (FCW) OFF Indicator Light

Immobilizer Fail/VPS Electrical Alarm Indicator Light

Green Indicator Lights

Active Lane Management Indicator Light

Auto HOLD Indicator Light

Yellow Indicator Lights

13

Parking/Headlights On Indicator Light

Front Fog Indicator Light

Turn Signal Indicator Lights

Cruise Control SET Indicator Light

Stop/Start Active Indicator Light

Automatic High Beam Indicator Light

White Indicator Lights

Active Lane Management Indicator Light

Green Indicator Lights

Hill Descent Control (HDC) Indicator Light

Cruise Control Ready Indicator Light

Cruise Control SET Indicator Light

Blue Indicator Lights

High Beam Indicator Light

Gray Indicator Lights

Cruise Control Ready Indicator Light

White Indicator Lights

1

14

GETTING TO KNOW YOUR VEHICLE

KEYS

K

EY

F

OBS

Your vehicle is equipped with a keyless ignition

key fob.
The keyless ignition key fob supports Passive

Entry, Remote Keyless Entry (RKE), Keyless

Enter ‘n Go™ (if equipped), Remote Start

(if equipped), and remote power liftgate operation.

The keyless ignition key fob supports vehicles

equipped with a START/STOP ignition button.

The keyless ignition key fob also includes an

emergency key, which is stored in the rear of the

key fob.
The key fob allows you to lock or unlock the doors

and liftgate from distances up to approximately

66 ft (20 m). The key fob does not need to be

pointed at the vehicle to activate the system.

NOTE:



The key fob’s wireless signal may be blocked if

the key fob is located next to a mobile phone,

laptop, or other electronic device. This may

result in poor performance.



With the ignition on and the vehicle moving at

2 mph (4 km/h), all RKE commands are

disabled.

Key Fob

1 — Unlock Button
2 — Liftgate Button
3 — Emergency Key
4 — Lock Button
5 — Remote Start Button
6 — PANIC Button

GETTING TO KNOW YOUR VEHICLE

15

NOTE:

In case the ignition switch does not change with

the push of a button, the key fob may have a low or

fully depleted battery. A low key fob battery can be

verified by referring to the instrument cluster,

which will display directions to follow

To Unlock/Lock The Doors And Liftgate

Push and release the unlock button on the key fob

once to unlock the driver’s door. If selected within

Uconnect Settings, pushing the unlock button

twice within five seconds will unlock all the doors

and the liftgate. To lock all the doors and the

liftgate, push the lock button once

When the doors are unlocked, the turn signals will

flash and the illuminated entry system will be

activated. When the doors are locked, the turn

signals will flash and the horn will chirp.

Key Left Vehicle Feature

If a valid key fob is no longer detected inside the

vehicle while the vehicle’s ignition system is in the

ON/RUN or START position, the message “Key Left

Vehicle” will be shown in the instrument cluster

display along with an interior chime. An exterior

audible and visual alert will also be activated to

warn the driver.

The vehicle’s horn will rapidly chirp three times

along with a single flash of the vehicle’s exterior

lights.
NOTE:



The doors have to be open and then closed in

order for the vehicle to check for the presence of

a key fob; the Key Left Vehicle feature will not

activate until all of the doors are closed.



These alerts will not be activated in situations

where the vehicle’s engine is left running with

the key fob inside.

Replacing The Battery In The Key Fob

The replacement battery is one CR2032 battery.
NOTE:



Customers are recommended to use a battery

obtained from Mopar®. Aftermarket coin

battery dimensions may not meet the original

OEM coin battery dimensions.



Perchlorate Material — special handling may

apply. See

www.dtsc.ca.gov/hazard

ouswaste/perchlorate for further information.



Do not touch the battery terminals that are on

the back housing or the printed circuit board.

Key Fob:
1. Remove the emergency key (2) by sliding the

emergency key release (1) on the back of the

key fob and pulling the emergency key out

with your other hand.

Emergency Key Removal

1 — Emergency Key Release
2 — Emergency Key

2

16

GETTING TO KNOW YOUR VEHICLE

2. Separate the key fob halves using a #2 flat

blade screwdriver or a coin, and gently pry the

two halves of the key fob apart. Make sure not

to damage the seal during removal.

Separating Case With A Coin

Key Fob Battery Replacement

3. Remove the back cover to access and replace

the battery. When replacing the battery, match

the (+) sign on the battery to the (+) sign on the

inside of the battery clip, located on the back

cover. Avoid touching the new battery with your

fingers. Skin oils may cause battery deterio

-

ration. If you touch a battery, clean it with

rubbing alcohol.

4. To assemble the key fob case, snap the two

halves together.

Programming And Requesting Additional

Key Fobs

Programming the key fob may be performed by an

authorized dealer.
NOTE:



Once a key fob is programmed to a vehicle, it

cannot be repurposed and reprogrammed to

another vehicle.



Only key fobs that are programmed to the

vehicle electronics can be used to start and

operate the vehicle. Once a key fob is

programmed to a vehicle, it cannot be

programmed to any other vehicle.

WARNING!



The integrated key fob contains a coin cell

battery. Do not ingest the battery; there is a

chemical burn hazard. If the coin cell battery is

swallowed, it can cause severe internal burns

in just two hours and can lead to death.



If you think a battery may have been swal

-

lowed or placed inside any part of the body,

seek immediate medical attention.



Keep new and used batteries away from

children. If the battery compartment does not

close securely, stop using the product and

keep it away from children.

WARNING!



Always remove the key fobs from the vehicle

and lock all doors when leaving the vehicle

unattended.



For vehicles equipped with Keyless

Enter ‘n Go™ Ignition, always remember to

place the ignition in the OFF position.

GETTING TO KNOW YOUR VEHICLE

17

Duplication of key fobs may be performed at an

authorized dealer. This procedure consists of

programming a blank key fob to the vehicle

electronics. A blank key fob is one that has never

been programmed.
NOTE:



When having the Sentry Key Immobilizer system

serviced, bring all vehicle keys with you to an

authorized dealer.



Keys must be ordered to the correct key cut to

match the vehicle locks.

SENTRY KEY

The Sentry Key Immobilizer system prevents

unauthorized vehicle operation by disabling the

engine. The system does not need to be armed or

activated. Operation is automatic, regardless of

whether the vehicle is locked or unlocked.
The system uses a key fob, keyless push button

ignition and a Radio Frequency (RF) receiver to

prevent unauthorized vehicle operation. Therefore,

only key fobs that are programmed to the vehicle

can be used to start and operate the vehicle. The

system cannot reprogram a key fob obtained from

another vehicle.

After placing the ignition in the ON/RUN position,

the Vehicle Security Light will turn on for three

seconds for a bulb check. If the light remains on

after the bulb check, it indicates that there is a

problem with the electronics. In addition, if the light

begins to flash after the bulb check, it indicates

that someone attempted to start the engine with

an invalid key fob. In the event that a valid key fob

is used to start the engine but there is an issue

with the vehicle electronics, the engine will start

and shut off after two seconds.
If the Vehicle Security Light turns on during normal

vehicle operation (vehicle running for longer than

10 seconds), it indicates that there is a fault in the

electronics. Should this occur, have the vehicle

serviced as soon as possible by an authorized

dealer.

All of the key fobs provided with your new vehicle

have been programmed to the vehicle electronics

IGNITION SWITCH

K

EYLESS

E

NTER

‘

N

G

O

™ I

GNITION

This feature allows the driver to operate the

ignition with the push of a button as long as the

key fob is in the passenger compartment.
The START/STOP ignition button has three

operating modes. The three modes are OFF,

ON/RUN, and START.

START/STOP Ignition Button

CAUTION!

The Sentry Key Immobilizer system is not

compatible with some aftermarket Remote Start

systems. Use of these systems may result in

vehicle starting problems and loss of security

protection.

1 — OFF
2 — ON/RUN

2

18

GETTING TO KNOW YOUR VEHICLE

(Continued)

The push button ignition can be placed in the

following modes:
OFF



The engine is stopped.



Some electrical devices (e.g. power locks,

alarm, etc.) are still available.

ON/RUN



Driving mode.



All electrical devices are available (e.g. climate

controls, heated seats, etc.).

START



The engine will start.

NOTE:

If the ignition state/mode does not change with the

push of a button, the key fob may have a low or

depleted battery. In this situation, a back up

method can be used to operate the ignition switch.

Put the nose side (side opposite of the emergency

key) of the key fob against the START/STOP

ignition button and push to operate the ignition.

Starting The Ignition With Depleted Key Fob Battery

NOTE:



For information on normal starting, see



When opening the driver's door and the ignition

is in the ON/RUN (engine not running) position,

a chime will sound to remind you to place the

ignition in the OFF position. In addition to the

chime, the “Vehicle On” message will display in

the cluster.

WARNING!



When exiting the vehicle, always remove the

key fob from the vehicle and lock your vehicle.



Never leave children alone in a vehicle, or with

access to an unlocked vehicle.



Allowing children to be in a vehicle unattended

is dangerous for a number of reasons. A child

or others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.



Do not leave the key fob in or near the vehicle,

or in a location accessible to children, and do

not leave the ignition of a vehicle equipped

with Keyless Enter ‘n Go™ in the ON/RUN

position. A child could operate power

windows, other controls, or move the vehicle.



Do not leave children or animals inside parked

vehicles in hot weather. Interior heat buildup

may cause serious injury or death.

CAUTION!

An unlocked vehicle is an invitation for thieves.

Always remove key fob from the vehicle and lock

all doors when leaving the vehicle unattended.

WARNING!

GETTING TO KNOW YOUR VEHICLE

19

(Continued)

REMOTE START — IF EQUIPPED

This system uses the key fob to start the

engine conveniently from outside the

vehicle while still maintaining security.

The system has a range of approximately

328 ft (100 m).
Remote Start is used to defrost windows in cold

weather and to reach a comfortable climate in all

ambient conditions before the customer enters the

vehicle.
NOTE:

Obstructions between the vehicle and key fob may

reduce this range

H

OW

T

O

U

SE

R

EMOTE

S

TART

Push and release the Remote Start button on the

key fob twice within five seconds. The vehicle

doors will lock, the parking lights will flash, and the

horn will chirp twice (if programmed). Then, the

engine will start, and the vehicle will remain in the

Remote Start mode for a 15 minute cycle. Pushing

the Remote Start button a third time shuts the

engine off.
To drive the vehicle, push the unlock button and

place the ignition in the ON/RUN position.
NOTE:



With Remote Start, the engine will only run for

15 minutes.



Remote Start can only be used twice.



If an engine fault is present or fuel level is low,

the vehicle will start and then shut down in

10 seconds.



The parking lights will turn on and remain on

during Remote Start mode.



For security, power window and power sunroof

operation (if equipped) are disabled when the

vehicle is in the Remote Start mode.



The ignition must be placed in the ON/RUN posi

-

tion before the Remote Start sequence can be

repeated for a third cycle.

All of the following conditions must be met before

the engine will remote start:



Gear selector in PARK



Doors closed



Hood closed



Liftgate closed



Hazard switch off



Brake switch inactive (brake pedal not pressed)



Battery at an acceptable charge level



PANIC button not pushed



System not disabled from previous Remote

Start event



Vehicle Security Light flashing (if equipped)



Ignition in the OFF position



Fuel level meets minimum requirement



Vehicle Security system is not signaling an intru

-

sion



Malfunction Indicator Light is not illuminated

WARNING!



Do not start or run an engine in a closed

garage or confined area. Exhaust gas contains

Carbon Monoxide (CO) which is odorless and

colorless. Carbon Monoxide is poisonous and

can cause serious injury or death when

inhaled.



Keep key fobs away from children. Operation

of the Remote Start system, windows, door

locks or other controls could cause serious

injury or death.

WARNING!



Do not start or run an engine in a closed garage

or confined area. Exhaust gas contains Carbon

Monoxide (CO) which is odorless and colorless.

Carbon Monoxide is poisonous and can cause

serious injury or death when inhaled.

2

20

GETTING TO KNOW YOUR VEHICLE

T

O

E

XIT

R

EMOTE

S

TART

M

ODE

To drive the vehicle after starting the Remote Start

system, push and release the START/STOP ignition

button prior to the end of the 15 minute cycle.
The Remote Start system will turn the engine off if

the Remote Start button on the key fob is pushed

again, or if the engine is allowed to run for the

entire 15 minute cycle. Once the ignition is placed

in the ON/RUN position, the climate controls will

resume previously set operations (temperature,

blower control, etc.).
NOTE:



For vehicles not equipped with the Keyless

Enter ‘n Go™ — Passive Entry feature, the igni

-

tion switch must be in the ON/RUN position in

order to drive the vehicle.



For vehicles equipped with the Keyless

Enter ‘n Go™ — Passive Entry feature, the

message “Remote Start Active — Push Start

Button” will show in the instrument cluster

display until you push the START/STOP ignition

button.



To avoid unintentional shutdowns, the system

will disable for two seconds after receiving a

valid Remote Start request.

R

EMOTE

S

TART

F

RONT

D

EFROST

A

CTIVATION

— I

F

E

QUIPPED

When Remote Start is active, and the outside

ambient temperature is 40°F (4.5°C) or below, the

system will automatically activate front defrost for

15 minutes or less. The timing is dependent on the

ambient temperature. Once the timer expires, the

system will automatically adjust the settings

depending on ambient conditions. See “Remote

Start Comfort Systems — If Equipped” in the next

section for detailed operation.

R

EMOTE

S

TART

C

OMFORT

S

YSTEMS

—

I

F

E

QUIPPED

When Remote Start is activated, the front and rear

defrost will automatically turn on in cold weather.

The heated steering wheel and driver heated seat

feature will turn on if programmed in the comfort

menu screen within Uconnect Settings

page 165. In warm weather, the driver vented

seat feature will automatically turn on when

Remote Start is activated, if programmed in the

comfort menu screen. The vehicle will adjust the

climate control settings depending on the outside

ambient temperature.

Automatic Temperature Control (ATC) —

If Equipped
The climate controls will automatically adjust to

the optimal temperature and mode settings

depending on the outside ambient temperature.

This will occur until the ignition is placed in the

ON/RUN position where the climate controls will

resume their previous settings.
Manual Temperature Control (MTC) — If Equipped



In ambient temperatures of 40°F (4.5°C) or

below, the climate settings will default to

maximum heat, with fresh air entering the

cabin. If the front defrost timer expires, the

vehicle will enter Mix mode.



In ambient temperatures from 40°F (4.5°C) to

78°F (26°C), the climate settings will be based

on the last settings selected by the driver.



In ambient temperatures of 78°F (26°C) or

above, the climate settings will default to

MAX A/C, Bi-Level mode, with Recirculation on.

For more information on ATC, MTC, and climate

control settings, see

NOTE:

These features will stay on through the duration of

Remote Start, or until the ignition is placed in the

ON/RUN position. The climate control settings will

change, and exit the automatic defaults, if manually



Keep key fobs away from children. Operation

of the Remote Start system, windows, door

locks or other controls could cause serious

injury or death.

WARNING!

GETTING TO KNOW YOUR VEHICLE

21

adjusted by the driver while the vehicle is in Remote

Start mode. This includes turning the climate

controls off using the OFF button.

R

EMOTE

S

TART

W

INDSHIELD

W

IPER

D

E

–I

CER

A

CTIVATION

— I

F

E

QUIPPED

When Remote Start is active and the outside

ambient temperature is less than 33°F (0.6°C),

the Windshield Wiper De-Icer will activate. Exiting

Remote Start will resume its previous operation. If

the Windshield Wiper De-Icer was active, the timer

and operation will continue.

R

EMOTE

S

TART

A

BORT

M

ESSAGE

—

I

F

E

QUIPPED

The following messages will display in the

instrument cluster display if the vehicle fails to

remote start or exits Remote Start prematurely:



Remote Start Aborted — Door Open



Remote Start Aborted — Hood Open



Remote Start Aborted — Fuel Low



Remote Start Aborted — Liftgate Open



Remote Start Disabled — Start Vehicle To Reset



Remote Start Aborted — Too Cold



Remote Start Aborted — Time Expired



Remote Start Disabled — Start Vehicle To Reset

The message will stay active until the ignition is

placed in the ON/RUN position.

VEHICLE SECURITY SYSTEM — IF EQUIPPED

The Vehicle Security system monitors the vehicle

doors, hood, liftgate, and the Keyless Enter ‘n Go™

Ignition for unauthorized operation. While the

Vehicle Security system is armed, interior switches

for door locks and liftgate release are disabled. If

something triggers the system, the Vehicle Security

system will provide the following audible and

visible signals:



The horn will pulse



The turn signals will flash



The Vehicle Security Light in the instrument

cluster will flash

NOTE:



The Vehicle Security system is factory adjusted

to standards from different countries.



The Vehicle Security system is a complementary

security system developed to hinder the occur

-

rence of vehicle theft and prevent vandalism. It

does not prevent the theft of your vehicle; the

system is a deterrent.



The Vehicle Security system does not monitor

glass breakage or the movement of objects or

people inside the vehicle. The alarm does not

intervene in the case of vehicle tilt variations

when it is parked.

T

O

A

RM

T

HE

S

YSTEM

Follow these steps to arm the Vehicle Security

system:
1. Make sure the vehicle’s ignition is placed in

the OFF position.



For vehicles equipped with Keyless Entry,

make sure the vehicle’s keyless ignition

system is OFF.

2. Perform one of the following methods to lock

the vehicle:



Push the lock button on the interior power

door lock switch with the driver and/or

passenger door open.



Push the lock button on the exterior Passive

Entry door handle with a valid key fob avail

-

able in the same exterior zone



Push the lock button on the key fob.

3. If any doors are open, close them.

When the Vehicle Security system is armed, the

Vehicle Security Light (located in the lower left

portion of the instrument cluster display) will begin

to flash every three seconds until it is disarmed.

2

22

GETTING TO KNOW YOUR VEHICLE

NOTE:

If the system is armed by pushing the lock button

on the interior door panel, the Vehicle Security

Light will flash rapidly for about 15 seconds once

the door is closed, then slow down to every three

seconds.

T

O

D

ISARM

T

HE

S

YSTEM

The Vehicle Security system can be disarmed using

any of the following methods:



Push the unlock button on the key fob.



Grab the Passive Entry door handle to unlock

the door



Cycle the ignition out of the OFF position to

disarm the system.

NOTE:



The driver's door key cylinder and the liftgate

button on the key fob cannot arm or disarm the

Vehicle Security system.



The Vehicle Security system remains armed

during power liftgate entry. Pushing the liftgate

button will not disarm the Vehicle Security

system. If someone enters the vehicle through

the liftgate and opens any door, the alarm will

sound.



When the Vehicle Security system is armed, the

interior power door lock switches will not unlock

the doors.

The Vehicle Security system is designed to protect

your vehicle. However, you can create conditions

where the system will give you a false alarm. If one

of the previously described arming sequences has

occurred, the Vehicle Security system will arm

regardless of whether you are in the vehicle or not.

If you remain in the vehicle and open a door, the

alarm will sound. If this occurs, disarm the Vehicle

Security system.
If the Vehicle Security system is armed and the

battery becomes disconnected, the Vehicle

Security system will remain armed when the

battery is reconnected; the exterior lights will flash,

and the horn will sound. If this occurs, disarm the

Vehicle Security system.

R

EARMING

O

F

T

HE

S

YSTEM

If something triggers the alarm, and no action is

taken to disarm it, the Vehicle Security system will

turn the horn off after approximately 90 seconds,

and then the Vehicle Security system will rearm

itself.

S

ECURITY

S

YSTEM

M

ANUAL

O

VERRIDE

The Vehicle Security system will not arm if you lock

the doors using the manual door lock.

DOORS

M

ANUAL

D

OOR

L

OCKS

The door locks can be manually locked from inside

the vehicle by using the door lock knob.

Manual Door Lock Knob

To lock each door, rotate the door lock knob on

each door trim panel forward until the lock

indicator is shown. To unlock the front doors, pull

the inside door handle to the first detent or rotate

the door lock button until the lock indicator is

hidden. To unlock the rear doors, rotate the door

lock button until the lock indicator is hidden. If the

door lock button is locked (lock indicator visible)

when you shut the door, the door will remain

locked. Therefore, make sure the key fob is not

inside the vehicle before closing the door.

GETTING TO KNOW YOUR VEHICLE

23

(Continued)

NOTE:



Manually locking the vehicle will not arm the

Vehicle Security system.



The manual door locks will not lock or unlock the

liftgate.

P

OWER

D

OOR

L

OCKS

The power door lock switches are located on each

front door panel. Push the switch to lock or unlock

the doors and liftgate.

Power Door Lock Switch

If you push the power door lock switch while the

ignition is in the ON/RUN position, and any door or

the liftgate is open, the power locks will not

operate. This prevents you from accidentally

locking the key fob in the vehicle. Placing the

ignition in the OFF position or closing the doors and

liftgate will allow the locks to operate.

K

EYLESS

E

NTER

‘

N

G

O

™ — P

ASSIVE

E

NTRY

The Passive Entry system is an enhancement to

the vehicle’s Remote Keyless Entry system and a

feature of Keyless Enter ‘n Go™ — Passive Entry.

This feature allows you to lock and unlock the

vehicle’s door(s) without having to push the key fob

lock or unlock buttons.
NOTE:



Passive Entry may be programmed on/off

through Uconnect Settings



The key fob may not detect the Passive Entry

system if it is located next to a mobile phone,

laptop or other electronic device; these devices

may block the key fob’s wireless signal and

prevent the Passive Entry system from locking

and unlocking the vehicle.

WARNING!



For personal security and safety in the event

of a collision, lock the vehicle doors before you

drive as well as when you park and exit the

vehicle.



When exiting the vehicle, always remove the

key fob from the vehicle and lock your vehicle.

If equipped with a Keyless Enter ‘n Go™ Igni

-

tion, always make sure the keyless ignition is

in the OFF position, remove the key fob from

the vehicle and lock the vehicle. Unsupervised

use of vehicle equipment may cause severe

personal injuries or death.



Never leave children alone in a vehicle, or

with access to an unlocked vehicle. Allowing

children to be in a vehicle unattended is

dangerous for a number of reasons. A child or

others could be seriously or fatally injured.

Children should be warned not to touch the

parking brake, brake pedal or the gear

selector.



Do not leave the key fob in or near the vehicle,

or in a location accessible to children. Do not

leave the Keyless Enter ‘n Go™ Ignition in the

ON/RUN position. A child could operate power

windows, other controls, or move the vehicle.

WARNING!

2

24

GETTING TO KNOW YOUR VEHICLE



If wearing gloves, or if it has been raining/

snowing on the Passive Entry door handle, the

unlock sensitivity can be affected, resulting in a

slower response time.



If the vehicle is unlocked by Passive Entry and

no door is opened within 60 seconds, the

vehicle will relock and, if equipped, will arm the

Vehicle Security system.

To Unlock From The Driver's Side Or Passenger’s

Side
With a valid Passive Entry key fob within 5 ft

(1.5 m) of either front door handle, grab the door

handle to unlock the door automatically.

Grab The Door Handle To Unlock



Either the driver door only or all doors will unlock

when you grab hold of the front driver’s door

handle, depending on the selected setting in the

Uconnect system



All doors and the liftgate will unlock when the front

passenger door handle is grabbed regardless of

the driver’s door unlock preference setting.

Frequency Operated Button Integrated Key

(FOBIK-Safe)
To minimize the possibility of unintentionally

locking a Passive Entry key fob inside your vehicle,

the Passive Entry system is equipped with an

automatic door unlock feature which will function if

the ignition switch is in the OFF position.
There are three situations that trigger a

FOBIK-Safe search in any Passive Entry vehicle:



A lock request is made by a valid Passive Entry

key fob while a door is open.



A lock request is made by the Passive Entry door

handle while a door is open.



A lock request is made by the door panel switch

while the door is open.

When any of these situations occur, after all open

doors are shut, the FOBIK-Safe search will be

executed. If it detects a Passive Entry key fob

inside the vehicle and it does not detect any

Passive Entry key fobs outside the vehicle, then the

vehicle will unlock and alert the customer.
NOTE:

The vehicle will only unlock the doors when a valid

Passive Entry key fob is detected inside the

vehicle. The vehicle will not unlock the doors when

any of the following conditions are true:



The doors are manually locked using the door

lock knobs.



Three attempts are made to lock the doors

using the door panel switch and then the doors

are closed.



There is a valid Passive Entry key fob outside the

vehicle and within 5 ft (1.5 m) of either Passive

Entry door handle.

To Lock The Vehicle’s Doors And Liftgate
With one of the vehicle’s Passive Entry key fobs

within 5 ft (1.5 m) of either front door handle, push

the Passive Entry lock button located on the

outside door handle to lock the vehicle doors and

liftgate.

Push The Door Handle Button To Lock

Content .. 1 2 ..

///////////////////////////////////////
